Avalon Stoves Wood Burning Stove & Insert User manual

WOOD BURNING STOVES AND
Wood Burning
Stoves & Inserts
�

Avalon Wood Burning
Renewable Energy
When fossil fuels like heating oil are burned, carbon dioxide - the gas
responsible for the greenhouse effect - is released into the atmosphere.
But when wood is burned, it’s part of a natural cycle: A tree absorbs
carbon dioxide as it grows. When a tree falls into decay or is burned
as firewood, the carbon dioxide is released and gets absorbed again by
other young trees. By practicing sustainable wood energy use and keep-
ing our forests healthy, this cycle can be maintained virtually forever!
Energy Independence
Heating with wood offers independence from the rising costs of
the utility companies. Even when your power goes out and all
other conventional heating systems are useless, a wood burning
stove will keep you warm and self-sufficient.
Wood Heats Like No Other Fuel
Wood is nature's renewable resource. A natural fuel that
burns like no other. A wood fire is cozy - the radiant and con-
vective heat from your Avalon wood stove or insert warms
body and soul.
Environmentally Responsible
An open fireplace or antique stove may conjure fond memo-
ries, but they actually create pollution and yield very low
energy efficiency. In contrast, our Avalon wood burning
appliances are EPA certified and produce virtually no visible
smoke or creosote. In fact the Avalon wood line as a whole
has been independently rated as the cleanest burning stove
line in the world!
1
Firestyles For Life
Your home is a reflection of your
personal style. Why shouldn't your
hearth appliance be the same? Just
as furniture and objects of art are
both functional and please the eye,
so can your stove or fireplace.
Avalon has beautifully designed
works of art to let your personal
expression shine through. No
matter what kind of decorating
taste you have, Avalon hearth
products will enhance it.
Choose the fire that best expresses
your home's personality and begin
heating with style.

Stoves and Inserts 2
Radiant &
ConveCtive heat
In addition to radiant heat, which only
warms objects within the room, all Avalon
wood-burning appliances feature a five-sided
convection chamber to circulate room air
around the stove and push warm air back
into the room. This dynamic process circu-
lates warm air to other areas of your home
without using a blower.
Avalon’s cast door is
designed to lasts a lifetime.
The finely crafted wood
handle has a naturally com-
fortable touch.
A single, easy-to-use
draft control simplifies
stove operation and heat
output.
Our unique knife-edge seal
between the door gasket
and stove body guarantees
an air-tight seal for life.

The beauty and grace of the Olympic stove is matched only by its remarkable efficiency.
At just 2.6 grams of emissions per hour, the Olympic is one of the cleanest-burning large wood
stoves ever approved by the EPA. Its large firebox can handle logs up to 24" long, providing up
to 12 hours of continuous burn time. It also features a single control to adjust heat output and
a by-pass damper to prevent smoke puff-backs while starting and reloading. In addition to
several leg styles, an optional pedestal base with or without an extra-large ashpan is available.
And for maximum convenience, the Olympic features a spacious cook top surface.
The Olympic stove is shown with optional solid brass door and pedestal base.
OLYMPIC™
3

Large Wood Burning Stove 4
Heating
Capacity*
1,500 to
2,500 Sq. Ft.
Heat Output**
74,300
BTU/Hr.
Cord Wood
Maximum
Burn Time
Up to
12 Hours
Firebox
Size
3.1 Cubic
Foot
Maximum
Log Size
24"Up to
Weight
510 lbs.
(With
Pedestal)
Construction
5/16" to 3/16"
Steel Plate
Efficiency
70%
(DEQ)
Emissions
2.6 Grams
Per Hour
The Olympic freestanding stove is shown with
black door and solid brass sculptured legs.
* Heating Capacity may vary depending on the degree of home insulation, floor plan, ambient temperature zone of the area in which you live.
* * BTU Output and Burn Times may vary depending on moisture content of wood, wood type, chimney draft and oxygen supply.
Height - Legs 26 1/2” Height - Pedestal 29 3/4”
Width - 23 5/8” Depth - 14 5/8”
Flue Center From Back - 4 1/8”
Weight
243 Lbs.
EPA
Emissions
4.4 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
66,800
Firebox
Size
1.6 Cu. Ft.
Heating Capacity*
600 to
1,200 Sq. Ft.
Maximum
Burn Time**
Up to 8 Hours
Maximum
Log Length
Up to 18 inches
Height - Legs 26 1/2” Height - Pedestal 30 5/8”
Width - 24” Depth - 23 1/2”
Flue Center From Back - 5 3/4”
Weight
430 Lbs.
EPA
Emissions
1.9 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
72,400
Firebox
Size
2.2 Cu. Ft.
Heating Capacity*
1.200 to
2,000 Sq. Ft.
Maximum
Burn Time**
Up to 10 Hours
Maximum
Log Length
Up to 18 inches

RAINIER™
With its unique heat transfer system and elegant design, the Rainier towers above other stoves
in its class. Featuring both radiant surfaces and a convective heat exchanger, the Rainier can
heat up to an 1,800 sq. ft. home. The Rainier’s large firebox can handle logs up to 20" long,
great for overnight burns, yet still one of the most efficient medium-size stoves ever tested. The
Rainier is also remarkably easy to operate and maintain. A single air control adjusts heat output,
and the optional pedestal base features a huge ashpan to minimize ash removal between burns.
5
The Rainier stove is shown with the standard black door and optional pedestal base.

Medium Wood Burning Stoves
The Rainier freestanding stove is shown with black
door and cast black legs.
The Rainier features models with either 90˚ or a 45˚
flues. This allows for a wide variety of installation
options, including mobile homes and as a hearth
stove in front of a fireplace.
6
Heating
Capacity*
800 to
1,800 Sq. Ft.
Heat Output**
71,800
Btu’s/Hr.
Maximum
Burn Time
Up to
9 Hours
Firebox
Size
1.8 Cubic
Foot
Maximum
Log Size
Up to
20"
Weight
355 lbs.
(With
Pedestal)
Construction
1/4" to 3/16"
Steel Plate
Efficiency
71.7%
(DEQ)
Emissions
2.0 Grams
Per Hour
* Heating Capacity may vary depending on the degree of home insulation, floor plan, ambient temperature zone of the area in which you live.
* * BTU Output and Burn Times may vary depending on moisture content of wood, wood type, chimney draft and oxygen supply.
Height - Legs 26 1/2” Height - Pedestal 29 3/4”
Width - 23 5/8” Depth - 14 5/8”
Flue Center From Back - 4 1/8”
Weight
243 Lbs.
EPA
Emissions
4.4 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
66,800
Firebox
Size
1.6 Cu. Ft.
Heating Capacity*
600 to
1,200 Sq. Ft.
Maximum
Burn Time**
Up to 8 Hours
Maximum
Log Length
Up to 18 inches
Height - Legs 26 1/2” Height - Pedestal 30 5/8”
Width - 24” Depth - 23 1/2”
Flue Center From Back - 5 3/4”
Weight
430 Lbs.
EPA
Emissions
1.9 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
72,400
Firebox
Size
2.2 Cu. Ft.
Heating Capacity*
1.200 to
2,000 Sq. Ft.
Maximum
Burn Time**
Up to 10 Hours
Maximum
Log Length
Up to 18 inches

Small in size yet big on heat, the Pendleton is ideal for a single room or smaller home. The Pend-
leton combines radiant and convective technologies into one compact design offering maximum
heat output. Like the larger Avalon stoves, the Pendleton features a single air control to adjust
heat output and simplifies stove operation. Several leg styles or an optional pedestal base are
available. The Pendleton features a 90˚ or a 45˚ flue for a wide variety of installation options,
including mobile homes, and as a hearth stove in front of a fireplace.
PENDLETON™
7
The Pendleton stove is shown with standard black door and optional pedestal base.

The Pendleton freestanding stove is shown
with black door and black sculptured legs.
The Pendleton features models with either 90˚ or
45˚ flue. This allows for a wide variety of installation
options, including mobile homes and as a hearth stove
in front of a fireplace.
PENDLETON™ Small Wood Burning Stoves 8
Heating
Capacity*
600 to
1,200 Sq. Ft.
Heat Output**
64,200
BTU/Hr.
Cord Wood
Maximum
Burn Time
Up to
8 Hours
Firebox
Size
1.3 Cubic
Foot
Maximum
Log Size
Up to
17"
Weight
320 lbs.
(With
Pedestal)
Construction
1/4" to 3/16"
Steel Plate
Efficiency
68%
(DEQ)
Emissions
3.0 Grams
Per Hour
* Heating Capacity may vary depending on the degree of home insulation, floor plan, ambient temperature zone of the area in which you live.
* * BTU Output and Burn Times may vary depending on moisture content of wood, wood type, chimney draft and oxygen supply.
Height - Legs 26 1/2” Height - Pedestal 29 3/4”
Width - 23 5/8” Depth - 14 5/8”
Flue Center From Back - 4 1/8”
Weight
243 Lbs.
EPA
Emissions
4.4 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
66,800
Firebox
Size
1.6 Cu. Ft.
Heating Capacity*
600 to
1,200 Sq. Ft.
Maximum
Burn Time**
Up to 8 Hours
Maximum
Log Length
Up to 18 inches
Height - Legs 26 1/2” Height - Pedestal 30 5/8”
Width - 24” Depth - 23 1/2”
Flue Center From Back - 5 3/4”
Weight
430 Lbs.
EPA
Emissions
1.9 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
72,400
Firebox
Size
2.2 Cu. Ft.
Heating Capacity*
1.200 to
2,000 Sq. Ft.
Maximum
Burn Time**
Up to 10 Hours
Maximum
Log Length
Up to 18 inches

9SPOKANE™
The same great style, performance and quality you've come to expect in Avalon wood stoves is
now available in a small or mid-sized entry models. For those customers just starting out, the
Spokane™ is the perfect stove for the starter home or young family. Without compromising
on construction or function, Avalon engineers have managed to produce a wood stove that's
affordable and just plain heats. No frills added. Enhance the heat transfer into your home with
the optional 160 CFM fan. Both models feature large cooktop surfaces and are available with
your choice of sculptured legs or pedestal.
The Spokane stove is shown with standard black door and optional pedestal base.

10
SPOKANE™ Value Priced Small & Medium Wood Stoves
The Spokane stove is shown with standard black door and optional pedestal base.
Spokane 1250 Spokane 1750
* Heating Capacity may vary depending on the degree of home insulation, floor plan, ambient temperature zone of the area in which you live.
* * BTU Output and Burn Times may vary depending on moisture content of wood, wood type, chimney draft and oxygen supply.
Height - Legs 26 1/2” Height - Pedestal 29 3/4”
Width - 23 5/8” Depth - 14 5/8”
Flue Center From Back - 4 1/8”
Weight
243 Lbs.
EPA
Emissions
4.4 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
66,800
Firebox
Size
1.6 Cu. Ft.
Heating Capacity*
600 to
1,200 Sq. Ft.
Maximum
Burn Time**
Up to 8 Hours
Maximum
Log Length
Up to 18 inches
Height - Legs 26 1/2” Height - Pedestal 30 5/8”
Width - 24” Depth - 23 1/2”
Flue Center From Back - 5 3/4”
Weight
430 Lbs.
EPA
Emissions
1.9 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
72,400
Firebox
Size
2.2 Cu. Ft.
Heating Capacity*
1.200 to
2,000 Sq. Ft.
Maximum
Burn Time**
Up to 10 Hours
Maximum
Log Length
Up to 18 inches
Height (Legs) 26 1/2"
Height (Pedestal) 29 3/4"
Width 23 5/8"
Depth 14 5/8"
Flue Center (from back) 4 1/8"
Height (Legs) 26 1/2"
Height (Pedestal) 30 5/8"
Width 24"
Depth 23 1/2"
Flue Center (from back) 5 3/4"
Heating
Capacity
600 to
1,200 Sq. Ft.
Heat Output
66,800
BTU/Hr.
Cord Wood
Maximum
Burn Time
Up to
8 Hours
Firebox
Size
1.6 Cubic
Foot
Maximum
Log Size
18"
Weight
243 lbs.
(With
Legs)
Construction
3/16"
Steel Plate
Efficiency
Up to
79.6%
Emissions
4.4 Grams
Per Hour
Heating
Capacity
1,200 to
2,000 Sq. Ft.
Heat Output
72,400
BTU/Hr.
Cord Wood
Maximum
Burn Time
Up to
10 Hours
Firebox
Size
2.2 Cubic
Foot
Maximum
Log Size
18"
Weight
430 lbs.
(With
Legs)
Construction
3/16"
Steel Plate
Efficiency
Up to
79.6%
Emissions
1.9 Grams
Per Hour

PERFECT-FIT™
Perfect heat with perfect style are now yours with the Perfect-Fit™ fireplace insert from Avalon.
We've brought the first wood insert to market that's perfectly flush to the fireplace so you can
enjoy maximum heat with style. The large double doors give you a beautiful view of the flames
and stay clean with our air wash system. The Perfect-Fit also has a hard-wiring option kit for the
variable-speed high-volume blower to give your hearth a clean, cordless look. Use less wood and
heat your home longer in this super-efficient insert - up to 2,000 square feet.
The Perfect-Fit is shown with optional black painted Victorian Lace face and 8" surround panels.
11

PERFECT-FIT™ Large Wood Burning Insert
The Perfect-Fit is shown with optional black painted Victorian Lace face and 8" surround panels.
Heating
Capacity*
1,200 to
2000 Sq. Ft.
Heat Output**
73,300
BTU/Hr.
Cord Wood
Maximum
Burn Time
Up to
12 Hours
Firebox
Size
2.9 Cubic
Foot
Maximum
Log Size
Up to
24"
Weight
497 lbs.
Construction
5/16" to 1/4"
Steel Plate
Efficiency
71.1%
(DEQ)
Emissions
4.1 Grams
Per Hour
Basic black matches any
decor and this black paint
finish complements every
style from rustic to
contemporary.
For a more dramatic
look, the glossy black
nickel with brushed
nickel grills and accent
detail makes your fire-
place a focal point and
mirrors the sparkle and
shine of the fire.
Victorian Lace Face Options
Black Paint Finish
Black Nickel Plate Finish With
Brushed Nickel Grills and Accents
12
* Heating Capacity may vary depending on the degree of home insulation, floor plan, ambient temperature zone of the area in which you live.
* * BTU Output and Burn Times may vary depending on moisture content of wood, wood type, chimney draft and oxygen supply.
Height - Legs 26 1/2” Height - Pedestal 29 3/4”
Width - 23 5/8” Depth - 14 5/8”
Flue Center From Back - 4 1/8”
Weight
243 Lbs.
EPA
Emissions
4.4 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
66,800
Firebox
Size
1.6 Cu. Ft.
Heating Capacity*
600 to
1,200 Sq. Ft.
Maximum
Burn Time**
Up to 8 Hours
Maximum
Log Length
Up to 18 inches
Height - Legs 26 1/2” Height - Pedestal 30 5/8”
Width - 24” Depth - 23 1/2”
Flue Center From Back - 5 3/4”
Weight
430 Lbs.
EPA
Emissions
1.9 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
72,400
Firebox
Size
2.2 Cu. Ft.
Heating Capacity*
1.200 to
2,000 Sq. Ft.
Maximum
Burn Time**
Up to 10 Hours
Maximum
Log Length
Up to 18 inches

No matter where you install it, the Olympic insert takes center stage as a leading attraction. The Olym-
pic is Avalon’s largest woodburning insert. Designed to fit most masonry fireplaces, the Olympic heats
up to a 2,500 square foot home. Its large firebox offers longer burns, giving you more time to relax and
enjoy the flames. A by-pass damper ensures an easy starting fire and smokeless refueling. The Olympic
can be installed recessed into the fireplace opening or extended onto the hearth for additional radiant
heating and a handy cook-top surface. This extra large insert produces only 2.6 grams of emissions per
hour, making the Olympic the cleanest burning large insert ever tested and certified by the EPA.
The Olympic is shown in a recessed installation and an 8" surround panel.
OLYMPIC™
13

The rugged Olympic insert is shown with cast black door and
extended onto the hearth, providing a handy cook-top surface.
Large Wood Burning Insert
Heating
Capacity*
1,500 to
2,500 Sq. Ft.
Heat Output**
74,300
BTU/Hr.
Cord Wood
Maximum
Burn Time
Up to
12 Hours
Firebox
Size
3.1 Cubic
Foot
Maximum
Log Size
Up to
24"
Weight
470 lbs.
Construction
5/16" to
3/16"
Steel Plate
Efficiency
70%
(DEQ)
Emissions
2.6 Grams
Per Hour
14
* Heating Capacity may vary depending on the degree of home insulation, floor plan, ambient temperature zone of the area in which you live.
* * BTU Output and Burn Times may vary depending on moisture content of wood, wood type, chimney draft and oxygen supply.
Height - Legs 26 1/2” Height - Pedestal 29 3/4”
Width - 23 5/8” Depth - 14 5/8”
Flue Center From Back - 4 1/8”
Weight
243 Lbs.
EPA
Emissions
4.4 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
66,800
Firebox
Size
1.6 Cu. Ft.
Heating Capacity*
600 to
1,200 Sq. Ft.
Maximum
Burn Time**
Up to 8 Hours
Maximum
Log Length
Up to 18 inches
Height - Legs 26 1/2” Height - Pedestal 30 5/8”
Width - 24” Depth - 23 1/2”
Flue Center From Back - 5 3/4”
Weight
430 Lbs.
EPA
Emissions
1.9 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
72,400
Firebox
Size
2.2 Cu. Ft.
Heating Capacity*
1.200 to
2,000 Sq. Ft.
Maximum
Burn Time**
Up to 10 Hours
Maximum
Log Length
Up to 18 inches

The powerful Rainier delivers maximum heat output in an easy to operate, non-catalytic design.
The Rainier uses radiant heat to warm objects nearby and a five-sided convection chamber to
distribute heat evenly throughout your home. It features a large firebox for longer burn times
with less reloading and the option of either a 90° or 45° flue for maximum installation flexibility.
Approved for masonry and metal (zero clearance) fireplace openings, the Rainier can be installed
recessed into the fireplace or extended onto the hearth for added radiant warmth. It can also be
converted to a freestanding wood stove should you move or your heating needs change.
15
The custom painted Rainier is shown in an extended installation.
RAINIER™

The Rainier with 90˚ flue is shown with cast black door and
installed recessed into the fireplace.
Medium Wood Burning Inserts
Heating
Capacity*
800 to
1,800 Sq. Ft.
Heat Output**
71,800
BTU/Hr.
Cord Wood
Maximum
Burn Time
Up to
9 Hours
Firebox
Size
1.8 Cubic
Foot
Maximum
Log Size
Up to
20"
Weight
300 lbs.
Construction
1/4" to
3/16"
Steel Plate
Efficiency
71.7%
(DEQ)
Emissions
2.0 Grams
Per Hour
The custom painted Rainier is shown in an extended installation.
16
* Heating Capacity may vary depending on the degree of home insulation, floor plan, ambient temperature zone of the area in which you live.
* * BTU Output and Burn Times may vary depending on moisture content of wood, wood type, chimney draft and oxygen supply.
Height - Legs 26 1/2” Height - Pedestal 29 3/4”
Width - 23 5/8” Depth - 14 5/8”
Flue Center From Back - 4 1/8”
Weight
243 Lbs.
EPA
Emissions
4.4 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
66,800
Firebox
Size
1.6 Cu. Ft.
Heating Capacity*
600 to
1,200 Sq. Ft.
Maximum
Burn Time**
Up to 8 Hours
Maximum
Log Length
Up to 18 inches
Height - Legs 26 1/2” Height - Pedestal 30 5/8”
Width - 24” Depth - 23 1/2”
Flue Center From Back - 5 3/4”
Weight
430 Lbs.
EPA
Emissions
1.9 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
72,400
Firebox
Size
2.2 Cu. Ft.
Heating Capacity*
1.200 to
2,000 Sq. Ft.
Maximum
Burn Time**
Up to 10 Hours
Maximum
Log Length
Up to 18 inches

The Pendleton may be compact, but its heating capacity exceeds most competitors' small inserts.
Perfect for a single room or small home, the Pendleton combines radiant and convective technolo-
gies to provide up to 64,200 BTUs. Yet at just 3 grams of emissions per hour, the Pendleton is one
of the cleanest burning small stoves ever tested. Available with either a 90° or 45° flue, the Pend-
leton can fit most masonry and metal (zero clearance) fireplaces (the 45° flue unit also features a
convenient cook-top surface). And if you move or your heating needs change, the Pendleton can
be converted into a freestanding wood stove.
The Pendleton is shown with the black door (standard) and an optional 8" panel.
PENDLETON™
17

Small Wood Burning Inserts
Heating
Capacity*
600 to
1,200 Sq. Ft.
Heat Output**
64,200
BTU/Hr.
Cord Wood
Maximum
Burn Time
Up to
8 Hours
Firebox
Size
1.3 Cubic
Foot
Maximum
Log Size
Up to
17"
Weight
280 lbs.
Construction
1/4" to
3/16"
Steel Plate
Efficiency
68%
(DEQ)
Emissions
3.0 Grams
Per Hour
The Pendleton with 90˚ flue shown with 8" Facing Panels.
The Pendleton is shown with the black door (standard) and an optional 8" panel.
18
* Heating Capacity may vary depending on the degree of home insulation, floor plan, ambient temperature zone of the area in which you live.
* * BTU Output and Burn Times may vary depending on moisture content of wood, wood type, chimney draft and oxygen supply.
Height - Legs 26 1/2” Height - Pedestal 29 3/4”
Width - 23 5/8” Depth - 14 5/8”
Flue Center From Back - 4 1/8”
Weight
243 Lbs.
EPA
Emissions
4.4 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
66,800
Firebox
Size
1.6 Cu. Ft.
Heating Capacity*
600 to
1,200 Sq. Ft.
Maximum
Burn Time**
Up to 8 Hours
Maximum
Log Length
Up to 18 inches
Height - Legs 26 1/2” Height - Pedestal 30 5/8”
Width - 24” Depth - 23 1/2”
Flue Center From Back - 5 3/4”
Weight
430 Lbs.
EPA
Emissions
1.9 Grams/Hr.
Efficiency
Up To 79.6 %
Maximum
Btu’s/Hour**
72,400
Firebox
Size
2.2 Cu. Ft.
Heating Capacity*
1.200 to
2,000 Sq. Ft.
Maximum
Burn Time**
Up to 10 Hours
Maximum
Log Length
Up to 18 inches

19
TURBULENCE
A single draft control is operated to meter
combustion air to a manifold , which dis-
tributes air to the stay-clean air wash and
the primary burn zone . The multiple sec-
ondary burn tubes are self-regulating and
will automatically adjust the air flow as needed. This
balance of combustion air In the correct proportion and
location easily starts and sustains the primary fire, and provides a
steady stream of fresh air across the viewing glass to help keep it clear.
Fresh air is injected above the primary fire which creates the necessary turbulence to mix fresh oxygen with the unburned gases pro-
duced by the fire.
TEMPERATURE
Elevated temperatures within the firebox are necessary to ignite the oxygen-rich gas mixture to reduce emissions and increase
efficiency. Several components work in conjunction to achieve this. The fire-box floor and walls are lined with dense, clay fire-
brick. The removable brick baffle features the same material, which absorbs heat, then radiates it back into the unburned gases.
The seamless unibody construction , is of the finest 3/16", 1/4", and 5/16" plate steel for years of dependable service. Even the
flue collar, which is subject to extremely high temperatures, is 5/16" thick. This heavy duty steel also contributes to higher internal
firebox temperatures.
TIME
The angle, shape, and size of the masonry baffle assembly has been engineered to maximize residence time of the unburned
gases yet allows the stove to draft adequately. This delay of the escaping, unburned gas and the turbulent introduction of oxygen
combine with the elevated temperatures to create a balanced combustion environment. The result is a beautiful fire to watch that
is also clean burning and efficient to operate.
Avalon woodstoves are proven performers,
having achieved one of the highest overall
ratings for efficiency of non-catalytic wood-
stoves from the Oregon Department of
Environmental Quality.
Our E.P.A. Phase II certified combustion
system burns so thoroughly that there is
very little visible smoke and very little ash
to remove.
The non-catalytic design perfectly
balances the three “T’s” of combustion:
Turbulence, Temperature &Time.
3
5
24
6
8
5
7
1
7
1
8
2
3
4
5
6
7
7
How Our Avalon Wood Stoves Work
