AWOW MP16 User manual

User Guide for
Computer Stick
www.awow-tech.com

Service to ensure
Thank you for purchasing this product, you can enjoy parts
and labor warranty service providing by our company for
one year .
The following conditions led to the service from our
company, the costs will be charged ：
·Not in accordance with product manual operation or
improper operation of instructions .
·Man-made damage, computer viruses, moisture, improper
installation or disassemble the software and so on.
· Fires, floods, storms, earthquakes and other force
majeure.
·Accessories, supplies, natural wear and tear caused by
use.
·The need to re-install the software on behalf of the
Company or adjust computer settings, will be charged as
appropriate.
·Our warranty identification damaged or dirty, making it
impossible to identify.
Before the product repair, please back up your information
and files separately, the repair process may affect the
integrity of the data.
We guarantee service, to make you buy it with satisfy.

Product Interface Description
①、
Power Button
②、
USB power supply connecting hole
③、USB3.0
④、
HDMI(Please connect to the display device)
⑤、
LED(The power indicator light)
⑥、
Micro USB2.0
⑦、
Micro SD （Storage expansion interface）

Product Specifications
Remarks:
1. Low-power radio motor for certified products,
unlicensed, companies, businesses, or a People are not
allowed to change the frequency, increase the power or
change the features and functions of the original design
2. Low frequency radio motor shall not affect the flight
safety and interference legitimate communication;When
there is interference it should be immediately suspended
and improved to no interference. Legal correspond refers
to wireless correspond, low-frequency radio work must
be able to tolerate legal communications or industrial,
scientific and medical radiation power radio waves.
3. Product contains miniature battery using by motherboard
CMOS, do not replace them yourselves; If Consumers
replace the incorrect type of battery ,might led to
dangerous issues, properly deal with the replace
battery.
Processor Intel®AtomTMZ8350
Operating
Support Windows 10
Memory 2GB DDR3
Storage
32GB eMMC
Expansion
Micro SD，Max 128GB
Display
HDMI
Wireless
WiFi 2.4GHZ, 802.11 b/g/n；Bluetooth
USB interface USB3.0×1，Micro USB2.0×1
Power input Micro USB interface
Power supply 5V/2.5A

Package Contents
1）、 Intelligent Computer stick
2）、 Adapter \ USB cable
3）、 OTG cable
4）、 HDMI cable
5）、 User Manual
Instructions
1、
Connect Directly to a Display

Plug the AWOW Compute Stick directly into a standard HDMI port
on a television or monitor.
The AWOW Compute Stick extends about 4 inches (102 mm) out
from the HDMI port.
2、
Connect to a Display with the HDMI Extender Cable
If space is limited around the HDMI port, use the flexible HDMI extender
cable that came in the box.
1）、Plug the AWOW Compute Stick into the female end of the extender cable
(A).

2）、Plug the male end of the extender cable into the HDMI port on the
television or monitor (B).
For a list of tested televisions and monitors, go to the Tested
Peripherals page on the support site.
3、
Powering the Device
Using the AC Adapter
Connect the power adapter to the AWOW Compute Stick as shown.

Note The Intel Compute Stick starts automatically when power is applied.
Shut down the AWOW Compute Stick using the normal shutdown process for
Windows* 10.1.
Subsequent power-ups are done by pressing the power button on the side of
the AWOW Compute Stick.

Using USB Port
If a television or monitor has an HDMI port and a USB port, you can try using
the USB port to power the Intel Compute Stick.
The Intel Compute Stick is designed to use up to 10 W of power. If the
television's USB port can supply enough power, you can use it to power the
Intel Compute Stick. A USB 2.0 port normally supplies 2.5 W of power.
To use the USB port:
1. Plug the micro USB end of the 3-foot USB cable into the
Intel Compute Stick.
2. Plug the standard USB end of the cable into the USB port
on the TV or monitor, instead of using the AC power
plug.

Caution
Do not power the Intel Compute Stick with the AC
power adapter and a USB port at the same time.
If the USB port does not supply enough power, these are the likely
symptoms:
•It will not turn on.
•It turns on, but does not complete the boot process.
•It turns on, but the operating system does not load.
•It turns on and the operating system loads, but it
performs very slowly, reboots, or locks up.
4、
Connect a Keyboard and Mouse
The AWOW Compute Stick supports the following:
•USB wireless keyboard and mouse, using a USB dongle.
•USB wired keyboard and mouse, using a USB hub.
•Bluetooth* keyboard and mouse.

Follow the instructions that came with the keyboard and mouse to pair them
with the AWOW Compute Stick.
Note
•You might need to temporarily connect a
wired mouse and keyboard to the Intel
Compute Stick to pair Bluetooth devices.
•Bluetooth devices that pair directly to the
onboard Bluetooth do not work during POST
or in BIOS.
Wireless keyboard and mouse connection example:

Bluetooth keyboard and mouse connection example:
Note Keyboard and mouse are not included.
For a list of tested keyboards and mice, go to the Tested Peripherals page on
the support site.
5、
Use the USB 2.0 Port
Use the USB 2.0 port to:
•Install software from a CD or DVD in a USB optical drive.
•Back up or access media files (such as music and photos)
on an external USB flash drive.

Note USB flash drive and USB cable are not included.
For a list of tested USB devices, go to the Tested Peripherals page on the
Support site.
6
、
Connect a USB Hub to the USB 2.0 Port
Connecting a USB hub to the Intel® Compute Stick provides more USB
ports.

Note USB Hub and USB cable are not included.
For a list of tested USB hubs, go to the Tested Peripherals page on the
Support site.
7
、
Use the MicroSD Card port
The AWOW Compute Stick supports MicroSD card sizes from 8 GB to 128 GB.
Note MicroSD card is not included.
For a list of tested Micro SD cards, go to the Tested Peripherals page on the
Support site.
8、
Secure the AWOW Compute Stick
Install a security cable loop in the security opening on the edge of the
AWOW Compute Stick. The security opening is 3 mm x 3 mm.

Note
Security cable loop is not included. You can build one using a
length of quality wire rope that is less than 3 mm. Insert the rope
through the security opening and then crimp the ends together
with a cable sleeve.
9、
Start the Device the First Time
The first time you start the device, Windows* 10.1 guides you through the
following steps:
1. Select your region and language.

2. Accept the Windows license terms.
3. Personalize Windows and assign a PC Name.
4. "Get Online" dialog to pick a wireless network (this step is
optional).
5. Choose Express Settings or Customize.
6. Assign a user name and password.
7. Finished.
10、
Connect to a Wireless Network
To connect to a wireless network:
1. Click the wireless network icon in the notification area
of the taskbar.
2. Click your network, and then click Connect.
3. Type the security key or passphrase.
11、
Operating System Recovery
There is a Windows recovery partition on the AWOW Compute Stick. You can
use this partition to refresh, reset, or restore Windows. Here is what each of
these actions do:

Refresh If your Compute stick isn't performing as well as it once did, and
you don't know why, you can refresh your Compute stick. This action does
not delete any of your personal files or change your settings. Refresh does
the following:
•Files and personalization settings won’t change.
•PC settings are changed back to their defaults.
•Apps from the Windows Store are kept.
•Apps installed from disks or websites are removed.
•List of removed apps is saved on the desktop.
Reset If you want to recycle your Compute stick, give it away, or start over
with it, you can reset it completely. This process removes everything. Reset
does the following:
•All personal files and apps are removed.
•Compute stick settings are changed back to their defaults.
•Windows is reinstalled.
Restore If a recently installed app or driver is causing problems with your
Compute stick, you can restore Windows back to an earlier point in time,

called a restore point. System Restore doesn’t change your personal files,
but it can remove recently installed apps and drivers.
Caution
Before completing a reset or refresh:
•Make sure to back up all personal data
to external storage.
•Remove SD card from the card slot, if
one is inserted.
Options to access the recovery media:
•If Windows boots from Windows Start,
type Recovery and select Recovery Options. See How
to refresh, reset, or restore your Compute stick for
complete details on how to use the recovery options.
•If Windows fails to boot, the recovery process should
automatically start.

•If Recovery does not automatically start, you can try to
initiate it by pressing F8 during boot, when you see the
prompt "F8 to Activate Windows 10.1 Recovery Mode."
Follow the recovery steps.
Note
•The recovery can take 1½ hours or longer to
complete.
•The computer might display to halt during the
recovery.
•Don't shut down the computer during the
recovery process.
