Aviom A-16D A-Net User manual

A-16D A-Net Distributor
Information in this document is subject to change.
All rights reserved.
Copyright ©2003 Aviom, Inc.
Printed in USA
Document Rev. 1.03 Part Number 9301 1002 0001
For use with the Personal Monitor Mixing System™

3
Aviom, Inc.
1157 Phoenixville Pike - Suite 201
West Chester, PA 19380-4254
USA
610-738-9005 (voice)
610-738-9950 (fax)
www.aviom.com

3
TO REDUCE THE DANGER OF ELECTRICAL SHOCK DO
NOT REMOVE COVERS.
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
ONLY
To reduce the risk of re or electrical shock, do not expose this
product to rain or other types of moisture.
To avoid the hazard of electrical shock, do not handle the power
cord with wet hands.
Operating Temperature: 10˚C to 40˚C (50˚F to 105˚F)
CAUTION
• Using any audio system at high volume levels can cause permanent
damage to your hearing.
• Set your system volume as low as possible.
• Avoid prolonged exposure to excessive sound pressure levels.
WARNING!
!

4
5
IMPORTANT:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to the product not expressly approved by Aviom,
Inc. could void the user’s FCC authority to operate the equipment.

4
5
READ THIS FIRST
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accor-
dance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or
third prong are provided for your safety. If the provided
plug does not fit your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the
point where they exit the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified personnel. Servicing is
required when the apparatus has been damaged in any
way, such as when the power-supply cord or plug is dam-
aged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.

6
7
Aviom, Inc. Limited Warranty
Aviom, Inc. warrants this product against defects in materials and workmanship for a
period of one year from the date of the original retail purchase.
This warranty does not apply if the equipment has been damaged due to misuse, abuse,
accident, or problems with electrical power. The warranty also does not apply if the
product has been modified in any way, or if the product serial number has been damaged,
modified, or removed.
If a defect is discovered, first write or call Aviom, Inc. to obtain a Return Authorization
number. No service will be performed on any product returned without prior authoriza-
tion. Aviom, Inc. will, at its option, repair or replace the product at no charge to you. The
product must be returned during the warranty period, with transportation charges prepaid
to Aviom, Inc., 1157 Phoenixville Pike, Suite 201, West Chester, PA 19380. You must use
the product’s original packing materials for shipment. Shipments should be insured for
the value of the product. Include your name, address, phone number, description of the
problem, and copy of the original bill of sale with the shipment. The Return Authorization
number should be written on the outside of the box.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY
HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE (OR JURISDIC-
TION TO JURISDICTION). AVIOM’S RESPONSIBILITY FOR MALFUNCTIONS
AND DEFECTS IN HARDWARE IS LIMITED TO REPAIR AND REPLACEMENT
AS SET FORTH IN THIS LIMITED WARRANTY STATEMENT. ALL EXPRESS AND
IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING BUT NOT LIMITED
TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY
PERIOD SET FORTH ABOVE. NO WARRANTIES, WHETHER EXPRESS OR
IMPLIED, WILL APPLY AFTER SUCH PERIOD.
AVIOM, INC. DOES NOT ACCEPT LIABILITY BEYOND THE REMEDIES SET
FORTH IN THIS LIMITED WARRANTY DOCUMENT. AVIOM, INC.’S LIABILITY
IS LIMITED TO THE REPAIR OR REPLACEMENT, AT OUR OPTION, OF ANY
DEFECTIVE PRODUCT, AND SHALL IN NO EVENT INCLUDE INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND.
SOME STATES DO NOT ALLOW EXCLUSIONS OR LIMITATION OF IMPLIED
WARRANTIES OR LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAM-
AGES, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
Aviom and the Aviom logo are trademarks of Aviom, Inc.

6
7
Warranty Information
Please record the following information for future reference:
Your Authorized Aviom Dealer:
Name: _____________________________
Address: _____________________________
_____________________________
Phone: _____________________________
Serial Numbers of Your Aviom Products: ____________________
____________________
Date of Purchase: ________________
Your Authorized Aviom Dealer is your primary source for service and support.
The information recorded above will be helpful in communicating with your
Authorized Aviom Dealer should you need to contact Aviom Customer Service.
If you have any questions concerning the use of this unit, please contact your
Authorized Aviom Dealer first. For additional technical support, or to find the
name of the nearest Authorized Aviom Repair Station, check the Aviom web site
at www.aviom.com.
To fulfill warranty requirements, your Aviom product should be serviced only at
an authorized Aviom service center. The Aviom serial number label must appear
on the outside of the unit, or the Aviom warranty is void.
This manual and its contents are copyrighted by Aviom, Inc. All rights are
reserved by Aviom, Inc. This document may not, in whole or in part, be copied,
photocopied, reproduced, translated, or reduced to any electronic medium or
machine-readable form without prior written consent from Aviom, Inc.
The software and/or firmware contained within Aviom products is copyrighted
and all rights are reserved by Aviom, Inc.
Although every effort has been made to ensure the accuracy of the text and
illustrations in this manual, no guarantee is made or implied as to the accuracy
of the information contained within.
A-16 Personal Monitor Mixing System is a trademark of Aviom, Inc.
A-Net is a trademark of Aviom, Inc.
©2003 Aviom, Inc.

8
9
Welcome
Thank you for purchasing the Aviom A-16D A-Net Distributor for use with
your Personal Monitor Mixing System™. This User Guide is designed to
familiarize you with your new product and to have you up and running in no
time.
Features
The A-16D is designed to distribute the A-Net Signal from either an A-16T
Transmitter or another A-16D Distributor. Each A-16D accepts one A-Net
input signal and provides for eight simultaneous A-Net outputs using Category
5 Cables. The A-16D A-Net Distributor enables parallel connection of A-Net
devices, simplifying stage and studio setups.
A-16D Features:
• Easily distribute A-Net from a central location or from other A-16D
Distributors
• One A-Net input, eight A-Net outputs
• Can insert DC power for A-Net devices into the Cat-5 cable
•  rack space footprint – mounts easily on standard rack shelf
• A-Net activity LED on the main input
• DC power indicator LEDs on each output
• Multiple A-16D Distributors can be used in a system
• Uses the same power supply as all A-16 system components
Your Personal Monitor Mixing System provides a host of professional features
designed to make the system flexible in a variety of music and audio situations.
A-16T Transmitter Features:
• Sixteen high-quality audio channels
• Adjustable input gain switches per channel pair
• Eight stereo channel Link switches
• Signal and Peak LEDs on each channel
• Sixteen -inch TRS jacks for audio Input connections
• Sixteen -inch TRS jacks for Thru connections
• Single-ended input accepts balanced or unbalanced signals and can
provide balanced or unbalanced signal pass-through
• 1U-high rack-mountable enclosure

8
9
A-16 Personal Mixer Features:
• Sixteen Channel select buttons with dual LEDs
• Dedicated Recall, Group, Solo, and Mute buttons
• Sixteen user Preset memory locations
• Pan/Spread control with LED readout
• Channel volume control with LED level readout
• Master Volume, Treble and Bass controls
• Tabletop or mic stand mountable (using optional stand-mounting
bracket)
Conventions Used in this Document
When indicating a button or knob on the front panel of any component of your
system, a special typeface is used. For example, when selecting a preset on the
A-16 Personal Mixer, press the RECALL button.

10
11
The A-16D Front Panel
A-Net Input
Power LED A-Net Active LED A-Net Outputs
DC Power available LEDs

10
11
The A-16D Rear Panel
A-16D Power jack
DC Power inputs

12
13
Connecting the A-16D
The A-16D is designed to create a network of A-Net devices. The A-Net signal
appearing at the input of the A-16D is distributed to each of the eight outputs on
the front panel. Devices are connected in parallel rather than in serial fashion.
Connections on the A-16D Front Panel
There are two sets of connectors on the front of the A-16D A-Net Distributor.
They are marked Input and Output.
The Input section accepts the A-Net signal coming from any A-Net device.
This is most likely going to be an A-16T Transmitter in average systems. You
can expand a Personal Monitor Mixing System by using as many A-16D A-Net
Distributors as required.
The Output section sends an exact copy of the input signal in parallel to each of
the eight outputs.
The connections on the A-16D front panel use standard Category 5 cables.
Front Panel LED Indicators
The front panel’s A-Net Input jack contains two LEDs. The yellow LED
indicates that the A-16D is powered on. The green LED blinks to indicate that a
valid A-Net signal is plugged into the Input jack.
The A-Net Output jacks also have an LED. This yellow LED indicates that a
particular channel has DC power available.
Connecting an A-16D to a System
In a simple system containing one A-16T Transmitter and a number of A-16
Personal Mixers, the A-16D A-Net Distributor sits between the A-16T and the
Personal Mixers.
A-Net Input
You can connect a Personal Monitor Mixing System in a variety of ways. In a
typical system, you will have your audio inputs connected to the Input jacks on
the rear of the A-16T. From the A-16T, the A-Net output on the front panel is

12
13
connected to the first Personal Mixer in the system. Each subsequent Personal
Mixer is connected by running a cable from the Mixer’s A-Net Output to the
A-Net Input on the next Personal Mixer. This type of connection is called a
daisy chain.
When using the A-16D A-Net Distributor, the daisy-chain linking of Personal
Mixers is optional. Up to eight Personal Mixers can be connected directly to the
A-Net signal outputs of the front of the A-16D.
To connect the A-16D:
• Connect the A-Net Output on the A-16T Transmitter to the A-Net
Input on the A-16D A-Net Distributor using a Category 5 cable.
A-Net Outputs
The eight A-Net Outputs on the A-16D A-Net Distributor all carry the same
signal. You can use any output to connect a Personal Mixer.
To connect a Personal Mixer:
• Connect a standard Category 5 cable from A-Net Output #1 on the
A-16D A-Net Distributor to the first Personal Mixer in your system.
• Plug the Personal Mixer’s DC power supply into an AC outlet.
At this point the Personal Mixer is connected to the A-Net signal chain. Any
audio appearing at the inputs of the A-16T should be available for mixing in the
Personal Mixer. Refer to the Personal Mixer User Guide for additional informa-
tion about using the mixing features of the A-16 personal Monitor Mixing
System.
Connect additional Personal Mixers using Category 5 cables from an available
Output on the A-16D A-Net Distributor to the A-Net Input on the Mixer.
Connections on the A-16D Rear Panel
There are two groups of DC power connectors on the rear of the A-16D A-Net
Distributor. The right side of the rear panel contains the power input for the
A-16D A-Net Distributor. The left side is marked Optional Remote DC Power.
These jacks are used to power any of the connected Personal Mixers connected
to the A-16D. Up to eight Personal Mixers can be powered in this manner.
Note: The power supplies used with the A-16 Personal Mixers and the A-16D
are interchangeable.

14
15
Powering a Personal Mixer Remotely
There are a number of advantages to adding power for a Personal Mixer at the
A-Net distribution point.
• No DC power supply is needed at the performer’s location
• Power supplies can be located at a central point offstage or in a
machine room of an audio facility.
• A one-cable solution for supplying A-Net and DC power to a
mixing station is possible.
To power a Personal Mixer:
• Connect the A-Net cables as described previously between system
components (from the A-16T to the A-16D).
• Connect the power supply for the Personal Mixer you want to
power remotely to the same numbered DC Power input on the rear
of the A-16D.
• On the front panel of the A-16D note that the yellow channel LED
will light for any channel output that has DC power connected.
• Connect a Category 5 cable from the powered A-Net output on the
A-16D to the A-Net input on the Personal Mixer.
• The Personal Mixer’s A-Net Active LED will light to indicate that a
valid A-Net signal is present.
• Continue connecting up to eight Personal Mixers in this manner.
Note: The DC power supply plugged into the rear panel of the A-16D can
power only one Personal Mixer. If you start a daisy chain from a Personal Mixer
powered from an A-16D, the additional Personal Mixer units will need a source
of DC power.
Each Personal Mixer that is powered remotely no longer needs a power supply
connected to its rear panel. If this happens accidently, however, note that you
cannot harm the system.
Expanding a System
Any number of A-Net devices can be used in a system. This includes A-16D
A-Net Distributors. To expand a system, additional A-16D Distributors can
be connected to any available A-Net Output, such as the outputs on Personal
Mixers or on other A-16D units.
To add another A-16D to a system, simply connect a standard Cat-5 cable from

14
15
the A-Net Output of the first device into the A-Net Input of the A-16D Distribu-
tor you want to use for system expansion.
At this point your audio network has grown to include an additional eight paral-
lel A-Net outputs. You have the option of adding DC power to any or all of the
A-Net Outputs on the expansion A-16D. Follow the instructions in the previous
section.
Rack Mounting
The A-16D A-Net Distributor can easily be mounted in a standard 19-inch
wide equipment rack. The A-16D occupies half of the rack width, allowing two
A-16D units to be placed side by side on a standard rack shelf. These shelves are
available as an accessory from many audio and studio suppliers.
There are two shelf-mounting holes in the bottom panel of the A-16D. The holes
accept a 6-32 size bolt. The depth of the hole in the A-16D bottom panel is 0.25
inches.
CAUTION!
Be careful when selecting mounting hardware for use with your accessory
shelf. Using bolts that are too long can damage the circuit boards of your
A-16D.
Use of improper mounting hardware will void your warranty.

16
Index
A
A-16D Features 8
A-16D Power jack 11
A-16T Rear Panel 12, 13
A-16T Transmitter 12
A-16T Transmitter Features 8
A-16 Personal Mixer Features 9
A-Net Active LED 10, 14
A-Net Input 10, 12
A-Net Outputs 10, 13
C
Connecting a Mixer 12
Connecting the A-16D 12, 13
D
daisy-chain 13
DC Power 13
DC Power available LED 10
DC Power inputs 11
Direct Output 12
E
Expanding 14
F
Features 8
Front Panel 10
Front Panel LED Indicators 12
G
green LED 12
I
Input 12
L
LED Indicators 12
O
Optional Remote DC Power
DC Power
Remote DC Power 13
Output 12
P
Personal Mixer 13
Powering a Personal Mixer 14
Power LED 10
R
Rack Mounting 15
Rear Panel 11, 13
T
Transmitter 12
Y
yellow LED 12
