AVS SCOPE212VIR3 User manual

4. Interface & IP Initization
IP Initialization
Dimension
3. Specification 5. IP Manager
3 MEGA PIXEL
HD NETWORK
IR DOME CAMERA
USER’S MANUAL
Design and specifications are subject to change without notice.
HD NETWORK IR DOME CAMERA
IP3-003
10) Check the Status
11) Try again for the failed cameras
8) Conrm if the changing values are correct.
9) Click Change
6) If you want to change many IP addresses, you can enter the starting
IP address and the ending IP address, and enter each increasing step.
7) Click Save
5) Click Batch
You can do all the settings about network by IP Manager.
1) Run IP Manager
2) Click Find
3) Choose the cameras you want to change
4) Click Change
CAMERA SECTION
IMAGE Image Sensor 1/2.8” Sony Exmore 3MP Image Sensor
Scan System Progressive Scan
Total Pixels 2144(H) x1588(V), 3.40 Mega Pixels
Eective Pixels 2048(H) x1536(V), 3.14 Mega Pixels
Function Day & Night Auto/Day(Color)/Night(BW)
Privacy Area On/O (6 Programmable Zone)
WDR DWDR (1~5Step)
DNR 1~63
Motion Detector 48 Zone (On/O, 1~5Step)
Elec. Shutter Auto(1/15~1/10000),
Suppress Rolling, Manual
Sense Up 1~6 Step
White Balance Auto/Indoor/Outdoor/Fluorescent
Ext. Video VBS1.0Vp-p
Lens Focal Length 2.8~10 Mega Lens
IR LEDs IR LEDs 35 units
Night View Distance 25m
Electrical Power Supply DC12[V] ±10% / POE
Current Max 650mA
Environmental Operating Temp. -10 ℃ ~ +50 ℃
Preservation Temp. -20 ℃ ~ +60 ℃
Humidity 0% ~ 90%
Mechanical Weight Approx. 1,050 g
NETWORK SECTION
System OS Embedded Linux
Network Interface RJ45 100/100 Base-T PoE
Protocol TCP/IP,UDP/IP,RTP,RTSP,RTCP,NTP,
HTTP,DHCP,FTP,SMTP,DNS,DDNS
Onvif ver2.0
DDNS iplinker.net
Simultaneous Access Max. 10 user
Video Compress Format H.264/MPEG4/MJPEG
Resolution 2048×1536/1600×1200/1920×1080/
1280×1024/1280×720/640×480
Frame rate 5fps ~ 15fps @ all resolution
Video Quality H.264,MPEG4 : Bitrate Control
MJPEG : Quality Level Control
Streaming Triple Stream (Stream1,2,3)
RTP/RTSP, UnicastRTP, Multicast RTP
Audio Compress Format G.711 u-law
Streaming Two way
Event Sensor In 1 (Digital Input)
Alarm Out 1 (Digital Outut, Open Collector)
Web Manager IE, Firefox, Safari, Opera
Browser Viewer IE only (Active-X)
IP Address 192.168.1.30
Gateway 192.168.1.1
Subnet mask 255.255.255.0
I D admin
Password admin
Web Port 80
RTSP Port 554
unit :mm
Factory
Default
* You should change the ID and Password after purchasing.
* You will be responsible for all the damages unless you change the ID and
Password.
Service Video
Power
Audio Out(yellow)
GND (Black)
Audio In(White)
LAN Cable
Sense In (Yellow)
GND (Black)
Alarm 12V Out (Red)
Alarm Out (White)
■ Sony 3Mega Pixel Image Sensor
■ Triple Codec (H.264/MPEG4/MJPEG)
■ Triple Stream
■ Support Onvif
■ Support POE
■
IR LED : 35 units 850nm Infrared LED, 20,000hrs
■ Night View Distance : Indoor 35 / Outdoor 25m
■ Sense-Up (x6)
■ True Day & Night(ICR)
■ True 3-Axis Easy Ball type Gimbal Bracket built-in
■ Built-in Heater & Blower
■ Weatherproof (IP68)
9)
8)
6)
7)
2)
3)
4)
2)
3)
4)
Components & Dimension
SCREW
SIDE CAP
Mounting Template
Manual
L-WRENCH
SUPER
WDR/3DDNR
DOMECAMERA
USER’SMANUAL
SUPER WDR 3D DNR
■
■
■
■
■
■
■
■
■
■
■
■
■
Sony1/3”ColorVerticalDoubleDensityCCD
Sony1/3”SuperHADIICCD
960HCCD(700TVLines)
HighResolution600TVLines
HighResolution700TVLines(960H)
WDR(WideDynamicRange)
3DDNR(DigitalNoiseReduction)
Sens-UpFunction(x512)
EclipseFunction
RS485(PELCO-D)Optional
UTPInterfaceOptional
Heater&BlowerOption
35pcsIRLEDVandalDomeCamera or
Non-IRLEDVandalDomeCamera
FlushorSurfaceMountingType
True3-AxisEasyBallTypeGimbalBracket built-in
IP67rateWaterproofDesign
70.0
109.0
MountingTemplate
SurfaceMount
Surface Mount
3/4” Cap (2EA)
Plastic Anchors
Surface Mounting Screws
M4 x 30
10
11
12
13
14
15
16
1Bubble
Dome Cover
2
Assembly Torx Screw
M4 X 9(3EA)
Flush Mount Base
7
8
9
Heater & Blower Board
(Optional)
Assembly Screw(Surface Mount)
M4 X 10 (4EA)
Lens
3
Bracket
6
Surface Mount
Fix Screw
LEDs
4
Gimbal
5
Safety Cable
1. Names and Functions of Parts 2. Installation
Surface Mount Installation
UNLOCK LOCK
STEP :
1. Mount the surface mount
plate to a sturdy surface or
wall with the installation
template (mouting screws
M4 x 30).
2. Connect the pre-drilled two
screws in the flush mounting
ring through the locking
hole( ) and turn it
counterwise for the
temporary locking system
before drilling four screws
(M4 x 10) of flush mount ring.
Please check if the symbol
in the surface mount ring and
the square hole ( ) in the
flush mount ring meet in a line
when it is locked.
3. Screw with four screws
(M4 x 10) from flush mount
ring to be mounted with the
surface mount.
4 .
Adjust the lens focus and zoom
of camera to monitor the objective.
5 . Fit three screws(M4 x 9) from dome
cover ring to the flush mount ring
and fix it by (3) screws. When you fit
the dome cover ring please fit the
symbols in the line.
1
2
3
1
2
3
Surface Mount Ring (Symbol)
Flush Mount Ring Square Hole
Dome Cover Ring (Symbol)
70.0
109.0
9.0°
174.7
85.1
91.3
R101.6
R51.6
9.9
4.5
56.7
PF 3/4”
113.0

7. Web Manager
8. Web Viewer
6.Web Viewer
9. Web Manager How to set WDR
If you want to watch the more clear image under back light condition,
you can do setting as below, and choose the step and click Save.
* You should check the pictures after click the Save button.
Case 3
Frame Rate 15[fps]
Bit Rate 2000[Kbps]
The pictures transferred per 1 sec. is decreased from 30 to 15.
The date size transferred per 1 sec. is decreased from 4000[Kbps] to 2000.
Picture quality is same, network load will be decreased from 4000[Kbps] to
2000, by half.
Therefore you should change both frame rate and bit rate.
Refer to below bit rate and frame rate example for your easier understanding.
Current Status
Frame Rate : 30[fps]
Bit Rate : 4000[Kbps]
Case 1
Frame Rate 15[fps]
Bit Rate 4000[Kbps]
The pictures transferred per 1 sec. is decreased from 30 to 15.
The date size transferred per 1 sec. is maintained on 4000[Kbps]
Picture quality will be better, and network load will be same.
Case 2
Frame Rate 30[fps]
Bit Rate 2000[Kbps]
The pictures transferred per 1 sec. is maintained on 30.
The date size transferred per 1 sec. is decreased from 4000[Kbps] to 2000.
Picture quality will be worse and network load will be decreased from
4000[Kbps] to 2000, by half.
Frame rate / Bit rate adjustment
If there is a rolling picture under lighting, you can use this Suppress rolling function.
If you choose “Strong”on Suppress Rolling function, electric shutter will be xed at
1/15 ~ 1/120 sec. you should be careful when you use it under bright lighting.
Click Help ( ) for more details.
Suppress rolling
4) After Update completed, click Restart
3) Wait until Update completed
* Don’t click any buttons when it is being updated.
Update is needed to improve the functions and quality.
1) Click the nd and choose the update le.
2) Click Update start and wait until Wait Downloading appears.
* Don’t click any buttons when you are waiting.
How to update the rmware
When it is working ne under LAN condition, but not working under WAN,
and the camera cannot receive the correct time from NTP server,
Check the network setting and change
You can control all the functions through Web Manager log on.
When you use, you should change ID and Password and don’t open for secure use.
1) Enter ID / Password
2) Click Manager
1) Stream : Choosing stream, displaying the status of chosen stream
2) Viewer Size : Choose the size of window
3) Disconnect : Disconnect the camera
4) Save : Record the current moving picture in AVI le format.
5) Capture : Save the current still picture in BMP le format.
6) Path : Choose the directory to Save, Capture
7) Audio On : Turn On/O Audio
Audio should be On at setting.
Web viewer functions
Install Active-X
You can connect the web server inside the camera and check the picture.
First enter the address on internet explorer.
1) Enter ID / Password
2) Click Viewer
ID
Password
admin
3) 4)
Image Mirror
WDR
Normal
Enable
WDR
Step 1 Step 2 Step 3 Step 4 Step 5
Save
Ligth Compensation
Back-light Front-light
1280x1024
640x480
Input 1
Input 2
Stream Source Codec show / hide
Save
Stream 1
Stream 2
Stream 3
Input
Frame Rate(fps)
Key Frame
Bit Rate(Kbps)
30
30
4000
(1~15)
(5~30)[15]
(64~12000)[8000]
Rate Mode VBR
None MJPEG
Frame rate(fps) 5 (1~15)
Quality 50 (5~80)[50]
None MPEG4
Frame Rate(fps) 15 (1~15)
Key Frame 30 (5~30)[15]
Bit Rate(Kbps) 4000 (64~12000)[8000]
( ) : Value Range [ ] : Default Value
Rate Mode VBR
H.264
Resolution
Stream Setting
1)
2)
3)
1)
5)
4)
2)
3)
1)
2) ID
Password
admin
1)
2)
3)
4)
5)
1)
4)
6)
2) Assigned IP
IP Address
DNS
3)
5)
192.168.1.30
MAC
Dynamic(DHCP)
Static
IP Address
Subnetmask
Gateway
1’st DNS 168.126.63.1
2’nd DNS
192.168.1.30
255.255.255.0
192.168.1.1
40:04:0C:01:00:AA
1)
2)
Shutter Speed
Auto
Suppress Rolling(60Hz)
User
weak
Shutter Speed 1/60
strong
(-)
(2)
(+)
AGC
2)
3)
4)
1)
