Aus Electronics Direct AA6312 User manual

User Manual
5 Port HDR HDMI Audio Extractor
Model No. AA6312

FEATURES OF THE INTERFACE:
Picture 1.0 front panel view
Picture 1.1 rear panel view
Input channel-2 indicator
Input channel-1 indicator
Input Switch Short press) & Automatic switch (Long press)
Audio EDID mode switch
ARC On/Off (Short press)
& Power standby(Long press)
ARC Status indicator
IR receiving window
Input channel-3 indicator
Input channel-4 indicator
Input channel-5 indicator
DC 5V input port
HDMI Input port2
HDMI Input port1
HDMI Input port3
HDMI Input port4
HDMI Input port5
HDMI Output port
3.5mm analog audio output Jack
Optical digital audio output Port

Picture 1.2 IR panel view and function introduction
* Please take out the film at the rear of the remote before you use. Please insert the film to remote rear if
you do not use the remote for long time.
Remote keys Panel keys Functional description
/I
Power standby on/off button
Press the Panel key more than 3
seconds to enter the standby mode
CH1~5
SWITCH
Input source channel selection
AUTO AUTO
Auto switch function enabled or
disabled.
Press the Panel key more than 3
seconds to enable or disable this
function.
∧/∨SWITCH
Loop switch the input channels in
order 1-5
ARC
ARC ARC (Audio Return Channel ) on/off

Connection and operation:
Matters needing attention:
1. Before using ARC, make sure your TV HDMI port supports ARC and the arc have been turned on.
2. When the ARC is enabled, the product extracts audio from the TV HDMI ARC port. Audio signal will
be output from the optical port, while AUX port has no output at this time. When the ARC function is
disabled,the optical and AUX output audio extracted from the HDMI input source.
3. Function description of "Audio EDID mode switch”
By selecting different EDID modes, the audio EDID information of the display device can be changed
to make the signal source output the corresponding audio format.
Audio EDID
mode
Description Suitable
situation
ADV
The audio output format is determined by the EDID
information of the HDMI output connected equipment.
You can get the best sound quality in this mode. But
Optical and AUX ports may not have sound output
because the format is not supported.
Recommended
HDMI output
TV/Display DVD/BD/STB X5
Power
Adaptor
AA6312
HDMI Cable
HDMI Cable
HDMI Cable
HDMI Cable
HDMI Cable
HDMI Cable

2CH All ports priority output the stereo audio in this mode. Recommended
AUX output
5.1CH
Priority output 5.1 channel bit stream in this mode. In this
mode, AUX port may not have sound output because the
format is not supported.
Recommended
Optical output
4. Function description of "Auto switch”
The Switch can support input channel Auto Switch function, it can auto jump to the input channel port
that just have HDMI Cable connected(means have new Signal Source connected); it can also
auto jump to other input channel port that have signal input if the current channel signal source is
closed (Power needs to be cut off for some equipment) or the current input port HDMI cable is taken
out. The Auto function can be turned on/off by the pressing the【AUTO】key at the panel or remote.
When the input channel led indicator flash for one time, the auto switch is turned on; when the input
channel led indicator flash for three times, the auto switch function is closed.

SPECIFICATIONS:
Model No. AA6312
Model name 5 Port HDR HDMI Audio Extractor
Input channel HDMIx5, DCx1
Output channel HDMIx1, Opticalx1, AUXx1
Video format 480P/720P/1080P/2160P@60/50/30/25/24(Support1080P@120)
Supports HDR and Dolby Vision
Deep color 8/10/12Bit@1080P, 8Bit@2160P
Audio format Dolby HD/DTS HD/Dolby Atoms/Dolby AC3/DTS/LPCM etc.
Transmission bandwidth 600MHz Max.
Transmission rate 18Gbps Max.
Input cable length 2160P/AWG 26 ≤5m；1080P/AWG 26 ≤10m
Output cable length 2160P/AWG 26 ≤5m；1080P/AWG 26 ≤12m
Power adapter specification Input: AC 100~240V / Output: DC 5V/1A
Max working current 500mA
Working temperature range -5 ~ +40℃
Working humidity range 5 to 85%RH（No Condensation）
Storage temperature -15 to 55℃
Storage humidity 5 ~95%RH(No Condensation)
Size 159*64*22 (mm)
Weight 230g
Accessories Manual, Power Adaptor, Remote Control
