AEG PERFEKT-GLIDE-30-2 User manual

Notes: AEG reserves the absolute and unrestricted right to change product materials and specifications, at any time, without notice. Warranties: Please see the Use & Care manual or AEG
website for a statement of limited warranty. For more information on our entire line of products, go to www.aeg-appliances.ca or call 905.829.3980. ©AEG. All rights reserved. 1
KEY FEATURES
30” Fully-Integrated Glide-Out Range Hood
RANGE HOOD FUNCTIONS
TECHNICAL DETAILS
Under Cabinet Glide Out
This hood extends to give a greater attachment
and extraction area. When not in use the glide
out filter can be retracted for a flush finish.
LED Lighting
These energy ecient LED lights give you
excellent visibility on the cooking process.
Dishwasher Safe Filters
The long life honeycomb filters can be washed
safely in the dishwasher, making cleaning your
filters simple.
Motor Power: 130W
Volts (V): 120 V
Frequency (Hz): 60 Hz
Amperage (Amp): 15 Amp
*Supplied with a Canadian plug and 1m long cord.
Additional Features
2 Speed Fan Adjustment
Anti-Fingerprint
Stainless Steel
Rocker Switch
Controls
LED
Lighting
PERFEKT-GLIDE-30-2
Width: 2927/32” (758mm)
Height: 35/2” (80mm)
HANDLE REPLACEMENT DIMENSIONS
Under cabinet glide/slide out hood - Powder coating grey
Duct Mode
2 x Speed adjustment
300 CFM / 65 dBa
Rocker switch controls
2 x Rectangle LED lights - Color Temp: 3,200K
2 x Honeycomb filters
2 x Replacement charcoal filters available (CF-D)
AC Capacitor motor
Stainless steel handle - can be replaced with matching cabinetry
DIMENSIONS
Appliance Dimensions (WxHxD)
W: 2927/32“ x H: 85/16” x D: 111/16”
W: 758mm x H: 211mm x D: 281mm
Cut Out Dimensions (WxHxD)
W: 30” x H: 83/8” x D: 12”
W: 762mm x H: 213mm x D: 305mm

Notes: AEG reserves the absolute and unrestricted right to change product materials and specifications, at any time, without notice. Warranties: Please see the Use & Care manual or AEG
website for a statement of limited warranty. For more information on our entire line of products, go to www.aeg-appliances.ca or call 905.829.3980. ©AEG. All rights reserved. 2
Installation Details
PERFEKT-GLIDE-30-2
PRODUCT DIMENSIONS (INCH/MM) CUT-OUT DIMENSIONS (INCH/MM)
Width: 2927/32“ / Height: 85/16” / Depth: 111/16”
Width: 758mm / Height: 211mm / Depth: 281mm
Width: 30” / Height: 83/8” / Depth: min. 12”
Width: 762mm / Height: 213mm / Depth: 305mm
RECOMMENDED CABINET MINIMUM CLEARANCE
HANDLE REPLACEMENT DIMENSIONS
Width: 2927/32” (758mm)
Height: 35/2” (80mm)
For optimal performance, the distance from the cooking surface
to the bottom of the range hood should be between 24” and
30”, unless otherwise noted. DO NOT install a range hood less
than 24” above cooking surface.
*Minimum. 24” clearance space must be present between an
electric or induction cook-top and the range hood, 30” min
clearance is required above gas cook-tops.

871 Cranberry Court Oakville, ON
L6L 6J7 Canada
905 829 3980
1 800 421 6332
[e-mail]
101-1014 Homer Street Vancouver,
BC V6B 2W9 Canada
604 235 3980
1 855 ELA WEST (352 9378)
[e-mail]
Other Product Downloads Available at aeg-appliances.ca
WARRANTY INFORMATION
AEG Appliances are designed and manufactured to the highest standards. Each appliance is
covered by a comprehensive 2-year parts and labour warranty.
Refer to product warranty policy for complete terms and conditions.
FOR PARTS & SERVICE
Euro-Parts & Service
39822 Belgrave Road, Belgrave, ON. N0G 1E0 1 866 722 2262
www.euro-parts.ca • [email protected] • [email protected]
AEG appliances are imported and distributed in North America by Euro-Line Appliances Inc.
For more information, please visit one of our showrooms or www.ela.ca / www.elawest.ca
