No. Part Code Part Name Qty.
1DG12-22 Connecting Tube 1
2DG13-1 Drip Tray 1
3DG2-1.1 Power Cord 1
4DG11-4 Drier Filter 1
5DG13-24 Rubber Stabilizing Tube 1
6DG1-38 Compressor 1
7DG6-1003.2 Transformer 1
8DG3-1029.3 Main PCB 1 set
9DG13-272 Electrical Box 1
10 Cabinet 1
11 DG22-1062 Upper left hinge 1
12 DG22-1096 S/S Supporting Piece for
Top Front Insert 3
13 DG3-1012.1 LED light board 1
14 DG13-1049 LED light cover 1
15 DG22-1063 Upper right hinge 1
16 DG22-1064 Axle 1
17 DG18-1007 Foam piece for
evaporator 2
18 DG12-1 Evaporator 1
19 DG7-3 Evaporator Fan 1
20 DG22-1019 Rear Inner Panel with fan
duct 1
21 DG19-1 Fan Cover A 1
22 DG8-8 Temperature Sensor
(Thermistor) 2
23 DG13-158 Support piece for rear
inner panel 5
24 DG13-1013.6 Top Front Insert 1
25 DG20-1008.1 Control Panel Film 1
26 DG23-1002.1 Door Assy. 1
27 DG14-105 Door Lock 1
28 DG14-1014 Hinge Axle 1
29 DG14-1029.6 Handle (20" Curved) 1
30 DG15-1008.1 Shelf 2
31 DG15-1008.2 Shelf (Large) 1
32 DG13-7 Fixing Piece for Shelf 6
33 DG22-1065 Bottom Grille 1
34 DG14-1013.3 Lower Right Hinge 2
35 DG13-508 Foot 4
36 DG22-1016 Metal Supporting Bracket
for Front Feet 1
37 DG12-15 Condenser 1
38 DG12-1005 Suction Tube 1
39 DG7-23.1 External Fan 1
40 DG14-56 Bracket for External Fan 1
41 DG19-3 Fan Cover B 1
42 DG22-1015 Compressor Bracket 1
43 FL-107 Drain Pipe 1
