Theselectablefeaturescanbesetmanuallyasexplainedbelow,orwiththeRFfeatureprogrammer.
TosetfeaturesusingtheRFprogrammer,followtheinstructionspackagedwiththeprogrammer.
Factory default settings are indicated by bold text.
Note : The method of manual override can either be selected to operate from the valet switch or operate as custom code.
Be certain to place a check mark indicating the method used in the box located on the last page of the owner's manual.
NOTE: Keyless Entry Models with no horn output will Flash the Parking Lights instead of chirp where chirp is indicated.
Also, No data will be indicated if a feature is not available for a particular model. The unit will enter the feature but no selection will be available.
RF Programmable Feature Bank 1 Is For Transmitter Programming See Transmitter Programming Guide.
RF Programmable Features Bank 2 Is Alarm Selectable Features:
Feature Selection 1 Chirp 2 Chirps 3 Chirps 4 Chirps 5 Chirps 6 Chirps
1st DoorL/UL 1 Sec. 3.5 Sec. 1 Sec L, Dbl. U/L Dbl L, 1 Sec UL DblL,DblUL 1 Sl/350mS ul
2nd Accy Lock Auto Lock On Auto Lock Off
3rd Accy. UL Auto UL Dr. Auto UL All Auto UL Off `
4th Headlights Not Available
5th Passive Locks Not Available
6th Pass/Act Arm Not Available
7th Siren/Horn Not Available
8th Horn Chirp 10mS 16mS 30mS 40mS 50mS
9th O/R Method Not Available
10th 2 Step U/L On Off
11th Chp Del Tx On Off
12th Vlot Sense/Hd Wire Not Available
13th Trigger Circuits Not Available
14thL/ULPoll Not Available
15th Aux Ch 5 Sel Pulse Push & Hold 10 Sec 20 Sec Latch On/Off Hold3/S For O/P
16th Aux Ch 6 Sel Pulse Push & Hold 10 Sec 20 Sec Latch On/Off Hold3/S For O/P
17th Aux Ch 7 Sel Pulse Push & Hold 10 Sec 20 Sec Latch On/Off Hold3/S For O/P
18th Trigger Delay Not Available
When using the RF programmer, enter the program mode as follows:
Turn the ignition on.
Press and release valet switch 3 times;
turn ignition off then on.
Press and hold valet switch for 5 seconds.
Siren and or lights chirp/flash 2 times indicating access to RF feature program mode.
Model APS-687
Installation Manual

128-7827
2 of 20
2
To program these selectable features;
Action System Response
Turn ignition on No response
Press and release the valet switch 3 times 1 Chirp - LED 1 flash
Within 3 seconds, turn ignition Off Then On Short chirp, then long chirp
This Action Accesses Feature Bank 2 Alarm Selectable Features
First Press and release the valet switch 1 time 1 chirp = 1 second door lock & unlock
Press transmitter Lock button to change 2 chirps = 3.5 second door lock & Unlock
Press transmitter Lock button to change 3 chirps = 1 sec. lock, dbl 1 sec. unlock
Press transmitter Lock button to change 4 chirps = dbl 1 sec lock, 1 sec unlock
Press transmitter Lock button to change 5 chirps = dbl 1 sec lock, dbl 1 sec unlock
Press transmitter Lock button to change 6 chirps = 350mS unlock. 1 sec lock
or
Second Press and release the valet switch 2 chirps = auto locks off
Press transmitter Lock button to change 1 chirp = auto locks on
or
Third Press and release the valet switch 3 chirps = auto unlock off
Press transmitter Lock button to change 1 chirp = auto unlock drivers door only
Press transmitter Lock button to change 2 chirps = auto unlock all doors
or
Fourth Press and release the valet switch Non Functional On This Unit
or
Fifth Press and release the valet switch Non Functional On This Unit
or
Sixth Press and release the valet switch Non Functional On This Unit
or
Seventh Press and release the valet switch Non Functional On This Unit
or
Eighth Press and release the valet switch 2 chirps = horn chirp output 16mS
Press transmitter Lock button to change 3 chirps = horn chirp output 30mS
Press transmitter Lock button to change 4 chirps = horn chirp output 40mS
Press transmitter Lock button to change 5 chirps = horn chirp output 50mS
Press transmitter Lock button to change 1 chirp = horn chirp output 10 mS
or
Ninth Press and release the valet switch Non Functional On This Unit
or
Tenth Press and release the valet switch 2 chirps = 2 step unlock off
Press transmitter Lock button to change 1 chirp = 2 step unlock on
or
Eleventh Press and release the valet switch 2 chirps = chirp delete from transmitter
inactive Press transmitter Lock button to change 1 chirp = chirp delete from transmitter active
or
Twelfth Press and release the valet switch Non Functional On This Unit
or
Thirteenth Press and release the valet switch Non Functional On This Unit
or
Fourteenth Press and release the valet switch Non Functional On This Unit
or
Fifteenth Press and release the valet switch 1 chirp = ch 5 pulsed output
Press transmitter Lock button to change 2 chirps = ch 5 output as long as button held
Press transmitter Lock button to change 3 chirps = ch 5-10 second output
Press transmitter Lock button to change 4 chirps = ch 5-20 second output
Press transmitter Lock button to change 5 chirps =ch 5 latch on/latch off output
Press transmitter Lock button to change 5 chirps = ch 6 hold 3 sec for pulsed output
or
Sixteenth Press and release the valet switch 1 chirp = ch 6 pulsed output
Press transmitter Lock button to change 2 chirps = ch 6 output as long as button held
Press transmitter Lock button to change 3 chirps = ch 6-10 second output
Press transmitter Lock button to change 4 chirps = ch 6-20 second output
Press transmitter Lock button to change 5 chirps =ch 6 latch on/latch off output
Press transmitter Lock button to change 5 chirps = ch 6 hold 3 sec for pulsed output
or
Seventeenth Press and release the valet switch 1 chirp = ch 7 pulsed output
Press transmitter Lock button to change 2 chirps = ch 7 output as long as button held
Press transmitter Lock button to change 3 chirps = ch 7-10 second output
Press transmitter Lock button to change 4 chirps = ch 7-20 second output
Press transmitter Lock button to change 5 chirps =ch 7 latch on/latch off output
Press transmitter Lock button to change 5 chirps = ch 7 hold 3 sec for pulsed output
or
Eighteenth Press and release the valet switch Non Functional On This Unit
or
Press and release the valet switch or turn the ignition off to: ExitProgrammingMode
or
Turn ignition switch off then on to advance to feature Bank 3:

128-7827
3 of 20
3
To exit program mode, turn ignition off, or press and release valet switch.
RF Programmable Features Bank 3 Is Remote Start Selectable Features:
Feature Selection 1 Chirp 2 Chirps 3 Chirps 4 Chirps 5 Chirps 6 Chirps
1st Defrost Output Pulsed 10 Mins
2nd RF Start Chirp Off On On & Car Finder
3rd RunTime 5 Mins 10 Mins 15 Mins 20 Mins
4th Parking Lights On Steady Flashing
5th Input Check Voltage Tach DBITach
6th Voltage Level >0.5V B4 Start < 0.5V B4 Start
7th Ign. 2 Select Off During Crank On During Crank Same As Accy.
8th Ign. 3 Select Off During Crank On During Crank Same As Accy Same As Starter
9th Diagnostics Off On
10thCrankTime 0.8 Sec 1.0 Sec 1.5 Sec 2.0 Sec
11th Gas/Diesel Gas Diesel 10 Diesel 15 Diesel 20
12th Transponder O/P While R/S On During Start Until Ign. Off
13th Temp Start NotAvailable
14th Crank Averaging Averaging PresetTime
Note: When averaging, the engine must be started 4 times with the key to be effective.
15th R/S Shock Not Available
16th Turbo Select Off 3 Mins 5 Mins 10 Mins
17th Black/Blue (Aux O/P) Single Pulse As Feat #1 Bank 2
When using the RF programmer, enter the program mode as follows:
Turn the ignition on.
Press and release valet switch 3 times;
turn ignition off then on.
Press and hold valet switch for 5 seconds.
Siren chirps 2 times indicating access to RF feature program mode.
To exit program mode, turn ignition off, or press and release valet switch.

128-7827
4 of 20
4
Action System Response
Turn ignition on No response
Press and release the valet switch 3 times 1 Chirp - LED 1 flash
Within 3 seconds, turn ignition Off, On, Off, On Short chirp, then 2 long chirps
This Action Accesses Feature Bank 3 Remote Start Selectable Features
First Press the valet switch one time 1 chirp = defrost output pulsed
Press transmitter Lock button to change 2 chirps = defrost output 10 Mins
or
Second Press and release the valet switch 2 chirps = RF start chirp on
Press transmitter Lock button to change 1 chirp = RF start chirp off
or
Third Press and release the valet switch 2 chirps = run time set for 10 mins
Press transmitter Lock button to change 3 chirps = run time set fro 15 mins
Press transmitter Lock button to change 4 chirps = run time set for 20 mins
Press transmitter Lock button to change 1 chirp = run time set for 5 mins
or
Fourth Press and release the valet switch 1 chirp = parking lights on steady w/RS active
Press transmitter Lock button to change 2 chirps = parking lights flashing w/RS active
or
Fifth Press and release the valet switch 2 chirps = tachometer input checking
Press transmitter Lock button to change 1 chirp = voltage sense input checking
or
Sixth Press and release the valet switch 1 chirp = greater than 0.5 V check before start
Press transmitter Lock button to change 2 chirps = less than 0.5 V check before start
or
Seventh Press and release the valet switch 2 chirps = ign 2 on during crank
Press transmitter Lock button to change 3 chirps = ign 2 same as accessory
Press transmitter Lock button to change 1 chirp = ign 2 off during crank
or
Eighth Press and release the valet switch 2 chirps = ign 3 on during crank
Press transmitter Lock button to change 3 chirps = ign 3 same as accessory
Press transmitter Lock button to change 4 chirps = Ign 3 same as starter
Press transmitter Lock button to change 1 chirp = ign 3 off during crank
or
Ninth Press and release the valet switch 1 chirp = diagnostics off
Press transmitter Lock button to change 2 chirps = diagnostics on
or
Tenth Press and release the valet switch 2 chirps = crank time 1.0 sec
Press transmitter Lock button to change 3 chirps = crank time 1.5 sec
Press transmitter Lock button to change 4 chirps = crank time 2.0 sec
Press transmitter Lock button to change 1 chirp = crank time 0.8 sec
or
Eleventh Press and release the valet switch 1 chirp = unit set for gasoline engine
Press transmitter Lock button to change 2 chirps = unit set for diesel engine 10 sec delay
Press transmitter Lock button to change 3 chirps = unit set for diesel engine 15 sec delay
Press transmitter Lock button to change 4 chirps = unit set for diesel engine 20 sec delay
or
Twelfth Press and release the valet switch 1 chirp = transponder output while R/S active
Press transmitter Lock button to change 2 chirps = transponder output during start only
Press transmitter Lock button to change 3 chirps = transponder output until ignition turned off
or
Thirteenth Press and release the valet switch Non Functional On This Unit
or
Fourteenth Press and release the valet switch 1 chirp = crank averaging w/voltage input checking
Press transmitter Lock button to change 2 chirps = preset crank time w/voltage input check
Fifteenth Non Functional On This Unit
or
Sixteenth Press and release the valet switch 1 chirp = turbo timer off
Press transmitter Lock button to change 2 chirps = turbo timer 3 mins
Press transmitter Lock button to change 3 chirps = turbo timer 5 mins
Press transmitter Lock button to change 4 chirps = turbo timer 10 mins
or
Seventeenth Press and release the valet switch 1 chirp = aux o/p Black/Blue single pulse
Press transmitter Lock button to change 2 chirps = aux o/p Black/Blue as alarm feature #1
Press and release the valet switch
or
turn the ignition off to: ExitProgrammingMode
Note : Once you enter the feature programming mode, do not allow more than 15 seconds to pass between steps or the
programming will be terminated.

128-7827
5 of 20
5
This system is to be used in vehicles with AUTOMATIC TRANSMISSIONS only! Although this combina-
tion Keyless Entry/Remote Start unit is a sophisticated system with many advanced features, IT MUST
NOT be installed into a vehicle with a manually operated transmission. Doing so may result in serious
personalinjuryandpropertydamage.
MUST HAVE a Tach Signal Input, and an Automatic Transmission.
INSTALLATIONOFTHEMAJORCOMPONENTS:
CONTROLMODULE:
Select a mounting location inside the passenger compartment (up behind the dashboard). The mounting
location selected must be within 24" of the ignition switch wiring harness to allow connection of the 6 pin
mainwiring harness.
Becertainthatthe chosenlocationwill notinterferewith properoperationof thevehicle. Avoidmounting the
moduleto orrouting thewiringaround thesteering shaft/column,as themoduleor wiringmay wraparound
or block the steering wheel preventing proper control of the vehicle. Secure the module in the chosen
location using cable ties or screws as necessary.
NOTE: DoNot MountThe Module InThe EngineCompartment, asit isnot waterproof.
HOOD PIN SWITCH:
Thehood pinswitch includedin thispackage isrequiredforthesafety shutdown ofthe remotestart unit. If
the vehicle is being worked on, this hood switch prevents the remote start activation even if the RF com-
mand to start is issued. This hood pin switch MUST be installed in all applications. Failure to install the
hood pin switch may result in personal injury or property damage. Mount the hood pin switch in an area
under the hood that is away from water drain paths. If necessary, the included brackets may be used to
movethe hoodpin switch awayfrom raingutters orallow mountingto thefirewall behindthe hoodseal. In
either case the hood pin switch must be set up to allow the hood to depress the switch at least 1/4" when
the hood is closed and fully extended when the hood is opened. For direct mounting, a 1/4" hole must be
drilled. Carefullycheck behindthe chosenlocationto insurethe drillwill notpenetrate anyexisting factory
wiringorfluid lines. Drilla1/4" holein the desiredlocation and threadthe hood pinswitch into itusing a 7/
16" nut driver or deep well socket. If using the mounting bracket, first secure the bracket to the desired
locationand secure thehood pinswitch inthe pre-threadedmounting bracket hole.
PUSH-BUTTONLED SWITCH
Select a mounting location known and accessible to the operator of the vehicle. A dash knockout plug or
frontdash panelis desirableasthe nowPush-Button LEDassembly needsthe LEDto bevisable fromthe
outsideof thevehicle and willbe usedfor valetmodes, programmingfeatures, programmingtransmitters,
and for overriding the remote start unit when the vehicle is being serviced. Inspect behind the chosen
locationto insurethatadequate clearanceisallowed forthebodyofthe switch,andalso thatthedrill willnot
penetrate any existing factory wiring or fluid lines. Drill a 5/16" or 8mm hole in the desired location and
mount the switch by passing the connectors, one at a time, through the panel from the front side and
pressing on the bezel until the switch is fully seated.
THERECEIVER/ANTENNAASSEMBLY:
TheReceiverAntennaAssembly providedwith thisunit allowsrouting frombelow thedashboard formaxi-
mumoperating range. Choosea locationabove thebelt line(dashboard) ofthe vehicleforbestreception.
Specialconsiderationsmust bemadeforwindshield glassassomenewer vehiclesutilizeametallicshielded
window glass that will inhibit or restrict RF reception. In these vehicles, route the antenna toward a rear
windowlocation forbest reception. Securethe antennawithdouble sticktape provided. After securingthe
antenna with tape, we advise also securing a section of the antenna cable to a fixed support. This will
prevent the antenna from dropping down in case the double stick tape is exposed to extreme heat, which
mayloosen itsgummedsurface. Route theconnector towardthecontrol moduleusing cautionnotto pinch
the cable as this will cause poor or no RF reception to the control module.

128-7827
6 of 20
6
This Remote Start System is designed for use with Automatic Transmission Vehicles Only! The unit
provideswait tostart inputfor glowplugpre-heat whichwill beused forall dieselapplications. If thiswire
isnot connected,then theunit willremain inthe Gasolinemode setting,which willcrank thecar whenthe
RFsignalis receivedwithno delay.Regardlessof thevehicle,Gasoline orDiesel,foreveryinstallation,the
vehicle
IMPORTANT!
DONOTPLUGTHE SIXPINMAIN POWERHARNESS ORTHE MULTIPININPUT/ OUTPUTHARNESS
INTOTHECONTROLMODULE UNTILALLCONNECTIONSTOTHE VEHICLEHAVE BEENMADE. AF-
TER SELECTING YOUR TARGET WIRESAS DEFINED BELOW, DISCONNECT THE NEGATIVE BAT-
TERYCABLE FROMTHEVEHICLE BATTERYPRIORTOMAKINGANYCONNECTIONS.
WIRING THE 6 PIN MAIN POWER HARNESS:
Note: Do not remove the fuse holders from this wire harness. Fuses must be used and located
as close as possible to the power source for adequate protection of the vehicle.
Fused RED w/ WHITE TRACE WIRE: + 12 volt Battery 1 Source
Locate the vehicle battery wire(s) at the ignition switch. Verification: These wires will register voltage in all
positions of the ignition switch. Connect the Red w/White wire to the vehicle's battery wire. This wire
provides power for the control circuit as well as the ignition 1 and ignition 2 relays.
Fused RED WIRE: + 12 Volt Battery 2 Source
Locate the vehicle battery wire(s) at the ignition switch. Verification: These wires will register voltage in all
positionsof theignitionswitch. ConnecttheRed wiretothevehicle'sbatterywire. Thiswireprovidespower
for the start relay and the accessory relay. IMPORTANT!
ITISTHERESPONSIBILITYOFTHEINSTALLINGTECHNICIANTODETERMINETHELOADFACTOROF
THEVEHICLESELECTRICALCIRCUITSWHENTHEVEHICLEISRUNNINGANDTOADEQUATELYFUSE
THETWO POWER WIRESBASED ONTHATLOAD. IFTHE VEHICLE,RUNNING UNDERLOAD WITH
THEAIRCONDITIONER, HEATERBLOWER MOTOR,ANDACCESSORIES EXCEEDS24AMPS CON-
TINUOUS,WE RECOMMENDTHATTWO FUSESBEUSEDINCOMBINATIONONEACH POWERWIRE
ASSHOWNBELOW. FORADDITIONALINFORMATIONSEETECHUPDATEISSUED9/30/96.
YELLOW WIRE: StarterOutput
Careful consideration for the connection of this wire must be made to prevent the vehicle from
starting while in gear. Understanding the difference between a mechanical and an electrical
Neutral Start Switch will allow you to properly identify the circuit and select the correct installa-
tion method. In addition you will realize why the connection of the safety wire is required for all
mechanical switch configurations.
Failure to make this connection properly can result in personal injury and property damage. In all installa-
tions it is the responsibility of the installing technician to test the remote start unit and assure that the
vehicle cannot start via RF control in any gear selection other than park or neutral.
Inboth mechanicalandelectrical neutralstartswitchconfigurations, theconnectionof theYellowwire willbe
madeto thelowcurrent startsolenoid wireoftheignitionswitch harness. Thiswirewillhave+12 voltswhen
the ignition switch is turned to the start (crank) position only. This wire will have 0 volts in all other ignition
switch positions.
at the ignition switch then it is possible to connect both wires to the vehicle s battery. This wire provides power for the
start relay and the accessory relay.

128-7827
7 of 20
7
NOTE: This wire must be connected to the vehicle side of the starter cut relay (when used). For the
electrical neutral switch configuration, this connection must be made between the starter inhibit
relay, (whenused) and theneutral safetyswitch as shownin thefollowing diagram.
Failure to connect this wire to the ignition switch side of the neutral safety switch can result in personal
injuryand propertydamage.
SEENEUTRALSTARTSAFETYTEST FOR FURTHER DETAILS.
BLUE WIRE: Ignition1 Output
Connect this wire to the ignition 1 wire from the ignition switch. This wire will show +12 volts when the
ignitionkeyisturned totheto the"ON"or "RUN"andthe "START" orCRANK"positions andwillhave 0volts
when the key is turned to the "OFF" and "ACCESSORY" positions.
ForDieselApplications, this wiremust beconnected tothe ignitioncircuit that powersthe glowplugs ifthe
vehiclerequiresglow plugpre-heating.
GREEN WIRE: Ignition2 Output
Connect this wire to the ignition 2 wire from the ignition switch. This wire will show + 12 volts when the
ignition key is turned to the "ON" or "RUN" position and is some cases the "START" or CRANK" position.
This wire will show 0 volts when the key is turned to the "OFF" and "ACCESSORY" positions.
NOTE: Seeprogramming informationconcerning thiswire toallowoutputduringthe "START"mode.
VIOLET WIRE: AccessoryOutput
Connect this wire to theAccessory wire from the ignition switch. This wire will show + 12 volts when the
ignitionswitch isturned tothe "ACCESSORY"or "ON"and "RUN"positions andwillshow 0volts whenthe
key is turned to the "OFF" and "START" or "CRANK" positions.

128-7827
8 of 20
8
WIRING THE 4 PINALTERNATE IGNITION HARNESS
ORANGE/BLACK Wire: ParkingBrake Input
This wire is used only when the turbo timer mode, Bank 3, feature # 16 is selected ON. This input insures
thatthevehicleparkingbrakeisappliedwheneverthevehicleissetupforandtheturbotimercircuitisused.
Thisinputmustswitchtogroundwhenthevehicle'sparkingbrakeisapplied.ConnecttheOrange/Blackwire
tothenegative outputofthe vehicle'sparkingbrake switch.
RED/BLACK Wire: + 12 Volts Input
Note: The Red/Black and Pink are dry contacts and may be used for negative switching when necessary.
Connecting the Red/Black to chassis ground will result in Pink being ground when the R/S is activated.
Thisinputistobeconnectedtoaseparate,(OtherthanthewireRedorRed/Whiteisconnectedto),constant
on+12 voltsource which willsupply + 12volt power tothe additionalignition output, (Pink),wire. Connect
this wire to a separate + 12 Volt source.
PINK Wire: Additional IgnitionOutput
Thiswirecan beusedasan additional+12Voltignition outputsuppliedbytheRed/Black wire. Thisoutput
can be selected to be on or off during the start cycle. (See feature bank 3 selection # 8) Connect this wire
to the third ignition circuit in the vehicle and set the selectable feature # 8 of Bank 3 according to the way in
whichthevehicle's ignitionswitch operates.
Note: Do not remove the fuse holders from this wire harness. Fuses must be
used and located as close as possible to the power source for adequate protec-
tion of the vehicle.

128-7827
9 of 20
9
WIRINGCONNECTIONS: 12 Pin Input / Output Harness
Black Wire: Chassis GroundSource Connectthe Blackwire toa knownvehicle groundsource orto asolid
clean metal part of the chassis. Be certain to remove any paint or grease and secure this wire with a self-
tappingscrew andring terminal.
GRAYWIRE:NegativeInhibitInput1
ConnecttheGRAYwiretothepreviouslymountedhoodpinswitchprovided. Thiswirewillberoutedthrough
the firewall into the engine compartment. It is necessary to use an existing grommet when passing wires
throughthefirewalltopreventshortcircuiting.Thisisanimportantsafetyfeatureof theSystem,failuretouse
thisfeaturecanresultinseriousinjury.Routethewiretothepinswitchandconnectitusingthebulletconnector
provided.
GRAYw/BLACKTRACERWIRE:NegativeInhibitInput2
Anytimethegray w/blacktracer wireisgrounded, theRemoteStarter willstopoperating, evenifthe signal
isreceivedfromthetransmitter.
Ifthebrakelightswitchinthevehicleswitchesgroundtothebrakelightcircuit,connecttheGrayw/Blacktrace
wireto the outputof the brakelight switch. Ifthe brake lightswitch inthevehicle switches+12 Volts, donot
use the Gray w/ Black wire; see Brown w/ Black tracer wire.
BROWNWIRE:PositiveInhibitInput1
Anytime +12 Voltsis appliedto theBrown wire,the RemoteStarter willstop operating,even ifthe signalis
receivedfromthetransmitter.
Ifthevehiclehasafactoryinstalledhoodpinswitchandthatswitchprovides+12Voltstoanunderhoodlight,
the Brown wire can be connected to the existing pin switch.
BROWN w/ BLACK Tracer Wire: Positive Inhibit Input 2
Anytime+12VoltsisappliedtotheBrownw/Blacktracerwire,theRemoteStarterwillstopoperating,even
ifthe signalisreceived fromthe transmitter.Ifthe brakelight switchinthe vehicleswitches +12Volts tothe
brake light circuit, connect the Brown w/ Black trace wire to the output of the brake light switch. If the brake
lightswitchinthevehicleswitchesground,donotusetheBrownw/Blackwire;seeGrayw/Blacktracerwire.
Brake Switch Positive Shutdown Detail

128-7827
10 of 20
10
YELLOW w/ BLACK Tracer Wire: + 12 Volt Alarm By - Pass Output
NOTE: You must disconnect the ignition input of the alarm from any other wire that it is presently connected
to in the vehicle.
Thiswire provides a+ 12 Voltoutputwhen the ignitionkeyis turned tothe“ON” position, and0Volts when theignition
key is “OFF” and when the vehicle is running under the control of the remote starter.
This wire should be connected to the ignition input of the alarm system.
The Yellow w/ Black wire output will allow you to remote start the vehicle while leaving the alarm armed, and to lock/
unlock the doors while running under control of the remote start unit.
(2) WHITE Wires: Parking Light Flasher
These wires are the COMMON and NORMALLY OPEN contacts of the on-board parking lamp relay.
If the vehicle's parking lights are a +12 volt switched system, connect (1) of the White wires to a fused (15A max.)
+12 volt battery source, and connect the second White wire to the vehicle's parking light wire.
If the vehicle's parking lights are a chassis ground switched system, connect (1) of the White wires to a chassis
ground source, and connect the second White wire to the vehicle's parking light wire.
LIGHT BLUE Wire: Ignition 3 / Shock Disable Output
This wire provides a 300mA ground output that becomes active 3 seconds before the Remote Start Unit initializes,
and remains grounded while running plus an additional 4 seconds after the Remote Start Unit turns off. In all of
the applications described below, a relay will be required. The Light Blue wire can be used to accommodate the
following situations:
A. Shock Sensor By Pass:
If there is Shock Sensor used with an alarm system and it is not shunted during the Remote Start activation
period, then vibration from the running vehicle can cause the alarm to trigger. In this case, connect the Light
Blue Wire to terminal #86 of a external relay. Connect terminal #85 of the relay to a fused + 12 volt battery
source. Cut the shock sensor trigger wire and connect one end of the cut wire to terminal #30 and the other end
of the cut wire to terminal #87a. Just before the Remote Start unit is activated, the relay contacts will open,
preventing the shock sensor's operation until the Remote Start unit shuts off.
B.Ignition 3Output:
Some newer vehicles use a third ignition wire, which is required to start and keep the vehicle's engine running.
If this is the case, connect the Light Blue wire to terminal #86 of an external relay. Connect terminal #30 & #85
to a fused + 12 volt battery source rated for a minimum of 25Amp. Connect terminal #87 to the third ignition wire
in the vehicle.
Switch

128-7827
11 of 20
11
C.GM VATSKey Override:
If the vehicle has the General Motors VATS system installed, you will need to bypass the system while the vehicle is
operating under the control of the Remote Start Unit. To Do This;
1.Measure the resistance of the resistor pellet on the ignition key then select a resistor within 5% of the key's
value from the resistor pack supplied.
2.Locate the pair of VATS wires in the vehicle, usually a pair of thin gauge wires running from the ignition switch
to the VATS control module.
NOTE: These wires are typically White w/ Black trace and Violet w/ Yellow trace, however in later model Cadillacs,
they are run through an orange sleeve, and are either both Black, both Yellow, or both White wires. Consult the
factory service manual for additional information.
3. Connect the Light Blue Wire from the Remote Start Unit to terminal #86 of an external relay. Connect terminal
#85 of the relay to a fused + 12 volt battery source.
4. Cut (#1) wire (as shown), and connect the ignition switch side of the cut wire to terminal #87a of the relay.
Connect the other side of the (#1) wire to terminal #30.
5. Connect the previously selected resistor from terminal #87 to the second (#2) wire (as shown).
NOTE: The above information and following diagram is for the GM VATS system only. For GM PASS LOCK System
you will require theAudiovoxAS-PASS II Module.
General Motors VATS By-Pass Diagram
Tachometer Input Wiring Detail
GREEN/ORANGE Wire:TachSensor Input
This wire will continually monitor the engine tach rate while the unit is under power of the Remote Start module.
This wire will be routed to the vehicle ECM tach input or through the firewall into the engine compartment and
connect to the negative side of the ignition coil. This Remote Start unit learns the tach rate of the vehicle and in most
cases will operate properly from one multi coil pack regardless of the number of cylinders. If the vehicle has a
single coil unit for each cylinder, it may be necessary to connect this wire to more than one cylinder for proper tach
reference. See multi coil wiring detail shown later in this manual for additional information.

128-7827
12 of 20
12
Green/Yellow Wire: Diesel Wait To Start Input
The Green/Yellow wire will connect to a diesel vehicles glow plug wire. When the unit receives a start command,
this wire must go to + 12 then to ground to allow the crank sequence to begin. When ignition #1 is activated by the
remote start unit, the glow plug circuit gets energized, (+ 12 volts), when the glow plug circuit of the vehicle drops the
+ 12 volts, which effectively grounds the wait to start input, then 500mS later the starter will engage. This wire can
also be connected to the Glow Plug Bulb wire in the vehicle if this bulb wire gets + 12 volts when the ignition comes
on and drops low when the glow plug circuits temperature is reached. Be sure to fuse the wire with a 1 Amp Fuse
when connecting to a high current circuit such as a factory glow plug wire. The fuse should be installed as close
to the high current wire as possible. If you are installing this unit in a Gasoline vehicle, this wire is not used.
NOTE: If the Glow Plug sense wire, Green/Yellow is connected, this wire will have priority over the setting of feature
Bank 3 Feature #11.
WIRING THE 4 PIN AUXILIARY OUTPUT HARNESS
Theauxiliary 4pinconnector provideslow currentoutputs tocontrol variousfunctions in thevehicle during
different stages of the Remote Start unit's operation. Understanding these outputs and the time in which
theyoccur willallowyoutodetermine ifthey areneededfor theparticular vehicleyouare workingon aswell
as how to use them.
Black w Blue Trace Wire: Pulsed Ground Output Before Start
The Black w/ Blue Trace wire will provide a 1 second 300 mA pulsed ground output 1.5 second before the
remotestartunit activatesas wellas whenthetransmitter isused todisarm thesystem. Typicaluse forthis
output would be to disarm a factory theft deterrent system to prevent false triggering of the factory alarm
when the remote start unit engages or when the transmitter is used to unlock the doors.
Black w/ Light Green Trace Wire: Pulsed Ground Output After Start
TheBlackw/ LightGreenTrace wirewillprovide a1second 300mApulsedgroundoutput afterthevehicle is
started under control of the remote start unit. Typically this wire will be used to re-lock the vehicle doors if
the doors unlock automatically when the factory anti-theft system is disarmed.
Black w/ Red Trace Wire: Pulsed Ground OutputAfter Shutdown
TheBlackw/Red Tracewirewill providea1 second300mA pulsedgroundoutput aftertheremote startunit
shuts down. This output will occur regardless of whether the circuit times out or is manually terminated.
Typically this output will be used to re-lock the vehicle doors if the doors unlock automatically when the
ignition circuit transitions to off.
Black w/ Yellow Trace Wire: Ground Output During Start (Crank)
The Black w/ Yellow Trace wire will provide a 300 mAground output while the starter output of the remote
start unit is active. This output can be used to activate the Crank Low/Bulb Test wire found in some GM
vehicles. This wire is also referred to as the ECM wake up wire in some Chrysler vehicles.
NOTE: Theoutputs abovearelow currentoutputs andmustbeusedwith arelayifthecircuit's requirement
is more than 300 mA.
Push-Button LED Programming Switch Assembly: (2 Pin Blue & 2 Pin White Connectors)
Routethe grayandblack wiresinthe 2pinconnector andthered andblue in thetwo pin connectorfrom the previously
installed push-button LED programming switch assembly to the control module and plug these into the mating blue
and white connectors on the side of the module.
2 Pin Transponder Control Output: (Yellow Connector)
Thisoutput isintended to allowthe controlof atransponder bypassinterface moduleor transponder
bypass relay. The system also allows software selections to control the way in which this output oper-
ates, see remote start feature # 10 for setting this output.
When the unit is selected for output during the start sequence, this output will be active at the same time
Ign. 3 becomes active, and will remain active until the vehicle has started. This will be used for one time
readtransponder circuits.
When the unit is selected for transponder on, this output will become active at the same time ign. 3
becomes active, and will remain active all the time the unit is operational under the control of the remote
start. When the unit is selected for continuous and the vehicle is started via the Remote Start, this
output will become active at the same time ign. 3 becomes active and will remain active until the ignition
in the vehicle goes low. This will allow the unit to be used for continuous read transponders circuits.

128-7827
13 of 20
13
5PinAccessoryOutputHarness
Dark Blue Wire : Delayed 300 mA Pulsed Output/Channel 3
Thedarkbluewire pulses toground viaan independentRF channelfrom thekeychain transmitter. Thisis
a transistorized, low current output, and should only be used to drive an external relay coil.
Thisoutputisactivatedbythesametransmitterbuttonthatisusedtoactivatetheremotestartfunction. Press
andholdthetrunk/keybuttontoactivatethistrunkreleaseoutput,orpressandreleasethetrunk/keybutton
two times within 2 seconds to activate the remote starter.
WARNING:Connectingthedarkbluewiretothehighcurrentswitchedoutputofthetrunkreleasecircuitsand
some remote start trigger inputs, will damage the control module.
Connectthedarkbluewiretoterminal86oftheAS-9256relay(orequivalent30Aautomotiverelay),connect
terminal85toafused+12voltsourceandwiretheremainingrelaycontactstoperformtheselectedfunction
desired. Channel 3 Relay Wiring Detail
Green w/ Black Trace Wire: 300mA Latched Channel 4 Output
TheGreen w/BlackTrace wiresuppliesa 300 mAswitchedoutput wheneverchannelfourofthe receiveris
accessed. Pressing the pre-programmed transmitter button(s) will access channel four and will remain
active, for up to 20 seconds, as long as the transmitter button(s) is held. This is a low current output and
mustbe connected toa relayto supplypower tothe device youintend tocontrol. Connect Greenw/ Black
Trace wire to terminal #86 of a VF45F11 P&B relay or equivalent. Connect terminal #85 of the relay to a
fused+ 12 voltsource. Connect the common,normally open,and normally closedcontacts ofthe relay to
performthe selectedfunctionof thechannel 4output.
NOTE: Thiswire also canbe usedfor defrostactivation as dictatedby thesetting offeature #1of Bank3.
Anytimethevehicle isrunningunder controlofthe RemoteStartand Channel4is activated,thendependent
on the selection of this feature, Green/Black will be activated as a pulse for 1 second, or for 10 minutes.
Note this wire will not operate when the vehicle is running under the power of the ignition key, only while
under the control of the remote start or if not used for defrost then an output will occur as indicated above.
WARNING ! Connecting the Dark Green w/Black trace wire to any high current switched out-
put (300mA max.) will damage the control module.
Lt Blue/Green Wire : DELAYED 300 mAPULSED OUTPUT / CHANNEL5
The light blue/green wire pulses to ground via an independent RF channel from the keychain transmitter.
This is a transistorized, low current output, and should only be used to drive an external relay coil.
WARNING: Connecting the light blue/green to the high current switched output of trunk release circuits,
some remote start trigger inputs, will damage the control module.
Connectthe lightblue/green toterminal 86of theAS -9256 relay(or equivalent30Aautomotive relay)and
wire the remaining relay contacts to perform the selected function of channel 5.
Lt Blue/Black Wire : DELAYED 300 mAPULSED OUTPUT / CHANNEL6
The light blue/green wire pulses to ground via an independent RF channel from the keychain transmitter.
This is a transistorized, low current output, and should only be used to drive an external relay coil.
WARNING: Connecting the light blue/black to the high current circuits, will damage the control module.
Connectthe lightblue/black to terminal86 oftheAS -9256 relay(or equivalent30Aautomotive relay)and
wire the remaining relay contacts to perform the selected function of channel 6.
From2Pin

128-7827
14 of 20
14
Blue/Red Wire : DELAYED 300 mAPULSED OUTPUT / CHANNEL7
Thelightblue/red wirepulsesto groundviaan independentRFchannel fromthekeychain transmitter.This is
a transistorized, low current output, and should only be used to drive an external relay coil.
WARNING: Connecting thelight blue/red tothe highcurrentcircuits, willdamage thecontrolmodule.
Connectthe lightblue/redto terminal86of theAS -9256relay (orequivalent30Aautomotive relay)and wire
the remaining relay contacts to perform the selected function of channel 7.
3PinInput/OutputHarness:
Dark Blue/Black Trace Wire: External Trigger Input
The Dark Blue/Black trace wire allows the remote start unit to be activated from an external source. The
intent of this wire is to allow the unit to be controlled from a "POSSE/CAR-LINK" paging system or similar
device. Whenthis wirereceives aground pulse,the unitwill startthevehicle. Connectthis wireto aground
pulsed output from the controlling circuit.
Green w/ White Trace Wire: Entry Illumination Ground Output
This wire provides a 30 second ground output (300 mA Max.) whenever the remote is used to unlock the
doors . This wire should be connected to an external relay, and wired to the vehicles interior entry lighting
wheneverthe optionalInterior Illuminationcircuit isdesired. See belowfor relaywiring details.
Black w/ White Trace Wire: 300 mAHorn Output
The black w/ white trace wire is provided to beep the vehicle’s horn. This is a transistorized low current
output, and should only be connected to the low current ground output from the vehicle’s horn switch.
If the vehicle uses a + 12 VDC horn switch, then connect the black w/ white trace wire to terminal 86 of the
AS 9256 relay ( or an equivalent 30Amp automotive relay ), and connect relay terminal 85 to a fused + 12
VDCbattery source.Connect relayterminal 87to thevehicle’s hornswitch output,andconnectrelaytermi-
nal 30 to a fused + 12 VDC battery source.
Entry Illumination Detail
3 Pin Antenna/Receiver Connector: (White Connector)
Plugthepreviouslyroutedantennaconnectorfrom theantennareceiver assembleintothe matingconnector
ofthecontrol module. Thisconnectorsupplies 12volts,ground andRFdata fromtheantenna receivertothe
remote start module. Be certain this connector is firmly seated making good contact to the control unit.
TIMEDSTARTPROGRAM:
TheRemoteStartunithastheabilitytostartthevehicleautomaticallyattimedintervals. Thisfeatureisuseful
inextremelycoldclimateswherestartingtheengineistheonlymeanstokeepthebatterychargedandfluids
warm. Theoperatorhastheoptiontohavetheunitstartevery2or4hoursforamaximumof48hours. Factory
pre-set is to start at 4 hour intervals. To select 2 or 4 hour automatic start timer:
1. Start By Holding the Pushbutton Switch On.
2.WhileHolding thePushbuttonSwitch TurnTheIgnition SwitchOn ThenOff
3a) Within 10 seconds of turning the ignition switch off, Release and then Push On and release the Push-
button Switch 2 times holding it on the second time until the siren and or lights flash and chirp 2 times
indicating that the 2 Hour Start Interval has successfully been set. or
3b) Within 10 seconds of turning the ignition switch off, (Step 2) Release
and then Push On and release the Pushbutton Switch 4 times holding it on the fourth time until the siren
and or lights flash and chirp 4 times indicating that the 4 Hour Start Interval has successfully been set.
NOTE: Once selected, 2 or 4, this timer interval will remain in memory until it is manually changed. To
change,theabovesequencewillhavetobefollowed.

128-7827
15 of 20
15
TIMEDSTARTOPERATION:
Tobeginthestarttimer,within10secondsofturningofftheignitionswitch,activatetheRFcommandtostart
2times.(Pressthetrunk/keybuttonfourtimes). Thelightswillflashandthesirenwillchirp4times.Indicating
timedintervalmodehasbeeninitiated.Thevehiclewillautomaticallystartevery2or4hoursasprogrammed.
To cancel the timed start mode start the vehicle either by RF or by the ignition key.
Programming Tach Rate:
NOTE: Allapplicationsrequirethat tachbeprogrammed.
Theunitwillnotoperateunlesstachisprogrammed. Ifanattemptismadetostartthevehicleviatheremote
startwithoutfirstprogrammingtach,theunitwillflashtheparkinglights7timesindicatingtachhasnotbeen
learnedandstored. Ifthetachrateisnotproperlyprogrammedtothespecificvehicle,theunitmaynotrealize
that the vehicle is running in certain instances and could re-engage the starter motor.
TheRemoteCarStarterwilllearnthetachrateofmostvehiclessingleignitioncoils,multiplecoilpacks,and
or single injector. To learn tach;
1. Turn the ignition key to the ON position.
3. Press and release the program push-button switch 3 times.
4. Immediately turn the ignition key OFF.
5. Hold the program push-button switch ON, then start the vehicle using the ignition key.
6. When the unit senses the tach signal, the parking lights will begin to flash.
7. Releasetheprogrampush-buttonswitch. Theparkinglightswillturnonfor3secondstoindicatethatthe
tach signal is stored and the unit is now out of the program mode.
3.Diagnostics:
1. Be sure that programmable feature number #9 is set to the "Diagnostics On" mode.
2. Press and hold the program push-button switch on, then turn the ignition key to the "ON" position.
3. Thelightswillflashandthenumberofflasheswillindicatethereasonforshutdownonthelastremotestart
attempt. The indications are as follows.
1 Flash 5, 10, 15, or 20, minute run timer expired.
2Flashes Lowor Notachsignalreceived.
3Flashes Positive inputshut down.
4Flashes Control switchwas movedto"Off" position.
5Flashes RFShutdowncommandreceived.
6Flashes HighRPM signaloverspeed shutdown.
7Flashes TachhasNOTlearned.
8Flashes Negativeinputshutdown
Multi Coil Pack Adapter: (Optional)
Themulti coilpackadapter, (P/N136B1400), isdesigned foruse withvehicles thatdonotrespondto single
coil tach programming. Although the tach resolution of this circuit is designed to interface direct with most
vehicles,there may bean occasionwhere thefollowing circuitmay be required.
To use the adapter, the Green/Black wires must connect to the negative side of the ignition coil(s).
1. For vehicles utilizing independent coils per cylinder, connect the three Green/Black leads to alternate
coils.To achieveoptimum performancethecoil signalsmust beevenlydistributed. This isaccomplished
by first mapping out the firing order of the engine in groups of as indicated below. Draw a circle around
any of the columns. The Green/Black wires should be connected to the negative (-) terminal of the
respectivecylinder number whichappears inany ofthe circles.
2. For vehicles utilizing 2 cylinder firing per coil pack, connect Green/Black to the tach side of each coil
pack. For 8 cylinder, four coil systems, connect to any of the three coils.
3. Connect theYellowwire toa+12 voltignition1 source. Thiswirewill have+12voltswiththe ignitioninthe
on and start position and have 0 volts with the ignition in the off position.
4. Connectthe Green wireto the(Green)or (Orange/Green) tachinput oftheAudiovox remotestartunit.

128-7827
16 of 20
16
TESTINGYOUR INSTALLATION:
WARNING!! The followingproceduremustbeperformed after theinstallationof anAudiovoxRemote
Start Device. It is the responsibility of the installing technician to complete these tests. Failure to test the
unitin the followingmanner mayresult in personalinjury, property damage,or both.
HOOD PIN SAFETY SHUT DOWN:
Theintention ofthehood pinsafety shutdownistoprevent theRemoteStartunit frombeing activatedwhile
amechanic orvehicleowner isperforming normalroutinevehiclemaintenance.
To test the integrity of this circuit:
1. With the driver's window in the down position, start the vehicle using the RF transmitter.
2. Reach inside the car and pull the hood release.
3. Raise the hood and confirm that the remote start unit shuts down.
Ifthe unit failsthis test,recheck your pinswitch connectionto the Gray/Blackwire oftheAudiovox Remote
Start Unit.
WARNING!!
DONOT RELEASE THISVEHICLE TO THECONSUMER UNTIL YOUCONFIRM THE
OPERATION OF THE HOOD PIN SAFETY SHUT DOWN FEATURE.
MANUALSHUT DOWN /ENABLE CIRCUIT:
Theintent ofthemanual shutdown/ enablecircuitis toallowthe vehicleoperatorto preventoperationof the
RemoteStart Unitregardless ofthe RFtransmitter operation.
1) With the system disarmed/unlocked, and the ignition switch off Press and Hold the PRLED on.
2) Turn the ignition switch on, off, on, off, on, off.
3) The LED begins to flash two short flashes followed by one long flashes and continues this pattern until
returnedto normalmodeof operation.
This puts the unit into the R/S Override mode indicating that the remote start is in the service mode and
will not start from RF or any other input Posse or otherwise.
ToExit R/SOverride Mode
1) With the system disarmed, Press and Hold the PRLED on.
2) Turn the ignition switch on, off, on, off, on, off.
3) The LED turns off indicating that the R/S unit is fully functional one again.
WARNING!!
DONOT RELEASE THISVEHICLE TO THECONSUMER UNTIL YOUCONFIRM THE
OPERATION OF THEMANUALSHUT DOWN /ENABLE FEATURE.
NEUTRALSTART SAFETY TEST:
The intent of the neutral start switch is to prevent the vehicle from starting while the gear selector is in any
positionother thanPark, or Neutral. Wheninstallinga RemoteStartDevice, itis imperativethat theYellow
Starter wire be connected to the ignition switch side of the Neutral Start Switch. Consideration for the
placementof a starterinhibit relayis important aswell, andshouldbe connectedto theignitionswitch side
of the Yellow Start Wire.
To test the integrity of the Neutral Start Safety Circuit:
1. Set the vehicle parking brake.
2. Blockthe drivewheels toprevent vehiclemovement.
3.Temporarilydisconnect theBrown/Black positive shutdown wirefrom thevehicle's brakeswitch.
4. Sitting in the vehicle, start the engine using the vehicle's ignition key.
5. Step on the brake pedal and shift the gear selector into reverse.
6. Allowthe transmissionto shift. When youfeel theenginepull, donot movethe gearselectorjust turnthe
ignition switch off. DO NOT attempt to remove the key.
7. Keepingthebrakepedal depressed,activatethe RFtransmitterin anattemptto startthevehicle. The car
should not start.

128-7827
17 of 20
17
8. Repeat the above test this time move the gear selector to the drive position. If the unit attempts to start,
failingthis test,recheck yourYellow Wire'sconnection.This wiremust beconnectedto theignition switch
side of the Neutral Start Switch. If the vehicle you are working on does not have an Electrical Neutral
SafetySwitch, itwill benecessaryto reconfigurethe RemoteStartsWiringtoaccommodate thisvehicle.
The information concerning the Mechanical Neutral Safety Switch provided below will help you to deter-
mine if the vehicle you are working on has this type of safety switch and will provide alternate wiring
methods to accommodate this situation. WARNING!!
REMEMBERTORECONNECT THE BROWN/BLACK WIRETEMPORARILY
DISCONNECTEDIN STEP 3.
DO NOT RELEASE THIS VEHICLE TO THE CONSUMER UNTILYOU CONFIRM THE OPERATION OF
THENEUTRALSAFETYSTARTFEATURE.
MECHANICALNEUTRALSAFETYSWITCHCONSIDERATIONS:
Mechanicalneutral safetyswitchconfigurations differslightly inthat theydonot offerthe samelevelof safety
when installing a remote start device. Often when the ignition switch is turned off while the gear selector is
in any position other than park or neutral, the mechanical function will not allow the key to be turned to the
startposition orberemoved fromtheignitioncylinder.Thisconfiguration preventsmechanical operationwhile
the vehicle is in gear but offers no consideration for electrical operation. Because of this potential problem,
thisinstallation requiresthe additionalconnection ofa safetywire fromthe remotestart deviceto thevehicle
Park/NeutralECMInputor thevehiclekey insensor. Thisconnectionwill preventremotestartoperationif the
key is left in the ignition switch regardless of the gear selector position.
PARK / NEUTRAL ECM INPUT:
ThePark / NeutralECM input isthe preferredmethod of installation. Thisnot onlymaintains the integrityof
thefactory circuit,it isalsothe easiestto install,providing thevehicleyou areworking onhas thisECMinput.
Theinstallation requiredfor thisapplication (shownbelow), indicatesthe slightreconfiguration ofthe control
switchwiring andthe additionof a4000 seriesdiode. Shown isatypicalGMPark/Neutral ECMinput circuit.
To connect theAudiovox remote start unit to the GM Park / Neutral ECM input:
1. Locatethe Orange /Black referencewire inthe "C2"connector found atthe ECMin GMB Bodyvehicles
or,locatetheequivalent referencewire inthe vehicleyouare installingtheAudiovoxRemote Start Unitin.
2. ConnecttheCathode, (Striped) end, ofa 4000 seriesdiode to thisreference wire.
3. Connect theAnode, (Non Striped) end, of the diode to one side of the Remote Start enable switch.
4. Connect the other side of the enable switch to the Black/White enable input wire of the Remote Start unit.
Thereference diagrambelow showsa typicalGM BBody ECMreference wireand howitistobe connected
to the Remote Start Unit.
KEYIN SENSOR CIRCUITS:
If the vehicle you are working on does not have or you cannot locate the ECM reference wire, there are two
alternatives available. Although not preferred, the vehicle Key In Sensor may be reconfigured to allow a
marginof safety andwill preventthe vehiclewith aMechanical Neutral StartSwitch fromstarting ingear.
AUDIOVOXADVISESTHATYOUMAINTAINTHEFACTORYCIRCUITWHENEVERPOSSIBLE. Thefollow-
ing two circuits may be used only if the above circuit is not available.

128-7827
18 of 20
18
NOTE: When completing an installation using either of the following key in sensor circuits, if the operator
insertsthe ignitionkey whilethevehicle isrunning underthecontrol ofthe RemoteStart,thevehicle
willshut down. Thismust beexplained totheoperator asit isin contrastto thenormal operationof
a vehicle utilizing an electrical neutral start switch and is inconsistent with the operator's manual.
Additionalinformationconcerning KeyInSensor methods1 & 2are listed belowand should bereviewed
beforeconsidering eitheralternative.
Method 1 willallow thesafety required forthe remotestart unitand preventthe vehiclefrom startingwhile
in any gear other than Park or Neutral while the key is in the ignition cylinder. However, if the key is left in
theignition switchand thedoor isleft opened,the addedrelay willbe energizedcausinga150mAdrain on
the battery.
Method 2 willallow thesafety required forthe remotestart unitand preventthe vehiclefrom startingwhile
inany gearother thanPark orNeutral whilethe keyis inthe ignitioncylinder. However,the originalfactory
keyin chimemodule willnotalert theowner thatthekey hasbeen leftin theignitionswitch. In addition,this
may also effect other warning tones such as the light on reminder.
These situations should be carefully considered before altering the vehicle's wiring and must be fully ex-
plainedto theconsumer.
Circuits may be used only if the above circuit is not available.
METHOD1
To connect to the key in sensor as shown in method 1:
A. Locate the control wire that connects the drivers door pin switch to the key in sensor switch.
B. Cut this wire and connect the ignition cylinder side to chassis ground.
C. Locate the key in sensor switch wire that connects the chime module to the ignition cylinder .
D.Cut thiswireand connecttheignition cylinderside toterminal#30 ofaP&B VF45F11or equivalentrelay.
E. Connect the cathode (striped) side of a 4002 series diode to this same wire, and connect the (non
striped) side to the negative shut down safety wire (Gray / Black) of theAudiovox Remote Start Unit.
F. Connect terminal #86 of the relay to a fused +12 volt constant battery source.
G. Connect terminal #87 of the relay to the Chime Module side of the previously cut wire in step D.
H.Connect terminal#85 ofthe relayto theDrivers Doorside ofthe pinswitch wirepreviously cutin stepB.
NOTE: Asecond 4002series diodemay be requiredto maintainthe integrityof thehood open,shut down
circuit. If this is the case, it must be installed as shown in the diagram above. The anode (Non
Striped) side must be connected to the Gray/Black wire of the Remote Start Unit. The cathode
(Striped) side must be connected to the hood pin switch. If the hood pin switch is also used for an
alarmtrigger input,be certaintouse thedual diodeassembly packaged withtheAudiovoxRemote
StartUnit as shownfollowing.
METHOD2
To connect to the key in sensor circuit as shown for method 2:
A. Locate the control wire that connects the drivers door pin switch to the key in sensor switch.
B. Cut this wire and connect the ignition cylinder side to chassis ground.

128-7827
19 of 20
19
C. Locate the key in sensor switch wire that connects the chime module to the ignition cylinder .
D. Cut this wire and connect the ignition cylinder side to the Remote Start Negative Safety Shut down Wire
Gray/Black,using a 4002series diode asshown above.
NOTE: A second 4002 series diode may be required to maintain the integrity of the hood open, shut down
circuit. If this is the case, it must be installed as shown in the diagram above. The anode (Non
Striped) side must be connected to the Gray/Black wire of the Remote Start Unit. The cathode
(Striped) side must be connected to the hood pin switch. If the hood pin switch is also used for an
alarm trigger input, be certain to use the dual diode assembly packaged with theAudiovox Remote
Start Unit as shown in this installation guide.
AFTER THE CONNECTION OF THE NEUTRAL START SAFETY WIREAS INDICATED IN ANY OF THE
PREVIOUSALTERNATECONFIGURATIONS,THISCIRCUITMUSTBETESTEDFOROPERATION.
Retest by following the steps outlined in the NEUTRALSTARTSAFETYTEST shown in this manual.
4 Pin Upgrade Telematic Module:
Red = + 5 Volts
Black = Ground
White = Data TX
Yellow = Data RX
Ifused, connectthe4 pinharnessfrom theTelematic onewaymodule kittothe matingportonthecontrolling
circuit. NOTE: Ifusing theTWO WAYTelematicmodule, onlyGround,TX,and RXare usedonthis port,the
+ 12 volt supply for the two way module must be sourced separately or the unit will not operate.
4 Pin Upgrade Data Bus/Flash Logic Module:
If you are using anAudiovox Flash Logic module, it can be connected directly to theAlarm/Remote Start's
controlmodule. Using theBlue 4pin blue,red, black,& whiteharness andconnect tothe matingconnector
on the Alarm/Remote Start control module. Wire the Flash Logic/Data Bus module to the vehicle as pre-
scribed in it's installation guide.
COMPLETINGTHE INSTALLATION:
Afteryou haveconfirmedtheoperationof theAudiovoxRemoteStartunit andtestedall thesafetyfeatures of
the system:
1. Ifyou havenotdonesoalready,place theredrubber handlecoverover thehandleof thecontrolswitch for
ease of identification. This will allow your customer to distinguish the Remote Start control switch from
theprogram switch.
2. Mount the control module up and behind the dash securing it in place with cable ties or screws. Be
certain that the chosen mounting location will not inhibit any of the controls of the vehicle.
3. Securely harness and tie all wiring up and away from all hot and moving parts that they may come in
contactwithunder thedash board orin the enginecompartment areas.
CAUTION:Particularly avoid the area around the steering shaft and column, as wires can wrap around
these mechanisms and impair thesafe operation ofthe vehicle.
4. Apply the Caution Labels supplied with this kit to a conspicuous area in the engine compartment. Make
sureto cleanthe surface beforeaffixing thelabel.
5. Check the vehicle's wipers, lights, horn, etc.... to insure proper operation.
6. Replace all panels that were removed during installation, and retest the system.
7. Explain all activated features and safety systems associated with Remote Start Unit installed to the
customer.

128-7827
20 of 20
20
© 2006 Audiovox Electronics Corp., Hauppauge, NY 11788 128-7827
