Aventura DH5-Series Quick user guide

DH5-Series DVR Server and
NVR-Series Video Storage Server
Hardware Reference Manual
Please read these instructions before installation and keep for later reference.
NOTES:
1. Do not use in extreme heat or cold temperatures.
2. Do not expose to rain or moisture
3. Do not expose to flammable, explosive, or corrosive gas.
4. Avoid exposure to dust or other particles that may get inside the equipment.
5. Use of extension cords may significantly increase risk of fire, electric shock, and damage to the
equipment.
6. To avoid risk of electric shock and damage to equipment do not open the device.
7. Professional installation is required.

DH5 and NVR Series Server Reference Manual 2
Reference Page
The information on this page should be filled out during or immediately following installation for later
reference.
SERIAL # ____________________________________________________
COMPUTER NAME ____________________________________________________
IP ADDRESS ____________ . ____________ . ____________ . ____________
DEFAULT GATEWAY ____________ . ____________ . ____________ . ____________
PRIMARY DNS ____________ . ____________ . ____________ . ____________
SECONDARY DNS ____________ . ____________ . ____________ . ____________
NOTES ____________________________________________________
____________________________________________________
____________________________________________________

DH5 and NVR Series Server Reference Manual 3
Brief Introduction
Aventura’s DH5 and NVR Series servers are standard 3U rack-mount systems with support for up to 16
hard drives, RAID 0,1,5,6 storage configurations, IP video decoding and up-to 32 channels of analog
video encoding (DH5 only).
Specifications
3U form factor
Intel i7 CPU
4 GB RAM
RAID 5 Storage Configuration (standard, options available)
Windows 7 Professional 32-bit (standard, options available)
Operating Conditions
This unit should be installed in a room with active climate controls such as air conditioning and
dehumidification.
Operating Temperature: 50 ~ 90F
Operating Humidity: 0 ~ 80%

DH5 and NVR Series Server Reference Manual 4
Networking
When using this unit on a network, connecting to a private (non-internet) network is highly
recommended for maximum security. Any potential problems or security issues resulting from an
internet-capable connection are the responsibility of the end-user.
Software
Aventura servers come pre-loaded with all the software required for proper operation. Installing
additional software such as virus protection is not recommended. Any potential problems or security
issues resulting from the installation of additional software is the responsibility of the end-user.
Hardware
Do not remove, install or modify any hardware components of the system. All maintenance must be
performed by Aventura or an affiliated authorized service.
Equipment Mounting
The unit should be rack-mounted using a rail system. Rails should be secured to the side of the unit and
to the server rack in accordance with their installation instructions.

DH5 and NVR Series Server Reference Manual 5
Back Panel Layout
The back panel of the unit is where all wired connections are made for power and connectivity with
external devices.
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12)
1. Power Supply (up-to 3 redundant power supply units)
2. PS/2 (Mouse)
3. PS/2 (Keyboard)
4. Serial (COM Port)
5. VGA (Monitor Out)
6. USB
7. 10/100/1000 Base-T Ethernet LAN (RJ-45)
8. Audio In (Top), Audio Out (Middle), Microphone in (Bottom)
9. (Optional) 10Gbps Ethernet LAN (RJ-45)
10. e-SATA
11. (Optional) Video Decoder Out
12. Video Encoder Inputs (D Connectors)

DH5 and NVR Series Server Reference Manual 6
NOTES:
Video encoder inputs require use of the supplied video pigtail connectors to convert BNC analog
video connections to the D connectors on the back panel.
COM port can be used to communicate with external devices. Additional hardware may be
required to interface between COM port and external devices. Additional COM ports can be
added with USB-to-COM Port adapters.
Audio output is available for systems with audio/video recording capabilities. Once speakers are
connected operators can enable or disable live audio and audio playback in the Aventura
software.
Video Decoder Outputs are an optional feature available with DH5 systems. Decoder outputs
can be used to create an analog composite video signal using any video or combination of video
feeds available to the server. Output is configured through the Aventura software.

DH5 and NVR Series Server Reference Manual 7
Front Panel Layout
(1) (2) (3) (4) (5)
1. DVD/RW Drive
2. USB
3. LED Panel
4. Power Switch
5. HDD Release Lever
Hard Drive Bays
DH5 and NVR Series Servers have 16 HDD bays in the front of the unit. Bays are hot-swappable and can
be released and removed by pulling on the HDD release lever located on the front of each bay.

DH5 and NVR Series Server Reference Manual 8
LED Panel
The LED panel of the unit provides a general indication of the current state of the machine as well as the
ability to reset the machine or silence alarms.
(1) (2) (3) (4) (5) (6) (7) (8)
1. USB
2. Reset Switch
3. Mute Alarm
4. HDD LED
5. Power LED
6. Alarm LED
7. LAN1 LED
8. LAN2 LED
Reset and Mute switches can be operated using a pin-tool. Switches are recessed to prevent accidental
activation.
HDD LED will flicker during hard drive activity.
Power LED should remain active and solid during normal machine operation.
Alarm LED should remain un-lit during normal machine operation.
LAN1 and LAN2 LED will flicker during network activity on the associated LAN port.

DH5 and NVR Series Server Reference Manual 9
Power
Aventura DH5 and NVR Series servers support up to three redundant power supplies of up to 300W
each. Unit requires AC 110V, 60 Hz grounded power source.
COM Port Devices
Aventura software supports communication with a number of external devices using the COM port.
One COM port is included standard as part of the main unit. If additional COM ports are required they
should be added using a standard USB-to-COM Port adapter.
RS-485 Setup
By connecting the optional VID-232485EX adapter to the DH5 Series COM port the unit can be used to
communicate with and operate RS-485 hardware such as PTZ cameras. Please follow instructions
included with the adapter and connected equipment for proper wiring. Connected devices must be
configured in the Aventura software according to the settings outlined in the device manual.
VID-232485EX

DH5 and NVR Series Server Reference Manual 10
Alarm Inputs/Outputs
Aventura software is capable of handling alarms when a DH5 Series server is connected to an external
alarm box. Two alarm boxes are available:
VID-ALARM-8CH-COM has 8 alarm inputs and 8 alarm outputs
VID-ALARM-16CH-COM has 16 alarm inputs and 8 alarm outputs
Alarm boxes should be connected to the COM port of the DH5 unit in accordance with the individual
unit’s installation instructions.
VID-ALARM-8CH-COM
VID-ALARM-16CH-COM

DH5 and NVR Series Server Reference Manual 11
Other COM Port Devices
Configuration options are also available for communication with external PTZ Keyboard Controllers, POS
Systems, Access Control Systems, and other devices. Please contact your Aventura representative to
discuss specific applications.
Technical Support
For difficulties using this unit please contact Aventura technical support at 631-300-4000 or toll-free at
1-877-707-9600. Online support is available at www.AventuraCCTV.com or email
[e-mail]
When contacting technical support be certain to have full details about your Aventura products
available, including model and invoice numbers.
Service
Any service required by this unit should be performed by Aventura or authorized service personnel.
Unauthorized service may invalidate warranties or service agreements. Some service may require
equipment to be returned to Aventura’s offices for evaluation and repair. Be certain to follow proper
packing and shipping instructions for all equipment to prevent damage during transport.
