Autodesk SIT-STAND STARTER DESK User manual

Ax8
C
5x5
x4
B
1
2
3
C
A
5
4x4
C
2.5x2.5
D
2
3
2
1
3
4
5
6
7
9
8
10
1
C
Ax12 Cx1 E
x1
Bx4 Dx15
F
x4 x1
G
M6 5x5 2.5x2.5
M8 ST4.2
M4
4x4
5x5
4
11
1 2 3
4 5 6
7 8 9
21 1
1
2
1 2
1 1
10 41 1 112 1
13 1
14 1
14
13
2
C
4
B
3
2
12
D
技术参数
70KG
25mm/s
100-240V
710mm
1210mm
1000-1600mm
0~40°C
2
500-800mm
10%(Pause 18 minutes for each continuous
2-minute operation)
Left Leg Right LegFeet
Hex Rod SidebarsMain Support Bar
Baffle Power cableAdapter
Adapter holder HandsetCable tie
Control BoxSwitch cord
Assemble (1)&(2)(3) together, use the 5x5 allen key (C) to tighten
the screws(A).
Install Main Support Bar (4)
Stretch
Loose
Unscrew the screws on support bar (4) with the
4x4 allen key (C), then adjust it (4) as required.
Install support bar (4) on the legs(2)(3), tighten
the screw (B) with the 5x5 allen key (C).
When rotating, do not turn more
than 120 degrees.
Connect hex rod (5) with legs (2)(3), and use the
2.5x2.5 allen key(D) to tighten it.
12
Install feet (1)
SIT-STAND
STARTER DESK
Installation Guide
Attention: The drawings below are for reference purposes only. If you have any issues, please contact our customer
service at [email protected] or watch our installation video on YouTube by scanning the QR Code on the right or following this
link: https://links.anthrodesk.ca/videos/starter-desk.
Installation Instructions
Install Hex Rod (5)

Ax4
C
5x5
6
C
A
3
2
Ex4
D
2.5x2.5
Fx14
D
8
E
4
10
10
10
4
7
11
F
11
4
12
14
C
4x4
C
4
5
G
G
1
10
2
9
711
1
2
12
14
13
STEP6-1
STEP6-2
STEP7
Connect sidebars(6) with legs(2)(3). use the 5x5 allen key(C)
to tighten the screws(A).
Install the power adapterInstall the tabletop, control box
and handset.
Not included
Install the adapter holder (11) to
the main support bar(4)
Attach the tabletop, control box(14) and the
handset(12) with the screws (F), then tighten
them (an electric drill is recommended).
The distance between the
table edge and the sidebar
should stay under 20cm.
The handset should be
installed on the side of the
leg with the motor.
Tighten the support bar and the hex
rod screw
Use the 4x4 allen key (C) to tighten the 4 screws on the
support bar (4), and then tighten the nut on the hex rod
(5) with the wrench (G).
Install baffle and power adaptor
Insert
Install the baffle (8) to the supporting beam (4) using
screws (E), and then tighten it with the 2.5*2.5 allen
key (D).
Connect all cables to the adapter (7)
Peel off Attach
Manage
cables
You can use the included cable
tie (10) to keep the cables tidy
under your desk.
Port for
handset
Switch
Cord Port
Motor
Wire Port
Install Sidebars (6)

Attention
1. Power supply: AC100V-240V,50/60Hz
2. Service Environment: 0-40℃
3. Unplug the power plug before cleaning, wipe the dust on surface with slight wet
dishcloth when cleaning, be careful not to let the drops into the internal parts, not loose
the connector.
4. The electric box contains electronic components, metals, plastics, wires etc., so
dispose of it in accordance with each country's environmental legislation, not the
general household waste.
5. Check carefully to ensure correct and complete assembly before using.
6. Be familiar with all functions and program settings of the product before first use.
7. Children are forbidden to play on the product because of unforeseen action when
playing, so any dangerous consequences caused by this improper action will not be on
manufacturers.
8. Slight noise caused by the V-ribbed belt or brake system due to structure will not
have any effect on the use of the equipment.
9. Corrosive or abrasive materials are forbidden to clean the equipment. Must ensure
that the cleaner used will not pollute the environment.
10. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance.
11. Cleaning and user maintenance shall not be made by children without supervision.
12. If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or a similarly qualified person in order to avoid a hazard.
13. Please make sure there is no hazard sources in your operating environment. e.g.,
do not litter the tools around. Always be careful to treat the packaging materials in order
to avoid any possible danger, e.g. plastic bag may lead to choking hazard to children.
14. Keep the original package of the equipment if necessary in case of the future use in
transportation.
Waste disposal This marking indicates that this product should
not be disposed with other household wastes.
To prevent possible harm to the environment or
human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. To return your used
device, please use the return and collection
systems or contact the retailer where the
product was purchased. They can take this
product for environmental safe recycling.
Troubleshooting
The tips below will help you identify common issues and how to fix them.
If you are facing a different issue, please contact us at
[email protected] or call us at 1-800-267-1783.
Error Method
No response when pressing a button
The desk is moving in the opposite
direction of the control pressed.
Slow movement up or down
The desk moving downwards
without any operation
The desk turns on and off on its own
Desk overloaded
Can’t reach the min or max height
Check if all the cables are well connected.
Reset the desk.
Check if overloaded, weight capacity: 70kg.
Check if overloaded, weight capacity: 70kg.
Check whether the power wire is connected
properly.
Suspend operation for at least 18 minutes
and then try again.
Reset the desk
Reset Instructions
a. If the desk is at its lowest position, long press the "▼" button
for 5 seconds to enter reset mode. The reset will be
completed when the desk reaches the bottom and "rebounds"
to stop.
b. If there is an error with your desk, release all buttons and then
hold the "▼" button. The reset will be completed when the
desk reaches the button and then "rebounds" to stop.
