AXXIV Serius 15S10 User manual

Contents
About this Quick Guide ....................................................................1
System Startup ..................................................................................4
System Map: Front View with LCD Panel Open .............................5
System Map: Front, Left, Right, Rear & Bottom Views ..................6
Keyboard & Function Keys .............................................................8
3.75G/HSPA Module ........................................................................9
Fingerprint Reader ..........................................................................10
Trusted Platform Module ................................................................11
Driver Installation ...........................................................................13
Troubleshooting ..............................................................................14
Specifications ..................................................................................15
Inhalt
Über diese Kurzanleitung ...............................................................17
Schnellstart ......................................................................................20
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm .............................................................................21
Systemübersicht: Ansicht von vorne, links, rechts, hinten und
unten ................................................................................................22
Tastatur & Funktionstasten ............................................................24
3.75G/HSPA-Modul .......................................................................25
Fingerabdruckleser ..........................................................................26
TPM (Trusted Platform Module) ....................................................27
Installation der Treiber ....................................................................29
Fehlerbehebung ...............................................................................30
Technische Daten ............................................................................31
Sommaire
A propos de ce guide rapide ............................................................33
Guide de démarrage rapide .............................................................36
Carte du système: Vue de face avec l’écran LCD ouvert ...............37
Carte du système: Vues de face, gauche, droite, arrière &
dessous ............................................................................................38
Clavier & touches fonction .............................................................40
Module 3.75G/HSPA ......................................................................41
Lecteur d'empreintes digitales .........................................................42
TPM (Trusted Platform Module) ....................................................43
Installation du pilote ........................................................................45
Dépannage .......................................................................................46
Spécifications ..................................................................................47
Contenidos
Acerca de esta guía rápida ...............................................................49
Guía rápida para empezar ................................................................52
Mapa del sistema: Vista frontal con panel LCD abierto .................53
Mapa del sistema: Vistas frontal, izquierda, derecha, posterior e
inferior .............................................................................................54
Teclado & teclas de función ............................................................56
Módulo 3.75G/HSPA ......................................................................57
Lector de huellas digitales ...............................................................58
TPM (Trusted Platform Module) ....................................................59
Instalación de controladores ............................................................61
Solución de problemas ....................................................................62
Especificaciones ..............................................................................63

Sommario
Informazioni su questa guida rapida ...............................................65
Guida di avvio rapido ......................................................................68
Descrizione del sistema: Vista anteriore con pannello LCD
aperto ...............................................................................................69
Descrizione del sistema: Vista anteriore, sinistra, destra,
posteriore e inferiore .......................................................................70
Tastiera & tasti funzione .................................................................72
Modulo 3.75G/HSPA ......................................................................73
Lettore d’impronte digitali ..............................................................74
TPM (Trusted Platform Module) ....................................................75
Installazione driver ..........................................................................77
Risoluzione dei problemi ................................................................78
Specifiche tecniche .........................................................................79

1
English
About this Quick Guide
This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitute for the
expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’sManual
disc supplied with your computer. This disc also contains the drivers and utilities necessary for the proper operation of
the computer (Note: The company reserves the right to revise this publication or to change its contents without notice).
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual disc does not contain an operating system.
Regulatory and Safety Information
Please pay careful attention to the full regulatory notices and safety information contained in the expanded User’s Man-
ual on the Device Drivers & Utilities + User’s Manual disc.
© August 2011
Trademarks
Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.

FCC Statement
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
1.This device may not cause
harmful interference.
2.This device must accept any
interference received, includ-
ing interference that may
cause undesired operation.

2
English
Instructions for Care and Operation
The computer is quite rugged, but it can be damaged. To pre-
vent this, follow these suggestions:
•Don’t drop it, or expose it to shock. If the computer falls, the
case and the components could be damaged.
•Keep it dry, and don’t overheat it. Keep the computer and power
supply away from any kind of heating element. This is an electri-
cal appliance. If water or any other liquid gets into it, the computer
could be badly damaged.
•Avoid interference. Keep the computer away from high capacity
transformers, electric motors, and other strong magnetic fields.
These can hinder proper performance and damage your data.
•Follow the proper working procedures for the computer. Shut
the computer down properly and don’t forget to save your work.
Remember to periodically save your data as data may be lost.
Servicing
Do not attempt to service the computer yourself. Doing so may
violate your warranty and expose you and the computer to
electric shock. Refer all servicing to authorized service person-
nel. Unplug the computer from the power supply. Then refer
servicing to qualified service personnel under any of the fol-
lowing conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work normally when you follow the oper-
ating instructions.
• If the computer has been dropped or damaged (do not touch the
poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your com-
puter.
Safety Information
• Only use an AC/DC adapter approved for use with this computer.
• Use only the power cord and batteries indicated in this manual. Do
not dispose of batteries in a fire. They may explode. Check with
local codes for possible special disposal instructions.
• Do not continue to use a battery that has been dropped, or that
appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it
may cause circuit damage, which may possibly result in fire.
• Make sure that your computer is completely powered off before
putting it into a travel bag (or any such container).
• Before cleaning the computer, make sure it is disconnected from
any external power supplies, peripherals and cables (including
telephone lines). It is advisable to also remove your battery in
order to prevent accidentally turning the machine on.
• Use a soft clean cloth to clean the computer, but do not apply
cleaner directly to the computer. Do not use volatile (petroleum
distillates) or abrasive cleaners on any part of the computer.
• Do not try to repair a battery pack. Refer any battery pack repair or
replacement to your service representative or qualified service per-
sonnel.
• Note that in computer’s featuring a raised LCD electro-plated
logo, the logo is covered by a protective adhesive. Due to general
wear and tear, this adhesive may deteriorate over time and the
exposed logo may develop sharp edges. Be careful when handling
the computer in this case, and avoid touching the raised LCD elec-
tro-plated logo. Avoid placing any other items in the carrying bag
which may rub against the top of the computer during transport. If
any such wear and tear develops contact your service center.

3
English
Polymer Battery Precautions
Note the following information which is specific to polymer
batteries only, and where applicable, this overrides the general
battery precaution information.
• Polymer batteries may experience a slight expansion or swelling,
however this is part of the battery’s safety mechanism and is not a
cause for concern.
• Use proper handling procedures when using polymer batteries. Do
not use polymer batteries in high ambient temperature environ-
ments, and do not store unused batteries for extended periods.

Battery Disposal & Caution
The product that you have purchased contains a rechargeable
battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose
of this battery into the municipal waste stream. Check with
your local solid waste officials for details in your area for recy-
cling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the
manufacturer. Discard used battery according to the manufac-
turer’s instructions.

4
English
System Startup
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Insert the battery and make sure it is locked in position.
4. Securely attach any peripherals you want to use with the
computer (e.g. keyboard and mouse) to their ports.
5. Attach the AC/DC adapter to the DC-In jack on the left of the
computer, then plug the AC power cord into an outlet, and
connect the AC power cord to the AC/DC adapter.
6. Use one hand to raise the
lid/LCD to a comfortable viewing
angle
(do not exceed 120 degrees) ; use the other hand (as
illustrated in Figure 1) to support the base of the computer
(Note: Never lift the computer by the lid/LCD).
7. Press the power button to turn the computer “on”.
Model Differences
This notebook series includes two different models (see
Specifications on page 15 for details).
System Software
Your computer may already come with system software
pre-installed. Where this is not the case, or where you are
re-configuring your computer for a different system, you
will find this manual refers to Microsoft Windows Win-
dows 7.
Figure 1 - Opening the Lid/LCD/Computer
with AC/DC Adapter Plugged-In

Shut Down
Note that you should
always shut your
computer down by
choosing Shut Down
from the Start Menu.
This will help prevent
hard disk or system
problems.

5
English
System Map: Front View with LCD Panel Open
Hot-Key Buttons
The Hot-Key buttons give instant access to the default In-
ternet browser and e-mail program, and allow you to tog-
gle the Silent Mode on/off with one quick button press.
Table 1 - Hot-Key Buttons
4
3
5
1
2
6
7
9
3
8
10
Note that the valid operational
area for the Touchpad’s scroll
bar and Buttons is that indi-
cated within the red dotted
lines above.
9
Figure 2 - Front View with LCD Panel Open
1. PC Camera (Optional)
2. LCD
3. Speakers
4. Power Button
5. Hot-Key Buttons
6. Keyboard
7. Built-In Microphone
8. Touchpad & Buttons
9. Fingerprint Reader
10. LED Indicators
Hot-Key Button Function
*Activate the Default E-Mail Browser
Activate the Default Internet Program
Toggle Silent Mode
*Note that without Outlook/Outlook Express installed this button
has no function. If Outlook/Outlook Express are installed then
the button will activate the application.

6
English
System Map: Front, Left, Right, Rear & Bottom Views
Figure 3 - Front, Left, Right, Rear & Bottom Views
2
1
78
46
3510
12
14
11
17
13
9
15
19
20
7
7
17
16
18
Bottom
Rear
Right
Left
Front
1. LED Indicators
2. DC-In Jack
3. External Monitor Port
4. RJ-45 LAN Jack
5. eSATA/USB 2.0 Combo
Port
6. HDMI-Out Port
7. Vent
8. 2 * USB 3.0 Ports
9. ExpressCard/54(34) Slot
10. Multi-in-1 Card Reader
11. S/PDIF-Out Jack
12. Microphone-In Jack
13. Headphone-Out Jack
14. Powered USB 2.0 Port
(see note below)
15. Optical Device Drive Bay
16. Security Lock Slot
17. Battery
18. Docking Port
19. Component Bay Cover
20. Hard Disk Bay Cover

USB
The USB 3.0 ports are colored blue. USB 3.0 will
transfer data much faster than USB 2.0, and is back-
wards-compatible with USB 2.0. When the powered USB
2.0 port is on it will supply power when the system is
off but still powered by the AC/DC adapter plugged into a
working outlet, or powered by the battery with a capacity
level above 20% (this may not work with certain devices
- see page 14). Toggle power to this port by using Fn +
power button.
8
14

7
English
LED Indicators
The LED indicators on the computer display helpful information about the current status of the computer.
Table 2 - LED Indicators
Icon Color Description
Orange DC Power is Plugged In
Blinking Orange The powered USB 2.0 Port is on (see page 6)
Green The Computer is On
Blinking Green The Computer is in Sleep Mode
Green Number Lock (Numeric Keypad) Activated
Green Caps Lock Activated
Green Scroll Lock Activated
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking Orange The Battery Has Reached Critically Low Power Status
Green Hard Disk Activity
Green The Wireless LAN Module is Powered On
Orange The Bluetooth Module is Powered On

8
Quick Guide
Keyboard & Function Keys
The keyboard has a numeric keypad for easy numeric data
input. Pressing the Fn +NumLk keys turns on/off the nu-
meric keypad. It also features function keys to allow you
to change operational features instantly.
The function keys (F1 - F12 etc.) will act as hot keys when
pressed while the Fn key is held down. In addition to the
basic function key combinations, visual indicators are
available when the hot key driver is installed.
Keys Function/Visual Indicators Keys Function/Visual Indicators
Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F8/F9 Brightness Decrease/
Increase
Fn + 3.75G/HSPA Module
Power Toggle Fn + F10 PC Camera Power Toggle
Fn + F1 Touchpad Toggle Fn + F11 WLAN Module Power
Toggle
Fn + F2 Turn LCD Backlight Off
(Press a key to or use Touchpad to turn on) Fn + F12 Bluetooth Module Power Toggle
Fn + F3 Mute Toggle Fn + NumLk Numeric Keypad Toggle
Fn + F4 Sleep Toggle Fn + ScrLk Scroll Lock Toggle
Fn +F5/F6 Volume Decrease/
Increase *Toggle Silent Mode
Fn + F7 Display Toggle *When enabled, Silent Mode will reduce fan noise and save power
consumption. Note this may reduce computer performance.
Table 3 - Function Keys & Visual Indicators
Function Keys NumLk &
ScrLk
Numeric
Keypad
Fn Key
3.75G/HSPA
Module Power Toggle
Figure 4 - Keyboard

9
English
3.75G/HSPA Module
If you have included an optional 3.75G/HSPA module in your purchase option, follow the instructions below to install
the USIM card (which will be provided by your service provider), and then run the appropriate application supplied with
your module.
USIM Card Insertion
1. Turn off the computer, and turn it over and remove the battery (slide the latches in the direction indicated below and slide the bat-
tery out).
2. Insert the USIM card as illustrated below until it clicks into position, and replace the battery.
Figure 5 - Battery Removal & USIM Card Insertion
1

USIM Card Orientation
Note that the USIM card’s readable side (with
the gold-colored contacts) should face up-
wards as illustrated.
1
1

10
English
Fingerprint Reader
Enroll your fingerprints as instructed below before use.
User Enrollment
1. Click Start >Programs/All Programs >Protector Suite >
Control Center, or double click the taskbar icon .
2. On the first run of the program you will be asked to click the
Accept button to accept the license.
3. If you have not set a Windows password you will be prompted
to do so (note: If you have not set a password Protector Suite
QL cannot secure access to your computer).
4. Click Submit when you have entered password.
5. You will then be prompted to enroll your fingerprints (you can
click Tutorial to get help with fingerprint enrollment at any
time).
6. Click the button above any of the fingers to begin the
enrollment process for that finger.
7. Swipe the finger until the progress bar reaches 100% to enroll
that finger.
8. Repeat the process for all the fingers you wish to enroll, and
then click Save and Continue.
9. Enter a backup password and click Apply.
10. Close the fingerprint status window.
11. You can also run the Tutorial, or Product Tour (to run the
product tour video) to get more information.
12. Right-click the taskbar icon to Start Control Center to
allow you to Edit Fingerprints, register Applications, and
access the Help menu etc.
13. If you swipe your finger over the reader at any time you can
access the Biomenu to lock the computer,register
websites, access the Personal Safe or E-Wallet, open the
Control Center and access the Help menu.
Figure 6 - Control Center & Biomenu
For Intel PRO Wireless 2200BG

Fingerprint Enrollment
Note that it is strongly rec-
ommended that you enroll
more than one finger in
case of injury etc.

11
English
Trusted Platform Module
Before setting up the TPM functions you must initialize
the security platform.
Activating TPM
1. Restart the computer.
2. Enter the Aptio Setup Utility pressing F2 during the POST.
3. Use the arrow keys to select the Security menu.
4. Select TPM Configuration and press Enter.
5. Select TPM Support and press Enter. Select Enable and
press Enter.
6. Select TPM State, press Enter and select Enable to change
the TPM state to enabled. You will then need to press F4 to
save the changes and restart the computer.
7. As the computer restarts press F2 to enter the BIOS again and
go to the TPM Configuration menu.
8. Select Pending TPM operation, press Enter and select the
option you require (if you are initializing TPM you should select
Enable Take Ownership). You will then need to press F4 to
save the changes and restart the computer.
9. You can now install the TPM driver and then initialize the TPM.
TPM Driver Installation
1. Click Option Drivers (button).
2. Click 6.Install TPM Driver > Yes.
3. Click Install > Next.
4. Click the button to accept the license and click Next.
5. Click Next > Next > Install.
6. Click Finish > Yes to restart the computer.
Initializing TPM
1. Run the application from the Infineon Security Platform Solu-
tion > Manage Security Platform item in the Start > Pro-
grams/All Programs menu.
2. Click User Settings (tab) and click Yes, or right-click the icon
in the notification area of the taskbar, and select Security
Platform Initialization (or click the Security Platform State
taskbar bubble).
3. The Quick Initialization method will automatically be selected
for you (if you need to use advanced settings provided by your
network administrator then select Advanced Initialization).
4. You will need to use a removable media (e.g. a USB Flash
Drive) to store passwords and data (keep the media in a safe
place until required).
Figure 7 - Security Platform Quick Initialization Wizard

12
English
5. Select the drive you want to use from the drop-down menu and
click Next.
6. Choose the Security Platform Features you want to use by
clicking the appropriate tickbox.
7. Enter a Basic User Password (and re-type to confirm it) and
click Next.
8. Click Next to confirm the settings.
9. The computer will then initialize the settings.
10. Click Finish.
11. Click the tabs and control panels to adjust the settings.
12. Double-click the taskbar icon to access the Infineon
Security Platform Settings Tool, or right-click the taskbar icon
and select a menu item.
Infineon Security Platform Settings
Tool
The Infineon Security Platform Settings Tool allows you
to manage and check the TPM state, manage your pass-
word information, and to backup and restore the TPM da-
ta. As TPM is usually administered within large
enterprises and organizations, your system administrator
will need to assist you in managing the information here.
Figure 8 - Infineon Security Platform Settings Tool

13
English
Driver Installation
The Device Drivers & Utilities + User’s Manual disc contains the drivers and utilities
necessary for the proper operation of the computer. This setup will probably have al-
ready been done for you. If this is not the case, insert the disc and click Install Driv-
ers (button), or Option Drivers (button) to access the Optional driver menu. Install
the drivers in the order indicated in Figure 9. Click to select the drivers you wish
to install (you should note down the drivers as you install them). Note: If you need to
reinstall any driver, you should uninstall the driver first.
If the Found New Hardware wizard appears during the installation procedure, click
Cancel to close the window, and follow the installation procedure as directed.
Figure 9 - Install Drivers

Driver Installation General
Guidelines
As a general guide follow the
default on-screen instruc-
tions for each driver (e.g.
Next >Next >Finish) unless
you are an advanced user. In
many cases a restart is requi-
red to install the driver.
Make sure any modules (e.g.
PC Camera, WLAN or
3.75G/HSPA) are ON before
installing the appropriate dri-
ver.
Windows Update
After installing all the drivers
make sure you enable Win-
dows Update in order to get
all the latest security updates
etc. (all updates will include
the latest hotfixes from Mi-
crosoft).

14
Quick Guide
Troubleshooting
Problem Possible Cause - Solution
The Wireless LAN/
Bluetooth/3.75G/HSPA
modules cannot be detected.
The modules are off. Check the LED indicator and/or function
key indicator to see if the WLAN/Bluetooth/3.75G/HSPA module is
on or off (see Table 2 on page 7 and Table 3 on page 8). If the
LED indicator is off, then press the Fn + F11 (WLAN), Fn + F12
(Bluetooth) or Fn + (3.75G/HSPA) in order to enable the
modules (see Table 3 on page 8).
The Bluetooth module is off
after resuming from Sleep. The Bluetooth module’s default state will be off after resuming from the Sleep power-saving state. Use the key combination (Fn
+ F12) to power on the Bluetooth module after the computer
resumes from Sleep.
The captured video files from
the PC Camera are taking up
too much disk space.
Note that capturing high resolution video files requires a
substantial amount of disk space for each file.
Note that the Windows system requires a minimum of 15GB of
free space on the C: drive system partition. It is recommended
that you save the capture video file to a location other than the
C:drive, limit the file size of the captured video or reduce video
resolution (Options >Video Capture Pin... >Output Size).
The computer is off (or in
Sleep Mode) but powered by
the AC/DC adapter plugged
in to a working outlet or
powered by the battery with a
capacity level above 20%. I
have plugged a device into
the powered USB port in
order to charge it, but the
device is not charging.
The port is not powered on. Toggle power to the port using the Fn
+ power button combination.
This function may not work with certain external USB compliant
devices (check your device’s documentation). If this is the case,
power the computer on and connect the external USB device
in order to charge it.

Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft is
usually prohibited. Make
sure the wireless mod-
ules are OFF if you are
using the computer
aboard aircraft.
Use the key combina-
tions to toggle power to
the 3.75G/HSPA/WLAN/
Bluetooth modules, and
check the LED indicator/
visual indicator to see if
the modules are powered
on or not (see Table 2 on
page 7 and Table 3 on
page 8).

15
English
Specifications

Latest Specification Information
The specifications listed in this section
arecorrectat thetime of goingto press.
Certain items (particularly processor
types/speeds) may be changed, de-
layed or updated due to the manufac-
turer's release schedule. Check with
your service center for details.
Processor Options
Model A:
Intel® Core™ i7 Processor
i7-2620M (2.7GHz)
4MB L3 Cache, 32nm, DDR3-1333MHz,
TDP 35W
Intel® Core™ i5 Processor
i5-2540M (2.6GHz), i5-2520M (2.5GHz), i5-
2410M (2.3GHz)
3MB L3 Cache, 32nm, DDR3-1333MHz,
TDP 35W
Intel® Core™ i3 Processor
i3-2330M (2.2GHz), i3-2310M (2.1GHz)
3MB L3 Cache, 32nm, DDR3-1333MHz,
TDP 35W
Intel® Pentium® Processor
B950 (2.1GHz), B940 (2.0GHz)
2MB L3 Cache, 32nm, DDR3-1333MHz,
TDP 35W
Model B:
Intel® Core™ i7 Processor
i7-2620M (2.7GHz)
4MB L3 Cache, 32nm, DDR3-1333MHz,
TDP 35W
Intel® Core™ i5 Processor
i5-2540M (2.6GHz), i5-2520M (2.5GHz)
3MB L3 Cache, 32nm, DDR3-1333MHz,
TDP 35W
Core Logic
Model A:
Intel® HM65 Chipset
Model B:
Intel® QM67 Chipset
BIOS
Model A:
AMI™ BIOS (32Mb SPI Flash ROM x 1)
Model B:
AMI™ BIOS (32Mb SPI Flash ROM x 2)
LCD
15.6" (39.62) HD/HD+ TFT LCD
Memory
Two 204 Pin SO-DIMM Sockets Supporting
DDR3 1333MHz Memory
Memory Expandable up to 8GB
(The real memory operating frequency
depends on the FSB of the processor.)
Video Adapter
Intel HD Graphics 3000
Shared Memory Architecture (DVMT)
up to 1.7GB
Microsoft DirectX®10 Compatible
Storage
(Factory Option) One Changeable
12.7mm(h) Optical Device Type Drive
(Super Multi)
One Changeable 2.5" 9.5 mm (h) SATA
(Serial) HDD

16
English
Keyboard
Full-size “WinKey” keyboard (with numeric
keypad)
Pointing Device
Built-in Touchpad
Security
BIOS Password
Security (Kensington® Type) Lock Slot
Fingerprint Reader
TPM v1.2
Intel vPro (Model B only)
Audio
High Definition Audio Compliant Interface
2 * Built-In Speakers
Built-In Microphone
Interface
One Powered USB 2.0 Port (see page 6)
Two USB 3.0 Ports
One eSATA/USB 2.0 Combo Port
One HDMI-Out Port
One Headphone-Out Jack
One Microphone-In Jack
One S/PDIF Out Jack
One RJ-45 LAN Jack
One DC-in Jack
One External Monitor Port
One ExpressCard/34(54) Slot
One Docking Port
Card Reader
Embedded Multi-In-1 Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/
SDXC
MS (Memory Stick) / MS Pro / MS Duo
Mini Card Slots
Slot 1 for WLAN Module or WLAN and
Bluetooth Combo Module
(Factory Option) Slot 2 for 3.75G/HSPA
Module
Communication
Built-In Gigabit Ethernet LAN
(Factory Option) 1.3M/2.0M Pixel USB PC
Camera Module
(Factory Option) 3.75G/HSPA Mini-Card
Module
Model A:
(Factory Option) Intel® Centrino®
Advanced-N 6230 Wireless LAN (802.11a/
g/n) + Bluetooth 3.0
(Factory Option) Intel® Centrino® Wire-
less-N 1030 Wireless LAN (802.11a/g/n) +
Bluetooth 3.0
(Factory Option) Third-Party Wireless LAN
(802.11b/g/n) + Bluetooth 3.0
Model B:
(Factory Option) Intel® Centrino®
Advanced-N 6230 Wireless LAN (802.11a/
g/n) + Bluetooth 3.0
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19V, 3.42A /18V, 3.5A (65W)
6 Cell Smart Lithium-Ion Battery Pack,
48.84WH
Environmental Spec
Temperature
Operating: 5°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Dimensions & Weight
374mm (w) * 256mm (d) * 37.9mm (h)
2.5kg (with 48.84WH Battery)

17
