AutomationDirect Productivity Open P1AM-200 User manual

USB Micro Interface
- Programming
- Online monitoring
Toggle switch
- Connected to
SWITCH_BUILTIN or Digital
Pin 31(Arduino),
board.SWITCH (CircuitPython)
CPU Status Indicators
- PWR LED indicates
power applied
- BASE LED indicates when
base controller is powered
and initialized
- LED connected to LED_BUILTIN
or Digital Pin 32 (Arduino),
board.LED (CircuitPython)
microSD Port
- removable flash memory
Arduino MKR shields &
Productivity Open shields
Additional Features
- ATECC608A Crypto
co-processor
- 2kb EEPROM with
unique MAC address
- 16MB QSPI Flash
- Supercap backed RTC
External Power
- 24VDC on bottom
connector
RESET Button
- Press once to manually
reset code execution,the Base
Controller, and all P1000
Series modules.
-Press twice quickly to put the
P1AM CPU into bootloader
mode.
Neopixel Compatible
Single-wire LED
- Connected to
NEOPIXEL_PIN or Digital
Pin 49 (Arduino),
board.NEOPIXEL (CircuitPython)
P1000 I/O Modules
P1AM-200 Arduino®MKR
Compatible CPU
The P1AM-200 is an Arduino-compatible CPU. It uses
the Atmel SAMD51P20 and can be programmed in
C++ using the Arduino IDE or in CircuitPython using
any text editor. It interfaces with all P1000 Series
I/O modules connected to the right side and most
Arduino MKR form factor shields connected to the
left side.
General Specifications
Operating Temperature 0° to 60°C (32° to 140°F)
Storage Temperature -20° to 70°C (-4° to 158°F)
Humidity 5 to 95% (non-condensing)
Environmental Air No corrosive gases permitted
Vibration IEC60068-2-6 (Test Fc)
Shock IEC60068-2-27 (Test Ea)
Heat Dissipation 4W
Enclosure Type Open Equipment
Module Location
Productivity1000 I/O modules connect on the right
side of module. Power supply, P1AM Shields and MKR
Shields connect on the left side on the module.
Number of Supported
Modules 8
Weight 82g (2.89 oz)
Agency Approvals
UL 61010-1 and UL 61010-2-201 File E139594, Canada
& USA
CE*
*See CE Declaration of Conformance for details.
Link to GitHub
Link to full additional resources

Document Name Edition/Revision Date
P1AM-200-DS 1st Edition 9/8/2023
Copyright 2023, AutomationDirect.com Incorporated/All Rights
Reserved Worldwide
Module Installation
Module Installation
WARNING: Do not add or remove modules with field power applied.
Step One: With latch
in “locked” position, align
connectors on the side of
each module and stack
by pressing together.
Click indicates lock is
engaged.
Step Three: To unstack modules, pull
locking latch up into the unlocked position
and then pull modules apart.
Step Two: Attach field wiring using
the removable terminal block or ZIPLink
wiring system.
LLOOCCKK
UUNNLLOOCCKK
Check all latches are
secure after modules
are connected.
WIRE STRIP
LENGTH
MIN
MAX
M
WARNING: To minimize the risk of potential safety problems, you should
follow all applicable local and national codes that regulate the installation
and operation of your equipment. These codes vary from area to area and
it is your responsibility to determine which codes should be followed, and
to verify that the equipment, installation, and operation are in compliance
with the latest revision of these codes.
Equipment damage or serious injury to personnel can result from
the failure to follow all applicable codes and standards. We do not
guarantee the products described in this publication are suitable for
your particular application, nor do we assume any responsibility for your
product design, installation, or operation.
This device is not intended for personnel, product, or machine
safety applications.
This publication is based on information that was available at the time
it was printed. At AutomationDirect.com®we constantly strive to improve
our products and services, so we reserve the right to make changes to
the products and/or publications at any time without notice and without
any obligation. This publication may also discuss features that may not be
available in certain revisions of the product.
Power Requirements
Base Controller and I/O
Power Requirement¹
24VDC ±2% 1.25 W per I/O module
@ 0.5 W for SAMD and Base Controller
@ 9W for max header power draw²
Recommended Fuse
(External) Edison S506-R, Time Delay, 1A Fuse
1. If you do not use a Productivity1000 power supply, like the P1-01AC, then use a power supply
that has a transformer isolation. Use different 24VDC supplies for the CPU and inductive loads to
keep the CPU power clean and free of voltage spikes caused by switching solenoids, motors and
relay coils.
2. See Header Power Limitations in P1AM User Manual in QR code link to additional resources.
