Installation & Assembly
Microwave Oven Bracket Installation Instruction
(Only to be used in models MO699SST-1/MO7080MW/MO7090MB/M07180TW/MO7280TB installation)
Parts List &
Hardware Before you start this installation make sure you have all the parts listedbelow. Read entire installation sheet before you start assembly of this item.
Microwave Oven Models MO699SST-1/MO7080MW/MO7090MB/M07180TW/MO7280TB
Part Number
Qty
Description
AMOM9704 1Mounting Bracket
B9704-001 2Locking Pin
C9704-002 3No. 8 x 5/8” Phillips Hex Head
Self Tapping Screw
D9704-003 4No. 8 x 1” Phillips Pan Head
Sheet Metal Screw
E9704-004 4Plastic Anchor (¼” x 1”)
Installation Procedures:
1) BracketConfiguration:
Holes (A),(B) and (C)are the existing holes in the upper part of the Metal bracket. Holes (D), (E), (F) and (G)
are alsoexisting holes in the lower part of the Metal bracket.
See illustration #1.
A B C
DEFG
Illustration #1
2) Installation of the upper side of the Metal bracket to the Microwave:
Place top of the bracket on the back of the microwave. Insert one of the (3) Phillips Hex Head Self Tapping
screws provided into pilot hole (A) then proceed installing the remaining (2) two Phillips Hex Head Self
Tapping screws into holes (B) and (C).Secure using a Phillips head screwdriver.
See illustration # 2.

2
Illustration # 2
3) Installation of the lower side of the Metal bracket to the Refrigerator:
Lay and center the Microwave oven (with bracket installed) on top of the refrigerator.
Flip down the lower part of the bracket.
Using the four (4) existing holes on the bracket as a guide, mark the locations where to drill the holes (D),
(E), (F) and (G). See illustration # 3.
Illustration # 3
4) Drillingthe four holes to the Refrigerator:
After marking the locations of the four (4) holes, remove the Microwave oven and bracket from the top of
the refrigerator and proceed drilling the four (4) holes witha¼”drill bit into the rear of the Refrigerator.
See illustration#4.

3
Illustration # 4
5) Inserting the Plastic Anchors to the Refrigerator:
Insert the four (4) Plastic Anchors provided into the four (4) holes (step 5) in the back of the refrigerator.
See illustration# 5.
Illustration # 5
6) Completing the assembly:
Lay the Microwave oven with the metal bracket already installed on top of the refrigerator.
Align the four (4) holes of the lower part of the metal bracket to meet the four (4) plastic anchors installed in
previous step 6.
Attach the lower part of the metal bracket to the refrigerator.
Secure with the four (4) Phillips Pan Head Sheet Metal screws(provided) using a Phillips head screwdriver.
7) Safety features :
For your Safety, this metal bracket comes with two Lock Pins that will prevent the Microwave oven from
tilting back while in use. These two (2) Lock Pins (provided) can be lifted and removed to allow you to
clean the refrigerator top.
It is recommended to have both Lock Pins installed once the refrigerator is cleaned. See illustration # 6.

4
Microwave Oven
Refrigerator
Lock Pin
Illustration # 6
