Azustar RockTube 2000 User manual

for RockTube™ 2000
Quick Start
Guide
www.azustar.com

C
M
Y
CM
MY
CY
CMY
K
BT1101 QuickStartGuide(English).pdf 1 2012/9/24 21:19:51

RockTube™ 2000
company, without any warranty. Improvements and changes to this
User Guide necessitated by typographical errors, inaccuracies of
current information, or improvement to software and device, may be
made by Auzura at any time and without notice. Such changes will,
however, be updated into new revisions of this User Guide.
All rights reserved.
Auzura Co. Ltd, 2012
Azustar is the registered trademark of Auzura Co. Ltd.
Bluetooth® and the Bluetooth logos are trademarks owned by
Bluetooth SIG, Inc, USA and any use of such marks by Auzura Co.
Ltd. is under license.
ENGLISH
ENGLISH
WELCOME, LET’S ROCK!
 Enjoy crystal clear music wirelessly from Bluetooth A2DP music
players or mobile phones.
 Fine quality aluminum tube housing design reduces sound leakage
and brings out crystal clear audio.


playback, and operations like playback/pause/skip to the next or
previous song.

or conference call with Bluetooth phones that support these
 Advanced DSP technology design for noise suppression and echo
Thank you for purchasing this Azustar® RockTube™ 2000 speaker.
This unit uses Bluetooth® wireless technology and below are its key
features:
C
M
Y
CM
MY
CY
CMY
K
BT1101 QuickStartGuide(English).pdf 3 2012/9/24 21:19:51

ENGLISH
ENGLISH
cancellation in noisy environment to enhance the audio quality.
 Built in high capacity re-chargeable lithium polymer battery of
2200mAh allows a long talk time (appro.15 hours), longer music
play time (appro.15 hours), long standby time (appro.1000 hours)
and can even be used for most mobile phone battery extenders
or chargers.
 This unit is designed and built for dust and splash proof
protection,
activities or listening to your favourite music near environments
with water.
 This unit is not designed to be submerged into water or liquid.
OVERVIEW
1. Multi-function Button (MFB)
Power On / Off
Pairing


ay / Pause
2. LED Status Indicator
3. Volume Up
4. Volume Down
5. Backward
6. Forward
7. Power Socket
8. Microphone
9. Speaker
Figure 1
C
M
Y
CM
MY
CY
CMY
K
BT1101 QuickStartGuide(English).pdf 4 2012/9/24 21:19:52

ENGLISH
ENGLISH
CHARGING
it with the supplied White color USB charging cable. Open the rubber
cover of the power socket (button 7, see Figure 2) and plug the audio
jack end of the White cable into power socket. Next, insert the USB
end into a computer / notebook ‘s USB port or a USB charger. The
charging time is about 6 hours for a full charge.
7
Use only the supplied
white colour USB cable to
charge RockTube™ 2000.
During charging,
RockTube™ 2000 is in
standby mode- meaning
you can still play music
in RockTube™ 2000
via Bluetooth (see next
section).
Figure 2


TURNING ON
AND OFF


To turn on RockTube™ 2000
Press and hold down MFB button until you hear a beep sound
and the LED turns Blue.
To turn off RockTube™ 2000
Press and hold MFB button until you hear a long beep and the
LED turns Red for 3 seconds.
To use RockTube™ 2000 with a phone, you need to pair RockTube™
2000 with a phone. After successful pairing, RockTube™ 2000
connects automatically to the phone as soon as RockTube™ 2000 is
turned on and within range.
PAIRING ROCKTUBE™ 2000
WITH A PHONE
C
M
Y
CM
MY
CY
CMY
K
BT1101 QuickStartGuide(English).pdf 5 2012/9/24 21:19:52

ENGLISH
ENGLISH
To pair RockTube™ 2000 with a phone:
1. Make sure RockTube™ 2000 is turned off.
2. Press and hold MF button for 8 seconds until the LED status
3. Turn on the Bluetooth function in the phone. For instructions, see
the phone User Guide.
4. Place the phone to be paired near to RockTube™ 2000 and
activate the search for Bluetooth devices and add a new device
steps in the pairing mode of the phone.
5. Once “RockTube™ 2000” appears in the phone, select it and
enter the passcode “0000”. When the pairing is successful,
times, followed by a long beep sound.
If the pairing cannot be completed within 3 minutes after activating
its red LED 5 times and will turn off. To pair again, repeat steps 1 to
5 for both devices.
Tips:
ADJUSTING THE
VOLUME
To change the volume of RockTube™ 2000 during a conversation or
listening to music, you can press Volume UP (3.) or Volume Down (4.)
Tips – For repeated volume adjustment press Up or Down Volume button.
A short beep tone indicates the maximum and minimum volume level.
C
M
Y
CM
MY
CY
CMY
K
BT1101 QuickStartGuide(English).pdf 6 2012/9/24 21:19:52

ENGLISH
ENGLISH
ROCK ON!
After a successful Bluetooth A2DP connection, turn the volume on
your phone/device fully up and then adjust the audio volume on the
RockTube™ 2000 with the Volume Up and Volume Down button to
a comfortable volume as mentioned above.
For best listening results, make sure your RockTube™ 2000 speaker
end is facing UP and Multi Function control button end facing DOWN.
Speaker
Besides being a speaker, your RockTube™ 2000 can be used as a
wireless speakerphone as well. For best conversation results, make
sure the control / microphone end of RockTube™ 2000 is facing UP
and near to your speech. The built-in microphone will work when
RockTube™ 2000 is connected via Bluetooth.
Microphone on the top.
LET’S TALK
C
M
Y
CM
MY
CY
CMY
K
BT1101 QuickStartGuide(English).pdf 7 2012/9/24 21:19:52

ENGLISH
ENGLISH
1.
2.
3.
4.
5.
To receive a call
When the music is playing on RockTube™ 2000 via Bluetooth® from
your phone and an incoming call interferes, the music will stop and a ring
tone will play on RockTube™ 2000. You can press the MF button once
to answer the call. You will hear a short beep on RockTube™ 2000.
Tips: You can adjust the volume of the call on the Bluetooth handset or
the Volume buttons on RockTube™ 2000.
To terminate a call
You can end a call by pressing the MF button once on RockTube™
2000 (you will hear a short beep).
Reject incoming call
To reject incoming calls, hold the MF button for 1 second and you will
hear a short beep. (Not applicable while charging).
Redial last number
In any mode, double press the MF button for last number redial. You
will hear a short beep.
Call Transfer
You can transfer the voice call from between RockTube™ 2000 to
your connected phone or vice versa while in talk mode by pressing
MF button for 1 second. You will hear a short beep.
6. Mute/Un-mute voice
You can mute or un-mute the voice during a call by pressing the MF
button twice. You will hear two short beeps that indicates the mute
effect.
7. Call Waiting
 You can perform call waiting during a call when you hear another
be released.

MF button twice.
 To reject the second call, press the MF button for 1 second.
Note:
 You can swap the call by pressing the MF button twice while in
talk mode.
 You can short press the MF button once to release the active call
while in talk mode.
C
M
Y
CM
MY
CY
CMY
K
BT1101 QuickStartGuide(English).pdf 8 2012/9/24 21:19:53

ENGLISH
ENGLISH
REMOTE CONTROL
YOUR MUSIC!
you can control your music tracks on your connected Bluetooth
device (that also supports AVRCP) from the RockTube™ 2000
control button.
Play – press Play/Pause button once
Pause – Press Play/Pause button once
Track forward – press Forward Button once
Track backward – press Backward button once
Note: The operation of the Bluetooth® connected device may
may not work. Kindly refer to the operating instructions of your
Bluetooth® device.
CHARGING YOUR
MOBILE PHONE
You can use the RockTube™ 2000 as your mobile phone battery
extender or charger. Please use the right charging cable for your
mobile phone charging connection.
For Micro USB Phones
For other mobile devices cable
plug into USB A cable for charging.
C
M
Y
CM
MY
CY
CMY
K
BT1101 QuickStartGuide(English).pdf 9 2012/9/24 21:19:53

ENGLISH
ENGLISH
1.
2.
3.
RESETTING / REMOVING
THE PAIRING HISTORY
You may reset the RockTube™ 2000 to its default settings. Resetting
will also remove the pairing history of your RockTube™ 2000 with
the mobile phone.
During standby mode without the plug in charging cable, press
and hold volume + and volume – at simultaneously for 5 seconds,
RockTube™ 2000 will have two short beeps and the red LED
Release the button and the RockTube™ 2000 will switch off.
RockTube™ 2000 is reset and the pairing history will be removed
in the previously paired devices.
You may also reset the RockTube™ 2000 to its default settings by
hard reset.
1. Plug charging cable into socket and press MF button and Volume
+ at the same time.
2. The red LED will turn on for 2 seconds and RockTube™ 2000
will switch off.
3. RockTube™ 2000 is reset.
Azustar® RockTube™ 2000 is designed to work with Bluetooth®
devices. However, due to different variations in function and
implementation of Bluetooth® devices, interoperability between
RockTube™ 2000 and all Bluetooth®-enabled products is not
guaranteed.
C
M
Y
CM
MY
CY
CMY
K
BT1101 QuickStartGuide(English).pdf 10 2012/9/24 21:19:53

ENGLISH
We, Auzura Company Ltd, declare that our following product:
Auzura type BT1101 is in conformity with the following essential
requirements of Council Directive 1999/5/EC (referred to as 
Directive): Article 3.1a, 3.1b and 3.2. and the product is manufactured in
accordance with Annex II of the above directive.
Auzura declares under our sole responsibility that the RockTubeTM 2000 is
in conformity with the provisions of the following Council Directive 1999/5/
EC (referred to as  Directive): Article 3.1a, 3.1b and 3.2. and the
product is manufactured in accordance with Annex II of the above directive.
Dispose of the packaging and this product in accordance with the
latest previsions. 04/2012 Printed in China
FCC ID: A4I-BT1101
DECLARATION OF CONFORMITY
FOR ROCKTUBE™ 2000
