AVFI CR2-WM User manual

CR2-WM
Instructions
www.video-furn.com 288 Don Hillock Drive |Aurora |Ontario|L4G 0G9 |
1.877.834.3876 Ver. 1.0

Parts
Included
Hardware
Included in HW bag.
Tools Required
Not Included
Washer
x4
LAG
Shield
x4
HEX
Bolt
x4
Hardware Bag
Socket set
LAG Bolt
x4
Toggle
Anchor
x4
Legs
x3
CR2-WM
Credenza
Stud Finder
If Drywall
DrillDrill bit set

Step 1
Unpack and
Lift off front
panels.
Step 2
Attach Legs
Step 3
Locate mounting points
And prepare Wall
Lift off Panels
Twist on legs x3
Baseboard trim
May need to cut away.
Leave Clearance for door.
Drywall/Stud wall
Locate studs using stud finder and mark
Approx 23” above floor height. Follow
Masonry step below to line up studs.
Place over an outlet
If possible.
Masonry wall
Place CR2-WM against wall at desired location
And mark 4 hole locations through holes at
Back of unit.

Step 3 Continued
Attach Fasteners to wall
Drywall/steel stud Wood Stud Masonry
Assembly Instructions
www.video-furn.com 288 Don Hillock Drive |Aurora |Ontario|L4G 0G9 |
1.877.834.3876
1 / 4 “Drill 1 / 2 “ Drill
Lag Shield

Assembly Instructions
www.video-furn.com 288 Don Hillock Drive |Aurora |Ontario|L4G 0G9 |
1.877.834.3876
Step 4
Install Equipment and Sound bar
Shelf is
Adjustable w pins.
Can be removed
If Soundbar is Tall.
3RU
Per side
Max depth 25”
Step 5
Reinstall Panels.
Up to 4x 120mm
Fans can be
Added underneath.
Side doors
For access to
System On/Off
Finished
Thanks for Purchasing AVFI.
Have a great day.
