Avon LFP Series User manual

LFP
AVON
LiFePO4
Lithium Iron Phosphate
Battery (LiFePO4)
AVON LFP User Guide
This guide should be read in conjunction with the appropriate battery’s specication
sheet for any specic requirements, this should be available from your point of
purchase. Alternatively, it is downloadable from www.avonbattery.co.uk
1. All AVON LFP batteries are supplied partially charged. Therefore, please ensure your battery
is fully charged BEFORE it goes into service
2. Your AVON LFP battery can be charged by 99% of all current Lead Acid battery chargers
as the charge is controlled by the batteries internal BMS (Battery Management System),
However, we advise to use a charger that has either an ‘AGM’ or ‘GEL’ setting. If in doubt,
consult your AVON Battery distributor or the Avon Battery web Site
3. The Bluetooth App, where tted, may give inaccurate information for the rst 4 - 10 charge
and discharge cycles. During these initial cycles the BMS is balancing and calibrating the
multiple lithium cells and the App is learning each batteries parameters
4. If you intend to use multiple AVON LFP batteries in series, parallel or both please see page 1
of this manual for detailed instructions
IMPORTANT : PLEASE READ BEFORE USE
Disposal & Recycling
Disposal & Recycling of a used or damaged Avon LFP battery must either be done at a
certied recycling location. There are many of these nationwide or returned to your point of
purchase or directly to Avon Batteries – please see www.avonbattery.co.uk for details.
Warranty
Avon LFP batteries are supplied with a 6-year (except Golf applications which is 3 years)
warranty from the date of purchase (please keep your proof of purchase) or 2000 cycles @ it’s
maximum discharge current (refer to product specication sheet), whichever comes rst and is
dependent upon correct application.
Note: A full cycle is determined by your battery being fully discharged down to 10% of its
designed capacity and then re-charged to 100% capacity. The warranty period assumes no
more than one full cycle per 24hr period.
In the event of a valid warranty claim your supplier will, at its discretion & consultation with
AVON Battery, supply a new or re-conditioned replacement battery dependent on how many
years have passed since the date of purchase or how many cycles the battery has undertaken to
ensure the original intended warranty period is achieved.
Whilst the AVON LFP has a warranty life of 6 years or 2000 cycles, its design life is far greater,
i.e. 3000 cycles @ 80% DOD or up to 6000 cycles @ 50% DOD (Depth of Discharge)
Conditions
1. Any warranty claim will only be validated by a proof of purchase
2. The warranty is invalid if the battery has been subject to misuse, abuse or physical damage
3. Your AVON LFP battery must be of the correct size, design and capacity for the intended
Application
4. The battery should be installed and operated at a temperature not exceeding the batteries design
limits as noted on the full specication sheet
5. The warranty shall become null & void if the battery becomes unserviceable due to misuse or
subjected to instances such as: re, abuse, modication or it suffers from an attempt to be re-
charge in a below zero °C temperature (unless tted with heating) and \or an over discharged
state. This includes the battery being subjected to instance outside of the Cells or BMS
6. Installation of the battery must be performed by a responsible and qualied person
7. Warranty is not transferable
In The Event Of A Warranty Claim
1. Contact or return to the original point of purchase
2. If returning via a courier service, the battery must only be returned in compliance with the
transport and packaging regulations ruling at the date of return. Failure to do this may result
in the carrier refusing to handle the battery
3. Warranty is on a ‘Return To Base’ basis to your place of purchase
Safety and Product Limitations
• Keep out of the reach of children
• Do not under any circumstances disassemble this battery
• Do not immerse the battery in liquid
• Do not use the battery with damaged cables or terminals
• This battery is not designed for high rate discharge applications
• Do not expose the battery to re or crush or puncture its casing
• Do not mix an AVON LFP battery with any other brand of Lithium OR Lead Acid batteries, in
any series or parallel conguration and do not mix new batteries with used batteries
Limited Liability
The manufacturer nor any of its employees, agents, distributors or resellers are liable for any
third-party damage howsoever caused. The extent to which the manufacturer is liable to a
customer is limited to the purchase price paid by the customer for their AVON LFP battery
More information can be found via the AVON Battery Website
www.avonbattery.co.uk
UN38.3

The App is available for all Apple and Android devices. Search the Apple
or Android App stores for AVON LFP and download for free. You can also
download the Android App directly from www.avonbattery.co.uk.
The App will give you visibility of your AVON LFP battery and its
performance. The App works via Bluetooth so you need to be within 10m
of the battery to access it.
If you are using more than one AVON LFP battery, you are only able to identify each battery
by the use of its serial number in the same way as if you are using a single battery
All batteries will appear in the search list if they are near to one another
This applies where you are using banks of batteries whether they be in Series, Parallel, or
Series\Parallel configurations
Viewing of battery banks as a whole is planned in a later revision of the AVON LFP App
If you have any questions about this connectivity, please speak to your distributor or visit
www.avonbattery.co.uk
NOTE – only one Apple/Android device at a time can be connected to each battery
NOTE – do not mix new AVON LFP batteries with old batteries,or batteries of different
technologies including lead acid, whether in series or parallel
Storage of AVON LFP
Your AVON LFP battery has an extremely low rate of self-discharge but if you intend not to
use the battery for an extended period of time please fully charge it prior to storage. It is
recommended to re-charge it once every 6 months
NOTE – allowing the battery to over discharge (+6 months since its last charge) can lead to a
shortened life. When connecting to the AVON LFP use the nuts and washers provided
Thank you for purchase of an AVON LFP lithium iron phosphate (LiFePO4) battery
You MUST ensure your battery or batteries are fully charged before use
• Always ensure you take care to connect your battery or batteries in the right way, paying
special attention to the Positive (+) & Negative (-) terminals and connections
• Don’t short circuit your battery otherwise permanent damage could be caused
• Avoid placing your battery in direct sunlight although it will work well in a wide temperature
range (-20 to +60 degrees C)
• Avoid using in damp or wet conditions unless using an all-weather enclosure such as a
battery box
• AVON LFP batteries can be connected and used in Series or Parallel congurations, OR
Series\Parallel combination congurations (Please see the appropriate Specication Sheet
for more details)
• If you are using more than 1 AVON LFP battery in a bank, please ensure they are the same
capacity and state of charge, and preferably balanced to within 0.05v of each other to
achieve the best results
• Whilst your AVON LFP battery will work in any orientation except upside-down, for the best
performance of your AVON LFP battery, it is best for it to be positioned with its terminals
facing upward
Most Mains lead acid battery chargers will charge your AVON LFP battery but some chargers
that are smart chargers or those that have multiple stages (more than 3) may only show a state
of charge up to 90%. If this is the case, we recommend speaking to your supplier for advice on
alternative chargers. However, you will not cause any damage to the battery if using your old
charger.
Below are important points on how to get the best from your AVON LFP battery
Example layouts are as below:
Series
24V
100Ah
Parallel
12V
200Ah
Series / Parallel
24V
200Ah
12V
100Ah
12V
100Ah
12V
100Ah
12V
100Ah
12V
100Ah
12V
100Ah
12V
100Ah
12V
100Ah
Accessing the AVON LFP App
LFP
AVON
For further information visit : WWW.AVONBATTERY.CO.UK
PART NUMBER Volts Ah DIMENSIONS (MM)
ALFP1212 12.8 12 151 X 98 X 101 (LxWxH)
ALFP1224 12.8 24 181 X 77 X 167 (LxWxH)
ALFP1236BT 12.8 36 195 X 133 X 171 (LxWxH)
ALFP1284BT 12.8 84 260 X 169 X 218 (LxWxH)
ALFP12100BT 12.8 100 328 X 172 X 220 (LxWxH)
ALFP12120BT 12.8 120 355 X 175 X 190 (LxWxH)
ALFP12150BT 12.8 150 483 X 170 X 240 (LxWxH)
ALFP12200BT 12.8 200 522 X 238 X 218 (LxWxH)
ALFP2440BT 25.6 40 260 X 168 X 209 (LxWxH)
GOLF SPECIFIC PART NUMBERS
ALFP1218G 12.8 18 168 X 128 X 75.5 (LxWxH)
ALFP1225G 12.8 25 168 X 128 X 102 (LxWxH)
PRODUCT SUPPORT
LFP
AVON
AVON Battery
AVON LFP
Lithium Iron Phosphate
[e-mail]
www.avonbattery.co.uk
In any tment where charging is via a dynamo or alternator, it is strongly advised to t a DC-
DC charger to control voltage. In systems that use a ‘Smart Alternator’ or where the voltage is
above 15v for a 12v system or multiple’s thereafter for series banks, a DC-DC charger MUST be
tted to avoid the BMS shutting down to protect the battery.
*12.8V for 12V nominal & 25.6V for 24V nominal
