ENERMAX LIQTECH TR4 Series User manual

ELC-LTTR280-TBPELC-LTTR240-TBP ELC-LTTR360-TBP
Incredible 500W+ TDP Over-clocking Support.
ENERMAX LIQTECH TR4
features 100% IHS Coverage
for AMD Threadripper CPU

ENERMAX LIQTECH TR4 is custom-designed exclusively for the top-end enthusiast AMD Threadripper CPUs. The
LIQTECH TR4’s base plate can neatly cover the entire Threadripper’s IHS (Integrated Heat Spreader) to deliver
uncompromised cooling performance. LIQTECH TR4 lineup offers unbeatable 500W+ cooling capacity; this liquid
cooling innovation is surely a perfect choice for high-end, overclocked CPUs. The series is available in 3 radiator
sizes: 360, 280, and 240mm.
Let's take a look at the installation process for an AMD Threadripper processor and ENERMAX LIQTECH TR4 cooler.
Step 1. Install Your AMD Ryzen Threadripper CPU:
1-1. The first step is to locate the 3 screws on the CPU socket and loosen them in sequence of
3→2→1, which is printed on the socket.

1-2. Release the CPU rail frame by pulling up on the blue tabs and take out the internal plastic cover.
1-3. Install your Threadripper CPU with the orange carrier frame and align it with the rail frame. Make
sure you slide the CPU all the way in until it clicks into place. Lower the rail frame back down and
close the retention cover. Tighten the screws in order of 3→2→1.

Step 2. Tighten the AMD sTR4 screws to the motherboard.
Step 3. Apply the thermal grease evenly on the CPU surface.
Step 4. Remove the protect film from the cold-plate.

Step 5. Place the pump on the CPU and tighten the springs until all four corners are secured.
Availability:
LIQTECH TR4 is now available on the market with 3 sizes: 360, 280 and 240. For installation demo video or more
product information, please visit our website: https://goo.gl/D8n7JT.
About ENERMAX
ENERMAX Technology Corporation is a world-renowned PC Power Supply Unit manufacturer and maker of peripherals such as chassis, coolers, fans, and
storage solutions, all with excellent quality, having won recognition from consumers around the world. Our farsighted R&D capability is our key strength and we
stick to our spirit of “Technical Innovation” and “Quality First” to create products which transcend international standards. Visit us at www.ENERMAX.com
©2017 ENERMAX TECHNOLOGY CORPORATION. All rights reserved. Specifications are subject to change without notice. Content of delivery might differ in
different areas or from illustrations. Some trademarks may be claimed as the property of others.
Step 6. Connect the fan connectors through Y cable and pump power connector to the motherboard.
