AVS SENS212WIR Assembly instructions

FEATURES
1. Bestsensitivityintheworld (0.00004lux F#1.4 50IRE)
2. 700TVlineinB/Wand580TVlineincolor.
3. Suitablefor24hourssurveillancewithDSSandICRfunctions.
4. IP66certifiedandairventilationismiximized.
5. Thisproductismadeofcorrosion-freesurfacetoresist
rustandcorrosionforalongtime.
6. Thiscamerahasaspeciallenswhichalwayshasacorrect
focusregardlessIRlightorvisiblelight.
7. Power&videocablesareconcealable.(Cablethroughbracket).
8. Allthefuncitonsarecontrolledthroughdooronthebottom
9. Full3axisbracketbuilt-in(Ceilingmountandwallmountavailable)
212WIR
Quick Manual

Configuration
Adjustthepositonofsunvisor
Controllens,dipswitches
Jointfor3axis
PanningJoint
TiltingJoint
Video
12VDC
24V AC
Splitglasstopreventreflection Ventilationholesto
preventcondensation Positionthesunvisorto preventdirectsunshine Extravideooutputforinstallation
1.Donotdisassembletheunitbyyourself.Whenthereisproblemwiththeunitpleasecontactafter-saleservicecenterortheshopwhereyoubought.
2.Useonlyregulatedpowersource.
3.Donotdisassembleorre-modelthecamera,itcouldcausefire,electricshockorotherhazards.

Connectingthepowerandvideo
Quickinstallation
Opentheboxandcheckthecontents
1. SCREW3EA / 2. WRENCH / 3. EXTRAVIDEOCABLE / 4. MANUAL
Bracketadjustment
Adjustthisjointtoinstallitonthewall Tiltingadjustment
Panningadjustment
Video
12VDC
24V AC

Adjustingthecontrolpanel
Menusetting
1. LED:OFF,ON
2. LED-ON:Fast,Slow
3. LED-BEAM:Low,Hi
4. E-VBS
YoucanturnontheLEDsoroffcontinuously
Fast:LEDswillbeonataround6lux
Slow:LEDswillbeonataround3lux
Low : Wide IR Beam with 65ft range
Hi : Narrow IR Beam with over 65ft range
Extravideooutput forinstallation
MainMenu
1.LENS:DC(PUSH),MANUAL
2.EXPOSURE:PUSH :SHUTTER,BRIGHTNESS,AGC,SENS-UP,BLC,D-WDR, RETURN
:SHUTTER : AUTO,FLK,MANUAL
:BRIGHTNESS :Adjust thebrightnessoflens
:AGC(AutomaticGainControl):High,Middle,Low, O
:SENS-UP: AUTO,OFF
This functioncanaccumulatethelightingbyx256tomakethepicture brighter.
:BLC:OFF,BLC,HSBLC (HighSuppressBLC)
HSBLC :Thisfunctioncanmakemaskingofhighlighting,likecarheadlighting.
:D-WDR(DigitalWideDynamicRange),OFF,INDOOR,OUTDOOR
This functionmakethecamerawatch bothbright anddarkareaatthesametime.
INDOOR:When youinstallthecamera indoorusingD-WDR.
3.WHITEBALANCE :ATW,AWB,AWC-SET,MANUAL,INDOOR,OUTDOOR
:AWB(AutomaticWhiteBalance):Automaticallyadjust whitebalanceaccording
tocondition.
Thismodeisrecommendedinmostcases.
:AWC-SET:Tondtheoptimalsettingonlyundercurrentcondition
Face thecameratowardwhitepaperfully andpressthebutton.
4.DAY/NIGHT : COLOR,AUTO,EXT, B/W
:AUTO:DELAY,S-LEVEL,E-LEVEL
Automaticallycolor changestoB/Waccordingtothelighting
DELAY:Settingdelaytimetochange colortoB/W
Factorydefault:5meansabout5seconds,no.meansseconds.
S-LEVEL :SettingstartingleveltochangecolortoB/W
Factorydefault:70meansabout3lux. Don'tchangeit(Technicianonly)
E-LEVEL:SettingendingleveltochangeB/Wtocolor
Factorydefault:50meansabout6lux, Don'tchangeit(Technicianonly)
5.3DNR: ON,OFF (DigitalNoise Reduction)
:ON:Toreducenoise onthescreen.
6.SPECIAL:CAMTITLE,D-EFFECT, RS485,MOTION,PRIVACY,SYNC,LANGUAGE, RETURN/END
:MOTION:OFF,ON Totransmitasignalwhenitdetects motiononselectedareas.
:PRIVACY:OFF,ON Tomaskareasyouwant,upto8 areasselectable.
:LANGUAGE: ENGLISH, KOREAN,JAPANESE,CHINESS(canbeadded byrequests)
7.ADJUST: SHARPNESS,BLUE,RED,RETURN/END
8.RESET:FactoryReset
9.EXIT:TonishOSDsetting
*PushtheSETbutton>menuopen
*Icon hassubmenus. Pressthesetbutton
toentersubmenus.
*Icon---meansitisnotavailableduetosetting
options.
1.UpandDown:MoveCusor
2.LeftandRight:Value
3.LeftandRight
>
Push
>
Menu
>
Value
4.END:Push
>
Previous
Quickinstallation

245.8
155.0
138.1
166.0
Power
Min.illumination
Gamma
CCDLevelControl
H-Resolution
S/N Ratio
Image Sensor
EffectivePixels
Sync System
MODEL
Model Number
LENS
Weight
Outside
Control
ScanningFrequency
ShutterSpeed
VideoSystem
ScanningSystem
NTSC PAL
DualVoltage:12V DC 1.5A +/-10%/24VAC
1/3 Inch, Sony CCD ( ICX638 / ICX639 )
SENS212WIR
Net:2.86 lbs
Far-Nearcontrol lever
Tele-Widecontrollever
LEDONLuxSelectDIPSW
LEDBeam Low/HiSelectDIPSW
OSDControlbuttons
Extravideoout
Vari-focalLens(2.8mm~12mm)
768(H)X494(V)
NTSCTVSystem
525Lines 2:1 Interlace
15.734[Khz]/59.94[Hz]
1/60~1/120,000sec
752(H)X582(V)
PALTVSystem
625Lines 2:1 Interlace
15.625[Khz]/50[Hz]
1/50~1/120,000sec
Internal Sync
Morethan560TVLines, B/W700TVLines
52 [dB]/ AGCO
0.00004Lux(F1.4/50IRE)
0.45 Approx
ALC(autoirislenscontrol)
High/Middle/Low/Off(Selectable)
Off/Auto (Selectablelimit x2~x256)
On/Off
OFF/INDOOR/OUTDOOR
OFF/BLC/ HSBLC
LevelAdjustable
GainControl
Sens- Up
3DNR
D-WDR
BLC
Sharpness
WhiteBalance
C.VideoOutput
ATW/AWB/AWC-SET/Manual/Indoor(4500'K~8,500'K)
Outdoor(1800'K~10,500'K)
VBS1.0Vp-p/75ohm
Video:0.7Vp-p / Sync:0.3Vp-p/Burst:0.3Vp-p
-10℃~+50℃
OperatingTemp.
SPECIFICATION
Dimension
IR Range 200FTMaxwithLEDBeamsettingon“High”
Max.1.5A whenLED on
Dimension 3.27”x3.23”x6.54mm
PrivacyZone O /On[ 8 Zones]
Mirror O/ On[H - Rev/V - Rev]
