Avanti OBC33SSD User manual

OBC33SSD Beverage Center - Explosion View
(see other tab for Parts List)

Item No. Material Code Description
11864806001 Control panel
21842001002 Door
2.1 1861701700 Handle
2.2 1853106000 Wiring harness for
Temp. Display
31864805803 Temperature display
41864001800 Gasket
61856200400 Lamp
71849735400 Lampshade
81800500900 Shelves
91800500500 Curved Shelf
10 1800501001 Flattened Basket
11 1800500800 Large Basket
12 1856200300 Lampholder
13 1880026201 Evaporator
14 1864400201 Top hinge cover
15 1860414801 Top hinge
17 1864620000 Foot
18 1864802300 Water drip tray
19 1858422000 Compressor
19.1 1858460700 Starting Relay
19.2 1858450900 Overload
20 1860414901 Bottom hinge
21 1880007800 Drier
23 1858203100 Fan
25 1880013702 Condenser
23 1861702700 Bottom shelf
27 1854206500 Circuit wafer
27.1 1854810000 Transformer
27.2 1854800500 3A fuse of controller
30 1824706304 Ballast
32 1853114400 Power cord
35 1851701601 Sensor
36 1861751100 Back grid
38 1845744400 Bottom Grille
OBC33SSD Beverage Center - Spare Parts List
