Auralex Acoustics Project 2 User manual

Roominator Performance Series™
USER GUIDE
Auralex®Acoustics, Inc.
1-800-959-3343 / 317-842-2600 / Auralex.com
9955 Westpoint Drive, Suite 101, Indianapolis IN USA 46256
EACH KIT INCLUDES:
INSTALLATION:
Project ➋™
(24) 2’x2’x2”Studiofoam®Wedge
(8) LENRD®Bass Traps
(144) EZ-StickPro™Tabs
Deluxe Plus™
(24) 2’x2’x2”Studiofoam®Wedge
(8) LENRD®Bass Traps
(6) T’Fusor™Diffusors
(168) EZ-StickPro™Tabs
Pro Plus™
(36) 2’x2’x2”Studiofoam®Wedge
(12) LENRD®Bass Traps
(8) T’Fusor™Diffusors
(248) EZ-StickPro™Tabs
STUDIOFOAM®WEDGE T’FUSOR™
LENRD®BASS TRAP
EZ-STICK PRO™
Studiofoam Wedge, LENRD Bass Traps and T’Fusor Diffusors can be
mounted to standard drywall with the included EZ-Stick Pro Tabs. Be advised
that the EZ-Stick Pro Tabs are designed for permanent installations and will
damage drywall and painted surfaces when removed.
Mark the target position on your wall or ceiling where the product will be
mounted using small pencil marks, pieces of masking tape or any similar
non marring method. Be sure the surface where the EZ-Stick Pro Tabs will
adhere is free of dirt, dust or other oily contaminants by spot cleaning with
rubbing alcohol.
Each Studiofoam Wedge panel and T'Fusor Diffusor use 4 EZ-Stick Pro
Tabs, each LENRD Bass Trap uses 6 tabs.
Remove one of the release layers on the EZ-Stick Pro Tabs and affix it to the
rear side of the Studiofoam Wedge perimeter, usually near the corners. On
LENRDs, place the tabs along the thin edge as shown below. For all Studiofoam
products, apply very firm pressure for 30 seconds in order to ensure the
EZ-Stick Pro Tabs properly adhere to the Studiofoam. Not using adequate
pressure will cause the EZ-Stick Pro Tabs to fail.
Remove the second layer of the release paper from each of the EZ-Stick Pro
Tabs, carefully orient the panels position prior to contact with the wall, then
press in place with firm pressure for 30 seconds.
990-413.Roominators Performance Series User Guide.indd (10/20/2014 - 2:40 PM)
LENRD®(EZ-Stick Pro Tab Placement)
FINAL APPLICATION AFTER APPLYING FIRM PRESSURE
INITIAL APPLICATION (Without Applying Firm Pressure)
ADHESIVE
ADHESIVE

Roominator Performance Series™
USER GUIDE
Auralex®Acoustics, Inc.
1-800-959-3343 / 317-842-2600 / Auralex.com
9955 Westpoint Drive, Suite 101, Indianapolis IN USA 46256
GENERAL PLACEMENT SUGGESTIONS
STUDIOFOAM:
Studiofoam Wedge panels reduce mid-high frequency reflections, flutter echo, room ring and excessive reverberation. To maximize
performance in a project studio or control room, consider placing the panels at the first reflection points located to the sides, front, rear and
ceiling above your listening position. To maximize performance in a live room, consider spacing the panels evenly throughout the room and
staggering treatment across parallel surfaces.
LENRD: Low End noisE REduction dEvicE
LENRD Bass Traps are designed for the 90 degree corners of a room. To increase performance, place them vertically between adjacent
walls and horizontally between a wall and the ceiling.
T’FUSOR:
T'Fusor Diffusors scatters high frequency energy preventing them from grouping so that there are no hot spots or nulls in the room. In
control rooms and project studios, T’Fusor diffusors are best placed in the rear of the room or above the mix position. In live rooms, space
the panels evenly, inter-mixed with Studiofoam Wedge panels. Backfilling the T’Fusors with Auralex Mineral Fiber Insulation or Auralex
PlatSheet™(Platfoam™)will help increase absorption in the low end.
SPECIFIC PLACEMENT SUGGESTIONS
FREE PERSONALIZED ROOM ANALYSIS:
For specific placement suggestions regarding your room, feel free to submit a free Personalized Room Analysis form online at:
www.Auralex.com/praf/. You provide information about your room including a room diagram and photos. Auralex will
diagram your room, including all surfaces with product placement indicated.
ROOM ANALYSIS PLUS:
For a more in depth analysis of your room, we offer the Room Analysis Plus service. We supply the frequency sweeps,
you send us the recordings of your room and we’ll deliver more detailed suggestions based on our findings. Contact
your Authorized Auralex Dealer for pricing.
ROOM ANALYSIS PRO:
For professional on-site acoustic analysis of your space, we offer the Room Analysis Pro service. Contact your
Authorized Auralex Dealer for pricing.
