AUVIO Docking Speaker System User manual

THE PERFORMANCE YOU NEED
®
®
Docking Speaker System
for iPod®/iPhone®
User’s Guide 4000040
Please read this user’s guide before using your new
docking speaker.

2
2
Package contents
Docking Speaker System for iPod/iPhone
AC Adapter
Remote Control with Battery
User’s Guide
Features
Charges your iPod and iPhone
Compatible models: iPod nano 4G/5G/6G, iPod
touch 2G/3G/4G, iPod classic; iPhone 3G/3GS/4
Connect the AC Adapter
Prepare the Remote
Control
Your remote control comes with a
battery already installed. Pull the plastic
tab out of the battery compartment to
begin using the remote.
DC IN 10.5V

3
3

Decrease volume.

Increase volume.
1
Turns docking
speaker on/off.
iPod/iPhone
Dock Adapter
Remote Sensor

Skip to
previous track.
Rewind
through tracks.
Dock your iPod/iPhone

Skip to next track.
Fast forward
through tracks.
Play/Pause §
nNote: The feet of the docking speaker may leave marks
on some materials. To prevent this, use a pad (not included).

4
4
Use the Remote Control
After docking your iPod/iPhone, you can only adjust volume
from your docking speaker or remote control. When you
adjust bass and treble settings, the speaker’s 1button
flashes (unless you have reached maximum or minimum
bass/treble setting).
/ 
Adjust volume
up/down.
1
Turns docking
speaker on/off.
UP
Scroll up in
menu list.
DOWN
Scroll down in
menu list.
+ BASE – /
+ TREBLE –
Adjust bass/treble
level.
By Pass
Reset bass/treble
to the speaker’s
default settings.
MUTE
Turn sound on/off.
Play/Pause §
ENTER
Confirm a selection.
MENU
Open a menu or
return to previous
menu.
Skip to previous
track.
Rewind through
tracks.
Skip to next track.
Fast forward
through tracks.
(Shuffle)
Play tracks or albums
randomly.
(Repeat)
Repeat one track, all
tracks in the album.

5
5
Replacing Remote Battery
1. While pressing the tab on the
battery compartment tray,
pull to slide the tray out.
2. Insert a Lithium CR2025, 3V
button cell battery, with the
positive (+) side facing the
remote’s back.
nBattery Notes:
Keep button-cell batteries away from children.
Swallowing a button-cell battery can be fatal.
If the control range decreases or your remote
control stops working, replace the battery.
Do not burn or bury batteries. Do not puncture or
crush. Do not disassemble.
Use only fresh batteries of the required size and
type.
Recycle lithium batteries. Do not dispose of in the
trash.
If you do not plan to use the remote for a long time,
remove the battery. Batteries can leak chemicals
that can damage electronic parts.
Never allow loose cells to short circuit against
battery tabs or other conductive items. Keep loose
cells and battery packs out of reach of children.
If the electrolyte in the cells should get on your
skin, thoroughly wash with soap and water. If in the
eyes, rinse thoroughly with cool water. Immediately
seek medical attention.
Press
tab

6
6
Connect to Other Audio Device
Use a 3.5mm audio patch cable (not included) to
connect an audio device to your docking speaker’s
AUDIO IN jack.
n Note: To use an audio device, remove your iPod/
iPhone docked to the speaker. If you use an audio cable
to connect your iPod/iPhone to the speaker, some
remote functions will be disabled.
Specifications
Output ................................................................... 12W × 2 RMS
Driver Size........................................................................ 2.5’’ × 2
Signal to Noise Ratio ....................................................... > 65dB
Frequency Response .............................................110Hz~20KHz
Rated Load Impedance ..................................................... 4 Ohm
Power Rating ...........................................100-240V, 50/60Hz, 1A
Power Supply............................................................DC 10.5V 3A
Dimension(HWD) ......... 4.5 × 12.5 × 3.7 in (115 × 318 × 95 mm)
Net Weight ............................................................ 2.4 lbs (1.1 kg)
Specifications are subject to change and improvement without notice.
Actual product may vary from the images found in this document.
AUDIO IN

7
7
Troubleshooting
Symptom Possible Cause Solution
Distorted or
weak sound
Volume too high Decrease volume.
Sound source
distorted.
Poor quality audio source. Try
a better quality digital audio
recording.
No sound
iPod/iPhone
not installed
properly
Make sure your iPod/
iPhone is well docked.
Unplug the AC adapter and
plug it again.
Volume too low Adjust volume to a proper
level.
iPod/iPhone not
playing Start your iPod/iPhone to play.
iPod/iPhone
software
compatibility
problem
Make sure you are using the
most current Apple software.
For help, visit Apple website.
Remote
control not
functioning
properly
Interference or
remote sensor
blocked
Point the remote at the
speaker’s remote sensor.
Remove obstacles
between the remote and
speaker.
Battery not
correctly
installed
Make sure the battery is
installed with + side facing the
remote’s back.
Battery power
low Replace the battery.
No
Response Malfunction
Unplug the AC adapter and
plug it again after one minute
to reset the docking speaker.

8
8
FCC Information
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by Ignition L.P.
may cause interference and void the user’s authority to operate the
equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Limited Warranty
Ignition L.P. warrants this product against defects in materials and
workmanship under normal use by the original purchaser for ninety
(90) days after the date of purchase. IGNITION L.P. MAKES NO
OTHER EXPRESS WARRANTIES.
This warranty does not cover: (a) damage or failure caused by or
attributable to abuse, misuse, failure to follow instructions, improper
installation or maintenance, alteration, accident, Acts of God (such
as floods or lightning), or excess voltage or current; (b) improper or
incorrectly performed repairs by persons who are not a Ignition L.P.
Authorized Service Facility; (c) consumables such as fuses or batteries;
(d) ordinary wear and tear or cosmetic damage; (e) transportation,
shipping or insurance costs; (f) costs of product removal, installation,
set-up service, adjustment or reinstallation; and (g) claims by persons
other than the original purchaser.

9
9
Should a problem occur that is covered by this warranty, take the
product and the sales receipt as proof of purchase date to the place
of purchase. Ignition L.P. will, at its option, unless otherwise provided
by law: (a) repair the product without charge for parts and labor;
(b) replace the product with the same or a comparable product; or
(c) refund the purchase price. All replaced parts and products, and
products on which a refund is made, become the property of Ignition
L.P. New or reconditioned parts and products may be used in the
performance of warranty service. Repaired or replaced parts and
products are warranted for the remainder of the original warranty
period. You will be charged for repair or replacement of the product
made after the expiration of the warranty period.
IGNITION L.P. EXPRESSLY DISCLAIMS ALL WARRANTIES AND
CONDITIONS NOT STATED IN THIS LIMITED WARRANTY. ANY
IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW,
INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY
AND, IF APPLICABLE, THE IMPLIED WARRANTY OF FITNESS FOR
A PARTICULAR PURPOSE, SHALL EXPIRE ON THE EXPIRATION OF
THE STATED WARRANTY PERIOD.
EXCEPT AS DESCRIBED ABOVE, IGNITION L.P. SHALL HAVE NO
LIABILITY OR RESPONSIBILITY TO THE PURCHASER OF THE
PRODUCT OR ANY OTHER PERSON OR ENTITY WITH RESPECT
TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR
INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR
ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING,
BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM
INCONVENIENCE AND ANY LOSS OF TIME, DATA, PROPERTY,
REVENUE, OR PROFIT AND ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES, EVEN IF IGNITION L.P. HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an implied warranty
lasts or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state. You may contact Ignition
L.P. at:
Ignition L.P., 3102 Maple Ave. Suite 450, Dallas, TX 75201 02/09
For product support, call
1-866-315-0426

10
10
Printed
in China
08A11
4000040
Get more from your audio and video equipment. See what
you’ve been missing. With Auvio, you control the experience.
Auvio was established by a group of technophiles to provide
high quality audio and video products without the high sticker
price. The Auvio philosophy is for you to experience audio
and video as it was intended to be: pure and distortion free.
We know electronics can be intimidating. Auvio simplifies
your experience by providing the right products, with the
right specs, to work with your equipment.
Be confident about your purchase: your new Auvio product
incorporates the latest technology, is built to the highest
quality standards, and reduces environmental impact by
complying with RoHS environmental restrictions.
© 2011. Ignition L.P. All rights reserved. Auvio is a
registered trademark used by Ignition L.P.
Package and user documentation are recyclable.
User documentation contains recycled material.
Protect the environment by recycling used electronics. Go to
E-CyclingCentral.com to find an electronic recycling center near you.
“Made for iPod” and “Made for iPhone” mean that an
electronic accessory has been designed to connect specifically
to iPod or iPhone, respectively, and has been certified by the
developer to meet Apple performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and regulatory standards.
iPhone, iPod, iPod classic, iPod nano and iPod touch are trademarks of Apple Inc.,
registered in the U.S. and other countries.
UMA0553A
