Avanti ARBC17T2PG User manual

Model ARBC17T2PG
REFRIGERATOR / BEVERAGE COOLER INSTRUCTION MANUAL
Design / Color may vary
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
Avanti has a policy of continuous improvement on its products and reserves
the right to change materials and specifications without notice.

3
APPLIANCE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always
read and obey all safety messages.
This is the Safety Alert Symbol. This
symbol alerts you to potential hazards that
can kill or injure you and others.
All safety messages will follow the Safety
Alert Symbol and either the wards”
DANGER”, “WARNING” or “CAUTION”.
Danger means that failure to heed this
safety statement may result in severe
personal injury or death.
Warning means that failure to heed this
safety statement may result in extensive
product damage, serious personal injury, or
death.
Caution means that failure to heed this
safety statement may result in minor or
moderate personal injury, or property or
equipment damage.
All safety messages will alert you to what the potential hazard is, tell you how to reduce the
chance of injury, and let you know what can happen if the instructions are not followed.
REFRIGERANT GAS WARNINGS
DANGER - Risk of fire orexplosion. Flammable refrigerant used.
DO NOT use mechanical devices to defrost refrigerator. DONOT puncture refrigerant
tubing.
DANGER - Risk of fire orexplosion. Flammable refrigerant used.
To berepaired only bytrained service personnel. DONOT puncture refrigerant tubing.
CAUTION - Risk of fire orexplosion. Flammable refrigerant used.
Consult repair manual / owner’s guide before attempting to service
this product. All safety precautions must be followed.
CAUTION - Risk of fire orexplosion. Dispose of property inaccordance
with federal orlocal regulations. Flammable refrigerant used.
CAUTION - Risk of fire orexplosion due to puncture of refrigerant tubing;
Follow handling instructions carefully. Flammable refrigerant used.

4
IMPORTANT SAFEGUARDS
Before the appliance is used, it must be properly positioned and
installed as described in this manual, so read the manual carefully. To
reduce the risk of fire, electrical shock or injury when using the
beverage cooler, follow basic precautions, including the following:
•
Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an
adapter, and do not use an extension cord
• Replace all panels before operating
• It is recommended that a separate circuit, serving only your beverage cooler, be provided.
Use receptacles that cannot be turned off by a switch or pull chain
• Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.
• Before proceeding with cleaning and maintenance operations, make sure the power line of
the unit is disconnected.
• Do not connect or disconnect the electric plug when your hands are wet
• Unplug the appliance or disconnect the power before cleaning or servicing. Failure to do so
can result in electrical shock or death.
• Do not attempt to repair or replace any part of your appliance unless it is specifically
recommended in this material. All other servicing should be referred to a qualified
technician.
• Use two or more people to move and install the appliance. Failure to do so can result in
back or other injury.
• To ensure proper ventilation for your appliance, the unit must be completely unobstructed.
Choose a well-ventilated area with temperatures above 550F (130C) and below 900F (32
0C). This unit must be installed in an area protected from the elements, such as wind, rain,
water spray or sunlight.
• The appliance should not be located next to ovens, grills or other sources of high heat.
• The appliance must be installed with all electrical, water and drain connections in
accordance with state and local codes. A standard electrical supply (115 V AC only, 60
Hz), properly grounded in accordance with the National Electrical Code and local codes
and ordinances is required.
• Do not kink or pinch the power supply cord of the appliance.
• The fuse (or circuit breaker) size should be 15 amperes.
• It is important for the appliance to be leveled in order to work properly. You may need to
make several adjustments to level it.
• All installation must be in accordance with local plumbing code requirements.
• Make certain that the pipes are not pinched or kinked or damaged during installation.
• Check for leaks after connection.
• Never allow children to operate, play with or crawl inside the appliance
• Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may
damage or discolor the interior.
• Do not use this apparatus for other than its intended purpose.

5
Electrical Connection
Warning
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord
is damaged, have it replaced by an authorized Avanti Products service center.
This appliance should be properly grounded for your safety. The power cord of this
appliance is equipped with a three-
prong plug which mates with standard three
prong wall outlets to minimize the possibility of electrical shock.
Do not under any circumstances cut or remove the third ground prong from the
power cord supplied.
This appliance requires a standard 115Volts~/60Hz electrical outlet with three-prong
ground.
The cord should be secured behind the appliance and not left exposed or dangling to
prevent accidental injury.
Never unplug the appliance by pulling the power cord. Always grip the plug firmly
and pull straight out from the receptacle.
Do not use an extension cord with this appliance. If the power cord is too short, have
a qualified electrician or service technician install an outlet near the appliance.
EXTENSION CORD
Because of potential safety hazards under certain conditions, it is strongly
recommended that you do not use an extension cord with this unit. However, if you
must use an extension cord it is absolutely necessary that it be a UL/CUL-Listed, 3-
wire grounding type appliance extension cord having a grounding type plug and
outlet and that the electrical rating of the cord be 115 volts and at least 10 amperes.
SURGE PROTECTOR
Most electrical appliances use a series of electric control boards to operate. These
boards are very susceptible to power surges and could be damaged or destroyed.
If the appliance is going to be used in an area or if your city / country is prone to
power surges / outages; it is suggested that you use a power surge protector for all
electrical devices / appliances you use. The surge protector that you select must
have a surge block high enough to protect the appliance it is connected to. If you
have any questions regarding the type and size of surge protector needed contact a
licensed electrician in your area.
Damages due to power surges are not considered a manufacturer covered defect
and will void your product warranty.

7
PARTS & FEATURES
1: Top Hinge with Cover
2: Refrigerator Shelf (Full Size)
3: Refrigerator Shelf (Half Size)
4: Temperature Control
5: Door with Integrated handle
6: Leveling Leg

8
IMPORTANT SAFETY INSTRUCTIONS

WARNING

To reduce the risk of fire, electrical shock,
or injury when using your appliance, follow
these basic precautions:
•Read all instructions before using the refrigerator.
•DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or
abandoned refrigerators are still dangerous. . . even if they will “just sit in the
garage a few days.”
•Before you throw away your old refrigerator:Take off the doors. Leave the
shelves in place so that children may not easily climb inside.
•Never allow children to operate, play with, or crawl inside the refrigerator.
•Never clean refrigerator parts with flammable fluids. The fumes can create a fire
hazard or explosion.
•Do not store or use gasoline or any other flammable vapors and liquids in the vicinity
of this or any other refrigerator. The fumes can create a fire hazard or explosion.
-Save these instructions-
INSTALLATION INSTRUCTIONS
Before Using Your Unit
•Remove the exterior and interior packing.
•Check to be sure you have all of the following parts:
•2 Shelves (1 Full / 1 Half )
•1 Instruction Manual
•Before connecting the unit to the power source, let it stand upright for approximately 2 hours.
This will reduce the possibility of a malfunction in the cooling system from handling during
transportation.
•Clean the interior surface with lukewarm water using a soft cloth.
Installing Your Unit
•This appliance is designed to be free standing only, and should not be recessed or built-in.
•Place your unit on a floor that is strong enough to support the unit when it is fully loaded. To
level your unit, adjust the leveling legs at the bottom of the unit.
•Allow 5 inches of space between the back and sides of the unit, which
allows the proper air circulation to cool the compressor and condenser.
•Locate the unit away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extreme cold ambient temperatures may also cause the unit not to perform
properly.
•Avoid locating the unit in moist areas.
•Plug the unit into an exclusive, properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified electrician or an
authorized Avanti Products service center.
•After plugging the appliance into a wall outlet, allow the unit to cool down for 2-3 hours before
placing food in the refrigerator compartment.

9
OPERATING YOUR UNIT
Setting the Temperature Control
•Your unit has only one control for regulating the temperature in the
compartment. The temperature control is located on the lower right
hand side of the compartment.
•The first time you turn the unit on, set the temperature control to
“MAX”.
•The range of the temperature control is from position "OFF” to
“MAX”. After 24 to 48 hours, adjust the temperature control to the
setting that best suites your needs. The setting of “NORMAL” should
be appropriate for home or office use.
•To turn the appliance off, turn the temperature control to ”OFF”.
NOTE:
Turning the temperature control to “OFF” position stops the cooling cycle but does not shut off the
power to the unit.
If the unit is unplugged, has lost power, or is turned off, you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the unit will not start.
CARE AND MAINTENANCE
Reversing the Door Swing of Your Appliance
This appliance has the capability of the door opening from either the left or right side. The unit is
delivered to you with the door opening from the left side. Should you desire to reverse the opening
direction, please call customer service for reversal instructions.
Cleaning Your Unit
•Turn the temperature control to "OFF", unplug the unit, and remove the food, shelf, and tray.
•Wash the inside surfaces with a warm water and baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart of water.
•Wash the shelf and tray with a mild detergent solution.
•The outside of the unit should be cleaned with mild detergent and warm water.
•Wring excess water out of the sponge or cloth before cleaning the area of the controls, or any
electrical parts.
•Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with
a clean soft cloth.
CAUTION:
Failure to unplug the unit could result in electrical shock or personal injury.
Power Failure
Most power failures are corrected within a few hours and should not affect the temperature of your
unit if you minimize the number of times the door is opened. If the power is going to be off for a longer
period of time, you need to take the proper steps to protect your food.
Vacation Time
•Short vacations: Leave the unit operating during vacations of less than three weeks.
•Long vacations: If the appliance will not be used for several months, remove all food and unplug
the power cord. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave
the door open slightly: blocking it open if necessary.

10
Moving Your Unit
•Remove all the food.
•Securely tape down all loose items inside your unit.
•Turn the leveling legs up to the base to avoid damage.
•Tape the door shut.
•Be sure the unit stays secure in the upright position during transportation. Also protect the
outside of unit with a blanket, or similar item.
Energy Saving Tips
•The unit should be located in the coolest area of the room, away from heat producing appliances,
and out of the direct sunlight.
•Let hot foods cool to room temperature before placing in the unit. Overloading the unit forces the
compressor to run longer.
•Be sure to wrap foods properly, and wipe containers dry before placing them in the unit. This cuts
down on frost build-up inside the unit.
•Unit storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners
interfere with cold air circulation, making the unit less efficient.
•Organize and label food to reduce door openings and extended searches. Remove as many
items as needed at one time, and close the door as soon as possible.

11
PROBLEMS WITH YOUR REFRIGERATOR ?
You can solve many common unit problems easily, saving you the cost of a possible service call. Try
the suggestions below to see if you can solve the problem before calling the servicer.
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE CAUSE
Unit does not operate.
Not plugged in.
The circuit breaker tripped or a blown fuse.
The unit temperature control is set at “OFF”
position.
Turns on and off frequently.
The room temperature is hotter than normal.
A large amount of food has been added to the
unit.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The unit does not have the correct clearances.
Vibrations.
Check to assure that the unit is level.
The unit seems to make too much noise.
The rattling noise may come from the flow of the
refrigerant, which is normal.
As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant in your
unit.
Contraction and expansion of the inside walls
may cause popping and crackling noises.
The unit is not level.
The door will not close properly.
The unit is not level.
The door was reversed and not properly installed.
The gasket is dirty or bent.
The shelves, bins, or baskets are out of position.

12
SERVICE FOR YOUR APPLIANCE
We are proud of our customer service organization and the network of professional service
technicians that provide service on your Avanti appliances. With the purchase of your Avanti
appliance, you can have the confidence that if you ever need additional information or assistance the
Avanti Products Customer Service team will be here for you. Just call us toll-free.
AVANTI PRODUCTS CUSTOMER SERVICES
Product Information
800-323 5029
Whatever your questions are about our products,
help is available.
Part Orders
800-220 5570
You may order parts and accessories that will be
delivered directly to your home.
You may order these items by personal check,
money order, Master Card, or Visa.
In-Home Repair Service
800-220 5570
An Avanti Products authorized service center will
provide expert repair service, scheduled at a time
that is convenient for you. Our trained servicers
know your appliance inside and out.
WIRING DIAGRAM

13
YOUR AVANTI PRODUCTS
WARRANTY
Staple your sales receipt here. Proof of original
purchase date is needed to obtain service under
warranty.
WHAT IS COVERED – LIMITED ONE-YEAR WARRANTY
Avanti Products warrants that the product is free from defects in materials and/or workmanship for a period of
twelve (12) months from the date of purchase by the original owner. The foregoing timeline begins to run upon
the date of purchase, and shall not be stalled, tolled, extended, or suspended for any reason whatsoever unless
described in detail in the warranty document. For one year from the date of purchase by the original owner,
Avanti products will, at its option, repair or replace any part of the product which proves to be defective in
material or workmanship under normal use. Avanti Products will provide you with a reasonably similar product
that is either new or factory refurbished. During this period Avanti Products will provide all parts and labor
necessary to correct such defects free of charge, so long as the product has been installed and operated in
accordance with the written instructions in this manual. In rental or commercial use, the warranty period is 90
days. All Avanti appliances of 4.2 cubic feet capacity or less must be brought/sent to the appliance service
center for repair.
LIMITED SECOND THROUGH FIFTH YEAR WARRANTY
For the second through the fifth year from the date of original purchase, Avanti Products will provide a
replacement compressor free of charge due to a failure. You are responsible for the service labor and freight
charges. In rental or commercial use, the limited compressor warranty is one year and nine months. Costs
involved to move the product to the service center and back to the user’s home, as maybe required, are the
user’s responsibility.
WARRANTY EXCLUSIONS / WHAT IS NOT COVERED:
The warranty coverage described herein excludes all defects or damage that are not the direct fault of Avanti
Products, including without limitation, one or more of the following:
•
A failure to comply with any applicable state, local, city, or county electrical, plumbing and/or building codes,
regulations, or laws, including failure to install the product in strict conformity with local fire and building codes
and regulations.
•Any external, elemental and/or environmental forces and factors, including without limitation, rain, wind, sand,
floods, fires, mud slides, freezing temperatures, excessive moisture or extended exposure to humidity,
lightning, power surges, structural failures surrounding the appliance, and acts of God.
•
Content losses of food or other content due to
spoilage.
•Incidental or consequential damages
•Parts and labor costs for the following will not be
considered as warranty:
•Evaporator doors, door springs, and/or frames.
•Inner door panels, door shelves, door rails,
and/or door supports.
•Light bulbs and/or plastic housing.
•Plastic cabinet liners.
•Punctured evaporator that voids the warranty on
the complete sealed system.
•Shipping and handling costs associated with the
replacement of the unit.
•Repairs performed by unauthorized servicers.
•Service calls that are related to external problems,
such as abuse, misuse, inadequate electrical
power, accidents, fire, floods, or any other acts of
God.
•Failure of the product if it is used for other than it
intended purpose.
•The warranty does not apply outside the
Continental USA.
•Surcharges including but not limited to, any after
hour, weekend, or holiday service calls, tolls, ferry
trip charges, or mileage expense for service calls to
remote areas.
In no event shall Avanti Products have any liability or responsibility whatsoever for damage to surrounding
property, including cabinetry, floors, ceilings, and other structures and/or objects around the product. Also
excluded from this warranty are scratches, nicks, minor dents, and other cosmetic damages on external surfaces
and exposed parts; Products on which the serial numbers have been altered, defaced or removed; service visits
for customer education, or visits where there is nothing wrong with the product; correction of installation problems
(you are solely responsible for any structure and setting for the product, including all electrical, plumbing and/or
other connecting facilities, for proper foundation/flooring, and for any alterations including without limitation
cabinetry, walls, floors, shelving etc., as well as the resetting of breakers or fuses.
OUT OF WARRANTY PRODUCT
Avanti Products is under no obligation, at law or otherwise, to provide you with any concessions, including
repairs, pro-rates, or product replacement, once this warranty has expired.
WARRANTY – REFRIGERATION - COMPRESSOR
Discover other RV appliances on our website.
