Avue AV762WDIR Guide

AV762WDIR
1.
Hood
2.Camera body
PRECAUTIONS
FEATURES
PARTS INSTRUCTION
3. Back cover
1
3
2
4
4. 3 axis bracket
5
5. OSD(take off the back cover)
6.Four install screws holes
(at bottom of the bracket)
6
ZO O M
FO C U S
DOW N
RIGHT
LEF T SET
UP
DESCRIPTION
1. Use the Appropriate Power Supply
The input power for AV762WDIR is DC 12V. Be sure to connect it to the appropriate power.
2. Do not attempt to disassemble the camera.
To prevent electric shock, do not remove screws or covers. There are no user serviceable
parts inside.Ask a qualified service person for servicing.
3. Handle the camera with care.
Do not abuse the camera. Avoid striking, shaking, etc. The camera could be damaged
by improper handling or storage.
4. Do not expose the camera to rain or moisture, or try to operate it in wet areas.
Do not place the camera in the following locations:
Locations where temperature is lower than -20 C or higher than 55 C;
Locations where humidity is higher than 90%;
Locations where there are large amounts of water vapor and steam.
5. Clean the CCD faceplate with care
When cleaning the CCD panel, do not use strong or abrasive detergents. Use a piece
of lens cotton tipped applicator and ethanol. tissue or
6. Do not attempt to aim the camera at the sun
Do not attempt to aim the camera at the sun or other extremely bright objects that cause
smear to appear irrespective of whether the camera is operating or not. This can
damage the CCD(Charge Coupled Device).
7.Do not put the camera in a place with interference.
When this camera is installed near the equipment like wireless communication device
that strong electromagnetic field, some irregularity such as noise on monitor emits
screen may happen.
Wrong connection may cause malfunction and /or damage to the video camera.
1. 1/3” 960H CCD；
2. High resolution, 700TVL, true color reducibility.
3. Support 2DNR
4. WDR
5. IR SMART control
6. Waterproof design
7. 3-Axis directional bracket, for adjusting camera angles, simple operation
8. OSD menu
SONY
AV762WDIR has advanced image technology with resolution as high as 700TVL,true color
reducibility;Support 2DNR, WDR, IR SMART control, AV762WDIR comes with a powerful OSD
menu that include motion detection, privacy mask, HLC, BLC, multiple languages, and other
functions. A waterproof combined with a 3-Axis directional bracket allows for customized viewing
and 24 hour monitoring,simple operation.

OSD function set:
SET:choose function or back to last level.
Up/down:Up or down to move vertically.
Left/right:to move left or right horizontally or modify parameters
1 Using the foam pat to locate holes in the wall
2
3
Drill 4 holes in the position needed in accordance with the installation hole on the
subpanel of the bracket,push the expansion bolt inside then tighten the screws,make
the installation hole aim at the four screws and fix it.
Camera installation
Appearance size
Setup Menu operation
Specifications
*Specifications subject to change without notice
In camera the key to set the camera
Main menu
HandleB
(adjustthefocus)
HandleA
thedistanceofimage)
Z O O M
FOCUS
D O W N
RIGHT
LEFT S E T
U P
ZO O M
FO C U S
DOW N
RIG H T
LEF T SE T
UP
Get the wire out from the bottle of the bracket.
Assembly instruction of 3D cable bracket
Fixed loop Screw 2
Screw 3
Screw 1
L-shape spanner
Figure 1
Take the screws out of the accessories pouch and use L-shape spanner
to assemble, as shown in the figure 1
Adjustment instruction of 3D bracket
Figure 2
Screw 1
360 rotation°
As shown in the figure 2, loosen
the screw 1 to rotate 360°
Figure 3
Screw 2
Fixed loop
360 rotation°
As shown in the figure 3, loosen the screw 2
and the fixed loop to rotate 360°
As shown in the figures 4 and 5, loosen the screw 3 to
from up to down or from left to right
rotate 180°
Screw 3
Figure 4
180 vertical rotation°
Screw 3
Figure 5
180 horizontal rotation°
259.3 mm
173 mm
131.7 mm
76.7 mm
◆DC
◆AGC
◆WDR ◆RETURN
◆ATW ◆ANTI.CRL
◆AWB ◆MANUAL
◆AWC→SET
◆HLC ◆BLC
◆OFF
DAY&NIGHT
◆AUTO ◆COLOR
◆EXT ◆B/W
DPC
◆START ◆DPC VIEW
◆LS VALUE ◆DIFF
◆AREA HS ◆AREA HE
◆AREA VS ◆AREA VE
◆RETURN
SPECIAL
◆CAM TITLE ◆MOTION
◆PRIVACY ◆PARK.LINE
◆IMAGE ADJ. ◆COMM ADJ.
◆LANGUAGE ◆VERSION
◆SAVE ◆NOT SAVE
◆RESET
◆MANUAL
EXPOSURE
◆SHUTTER
WHITE BAL
BACKLIGHT
LENS
EXIT
Pick up device
Effective pixels
Scanning system
Sync. System
Resolution
Lens
O.S.D
White balance
AGC
HLC/BLC
NR
Mirror function
Image adjustment
Motion detection
Privacy zones
Day & night
S/N ratio
Electronic shutter
Video output
Min. Illumination
Power supply
Current consumption
Operation temperature
Dimension
Weight
Contrast/Sharpness
2:1 interlaced
Internal
Built-in
ATW/AWB/AWC->SET/ANTI.CRL/MANUAL
ON/OFF/AUTO
2D noise reduction
ON/OFF
Off/on(4 areas)
Auto / B/W / Exton / Color
Auto(1/60(1/50)~1/100,000)/Fixed/Manual
1.0Vp-p composite video output, 75Ω
0 Lux(IR on)
Off/on(8 areas)
High, Middle, Low, Off
IR distance 20~30M/
WDR ON/OFF
76.7(W)*131 7(H)*259 3(L)mm. .
NTSC:976(H)*494(V)
700 TVLines
PAL:976(H)*582(V)
1/3" Sony 960H CCD
2.8-12mm
more than 52dB (AGC off)
