Lily Ann Cabinets T-504-01 User manual

Installation Instructions
http://www.lilyanncabinets.com/
T-504-01 (Beige)
.63”
(16mm)
20.157”
(512mm)
1/2”
12mm
min:
1
2
Place on cabinet bottom
install pilasters directly
against faceframe for
cabinets assembled
with the dovetail
construction.
For cabinets assembled
with metal clips,
pilasters must be
placed ½” behind face
frame
Position front pilasters
For Metal Clip
Assembled
Cabinets
For Dovetail
Construction
Cabinets
Cabinet sides
must be min. ½”
(12.7mm) thick
T-504-01
(Beige)
.63”
(16mm)
x4
3
HAR-020

5
6
7
90°
4b
4c
4a
HAR-111
HAR-112
T-506
Locate the first and last
holes for mounting the Hook
Dowels and Spacers.
Attach T-506 Hook Dowel with
hook pointing up, with Spacer.
Left and right
sides will be
opposite.
Remove the drawer member
from the slide.
Use Pilaster to
help straighten
and tighten
Hook Dowels.
Insert Hook Dowels into front and Rear Pilaster.
Using both slides, the Rear Pilaster can be
attached. This will align the slides to the cabinet.
Repeat for other side
of the cabinet
Attach slide
drawer members
to drawers
Flush to the bottom
and the front
Adjust slides to
desired heights
and push
drawers into
place.
4
