Autojack PEGGY Installation manual

PEGGY
20 Litre Wet & Dry Vacuum Cleaner
PEGGY
ORIGINAL INSTRUCTIONS
SAFETY AND OPERATING MANUAL

PEGGY
TABLE OF CONTENTS
Welcome to Autojack!
Dear customer, Congratulations on your purchase. Before using the
product for the first time please be sure to read these instructions for use.
They provide you with all information necessary for using the product safely and to
ensure its long service life.
Closely observe all safety information in these instructions!
General Power Tool Safety Warnings………………………………….……....01
Symbols & Cable Rating Chart ……….…………………………………….………04
Machine Details and Product features……….…………………………….….05
Assembly……………………………………………………………………………………..06
Operation……………………………………….…………………………………………..08
Maintenance and Service…………………………………………………………..09
Autojack Guarantee…………………………………………………………………….10
Declaration of conformity……………………………………………………………12
Parts list……………………………………………………………………………………...13
Parts Diagram………………………………………………………………………………14

PEGGY 01
WARNING Read all safety warnings and
all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for
future reference. The term "power tool" in
the warnings refers to your electric (corded)
power tool or battery-operated (cordless) power
tool.
1. Work area safety
a)Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with grounded power tools.
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with grounded surfaces,
such as pipes, radiators, ranges and
refrigerators.There is an increased risk of electric
shock if your body is grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off position before connecting to
power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
GENERAL POWER TOOL SAFETY WARNINGS

PEGGY 02
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving
parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused
by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions, taking
into account the working conditions and the work
to be performed. Use of the power tool for
operations different from those intended could
result in a hazardous situation.
5. Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
b) If the replacement of the supply cord is
necessary, this has to be done by the
manufacturer or its agent in order to avoid a
safety hazard.
GENERAL POWER TOOL SAFETY WARNINGS

PEGGY 03
6. Additional Safety Instructions for
Vacuum Cleaner
a) Pull the mains plug out of the socket when:
the unit is not in use, before opening the unit,
before cleaning and maintenance
b) Never clean with solvents.
c) Do not use the cable to pull the plug out of
the socket.
d) When unit is ready for use, do not leave
unattended.
e)Care must be taken that the mains
connection lead is not damaged by being driven
over, crushed, stretched, etc.
f)The unit must not be operated if the mains
connection lead is not in perfect condition
g)If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent to a similarly qualified person in order to
avoid a hazard.
h)On no account vacuum: burning matches,
glowing ashes and cigarette ends, inflammable,
corrosive, fire hazard or explosive substances,
vapours and liquids
i)This unit is not suitable for vacuuming dust
which is damaging to health
j)Store the unit in a dry place
k)Do not operate a defection unit
l)Servicing only by an authorized after-sales
service point
m)Use only for operations for which the unit is
intended
n)This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
o)Children should be supervised to ensure that
they do not play with the appliance.
p)IPX4 is only granted by connect an IPX4 plug to
socket-out of the appliance or the cover of the
socket-out is closed.
7. Using an Extension Cable.
a) If an extension cable is required, use an
approved triple core extension cable suitable for
the power input of the tool.
b) Grounded tools always require a three wire
extension cable.
c) As the distance from the supply outlet
increases you must use a heavier gauge extension
cable. Using extension cables with inadequately
sized wire causes a serious drop in voltage,
resulting in loss of power and possible tool
damage.
d) The smaller the gauge numbers of the wire the
greater the capacity of the cord.
e) When using a cable reel, always unwind the
cable completely.
GENERAL POWER TOOL SAFETY WARNINGS

PEGGY 04
SYMBOLS AND POWER RATING CHART
Danger! – Read the operating
instructions to reduce the risk of
injury.
Caution! Wear safety goggles.
Caution! Wear ear defenders. The
impact of noise can cause damage
to hearing.
Amperes 7.5M 15M 25M 30M 45M 60M
0 – 2.0 6 6 6 6 6 6
2.1 – 3.4 6 6 6 6 6 6
3.5 - 5.0 6 6 6 6 10 15
5.1 – 7.1 10 10 10 10 15 15
7.1 – 12.0 15 15 15 15 20 20
12.1 – 20.0 20 20 20 20 25 -
Caution! Risk of Injury! Do
not reach into the running
saw blade.
Caution! Wear a dust mask.

PEGGY 05
MACHINE DETAILS AND PRODUCT FEATURES
Machine Details
Specifications:
Mains Voltage - 230V / 50Hz
Power- 1200W
Vacuum degree – ≥17Kpa
Capacity – 20Litre
Package Contents:
Vacuum cleaner
1.5m hose
1 piece metal telescopic tube
Wide floor nozzle
Wet filter
Dust paper bag
Crevice nozzle
Sofa brush
Intended Use
Designed to generate vacuum cleaner
Using equipment in ways other than its
intended use the user and not the
manufacture will be liable for any damage or
injuries caused.
Also note that this equipment is not designed
for commercial or industrial use. Warranty will
be voided if used for these purposes.
1. Handle
2. ON/OFF Switch
3. Top section
4. Filter basket
5. Safety float valve
6. Clasp
7. Container
8. Vacuum hose connection
9. Idler wheel
10. Flexible vacuum hose
11. Vacuum tube
12. Air inlet
13. Large vacuum nozzle
14. Dust bag
15. Wet filter
16. Crevice nozzle
17. HEPA filter
Pedal brush
HEPA filter
18
19
18. Pedal brush
19. Sofa brush

PEGGY 06
ASSEMBLY
Assembling the castors
1. Turn the container upside down.
2. Insert the castor assemblies into the base of
the tank.
Fitting the motor
1. When fitting the motor to the tank,
position it so that the motor securing
clips on the tank align with the fastening
points on the motor.
2. Fasten the motor securing clips to the motor,
making sure that they lock into place correctly.
3. To remove the motor, open the motor
securing clip and lift the motor out of the tank.
Fitting the handle
1. Align the holes on either side of the handle
with the holes in the top side of the motor.
2. Insert two screws into the handle and
tighten with a screwdriver.
Fitting the dust bag
1.For vacuuming fine, dry dirt it is recommended
that you fit the dust bag. The dust bag is suitable
for dry vacuuming only. Using the dust bag makes
it easier to dispose of the dust that has been
collected.
3. To attach, slip the dust bag over the vacuum
inlet.

PEGGY 07
ASSEMBLY
Fitting the filter
IMPORTANT! Never use the wet and dry vacuum
cleaner without a filter! Always ensure that the filters
are perfectly secure!
Fitting the foam filter -vacuuming liquid
For wet-vacuuming, slip the supplied foam filter over
the filter basket.
NOTE: Do not use the HEPA filter and/or dust bag
when vacuuming liquid.
Fitting the HEPA Filter-vacuuming dry
matter
For dry vacuum cleaning always use the filter bag.
Mount the filter bag, so that no air is sucked through
the filter cage without being filtered.
NOTE: Do not use the foam filter when vacuuming
dry matter.
Fitting hose & nozzles
Connect the suction hose to the corresponding
connector on the wet and dry vacuum, depending
on the application required:
Vacuuming
Connect the suction hose to the vacuum inlet
Blowing
Connect the suction hose tothe blow outlet.

PEGGY 08
ASSEMBLY& OPERATION
Extension Tube and Adaptor
1. The suction hose can be extended by
attaching one or more sections of the 3 part
extension tubes.
2. The adapter must be inserted between
the extension tube and whichever of the
nozzles is required.
Suction Tools
Floor Tool
The floor tool is for vacuuming solids and liquids
over medium to large areas.
Crevice Tool
The crevice tool is designed for cleaning crevices
and edges.
Operation
This vacuum must be used with a residual current
device with a rated residual current of 30mA or
less.
IMPORTANT! Switch off the equipment if liquid or
foam is emitted with the exhaust air when wet
vacuum cleaning.
On/Off Switch
Switch position 0: OFF
Switch position I: ON
Dry Vacuuming
Use the dust bag and the filter bag for dry vacuuming.
Check that the filter is securely fitted at all times.
Wet Vacuuming
For wet-vacuuming, use the foam filter
Check that the filter is securely fitted at all times.
NOTE: The tank will collect 12 Litre max of fluid
and the float switch will turn off the vac.
IMPORTANT!When wet vacuuming, the safety float
turns off the wet and dry vacuum cleaner
automatically when the maximum level is reached.
IMPORTANT! The wet and dry vacuum cleaner is
not suitable for the vacuuming of combustible
liquids.

PEGGY 09
OPERATION&MAINTENANCE AND SERVICE
Blowing
Connect the suction hose to the blow outlet on
the wet and dry vacuum cleaner
Cleaning & Storing
IMPORTANT! Before cleaning your wet & dry vac
or carrying out any maintenance procedure, make
sure that the motor is off and the vac
disconnected from the power supply to prevent
accidental starting.
Cleaning
- Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
We recommend that you clean the equipment
immediately after you use it.
Cleaning the motor housing
- Clean the appliance regularly with a damp cloth
and some soft soap. Do not use cleaning agents or
solvents; these may be aggressive to the plastic
parts in the appliance.
Cleaning the tank
- The tank can be cleaned with a damp cloth and
some soft soap or under running water, depending
on the amount of dirt.
Cleaning the foam filter
- Clean the foam filter with a little soft soap under
running water and allowit to air-dry.
Storing
- Ensure the Wet & Dry Vac has been fully emptied
of any dry matter or liquid before it is stored.
- Wrap the power cable around the cable hooks.
- Keep all the accessories with the unit to avoid
losing them.
- Keep in a dry place out of reach of children.

PEGGY 10
AUTOJACK GUARANTEE
1.Guarantee
1.1 Autojack guarantees that for a period of 12
months from the date of purchase the
components of qualifying products (see clauses
1.2.1 to 1.2.8) will be free from defects caused
by faulty construction or manufacture
1.2 During this period, Autojack, will repair or
replace free of charge any parts which are
proved to be faulty in accordance with
paragraph 1.1 providing that:
1.2.1 You follow the claims procedure set out in
clause 2.
1.2.2 Autojack and its Authorised Dealers are
given reasonable opportunity after receiving
notice of the claim to examine the product.
1.2.3 If asked to do so by Autojack or its
Authorised Dealer, you return the product at
your own cost to Autojack’s or the supplying
Authorised Dealer’s Premises, For the
examination to take place clearly stating the
Returns Material Authorisation Number given by
Autojack or an Authorised Dealer.
1.2.4 The fault in question is not caused by
industrial use, accidental damage, fair wear and
tear, wilful damage,neglect, incorrect electrical
connection, misuse, alteration or repair of the
product without approval.
1.2.5 The product has been used in a domestic
environment only.
1.2.6 The fault does not relate to consumable
items such as blades, bearings, drive belts or other
wearing parts which can reasonably be expected
to wear at different rates depending on usage.
1.2.7 The product has not been used for hire
purposes.
1.2.8 The product has been purchased by you, as
the guarantee is not transferable from a private
sale.
2. Claims Procedure
2.1 In the first instance please contact the
Authorised Dealer who supplied the product to
you. In our experience many initial problems with
machines that are thought to be fault due to faulty
parts are actually solved by correct setting up or
adjustment of the machine. A good Authorised
Dealer should be able to resolve the majority of
these issues much more quickly than processing a
claim under the guarantee. If a return is requested
by the Authorised Dealer or Autojack, you will be
provided with a Returns Material Authorisation
Number which must be clearly stated on the
returned package, and any accompanying
correspondence. Failure to provide a Returns
Material Authorisation Number may result in item
being refused delivery.

PEGGY 11
AUTOJACK GUARANTEE
2.2 Any issues with the product resulting in a
potential claim under the guarantee must be
reported to the Authorised Dealer from which it
was purchased within 48 hours of receipt.
2.3 If the authorised Dealer who supplied the
product to you has been unable to satisfy your
query, any claims made under this guarantee
should be made directly to Autojack. The claim
itself should be made in a letter setting out the
date and place of purchase, giving a brief
explanation of the problem which has led to the
claim. This letter should be then sent with proof
of purchase to Autojack. If you include a contact
number with this it will speed your claim up.
2.4 Please note that it is essential that the letter
of claim reaches Autojack on the last day of this
guarantee at the latest. Late claims will not be
considered.
3. Limitation of Liability.
3.1 We only supply products for domestic and
private use. You agree not to use the product for
any commercial, business or resale purposes and
we have no liability to you for any loss of profit,
loss of business, business interruption or loss of
business opportunity.
3.2 This guarantee does not confer any rights
other than these expressly set out above and does
not cover any claims for consequential loss or
damage. This guarantee is offered as an extra
benefit and does not affect your statutory rights as
a consumer.
4. Notice
This guarantee applies to all product purchased
from an Authorised Dealer of Autojack within the
United Kingdom. Terms of guarantee may vary in
other countries.

PEGGY 12
CE DECLARATION OF CONFORMITY
TOOLSAVE
Unit C, Manders Ind. Est.,
Old Heath Road, Wolverhampton,
WV1 2RP.
Tel: [phone]
Declares that the VACUUM CLEANER, (PEGGY)
Is in compliance with the regulations included in the Directives:2014/35/EU
EC DECLARATION OF CONFORMITY
Certificate for EC-type examination delivered by Interk Testing Services Hangzhou 16
No. 1 Ave., Xiasha Economic Development District, Hangzhou 310018, China
(Verification No.:160400930HZH-V1 )
Person who declares: Bill Evans
01.04.2018
The Director

PEGGY 13
No.
Description
No.
Description
1 Hand bar screw 4*14 21 308 Clamps
2
308 Hand bar
22
308 Clamps base
3 Switch(2P) 23
308 Clamps handle
4
Label
24
Clamps screw 4*14
5
308 Top cover
25
308 Air-inlet sets sealing ring
6 308 Motor cover 26
308 Air-inlet sets
7
Top cover screw 4*14
27
Air-inlet sets screw 4*16
8 Cable press board + screw 28
Tank
9 Cable 29
308 Bottom base
10
Bottom cover
30
308 Caster
11 Top sealing ring of motor 31
Wheels
12 A24 Motor 32
Caster screw 4*14
13
Bottom sealing ring of motor
33
308 Hose sets
14 Motor noise reduction sponge 34
Static chain
15
Bottom frame for motor
35
φ32 Crevice tool
16
203 Safety valve
36
Floor brush
17 308 Bottom cover basket 37
Dust bag
18
Bottom cover basket screw
4*20
38
Manual
19
Foam filter
39
Metal telescopic tube
20
HEPA filter
Parts List

PEGGY 14
Parts Diagram
