AXIOMTEK NA-401 Manual

NA-401
Hardware Installation Guide
For service person only

ii
Disclaimers
The information in this manual has been carefully checked and is believed to
be accurate. AXIOMTEK Co., Ltd. assumes no responsibility for any
infringements of patents or other rights of third parties, which may result from
its use.
AXIOMTEK assumes no responsibility for any inaccuracies that may be
contained in this document. AXIOMTEK makes no commitment to update or
to keep current the information contained in this manual.
AXIOMTEK reserves the right to make improvements to this document and/or
product at any time and without notice.
No part of this document may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without the prior written permission of
AXIOMTEK Co., Ltd.
Copyright 2006 by AXIOMTEK Co., Ltd.
All rights reserved.
Version A1 October 2006
Printed in Taiwan

iii
Safety Approvals
CE Marking
FCC Class A
FCC Compliance
This equipment has been tested and complies with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. If not installed and used in
accordance with proper instructions, this equipment might generate or
radiate radio frequency energy and cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measurers:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Shielded interface cables must be used in order to comply with
emission limits.

iv
Safety Precautions
Before getting started, read the following important cautions.
1. Be sure to ground yourself to prevent static charge when
installing the internal components. Use a grounding wrist strap
and place all electronic components in any static-shielded
devices. Most electronic components are sensitive to static
electrical charge.
2. Disconnect the power cords from the NA-401 before making any
installation. Be sure both the system and the external devices are
turned OFF. Sudden surge of power could ruin sensitive
components. Make sure the NA-401 is properly grounded.
3. Do not open the system’s top cover. If opening the cover for
maintenance is a must, only a trained technician is allowed to do
so. Integrated circuits on computer boards are sensitive to static
electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
9Before handling a board or integrated circuit, touch an unpainted
portion of the system unit chassis for a few seconds. This will help
to discharge any static electricity on your body.
9When handling boards and components, wear a wrist-grounding
strap, available from most electronic component stores.
Trademarks Acknowledgments
AXIOMTEK is a trademark of AXIOMTEK Co., Ltd.
Other brand names and trademarks are the properties of their
respective owners.

v
Table of ContentsDisclaimers ......................................................ii
FCC Compliance.........................................................................iii
Chapter 1..............................................................................................1
1.1 General Description............................................................1
1.2 Standard Features..............................................................2
1.3 System Specifications.........................................................2
1.3.1 Hardware .................................................................2
1.4 Dimensions.........................................................................5
1.5 Front Panel Outlets.............................................................6
1.6 Rear Panel Outlets .............................................................7
1.7 Indications of Front Panel......................................................8
Chapter 2..............................................................................................9
2.1 Preinstallation Checklist .....................................................9
2.2 Board Placement............................................................. 10
2.3 Connectors and Jumpers .................................................11
2.3.1 Connectors ............................................................11
2.3.1 General Output Connector: CN24........................ 12
2.3.2 Jumper Settings ...................................................... 13
2.4 Setting up the appliance.................................................. 15
2.4.1 Removing and Replacing the Top Cover.............. 15
2.4.2 Installing a Microprocessor (CPU)........................ 16
2.4.3 Installing a memory module (DIMM)....................... 21
2.4.4 Installing a DMA/66/100 hard drive ...................... 22
2.4.5 Install Riser Card..................................................... 24
2.4.6 Installing Display Interface.................................... 24
2.4.7 Installing Serial Port Interface............................... 25
2.4.8 Installing USB Connector (Optional)..................... 25

vi
2.4.9 Installing and Program LCD Module..................... 26
Chapter 3........................................................................................... 30
3.1 BIOS Introduction ............................................................ 30
3.2 BIOS Setup...................................................................... 30
3.3 Standard CMOS Setup.................................................... 32
3.4 Advanced BIOS Features................................................ 36
3.5 Advanced Chipset Features............................................ 41
3.6 Integrated Peripherals..................................................... 44
3.7 Power Management Setup.............................................. 48
3.8 PNP/PCI Configuration.................................................... 51
3.9 PC Health Status............................................................. 53
3.10 Load Optimized Defaults................................................. 54
3.11 Set Supervisor/User Password........................................ 55
3.12 Save & Exit Setup............................................................ 58
3.13 Quit Without Saving......................................................... 59
Appendix A......................................................................................... 60

NA-401 Hardware Installation Guide
Introduction 1
Chapter 1
Introduction
This chapter contains the general information and the detailed specifications
of the NA-401 NetworkAppliance server. Chapter 1 includes the following
sections:
1.1 General Description
NA-401 server is designed for network software solution providers those
have data secure, voice over IP, video streaming, network bandwidth
controller and another networking appliance requirements across this stable
and reliable multiple LAN device.
It is a reliable and affordable, 1U-height unit that requires only power and
network connections for setup. There can be deployed up to four LAN ports
combinations for customer selection in the maximum for application.
NA-401 has pretty good enclosure management interface to be
implemented in the factory default. It can support P.O.S.T (Power on Self
Test) feature through hyper-terminal by console port. LCD module function is
available for customer coding also.
And it has room space for one hard drive deployment. Customer can
implement system log and monitoring functions through this hardware
specification. With its innovative mechanical and electrical design, NA-401
server provides one PCI expansion slot for VPN encryption / decryption adapter
board and another special functions enabling. It cans enhancement network
security process performance and of-load the CPU loading.

NA-401 Hardware Installation Guide
Introduction
2
NA-401 can support wonderful networking application platform by excellent cost
with performance ratio.
1.2 Standard Features
z1U-height rack-mount/stacked-up design
zHigh performance Intel Pentium 4 processor (LGA775-Pin)
zFour gigabit LAN ports (through PCI-Express by one interface)
combinations are for NA-401.
zSupport BIOS redirected to COM port feature
zSupport RS-232 and two USB
zPCI 32-bit/33MHz expansion slot and one Mini-PCI slot for
another network security encryption board
zLCM setting functions is available
zSupports Redhat Linux and Fedora Code III Networks
1.3 System Specifications
1.3.1 Hardware
zForm Factor:
1U rack-mount/stacked-up on desktop design
zCapacity:
It is from 0 to 250GB and beyond, depending on the 3.5” hard disk
drive capacity.
zPower Supply:
Single 300W ATX HRP power supplies
Standard ATX power input connector
zHard Drive:
Spacing for 1 x IDE HDD (3.5”)
zRear Panel Connector:
4 x 10/100/1000 Base-T Ethernet LAN port w/LED through PCI-E by
one interface

NA-401 Hardware Installation Guide
Introduction 3
1 x Console port
2 x USB port
zFront Panel LED:
1 x LED for HDDs
1 x Power LED for System
zProcessor:
IntelPentium4 processor up to 3.6GHz, LGA 775 Pin
FSB 800MHz
zBIOS:
Award 4MB Flash BIOS Plug & Play
zL2 Cache:
Built-in in CPU
zMain Memory:
Four DDR266/DDR333 memory DIMM can be up to 4GB in the
maximum
zIDE Interface:
Support one ATA 66/100/133 EIDE channels
Support four channels for S-ATA 1
zEthernet:
Totally has four Gigabit LAN port connections are available.
zExpansion:
One PCI 32-bit/33MHz and one Mini-PCI 32-bit/33MHz for security
encryption card or other third-party cards expansion
zCompact-FlashTM:
One IDE interface CompactFlashTM socket for embedded use
zDimensions:
427mm(19”)(W) x 44mm(1.75”)(H) x 382mm(11.9”)(D)
zWeight:
Approx. 8.5kg with Power supplies, without any hard drive
zOperation environment:
Air temperature: 0° C – 40°C
Humidity: 10% – 95%
zStorage environment:
Air temperature: -20° C – 70°C

NA-401 Hardware Installation Guide
Introduction
4
Humidity: 10% – 95%

NA-401 Hardware Installation Guide
Introduction 5
1.4 Dimensions

NA-401 Hardware Installation Guide
Introduction
6
1.5 Front Panel Outlets
Located at the front panel of the NA-401 server are the I/O outlets for
connections of serial and Ethernet interface-supported devices. You also can
find out the LCD module.
The NA-401 Server Rear Panel
Expansion Slot LCD Module
Console Port USB Port
LAN link / transfer rate
zConsole port – DB-9 RS-232 Console port for command line interface
and diagnostic support by P.O.S.T (Power on Self Test).
zPower – Lights when the NA-401 is powered up and performing
diagnostic tests to check for proper operation.
zUSB port – For specialize functions was defined by solution provider.
zLAN Link – Lights up with a twisted pair connection of RJ-45 that has
made to another Ethernet device on the port.
zTransfer Rate – Show network transfer rate while make connections,
show the status through light of RJ-45
zActivity – Lights up when the NA-401 transmits or receives a packet
through the twisted pair port, show the status through light of RJ-45
zExpansion Slot -- To support one PCI 32-bit and 33Mhz slot which is
for adapter card expansion

NA-401 Hardware Installation Guide
Introduction 7
1.6 Rear Panel Outlets
Located at the rear panel of the NA-401 server are the I/O outlets. You will
also find the main power switch and cooling fans.
Internal FANs Power Switch
100-240VAC
50-60Hz
Power input

NA-401 Hardware Installation Guide
Introduction
8
1.7 Indications of Front Panel
zPower on LED
System and power on
zHDD LED
Link/Active LED (single color)
1. The green LED is on when the HD has connection normally
2. The LED flashes when there is transmit or receive activity
zLink/Active LED (Single color)for LAN port #1, port#2, port#3 and
port#4
1. The yellow LED is on when there is an active connection on the LAN
port.
2. The LED flashes when there is transmit or receive activity to or from
the appliance.
3. The LED is dark when it off line.
zTransmitted LED (Dual color) for LAN port #1, port#2, port#3 and
port#4
1. The orange LED light is on 10/100/1000Mbps transfer rate
2. The green LED light is on 10/100Mbps transfer rate
3. The LED is dark if the Link/Active LED is light or flash in the same
time; it’s on 10Mbps transfer rate
4. The LED is dark if the Link/Active LED is dark also.
There is no any networking device was attached.

NA-401 Hardware Installation Guide
Installation Procedures 9
Chapter 2
Installation Procedures
2.1 Preinstallation Checklist
In addition to this installation guide, make sure you have the following
items,
The NA-401 network appliance hardware platform
Power cord
Utility CD (including this installation guide)
Mounting screws for disk drive and screws used in this
appliance for spare
NA-401 cable kits (1 x 44-pin IDE)
Mounting brackets for rack installation (left/right) x 2
Plastic stand for stack–up x 4
If you ordered options for the appliance, this package might
contain additional hardware or publications for those options.

NA-401 Hardware Installation Guide
Installation Procedures
10
2.2 Board Placement

NA-401 Hardware Installation Guide
Installation Procedures 11
2.3 Connectors and Jumpers
This section provides the information about the jumpers and
connectors setting of NA-401.
2.3.1 Connectors
The connectors allow the CPU card to connect with other parts of the
system. Some problems encountered by your system may be a result from
loose or improper connections. Ensure that all connectors are in place and
firmly attached. The following table lists the function of each connector on
the main board.
Connectors Label Connectors Label
COM1 DB-9pin CN1 ATX 12V CPU Power Connector CN35
LAN4 RJ-45 CN2 FAN3 connector CN38
LAN3 RJ-45 CN3 FAN2 Connector CN39
LAN2 RJ-45 CN4 FAN1 Connector CN40
LAN1 RJ-45 CN5 LCM Interface CN41
USB Port Connector (External) CN6 Power Connector for HDD CN42
USB Port Connector (Internal) CN36 Power LED LED2
VGA Connector (Box-Header 2*8) CN8 HDD ACT LED LED3
Mini PCI CN13 CPU U31
PCI slot / PICMG slot CN16 BIOS U21
CF Connector CN19 DDR Memory Module slot 1 DDR1
EIDE Connector (Box-Header 2*8) CN23 DDR Memory Module slot 2 DDR2
General Output Connector CN24 DDR Memory Module slot 3 DDR3
ATX 24pin Power Connector CN26 DDR Memory Module slot 4 DDR4
COM2 (Box-Header 2*8) CN29 CR-2032 Battery socket BAT1
S-ATA port CN31 Internal Buzzer BU1

NA-401 Hardware Installation Guide
Installation Procedures
12
2.3.1 General Output Connector: CN24
135791113151719
2 4 6 8 10 12 14 16 18 20
Power LED
This 3-pin connector, designated at Pins 1, 3, and 5 of CN24, connects the
system power LED indicator to its respective switch on the case. Pin 1 is +,
and pin 5 is assigned as -. The Power LED lights up when the system is
powered ON.
External Speaker and Internal Buzzer Connector
Pins 2, 4, 6, and 8 of CN24 connect to the case-mounted speaker unit or
internal buzzer. Short pins 4-6 when connecting the CPU card to an
internal buzzer. When connecting an external speaker, set these jumpers to
Open and install the speaker cable on pin 8 (+) and pin 2 (-).
System Power Switch
Pins 13 &4.
System Reset Switch
Pins 17 &18 of CN24 connect to the case-mounted reset switch and allow
rebooting of your computer instead of turning OFF the power switch. This is
a preferred method of rebooting in order to prolong the life of the system’s
power supply.
HDD Activity LED
This connector extends to the hard drive activity LED on the control panel.
This LED will flash when the HDD is being accessed. Pins 19 & 20 of

NA-401 Hardware Installation Guide
Installation Procedures 13
CN24 connect the hard disk drive and the front panel HDD LED. Pins 19 is
-, and pin 20 is assigned as +.
Reserved pins
Pins 7 and 9-11, 15 and 16 of CN24 are reserved pins.
2.3.2 Jumper Settings
Making the proper jumper settings configures the NA-401 to match the
needs of your application. The following summary table lists all onboard
jumpers and their corresponding functions and/or default setting.
Jumper Default Setting Jumper Setting
JP13 PICMG slot Function Select Open: PCI slot
Short: PICMG slot
JP14 PICMG slot Function Select Short 1-2: PCI slot
Short 2-3: PICMG slot
JP15 PICMG slot Function Select Open: PCI slot
Short: PICMG slot
JP17 CF Card Master/Slave Setting : Slave Short 1-2: Master
Open 1-2: Slave
JP18 CF Power Select: 3.3V Short 1-2: 3.3V
Short 2-3: 5V
JP20 Watch Dog Function Select: Disable Short 1-2: System Reset
Short 2-3: GPIO
Open: Disable
JP21 Clear CMOS: Normal Short 1-2: Clear
Short 2-3: Normal

NA-401 Hardware Installation Guide
Installation Procedures
14
2.3.2.1 PICMG slot Function Select : JP13 / JP15
■
■
OPEN PCI Slot
SHORT PICMG Slot (Default)
2.3.2.2 PICMG slot Function Select : JP14
□
■
■
SHORT
1-2 PCI Slot
SHORT
2-3 PICMG Slot (Default)
1
2
3
2.3.2.3 CF Function : JP17
□
□
OPEN Slave (Default)
SHORT Master
2.3.2.4 CF Power Select : JP18
■
■
□
SHORT
1-2 3.3V (Default)
SHORT
2-3 5V
1
2
3
