Awox CamLIGHT CL-w7 User manual

CL-w7
User Guide
Mode d’emploi
Benutzerhandbuch
Manual del usuario
Guida dell'utente
Návod k použití
Guia do Utilizador
Руководство
пользователя
Användarhandbok
Navodilo za uporabo
Kullanıcı Kılavuzu
Brugerguide
Gebruikersgids
Käyttöopas
Használati utasítás
Brukerveiledning
Podręcznik użytkownika

AwoX CamLIGHT™
Wireless HD Video Camera & LED Light
User Guide

www.awox.com
2 | AwoX CamLIGHT - User Guide
EN
Contents
Introduction ........................................................................ 3
Getting started.................................................................... 5
Using your CamLIGHT ......................................................... 8
Sharing cameras................................................................ 11
CamLIGHT settings ............................................................ 12
Troubleshooting................................................................ 14
© 2015 AwoX. All rights reserved. AwoX CamLIGHT, the AwoX logo and other AwoX
marks are owned by AwoX. iPhone, iPad, and iPod are trademarks of Apple, Inc.,
registered in the U.S and other countries. Android is a trademark of Google Inc. All
other trademarks are the property of their respective owners. Smartphone or tablet
device sold separately. This is a non-contractual document. Read provided safety
information before using this product.
Rev 01 (EU)

www.awox.com
AwoX CamLIGHT - User Guide | 3
EN
Introduction
Welcome
Congratulations and thank you for choosing AwoX CamLIGHT™.
This product contains both a wireless HD video camera and a low-
energy LED light bulb. Use your smartphone to check in on your
home or office and to control the camera and light.
Access and share your camera(s) remotely via secure AwoX
cloud (1)
Use the free AwoX camera software for your iPhone®, iPad®,
iPod touch®, or Android smartphone or tablet.(2)
(1) Requires Internet connection. (2) Download the free AwoX CamLIGHT™
software for your Apple or Android OS device.
Product features
WiFi enabled, motorized HD video camera (720 p)
Low-energy LED light bulb
Share cameras with other users
Micro SD memory card slot (up to 32 GB, card not included)
Automatic night vision infrared light
Capture still images and video
Speak or listen in on the room
Rotate camera image on your mobile device

www.awox.com
4 | AwoX CamLIGHT - User Guide
EN
What’s in the box
AwoX CamLIGHT™WiFi light bulb with camera
This user guide
Safety and warranty leaflet
What else you need
WiFi/Internet connection for local use
Internet data access on your smartphone for remote use
A supported smartphone or tablet running AwoX CamLIGHT
(available for free on mobile app stores)
CamLIGHT™WiFi overview
Fits standard E27
(European) light
bulb socket
Motorized video camera
Light ON/OFF button
(short-press).
Initialization (10 seconds)
Micro SD card slot

www.awox.com
AwoX CamLIGHT - User Guide | 5
EN
Getting started
1. Download the free AwoX CamLIGHT app for smartphone or
tablet:
Apple
iPhone,
iPad, iPod
touch
Download and install AwoX
CamLIGHT™ software from the
App Store.
Google
Android
devices
Download and install AwoX
CamLIGHT™ software from the
Google Play Store.
On your Apple or Android device, make sure WiFi is turned
on and then use the mobile device’s settings to connect to
your home network. These instructions here are identical for
both operating systems.
2. Screw your AwoX CamLIGHT into a light socket and turn on
the power. The light turns on.
Note: Do not use dimmer switches with this product.
3. Tap the CamLIGHT application icon on your mobile device.
4. The first time you run the application, tap on Sign up for the
free AwoX cloud service. This service enables you to access
your video camera remotely and to share cameras with
other users. Fill in the User name, Password, and E-mail
fields Tap the checkbox to Agree to terms of use. Tap
on Submit in the upper right-hand corner.

www.awox.com
6 | AwoX CamLIGHT - User Guide
EN
The next time you use CamLIGHT, simply enter your User
name and Password and then tap on Done.
Note: If you forget your password, tap on Forgot Password
and your password will be sent to you by e-mail
5. The My Cameras screen opens, without any cameras
present the first time you run the application.
Tap on Add and follow
the instructions on the
screen.
You may either tap on
Scan QR code for enter
the camera ID number
directly to begin
configuring your AwoX
CamLIGHT.

www.awox.com
AwoX CamLIGHT - User Guide | 7
EN
Configuring your camera
Option 1: Scan the QR code on your product:
1. Tap on Add in the My Cameras QR code
2. Use the device screen to scan the QR code sticker on your
CamLIGHT product or on the back of this guide.
3. As soon as the QR code is identified, the product’s ID
number is automatically placed in the ID field Next
4. Enter a name for your camera and tap Next
Option 2: Enter the product ID manually:
1. Alternatively, you may tap on ID
2. Enter the ID number manually and tap Done.
3. Enter a name for your camera and tap Next
Adding your camera to your home WiFi network
1. Tap Scan QR code Choose the WiFi network for your
camera Enter the network password Next
2. Press the button on your CamLIGHT for 10 seconds. The light
will turn off and a small LED will blink red.
3. Follow the instructions on your device’s screen until a QR
code is displayed.
4. Hold your device’s screen in front of the CamLIGHT camera,
at a distance of 6 –12 inches (15 –30 cm). You will hear an
audio message confirming when CamLIGHT recognizes the
QR code and connects directly to your WiFi network (you
may need to activate WiFi pairing on your router).
5. Tap on Next. When you see your camera’s details on the
screen, tap on Submit.

www.awox.com
8 | AwoX CamLIGHT - User Guide
EN
Using your CamLIGHT
Tap on your camera in the list, then tap on image to access
features. Swipe screen with a finger to rotate camera view.
If you want to delete a
camera, long-press its line
and select delete.
Tap to see video
Swipe right, left, up or down to use
camera motors and change view, or
pinch to zoom in/out.

www.awox.com
AwoX CamLIGHT - User Guide | 9
EN
Main application features
The six icons in the lower part of the screen are activated when
you view a video stream from your camera or a shared camera.
Lets you to talk through the product’s built-in speaker. People in
the room with CamLIGHT will hear your voice.
Takes a still shot of the current video.
Records video to your smartphone or
tablet’s memory.
Rotates the video image on your screen.
Turns the LED light on or off.
Turns on the product’s microphone so
you can listen in on the room.

www.awox.com
10 | AwoX CamLIGHT - User Guide
EN
Talk, record, audio, and light features
These four features are simple on/off options. Their icons
indicate whether they are active or not. Press to activate, press
again to deactivate.
With the Record option, you may store the video stream directly
to your smartphone or tablet.
Flipping the video image
Depending on how your light is installed, you may wish to flip the
video image for easier viewing. Press the icon to flip the image,
press again to restore to the original view.
Taking a screenshot
When you tap on the screenshot icon, CamLIGHT takes a
snapshot of the current video frame. You may choose one of
these two options to save or send the image:
Sends the image to various destinations,
depending on your configuration
Saves the image to your device’s local image
gallery.
Live or recorded video playback
At the top of the screen, tap on Live to see live-action footage
from your camera.
Tap on Replay to choose the date and time to view video
stored on your CamLIGHT’s SD card. New video overwrites
old video when the memory card is full.

www.awox.com
AwoX CamLIGHT - User Guide | 11
EN
Sharing cameras
Sharing your camera with other users
With CamLIGHT, you can share your camera(s) with an unlimited
number of other users. To publish your camera(s) to one or more
specific users:
Tap on Done when you have finished
(the label on the Done button changes to Edit).
To delete one or more users in your list, or to disable or enable all
camera sharing at once, tap on the Edit button and then tap on
the desired button at the bottom of the screen.
Tap on the triangle
Share
Enter the name of a user you
would like to share with tap
on Add.
You may add as many users
here as you want.
Activate sharing using the
ON/OFF toggle switch.

www.awox.com
12 | AwoX CamLIGHT - User Guide
EN
Seeing other users’ cameras
Activate motion detection for alerts
Your CamLIGHT has a built-in motion detector that records if
movement is detected by the camera. The number of
occurrences is indicated on the My Cameras screen. To activate
motion detection, tap on Settings tap ON/OFF to
enable or disable motion detection.
CamLIGHT settings
Tap on More in the main screen for additional options:
Logout
Clears your local user data. You must login again
to use your camera
Change
Password
Enables you to change your current password.
Update check
Checks online for the latest application version.
Tap on these icons to toggle between your
camera lists. The Shared cameras list shows
the cameras of other users have shared with
you.

www.awox.com
AwoX CamLIGHT - User Guide | 13
EN
Technical specifications
Hardware
Input power
LED bulb, 100-240V, E27 socket, 7W (40 W
equivalent)
Network
WiFi b/g/n (WEP/WPA)
Dimensions
H 14 cm (5.5 in.), Ø 120 mm (4.7 in.)
Weight
Approximately 700 g (25 oz.)
Video
720p, 8x digital zoom, H.264, up to 25 fps,
400 Kbps max bit rate, field of view 90°
vert, 360° horiz., automatic infrared night
vision (10 m), motion detection
Audio
2-way, built-in mic and speaker (off by
default to protect privacy)
Supported
devices
Android 4.3 or higher smartphone / 3.0 or
higher tablet. iOS 4.3 or higher, iPhone,
iPad, or iPod touch
Memory
Micro SD card up to 32 GB
(approximately 130 MB/hr)
Environmental
Operating
conditions
0° to +35°c
10% to 85% RH (no condensation)
Storage
conditions
-10° to +60°c
5% to 90% RH (no condensation)
Consumption
15 W max

www.awox.com
14 | AwoX CamLIGHT - User Guide
EN
Troubleshooting
I can’t sign up for the service or access my CamLIGHT
Check that your smartphone or tablet is configured to use your
local WiFi network. If you are trying to access your CamLIGHT
from a remote location, make sure that your mobile device has
Internet access.
My CamLIGHT didn’t connect to my home WiFi network
Make sure that your CamLIGHT is within wireless range of your
network router, and repeat the initial setup procedure described
earlier in Getting Started.
No video image appears on my screen
Check to make sure your CamLIGHT is accessible from the
software by checking under Settings to see if it is Online.
I can’t use the Replay feature with my camera
Make sure you have installed a micro SD memory card (up to 32
GB) in your CamLIGHT product.
How can I switch my CamLIGHT to another WiFi network?
Under Settings QR code scan, choose another network, enter
the password, and follow the on-screen instructions.
How do I reset the WiFi on my CamLIGHT?
Press and hold the button on your product for more 10 seconds.
This completely clears your WiFi configuration.
Do I have to use my smartphone to turn the light on/off?
A short-press on the bulb’s button also turns the light on and off.

AwoX CamLIGHT™
Caméra HD et ampoule LED WiFi
Mode d’emploi

www.awox.com
2 | AwoX CamLIGHT - Mode d'emploi
FR
Table des matières
Introduction ........................................................................ 3
Première utilisation............................................................. 5
Utilisation de la CamLIGHT ............................................... 10
Partager des caméras........................................................ 14
Réglages de la CamLIGHT.................................................. 16
Dépannage ........................................................................ 18
© 2015 AwoX. Tous droits réservés. AwoX CamLIGHT, le logo AwoX et les autres
marques AwoX sont la propriété d'AwoX. iPhone, iPad et iPod sont des marques
déposées d'Apple, Inc., aux États-Unis et dans d'autres pays. Android est une
marque déposée de Google Inc. Toutes les autres marques déposées sont la
propriété de leurs détenteurs respectifs. Smartphone ou tablette non fournis avec
l’appareil. Document non contractuel. Lire attentivement les consignes de sécurité
avant toute utilisation.
Version 01 (UE)

www.awox.com
AwoX CamLIGHT - Mode d'emploi | 3
FR
Introduction
Bienvenue
Merci d'avoir choisi AwoX CamLIGHT™. Ce produit combine une
caméra HD WiFi et une ampoule LED à économie d'énergie. Il
vous permet de surveiller votre domicile ou bureau et de
télécommander la caméra et l'ampoule depuis votre smartphone
ou tablette.
Consultez et partagez à distance votre/vos caméra(s) via le
cloud AwoX sécurisé(1).
Télécommandez la caméra grâce à l'application gratuite
AwoX pour votre iPhone®, iPad®, iPod Touch® ou tablette /
smartphone Android(2).
(1) Nécessite une connexion Internet. (2) Téléchargez gratuitement l'appli AwoX
CamLIGHT™ correspondant à votre smartphone ou tablette.
Fonctions
Caméra HD (720 p) motorisée et compatible WiFi.
Ampoule LED à économie d'énergie.
Partagez vos caméras avec d'autres utilisateurs.
Emplacement pour carte mémoire MicroSD (jusqu'à 32 Go,
non fournie).
Caméra infrarouge, activation automatique.
Photographies et vidéos.
Haut-parleur et micro.
Rotation de l'image depuis votre smartphones ou tablette.

www.awox.com
4 | AwoX CamLIGHT - Mode d'emploi
FR
Contenu
Ampoule-caméra WiFi AwoX CamLIGHT™
Mode d'emploi
Consignes de sécurité et garantie
Configuration requise
WiFi / connexion Internet pour une utilisation locale
Smartphone ou tablette équipés d'une connexion Internet
pour une utilisation à distance
Smartphone ou tablette compatibles, dotés de l'application
AwoX CamLIGHT (téléchargeable gratuitement sur l'App
Store ou sur le Google Play Store)
