XVTEC XVC-HEVC User manual

HDMI IN 12G-SDI IN
LINE IN
ETH
0
ETH 1
12-32V DC
HDMI IN 12G-SDI IN
LINE IN
ETH
0
ETH 1
12-32V DC
Product overview
Check kit contents
Power & connect
Connect the video source to the HDMI or SDI
input (optional).
1
RST
SW
PWR LED
ETH0 LED
ETH1 LED
STAT LED
LCK LED
ACT LED
REC LED
USB0*
USB1*
RS-232*
HDMI IN
12G-SDI IN
LINE IN
* Future release
ETH0
ETH1*
12-32V DC
14
15
16
17
18
1
2
5
10
11
12
13
3
8
6
4
9
7
Follow the instructions in this guide in order to quickly prepare your XVC-HEVC for operation.
NOTE: For additional procedures and information refer to the XVC-HEVC Encoder User Guide.
FRONT
XVC-HEVC encoder
Power supply, international cable kit
Four rubber feet pads
Warranty + EULA
2Connect the host PC to the ETH0 port using
a CAT5 LAN cable - either directly or via a
switching hub (network switch).
QUICK INSTALLATION GUIDE
RS-232
USB
1
USB 0
PWR ETH
0
ETH 1
STAT LCK ACT RECRST SW
7654321 12 111098
HDMI IN 12G-SDI IN
LINE IN
ETH
0
ETH 1
12-32V DC
13 1816 1714 15
REAR

HDMI IN 12G-SDI IN
LINE IN
ETH
0
ETH 1
12-32V DC
4Download and install the XVTEC managment
tool from:
http://www.xvtec.com/support/downloads
on a Windows-based OS.
Refer to the user guide for the next steps.
Download the user guide from:
https://www.xvtec.com/wp-content/
downloads/XVC_HEVC/XVC-HEVC_Users_
Guide.pdf
To access and congure the XVC-HEVC using
the web-based user interface, enter the IP
address of the encoder unit in the address bar
of the browser.
7
The main page of the Conguration System
appears in the browser window.
9
8
Execute the XVTEC Management Tool.
The application discovers the devices in your
network and displays them as a list.
You may need to disable Windows Firewall to
enable discovery.
5
Find the row in the table associated with your
encoder. Right-click on the row and select
"Set IP", the Set Device IP dialog box appears.
Select "Static" or "DHCP" IP conguration.
If “Static” is selected, enter the encoder’s IP
Address, Subnet Mask, and Default Gateway
settings. Click Apply to save the new settings.
6
Turn system's power ON by connecting the
power supply to the input power connector
(Note, the power supply is provided with
a locking connector. To lock, plug in the
connector and turn it clock wise).
3
V12
