Autojack PTC4D Installation manual

PTC4D
Portable Tool Cabinet with 4 drawers
PTC4D
ORIGINAL INSTRUCTIONS
SAFETY AND OPERATING MANUAL

PTC4D
TABLE OF CONTENTS
Welcome to Autojack!
Dear Customer, Congratulations on your purchase. Before using the
product for the first time please be sure to read these instructions for use.
They provide you with all information necessary for using the product safely and to
ensure its long service life.
Closely observe all safety information in these instructions!
Safety Instructions…………………………..………………………………….….....01
Machine details………………………….……………………………………….………02
Assembly……….…………………………………………………….………………….….03
Cleaning and Disposal of waste equipment……………..…………………..04
Autojack Guarantee……………………………………..……………………………..05

PTC4D
01
When using the equipment, a few safety
precautions must be observed to avoid injuries
and damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage or
accidents which arise due to a failure to follow
these instructions and the safety instructions.
General Safety regulations
Read all safety regulations and instructions. Any
errors made in following the safety regulations
and instructions may result in an electric shock,
fire and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
Additional safety instructions:
•When loading and unloading the drawers,
ensure that the tool trolley and the drawers are
evenly loaded.
•Apply the break when loading and unloading.
•On slopes or uneven floors make sure that the
tool trolley does not topple.
•When moving the trolley on slopes, hold it by
the handle.
•Make sure that the maximum total load is not
exceeded. (165 lbs/75 kg) Do not overload the
drawers of the tool trolley.
•After transportation and/or assembly make sure
that all drawer compartments are completely
closed.
•For safety reasons the tool trolley is equipped
with pull-out stops for the drawers. This prevents
several drawers being opened at the same time.
•The tool trolley is very heavy when fully loaded.
Improper opening can lead to tipping. Never open
multiple drawers at the same time.
•Always push the tool trolley to avoid injury!
•Check for damage before use! Use the tool
trolley only if it is in a faultless and safe
operational condition.
•Any changes, modifications or additions to the
trolley are prohibited.
•Any use of accessories or spare parts which are
not expressly recommended by the manufacturer
can result in injury or damage.
•Use only genuine accessories and spare parts.
•The tool trolley is not a toy! Do not climb or
stand on.
•Store it in a location which is not accessible to
children. The ideal storage temperature is
between 10 and 30°C.
•If safe operation is no longer possible,
decommission the product and protect it from
accidental use. Safe operation is no longer
guaranteed if the product:
- has visible damage,
- no longer working properly,
- has been stored for an extended period under
unfavourable environmental conditions,
- was exposed to considerable transport loads.
•Have maintenance, adjustment and repair work
carried out exclusively by a specialist or a specialist
workshop.
Safety Instructions

PTC4D
02
MACHINE DETAILS
Machine Details
Specifications:
Max. Load capacity –75kg
Dimensions –616x330x760mm
Net Weight –approx. 17.8Kg
Package Contents:
•Tool trolley
•Handle
•4 screws
•2 wheels with brake
•2 wheels without brake
•Manual
Also recommended accessory our NSL450
Non Slip draw liner.
Intended Use
• The tool trolley is designed for mobile
storage of tools and small parts. It can be used
indoors on a variety of (firm and flat) floor
coverings.
• The equipment is to be used only for its
described purpose. Any other use is deemed
to be a case of misuse. The user/operator and
not the manufacturer will be liable for any
damage or injuries of any kind caused as a
result of this.
1. Tool trolley
2. Wheels
3. Handle
NOTE: Load capacity of the
support area per drawer.

PTC4D
03
Assembly
Assembly
• Open the packaging and take out the
equipment with care.
•Remove the packaging material and any
packaging and/or transportation braces
(if available).
• Check to see if all items are supplied.
•Inspect the equipment and accessories
for transport damage.
• If possible, please keep the packaging
until the end of the guarantee period.
Important! To avoid malfunctions,
please note that all the drawers must be
completely closed before you pull one
out!
Fitting the handle
–Fit the handle (3) with the screws (a) as
shown in Fig. 2.
Fitting the wheels
–Fit the wheels (2) as shown in Fig. 3.
Before starting the equipment
–Unlock the drawers by pushing down the
locking switch (4) located in the bottom
drawer. (Fig. 4-5)

PTC4D
04
Cleaning and Disposal of waste equipment
Cleaning
–Clean the tool trolley with a slightly
damp cloth and if necessary a small
amount of conventional paint cleaner. To
avoid damaging the surfaces do not use
solvents or other aggressive or scouring
cleaning products.
Disposal of waste equipment
–Equipment must be disposed of in
accordance with the rules and regulations
of the local waste disposal.
Use the provided for the disposal of
electrical equipment collection points and
enter your electrical and electronic
equipment that you no longer use. They
help ensure that the potential effects of
incorrect disposal on the environment and
human health to be avoided. So do your
part to recycle, recycling and other forms
of recovery of waste electrical and
electronic equipment. Information on
where the devices are disposed of, please
contact your local authorities or local
Governments.
Meaning of the "dustbin"
Protect our environment;
electrical appliances do
not belong in household
waste.

PTC4D
05
AUTOJACK GUARANTEE
1. Guarantee
1.1 Autojack guarantees that for a period of 12
months from the date of purchase the
components of qualifying products (see clauses
1.2.1 to 1.2.8) will be free from defects caused
by faulty construction or manufacture
1.2 During this period, Autojack, will repair or
replace free of charge any parts which are
proved to be faulty in accordance with
paragraph 1.1 providing that:
1.2.1 You follow the claims procedure set out in
clause 2.
1.2.2 Autojack and its Authorised Dealers are
given reasonable opportunity after receiving
notice of the claim to examine the product.
1.2.3 If asked to do so by Autojack or its
Authorised Dealer, you return the product at
your own cost to Autojack’s or the supplying
Authorised Dealer’s Premises, For the
examination to take place clearly stating the
Returns Material Authorisation Number given by
Autojack or an Authorised Dealer.
1.2.4 The fault in question is not caused by
industrial use, accidental damage, fair wear and
tear, wilful damage, neglect, incorrect electrical
connection, misuse, alteration or repair of the
product without approval.
1.2.5 The product has been used in a domestic
environment only.
1.2.6 The fault does not relate to consumable
items such as blades, bearings, drive belts or other
wearing parts which can reasonably be expected
to wear at different rates depending on usage.
1.2.7 The product has not been used for hire
purposes.
1.2.8 The product has been purchased by you, as
the guarantee is not transferable from a private
sale.
2. Claims Procedure
2.1 In the first instance please contact the
Authorised Dealer who supplied the product to
you. In our experience many initial problems with
machines that are thought to be fault due to faulty
parts are actually solved by correct setting up or
adjustment of the machine. A good Authorised
Dealer should be able to resolve the majority of
these issues much more quickly than processing a
claim under the guarantee. If a return is requested
by the Authorised Dealer or Autojack, you will be
provided with a Returns Material Authorisation
Number which must be clearly stated on the
returned package, and any accompanying
correspondence. Failure to provide a Returns
Material Authorisation Number may result in item
being refused delivery.

PTC4D
06
AUTOJACK GUARANTEE
2.2 Any issues with the product resulting in a
potential claim under the guarantee must be
reported to the Authorised Dealer from which it
was purchased within 48 hours of receipt.
2.3 If the authorised Dealer who supplied the
product to you has been unable to satisfy your
query, any claims made under this guarantee
should be made directly to Autojack. The claim
itself should be made in a letter setting out the
date and place of purchase, giving a brief
explanation of the problem which has led to the
claim. This letter should be then sent with proof
of purchase to Autojack. If you include a contact
number with this it will speed your claim up.
2.4 Please note that it is essential that the letter
of claim reaches Autojack on the last day of this
guarantee at the latest. Late claims will not be
considered.
3. Limitation of Liability.
3.1 We only supply products for domestic and
private use. You agree not to use the product for
any commercial, business or resale purposes and
we have no liability to you for any loss of profit,
loss of business, business interruption or loss of
business opportunity.
3.2 This guarantee does not confer any rights
other than these expressly set out above and does
not cover any claims for consequential loss or
damage. This guarantee is offered as an extra
benefit and does not affect your statutory rights as
a consumer.
4. Notice
This guarantee applies to all product purchased
from an Authorised Dealer of Autojack within the
United Kingdom. Terms of guarantee may vary in
other countries.
