ALS100/L/M Integrated Audio Subsystems
User’s Guide
Document Number 10070 1.0
December 13, 1995
8
8
7
9
9
9

ALS100/L/M User’s Guide 10070 1.0
ii
Copyright 1995 by Avance Logic, Inc. All rights reserved.
This document is the property of Avance Logic, Inc. No copies shall be made of its contents in
whole or in part, nor shall the contents be disclosed to any party not previously and expressly
authorized by Avance Logic, Inc.
The information contained in this document is subject to change without notice. Avance Logic,
Inc. shall not be held liable for any damages attributable to subsequent changes to the contents
of this document.
The technical specifications contained in this document are based on computer simulations and
not on actual measurements. These specifications are subject to change and will be updated as
required by revisions to this document.
MS-DOS is a registered trademark and Windows is a trademark of the Microsoft Corporation.
IBM, IBM XGA, Video Graphics Adapter (VGA), Extended Graphics Array (EGA), OS/2, OS/
2 Warp, and PS/2 are registered trademarks of the International Business Machines Corpora-
tion. FrameMaker is a registered trademark of the Frame Technology Corporation. All other
brand and product names are either trademarks or registered trademarks of their respective
owners.
This product is intended for use in normal commercial applications. Use in an environment oth-
er than that listed herein is not recommended without prior approval by Avance Logic, Inc.
This document was written using FrameMaker 4 document publishing software.

ALS100/L/M User’s Guide 10070 1.0
iii
Document Change History
Draft 1 ...........................................................................................................October 25, 1995
Draft 2 ...........................................................................................................October 30, 1995
Draft 3 .......................................................................................................November 09, 1995
Draft 4 ....................................................................................................... December 11, 1995
Revision 1.0 Initial release ........................................................................ December 13, 1995

ALS100/L/M User’s Guide 10070 1.0
iv
8
8
7
9
9
9

ALS100/L/M User’s Guide 10070 1.0
v
Table of Contents
Introduction ........................................................................................................................... 1
Hardware Features .......................................................................................................... 3
Built-in Functional Blocks.............................................................................................. 3
Software Support ............................................................................................................ 4
Compatibility .................................................................................................................. 4
Applications.................................................................................................................... 4
Emulation........................................................................................................................ 4
Evaluation Sound Cards ........................................................................................................ 5
AS9520 Sound Card Description.................................................................................... 5
AS9521 Sound Card Description.................................................................................... 6
AS9540 Sound Card Description.................................................................................... 7
AS9545 Sound Card Description.................................................................................... 8
AS9548 Sound Card Description.................................................................................... 9
Evaluation Sound Card Summary .................................................................................. 10
Input/Output Connections............................................................................................... 11
Sound Card Installation .................................................................................................. 13
I/O Addresses.................................................................................................................. 15
PC Motherboard Settings................................................................................................ 15
AS9520 Sound Card.............................................................................................................. 16
Specifications:................................................................................................................. 17
AS9521 Sound Card.............................................................................................................. 18
Specifications.................................................................................................................. 19
AS9540 Sound Card.............................................................................................................. 20
Specifications:................................................................................................................. 21
AS9545 Sound Card.............................................................................................................. 22
Specifications.................................................................................................................. 23
AS9548 Sound Card.............................................................................................................. 24
Specifications.................................................................................................................. 25
AS9539 PC Motherboard Sound System Design.................................................................. 26
AS9538 PC Notebook Sound System Design....................................................................... 27
Software Applications Supported.......................................................................................... 28
Software Driver Installation .................................................................................................. 29
DOS and Windows 3.1 ................................................................................................... 29

ALS100/L/M User’s Guide 10070 1.0
vi
Windows 95.................................................................................................................... 30
Windows NT 3.5............................................................................................................. 30
OS/2 Warp ...................................................................................................................... 30
Setup Utility Program............................................................................................................ 31
Trouble Shooting................................................................................................................... 33
FCC Notice............................................................................................................................ 35
Technical Support ................................................................................................................. 36

ALS100/L/M Integrated Audio
Subsystems
User’s Guide
8
8
7
9
9
9

ALS100/L/M User’s Guide 10070 1.0
Introduction 1
Introduction
The ALS100 Integrated Audio Subsystem, its low voltage version the
ALS100L, and its multiple CD-ROM interface version the ALS100M, are
highly-integrated, single chip sound products. The ALS100 and the ALS100L
are functionally identical, differing only in the required power supply voltage
(VCC) and the physical package of the module. The ALS100 and the
ALS100M are functionally and physically identical, differing only in what
functions are tested. The ALS100 is not tested with CD-ROM interfaces other
than the ATAPI IDE CD-ROM interface. The ALS100 and the ALS100M are
intended for use in add-in sound cards and PC motherboard applications,
whereas the ALS100L is intended for use in notebook motherboard applica-
tions only. Four sound cards are described in this manual, but only three are
currently available. Two of the sound cards are for the evaluation of the
ALS100 and one each for the evaluation of the ALS100L and the ALS100M.
Detailed design information of the four sound cards and the PC motherboard
and PC Notebook designs is available in the ALS100/L/M Integrated Audio
Subsystems Design Manual, Avance Logic document number 10068.
The following functions are integrated into the ALS100/L/M.
• Subsystem control logic
• Digital to analog and analog to digital conversions
•Mixerfunctions
• Digital to analog conversion for the synthesizer and surround
sound functions
• Game/MIDI port (ALS100M requires external circuitry)
• CD-ROM controller (ATAPI IDE - ALS100 and ALS100L/
ATAPI IDE, Sony, Mitsumi, Panasonic, or SCSI II - ALS100M)
The ALS100/L/M fully supports the ISA Plug and Play standard. For non-ISA
Plug and Play compatible systems, a software utility (“ISA Configuration
Utility (ICU)”) is available that sets the IRQ and DMA addresses. Sound
cards and motherboard implementations designed around the ALS100/L/M
are completely jumper and switch free.

ALS100/L/M User’s Guide 10070 1.0
2 Introduction
Control logic is built into the ALS100/L/M to support the following functions:
• Audio Input
· CD-ROM Audio
· Monaural In
· Stereo Line In
· Microphone In
• Audio Output
·StereoLineOut
· Stereo Main/Surround Sound Out
• Game/MIDI Port (ALS100M requires external circuitry)
· External MIDI input and output
· Joystick input
• FM/Wavetable
· Optional Yamaha OPL3 FM Synthesizer
· Optional Yamaha OPL4 Wavetable Synthesizer
• CD-ROM Controller
· ATAPI IDE
· Sony (ALS100M only)
· Mitsumi (ALS100M only)
· Panasonic (ALS100M only)
· SCSI External Controller Input (ALS100M only)

ALS100/L/M User’s Guide 10070 1.0
Introduction 3
Hardware Features
• Single, mixed-signal, high performance VLSI sound ASIC
• Six software selectable DMA lines (0, 1, 3, 5, 6, 7)
• Seven software selectable interrupt lines (5, 7, 9, 10, 11, 12, 15)
• 8-bit ISA Plug and Play bus interface
• 8-bit or 16-bit CD-ROM interface
• 8-bit or 16-bit DMA interface with FIFO
• Game port
• MIDI port with input and output FIFO
• 8-bit or 16-bit monaural/stereo digital audio from 4 kHz to 48
kHz
• Full duplex for concurrent recording and playback
Built-in Functional Blocks
• ISA Plug and Play support logic and resource ROM
• High speed 16-bit digital to analog and analog to digital convert-
ers with filters
• Yamaha OPL3/4 FM/Wavetable Synthesizer address decode
• Digital to analog converter to support external FM/wavetable
synthesis
• Thirty-two level stereo audio mixer with six input sources (DAC,
synthesizer, monaural, microphone, line in, and CD audio)
• Built-in amplifier for the microphone input
• ADPCM decompression engine
• High speed 8-bit or 16-bit DMA interface with FIFO
• MPU-401 MIDI controller with FIFO
• CD-ROM controller

ALS100/L/M User’s Guide 10070 1.0
4 Introduction
Software Support
•Windows3.1
•Windows95
• Windows NT 3.5
• Windows Sound System
•OS/2Warp
• All DOS-based games
Compatibility
• Adlib
• All Sound Blaster Pro applications
• All Sound Blaster 16 applications
• Yamaha OPL3 FM Synthesizer
• Yamaha OPL4 Wavetable Synthesizer
• MPU-401 UART MIDI
Applications
• 16-bit stereo sound cards
• PC motherboard based sound systems
• PC Notebook sound systems (ALS100L)
• MIDI controller
• Game port
•CD-ROMcontroller
• Wavetable card support
Emulation
• Sound Blaster Pro
• Sound Blaster 16
• Sound Blaster ADPCM
• MPU-401 UART MIDI interface

ALS100/L/M User’s Guide 10070 1.0
Evaluation Sound Cards 5
Evaluation Sound Cards
There are five evaluation sound cards. Currently four are available. The sound
cards differ in the sound system design that they embody.
AS9520 Sound Card Description
The AS9520 sound card is an example of the AS9520 sound system design and
is intended for the evaluation of that design.
The AS9520 sound system design is based on the ALS100 Integrated Audio
Subsystem ASIC and contains the following features.
• 16-bit ISA Plug and Play design
• ATAPI IDE CD-ROM interface
• Game/MIDI port
• Audio inputs from:
· External Wavetable card
· ATAPI IDE CD-ROM audio
·MitsumiCD-ROMaudio
· Sony CD-ROM audio
· Microphone
·LineIn
• Audio Outputs to:
· Line Out
· Main/SS Speaker Out
• Yamaha OPL3 FM Synthesizer
• Wave Blaster compatible upgrade capability

ALS100/L/M User’s Guide 10070 1.0
6 Evaluation Sound Cards
AS9521 Sound Card Description
The AS9521 sound card is an example of the AS9521 sound system design and
is intended for the evaluation of that design.
The AS9521 sound system design is based on the ALS100M Integrated Audio
Subsystem ASIC, the multiple CD-ROM input version of the ALS100, and
contains the following features.
• 16-bit ISA Plug and Play design
• CD-ROM interfaces for:
· ATAPI IDE CD-ROM
· Mitsumi CD-ROM
· Sony CD-ROM
· Panasonic CD-ROM
• SCSI CD-ROM external controller interface
• Game/MIDI port
• Audio inputs from:
· External Wavetable card
· ATAPI IDE CD-ROM audio
· Mitsumi CD-ROM audio
· Sony CD-ROM audio
· Panasonic CD-ROM audio
· Microphone
·LineIn
• Audio Outputs to:
· Line Out
· Main/SS Speaker Out
• Yamaha OPL3 FM Synthesizer
• Yamaha OPL4 Wavetable Synthesizer
• Wave Blaster compatible upgrade capability

ALS100/L/M User’s Guide 10070 1.0
Evaluation Sound Cards 7
AS9540 Sound Card Description
The AS9540 sound card is an example of the AS9540 sound system design and
is intended for the evaluation of that design.
The AS9540 sound system design is based on the ALS100 Integrated Audio
Subsystem ASIC and has the lowest implementation cost of all of the sound
system designs. The AS9540 sound system design contains the following fea-
tures.
• 16-bit ISA Plug and Play design
• ATAPI IDE CD-ROM interface (optional)
• Game/MIDI port
• Audio inputs from:
· External Wavetable card
· ATAPI IDE CD-ROM audio
·MitsumiCD-ROMaudio
· Sony CD-ROM audio
· Microphone
·LineIn
• Audio Outputs to:
· Line Out
· Main/SS Speaker Out (optional)
• Yamaha OPL3 FM Synthesizer
• Wave Blaster compatible upgrade capability

ALS100/L/M User’s Guide 10070 1.0
8 Evaluation Sound Cards
AS9545 Sound Card Description
Hardware implementation of the AS9545 sound card is not currently available.
The following functional description and reference to this sound card else-
where in this manual are for informational use only.
The AS9545 sound card is an example of the AS9545 sound system design and
is intended for the evaluation of that design.
The AS9545 sound system design is based on the ALS100 Integrated Audio
Subsystem ASIC and contains the following features.
• 16-bit ISA Plug and Play design
• ATAPI IDE CD-ROM interface
• Game/MIDI port
• Audio inputs from:
· External Wavetable card
· ATAPI IDE CD-ROM audio
· Mitsumi CD-ROM audio
· Sony CD-ROM audio
· Microphone
·LineIn
• Audio Outputs to:
· Line Out
· Main/SS Speaker Out
• Yamaha OPL3 FM Synthesizer
• Yamaha OPL4 Wavetable Synthesizer
• Wave Blaster compatible upgrade capability

ALS100/L/M User’s Guide 10070 1.0
Evaluation Sound Cards 9
AS9548 Sound Card Description
The AS9548 sound card contains an example of the AS9538 sound system de-
sign and is intended for the evaluation of that design. The AS9538 sound sys-
tem design is intended for use in PC Notebooks (see “AS9538 PC Notebook
Sound System Design” on page 27).The AS9548 sound card has circuitry in
addition to the AS9538 sound system design so that it can operate in a standard
PC for a more convenient evaluation platform.
The AS9538 sound system design is based on the ALS100L Integrated Audio
Subsystem ASIC, the 3.3 V input voltage version of the ALS100, and contains
the following features.
• 16-bit ISA Plug and Play design
• Game/MIDI port
• Audio inputs from:
· ATAPI IDE CD-ROM audio
· Sony CD-ROM audio
· Microphone
·LineIn
• Audio Outputs to:
· Line Out
·SpeakerOut
• Yamaha OPL3 FM Synthesizer

ALS100/L/M User’s Guide 10070 1.0
10 Evaluation Sound Cards
Evaluation Sound Card Summary
Feature AS9520 AS9521 AS9540 AS9545 AS9548
Integrated Audio Subsystem ASIC ALS100 ALS100M ALS100 ALS100 ALS100L
16-bit ISA Plug and Play ●●●●●
CD-ROM Interfaces
ATAPI IDE ●●Optional ●
Mitsumi ●
Sony ●
Panasonic ●
SCSI Controller Interface ●
Game/MIDI Port ●●●●●
Audio Inputs
External Wavetable card ●●●●
ATAPI IDE CD-ROM ●●●●●
Mitsumi CD-ROM ●●●●
Sony CD-ROM ●●●●●
Panasonic CD-ROM ●
Microphone ●●●●●
Line In ●●●●●
Audio Outputs
Line Out ●●●●●
Main/SS Speaker Out ●●Optional ●Optional
Yamaha OPL3 FM Synthesizer ●●●●●
Yamaha OPL4 Wavetable Synthe-
sizer
●●
Wave Blaster compatible upgrade ●●●●
