azalp 10-122-0103-0 User manual

200O
510 110
620
26
620
900O
1060O
210
540
590 1150 320
3300

1060
360
226
O540

590
50 250
320
310O
300O
900O
500O
540O
900250

2
19
17
6
8 7
27
16
126 28
18
4
11
9
24
12
10
15
14
22 2120
23
25 32828 26
5
29
13

Nr Tähis Nimetus Kogus
1 28-001.000 Kolle 1
2 28-000.001 Jalg 2
3 28-000.002 Tagatükk 1
4 27-000.006 Kronstein peegel 8
5 27-000.005 Kronstein 8
6 28-000.008 Lauaplaat 8
7 28-003.000 Siiber 1
8 28-000.004 Sahtel 1
9 28-000.003 Tuleserv 2
10 abikoost Restid abikoost 1
11 28-000.017 Toru 2
12 28-002.000 Pannialus 1
13 27-000.100 Tuharest 300 1
14 28-005.000 Väike alus 1
15 28-007.000 Konks 1
16 28-016.000 Kubu kronstein 2
17 28-011.000 Kubu 1
18 28-000.018 Plaat 2
19 27-010.001 Suitsutoru 2 1
20 27-010.002 Korsten 1
21 27-010.003 Krae 1
22 27-012.000 Korstna katus 1
23 x Nupp 1
24 x Nõelsplint d=5 DIN
11024
3
25 x Polt M6x15 DIN 933 14
26 x Mutter DIN934 M6 18
27 x DIN603 M6x20 4
28 x Seib M6 DIN 125 32
29 x Puidukruvi 32

ASSEMBLY INSTRUCTIONS FOR THE BARBECUE GRILL

NB!Pleasefollowtheassemblydrawingsalongwiththeseinstructions.
1. Removetheknob(23)ofthedamperturningitcounterclockwise.Removetheash
drawer(8)anddamper(7)fromthebodyofthegrill.
2. Fixthelegs(2)ofthegrilltothebody(1)usingfoursetsofnuts(26),bolts(25)and
washers(28).Donottightenthenutsallthewaysothepositionofthelegscanbe
adjustedafterthebackpieceisattached.
3. Fixthebackpiece(3)tothebody(1)andlegs(2)usingsixsetsofnuts,boltsand
washers.Adjustthelegsandthebackpiecetoagoodfitandtightenallthenuts.
4. Insertthedamperallthewayintothebodyofthegrill.Liftthedamperupontothe
supportingedgesandpullbacktowardsthefrontsoitwillrestonthesupportingedges.
Bringthehandleofthedamperthroughtheholeinthefrontfaceofthegrillbody.
Attachtheknobofthedamper.
5. Inserttheashdrawer(8)tothebodyofthegrill.
6. Placethetwofireguards(9)onthebodyofthegrillsotheywillinserttothe
correspondingopenings.Turntheguardsslightlycounterclockwisetofixtheminplace.
7. Placethecastirongrate(13)inthemiddleofthegrill.
8. Inserttwostainlesssteelpipes(11)withholesdowntothetwoholesinthegrillbody.
Insertthehook(15),smallcookingtray(14)andbigcookingtray(12)ontothestainless
steelpipes(11).Fixtheminplaceusingfixingpins(24).
9. Attachtwosupports(4and5)toeachwoodentableusingthewoodscrews(29).Mind
thatthereareseparatetypesofsupportsforleftandrightsideofeachtable(pleasesee
thedrawing).Theholesforthescrewsarepredrilledforeaseofassemblyandbestfit.
Checkthatthesupportsfittheopeningsinthegrillbodybeforetighteningthescrews.
10. Fixthegrilltothefloorthroughtheholesinthegrilllegswithsuitablescrewsoranchors
(notsupplied).



ASSEMBLY INSTRUCTIONS FOR THE SMOKE CATCHER

1. Attachtwobrackets(16)tothehoodusingnuts,washers,roundheadsquareneckbolts
(27)andtheplatesfromstainlesssteel.Mindthattheplatewillbeplacedoutsidethe
hood.Donottightenthenutsallthewaysothepositionofthebracketscanbeadjusted.
2. Liftthesmokecatcher(17)withbracketsontothepipes.Nowfixthenutsofthehood
brackets.
3. Puttheplanechimneypipe(19)ontothesmokecatcher.
4. Placethechimneycollar(21)onaroundthechimneypipewithpressing(20).
5. Insertthepipewiththecollarintochimneyopeningsoitwillrestonthecollarandthe
chimneypipewithoutthepressingisinsidetheotherpipe.
6. Putthechimneyhat(22)ontothechimneyandtightenwithwingnutandwingbolt.

