Avantco SS Series User manual

User Manual
05/2023
SS Series Reach-In
Refrigerators and Freezers
Models:
Refrigerator Models
#178SS1RHC 29" Solid Door
#178SS2RHC 54" Solid Door
#178SS3RHC 81" Solid Door
#178SS1RGHC 29" Glass Door
#178SS2RGHC 54" Glass Door
#178SS1R2HC 29" Solid Half Door
#178SS2R4HC 54" Solid Half Door
Freezer Models
#178SS1FHC 29" Solid Door
#178SS2FHC 54" Solid Door
#178SS3FHC 81" Solid Door
#178SS1F2HC 29" Solid Half Door
#178SS2F4HC 54" Solid Half Door
Note:
You should read this manual in its entirety prior to equipment setup, operation, and maintenance.
www.AvantcoRefrigeration.com

2
User Manual
www.AvantcoRefrigeration.com
SS Series Reach-In Refrigerators and Freezers
Warnings
DANGER – RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED. TO BE REPAIRED ONLY BY
TRAINED SERVICE PERSONNEL. DO NOT PUNCTURE REFRIGERANT TUBING.
PELIGRO – RRIESGO DE INCENDIO O EXPLOSION. REFRIGERANTE INFLAMABLE UTILIZADO. PARA
SER REPARADO SOLAMENTE POR PERSONAL DE SERVICIO CALIFICADO. NO PINCHAR LA TUBERÍA
REFRIGERANTE.
DANGER – RISQUE DE FEU OU D’EXPLOSION. LE FRIGORIGÈNE EST INFLAMMABLE. CONFIER LES
RÉPARATIONS À UN TECHNICIEN SPÉCIALISÉ. NE PAS PERFORER LA TUBULURE CONTENANT LE
FRIGORIGENE.
CAUTION – RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED. CONSULT REPAIR MANUAL/
OWNER’S GUIDE BEFORE ATTEMPTING TO SERVICE THIS PRODUCT. ALL SAFETY PRECAUTIONS MUST
BE FOLLOWED.
ATENCION – RIESGO DE INCENDIO O EXPLOSIÓN. REFRIGERANTE INFLAMABLE UTILIZADO. CONSULTE
EL MANUAL DE REPARACIÓN / GUÍA DEL PROPIETARIO ANTES DE INTENTAR DAR SERVICIO A ESTE
PRODUCTO. DEBEN CUMPLIR CON TODAS LAS PRECAUCIONES DE SEGURIDAD.
ATTENTION – RISQUE DE FEU OU D’EXPLOSION. LE FRIGORIGÈNE EST INFLAMMABLE. CONSULTER LE
MANUEL DU PROPRIÉTAIRE/GUIDE DE RÉPARATION AVANT DE TENTER UNE RÉPARATION. TOUTES LE
MESURES DE SÉCURITÉ DOIVENT ÊTRE RESPECTÉES.
CAUTION – RISK OF FIRE OR EXPLOSION DUE TO PUNCTURE OF REFRIGERANT TUBING; FOLLOW
HANDLING INSTRUCTIONS CAREFULLY. FLAMMABLE REFRIGERANT USED.
ATENCION – RIESGO DE INCENDIO O EXPLOSIÓN DEBIDO A LA PERFORACION DE LA TUBERÍA
REFRIGERANTE; SIGA LAS INSTRUCCIONES DE MANIPULACIÓN CON CUIDADO. REFRIGERANTE
INFLAMABLE UTILIZADO.
ATTENTION – RISQUE DE FEU OU D’EXPLOSION SI LA TUBULURE CONTENTANT LE FRIGORIGÈNE
EST PERFORÉE; SUIVRE LES INSTRUCTIONS DE MANUTENTION AVEC SOIN. LE FRIGORIGÈNE EST
INFLAMMABLE.
CAUTION – RISK OF FIRE OR EXPLOSION DUE TO FLAMMABLE REFRIGERANT USED. FOLLOW
HANDLING INSTRUCTIONS CAREFULLY IN COMPLIANCE WITH LOCAL GOVERNMENT REGULATIONS.
ATENCION – RIESGO DE INCENDIO O EXPLOSIÓN DEBIDO A REFRIGERANTE INFLAMABLE UTILIZADO.
SIGA LAS INSTRUCCIONES DE MANIPULACIÓN CON CUIDADO CONFORME A LAS REGLAS DE LA
MUNICIPALIDAD.
ATTENTION – RISQUE DE FEU OU D’EXPLOSION SI LE FRIGORIGÈNE EST INFLAMMABLE. SUIVRE LES
INSTRUCTIONS DE MANUTENTION AVEC SOIN CONFORMÉMENT AUX RÈGLEMENTATION
GOUVERNEMENTALE LOCAUX.

3
User Manual
www.AvantcoRefrigeration.com
SS Series Reach-In Refrigerators and Freezers SS Series Reach-In Refrigerators and Freezers
Installation
Please read this manual thoroughly prior to equipment setup, operation, and maintenance.
This unit is intended for use in a temperature-controlled environment of less than 75 degrees
Fahrenheit and 60% relative humidity. Malfunction due to improper conditions is not covered
under warranty.
Important! Please Read Before Installation
• If the shelf has a raised lip, the lip needs to be installed facing up towards the rear of the cabinet
to promote proper air flow. Failure to install the shelves properly is considered user error and is
not covered by warranty.
• If the unit has recently been transported on its side, please let unit stand upright for a minimum
of 24 hours before plugging it in.
• Make sure that the unit has reached the desired temperature before loading the unit with
products. This unit is meant for keeping cold products cold, not chilling warm products.
• Make sure that there is proper ventilation around the unit in the area where it will operate.
• Make sure all accessories are installed (i.e., shelves, shelf clips, casters) before plugging the
unit in.
• Do not attempt to remove or repair any component of the unit. Consult an authorized service
technician for servicing/repair.
• Do not hang on doors or stand inside the unit.
• Please read through the manual in its entirety.
• This unit is designed to perform in a temperature-controlled environment at 60% relative
humidity. The unit should be located away from doors, air ducts, and fans that could disrupt
airflow and negatively impact performance.
Field Convertible Doors
The Avantco 178SS1RHC and 178SS1FHC both ship with a right-hinged door design. If
you would like to convert the reach-in to a left hinged door design (solid door models), you
must purchase the left hinges seperately (Avantco item #178SS1KITFR ) and follow these
instructions:
Tools Needed:
• Socket Set
• Pliers
• Adjustable Wrench
• Phillips Head Screwdriver

4
User Manual
www.AvantcoRefrigeration.com
SS Series Reach-In Refrigerators and Freezers
1. Remove the bottom vent, which is held on by loosening the 4 Phillips head screws that hold it
on. You do not need to remove the whole way, as the vent will slide up and out.
2. Remove the top panel next. It is held on with 2 small screws. Once the screws are out, the top
panel will hinge up.
3. Remove the small Philips head screws at the top and bottom door hinge where it attaches to the
brackets. Be careful not to lose the small washers.
4. Next take o the top bracket. It is held on with 3 bolts.
5. The door should come o at this point.
Note: Do not lose the small round brass spacer on the bottom hinge!
6. Remove the bottom bracket. It is held on with 3 bolts.
7. Replace the bottom hinge with the new left hand bottom bracket. It is held on with 3 bolts.
8. At this point, you will need to adjust the top and bottom spring tensioners so the door will close
properly.
9. Put the door on the bottom hinge on the left side. You will need to reuse the brass spacer from
step 5.
10. Next, place the top bracket on the top of the door before bolting it to the unit with the 3 bolts.
11. Replace the small screws on the top and bottom of the bracket and door spring. Make sure the
door is on properly before you do this.
12. Reattach the bottom vent and the top panel.
Cabinet Location Guidelines
• Install the unit on strong and leveled surfaces.
• If the surface is uneven, the unit may be noisy.
• The unit may malfunction if the surface is uneven.
• Install the unit in an indoor, well-ventilated area.
• For best performance, please maintain clearance of 6" on the back of the unit.
• Do not use outdoors. For indoor use only.
• Avoid direct sunlight.
• Avoid installation in a high-humidity and/or dusty area.
• Humidity above 60% can cause the unit to rust, collect condensation, and may
decrease eciency.
• Dust collected on the condenser coil will cause the unit to malfunction.
• Malfunctions due to temperatures above 75 degrees Fahrenheit, humidity above 60%, or
improperly maintained condenser coil will void the warranty.
• Select a location away from heat and moisture-generating equipment.
• Ambient temperatures above 75 degrees Fahrenheit may cause the compressor
to malfunction.
• Malfunctions due to ambient temperatures above 75 degrees Fahrenheit will void
the warranty.
• Do not install the unit inside a closet or alcove.

5
User Manual
www.AvantcoRefrigeration.com
SS Series Reach-In Refrigerators and Freezers SS Series Reach-In Refrigerators and Freezers
Electrical
• Please ensure that the required voltage is being supplied at all times.
• The unit should be plugged into a grounded and properly-sized electrical outlet with
appropriate over-current protection. Please refer to the electrical requirements on the unit’s
nameplate.
• The unit should have its own dedicated outlet.
• Do not use extension cords.
• Ensure the unit is not resting on or against the electrical cord.
• If the unit is not in use for a long period of time, please unplug the unit from the outlet.
• To avoid shock and fire hazards, do not plug in or unplug the unit with wet hands.
• After unplugging the unit, wait at least 10 minutes before plugging it back in. Failure to do so
could cause damage to the compressor.
Temperature Controls
Adjusting the Temperature
Your new refrigerator or freezer is already factory set to run at optimum temperatures for food
safety and should require no adjustments.
• Refrigerators are set to cycle between a minimum temperature of 33 degrees Fahrenheit and a
maximum temperature of 40 degrees Fahrenheit.
• Freezers are set to cycle between a minimum temperature of -5 degrees Fahrenheit and a
maximum temperature of 2 degrees Fahrenheit.
• Adjusting the temperature changes the minimum temperature at which your unit will run. Your
unit will not run constantly at this setting. To change it, follow these instructions:
Freezer Control
Prg
mute
Set
aux
def
Refrigerator Control
set
mute
Digital Control Units
1. Hold "SET" for 1 second. The display will flash the current minimum temperature.
2. Use the arrow buttons to adjust the minimum temperature you'd like the unit to run at.
3. Press "SET" again to save your settings.
Always remember to calculate the differential if you change the minimum temperature setting.
The cabinet temperature will fluctuate up to 7 degrees Fahrenheit over your set minimum
temperature as the compressor runs and shuts off. Setting the temperature too high will result
in unsafe maximum temperatures and possible health code violations.

6
User Manual
www.AvantcoRefrigeration.com
SS Series Reach-In Refrigerators and Freezers
Defrost System
Automatic Defrost Cycle
• Refrigerator coils are kept below the freezing point (32 degrees Fahrenheit).
• During compressor downtime, the evaporator fan continues to circulate air through the
evaporator coil. This air circulation raises the coil temperature above the freezing point, melting
any accumulated frost.
• Run-o water is drained into the evaporator pan and evaporated.
• Freezer coils are defrosted electronically.
• Automatic defrost timers initiate at pre-set intervals and for a predetermined duration.
Running a Manual Defrost Cycle
Units are preprogrammed to run automatic defrost cycles at preset intervals. However, if you
would like to run a manual defrost cycle at any time, follow the steps below:
Refrigerators: Press the defrost button ("DEF" and ) for approximately 5 seconds. Repeat to
stop the defrost cycle.
Freezers: Press the defrost button (snowflake symbol and ) for approximately 3 seconds. Repeat
to stop the defrost cycle.
Safety & Warning
Pay close attention to the safety notices in this section. Disregarding these notices may lead to
serious injury and/or damage to the unit.
Attention
• To minimize shock and fire hazards, be sure not to overload outlet. Please designate one outlet
for your unit.
• Do not use extension cords.
• Do not put your hands under the unit while it is being moved.
• When the unit is not in use for a long period of time, please unplug the unit from the outlet.
• After unplugging the unit, wait at least 10 minutes before plugging it back in. Failure to do so
could cause damage to the compressor.
Unplug Cord
• To minimize shock and fire hazards, please do not plug or unplug the cord with wet hands.
• During maintenance and cleaning, please unplug the unit.
Proper Grounding Required
• To minimize shock and fire hazards, make sure that the unit is properly grounded.

7
User Manual
www.AvantcoRefrigeration.com
SS Series Reach-In Refrigerators and Freezers SS Series Reach-In Refrigerators and Freezers
Warning
• Do not attempt to remove or repair any component unless instructed by factory.
• Make sure that the unit is not resting on or against the electrical cord and plug.
• To minimize personal injury, do not hang on the doors.
• Do not store any flammable and explosive gas or liquids inside the unit.
• Do not attempt to alter or tamper with the electrical cord.
Operation & Maintenance
DISCONNECT POWER CORD BEFORE CLEANING ANY PARTS OF THE UNIT.
It is strongly recommended that any servicing of the unit be performed by an authorized
service technician.
Loading the Product
• Make sure there is at least four inches of clearance from the evaporator.
• Ensure all shelves are sitting level and properly secured before loading products.
• Do not store flammable and explosive gas or liquids inside the unit.
Cleaning the Fan Blades and Motor
• If necessary, clean the fan blades and motor with a soft cloth.
• If it is necessary to wash the fan blades, cover the fan motor to prevent moisture damage.
Cleaning the Interior of the Unit
• When cleaning the cabinet interior, use a solvent of warm water and mild soap.
• Do not use steel wool, caustic soap, abrasive cleaners, or bleach that may damage the
interior finish.
• Wash door gaskets on a regular basis, preferably weekly. Simply remove door gasket from
the frame of the door, soak in warm water and soap for thirty (30) minutes, dry with soft cloth,
and replace.
• Check door gaskets for proper seal after they are replaced.
• Periodically remove the shelves and pilasters from the unit and clean them with mild soap and
warm water. To remove the pilasters, first remove the shelves and shelf brackets. Then, simply lift
the pilaster up and out.

8
User Manual
www.AvantcoRefrigeration.com
SS Series Reach-In Refrigerators and Freezers
Cleaning the Exterior of the Unit
• In order to properly care for the exterior surfaces of your unit, you must regularly clean the
stainless steel.
• Approved tools are soft cloths, microfibers, sponges, or plastic scouring pads.
• Do not use steel wool, caustic cleaners, or abrasive cleaners.
• Excel by Noble Chemical is a water-based aerosol cleaner / polish made to pair with your unit
(Item #999EXCEL).
Cleaning the Condenser Coil
• For ecient operation, keep the condenser surface free of dust, dirt, and lint.
• We recommend cleaning the condenser coil at least once per month.
A dusty condenser may lead to high energy consumption, less cooling eectiveness, and
compressor damage.
Condenser Coil Cleaning Instructions
The condenser coil is located at the bottom behind the panel.
1. Disconnect the electrical power from the unit.
2. Remove the front cover and base cover with a screwdriver.
3. Using a soft brush and/or vacuum, remove the dirt, lint, etc. from the finned condenser coil in a
vertical direction.
4. Clean the condenser with a commercial condenser coil cleaner, available from any kitchen
equipment retailer. Ex. Noble Chemical Tech Line.
5. After cleaning, straighten any bent condenser fins with a fin comb.
6. When finished, be sure to reinstall the front cover and base cover.
7. Reconnect the electrical power to the unit.

9
User Manual
www.AvantcoRefrigeration.com
SS Series Reach-In Refrigerators and Freezers SS Series Reach-In Refrigerators and Freezers
Troubleshooting
Problem Possible Cause Possible Solution
Compressor
not running.
Fuse blown or circuit breaker tripped. Replace fuse or reset circuit breaker.
Power cord unplugged. Plug in power cord.
Thermostat set too high. Set thermostat to lower temperature.
Cabinet in defrost cycle. Wait for defrost cycle to finish.
Condensing units run for
long periods of time.
Excessive amount of water product in
cabinet. Allow adequate time for product to cool down.
Prolonged door opening or door ajar. Ensure doors are closed when not in use. Avoid
opening the doors for long periods of time.
Door gasket(s) not sealing properly. Ensure gasket(s) are snapped in completely. Remove gasket and wash with soap and water. Check
condition of gasket and replace if necessary.
Dirty condenser coil. Clean the condenser coil.
Evaporator coil iced over. Unplug unit and allow coil to defrost. Make sure thermostat is not set too cold. Ensure that door
gasket(s) are sealing properly.
Cabinet temperature is
too warm.
Thermostat set too warm. Set thermostat to lower temperature.
Airflow blocked. Re-arrange product to allow for proper air flow. Make
sure there is at least 4" of clearance from evaporator.
Excessive amount of warm product
placed in cabinet. Allow adequate time for product to cool down.
Fuse blown or circuit breaker tripped. Replace fuse or reset circuit breaker.
Dirty condenser coil. Clean the condenser coil.
Evaporator coil iced over. Ensure doors are closed when not in use. Avoid
opening doors for long periods of time.
Low refrigerant levels. Contact a service technician to check refrigerant
levels.
Door is slightly ajar. Make sure door is completely closed.
Interior light is not
working.
Poor switch connection. Turn o light switch and turn it back on.
Bulb is not connected. Make sure the bulb is correctly inserted in the
socket.
Bulb has burned out. Replace the bulb.
Condensation is
collecting on the cabinet
and/or floor.
Gasket is not sealing properly. Clean, repair, or replace the gasket as necessary.
Relative humidity is above 60%. Move unit to area below relative humidity or lower
humidity level.
