B-TEC Lithium EPL-100BT-12V-G2 User manual

Enerdrive B-TEC Lithium LiFePO4, Lithium Ion Phosphate
Prismatic Cell Battery with Smart Phone Monitoring
Enerdrive B-TEC G2 Manual (Rev. 2.1)
EPL-200BT-12V-G2
EPL-100BT-12V-G2 EPL-125BT-12V-G2

Enerdrive B-TEC G2 Manual (Rev. 2.1)
EPL-100BT-12V-G2
EPL-125BT-12V-G2
EPL-200BT-12V-G2
April 2020
Warranty Returns: Reply Paid 8786, Wynnum Plaza, QLD 4178
Email: [email protected]
Support Contact Information
For safe and optimum performance, the Enerdrive LiFePO4 Lithium Ion Phosphate Battery with Smart Phone
Monitoring must be used properly. Carefully read and follow all instructions and guidelines in this manual and
give special attention to the CAUTION and WARNING statements.
While every precaution has been taken to ensure the accuracy of the contents of this guide, Enerdrive assumes no
responsibility for errors or omissions. Note as well that specifications and product functionality may change
without notice.
Please be sure to read and save the entire manual before using your Enerdrive LiFePO4 Lithium Ion Phosphate
Battery with Smart Phone Monitoring. Misuse may result in damage to the battery and/or cause harm or serious
injury. Read manual in its entirety before using the unit and save manual for future reference.
Page 2 Enerdrive B-TEC G2 Manual (Rev. 2.1)

TABLE OF CONTENTS
SECTION 1 - QUICK START GUIDE
SECTION 2 - CHARGING
SECTION 3 - DISCHARGING (USING THE BATTERY)
SECTION 4 - PROTECTING YOUR BATTERY
SECTION 5 - RESTARTING YOUR BATTERY
SECTION 6 - USING THE BLUETOOTH BATTERY MONITOR APP
SECTION 7 - WARNINGS
SECTION 8 - FAQ
SECTION 9 - BATTERY SPECIFICATIONS
SECTION 10 - WARRANTY & SUPPORT INFORMATION
4
5
6
7
8
9
10
11
13
16
www.enerdrive.com.au Page 3

Section 1 - Quick Start Guide
Cable Conversion Guide
Step 1. Connect the Positive (Red) and Negative (Black) cables to the battery, ensuring you are using
cable that is of adequate size for the demands of the system, and well crimped and protected
termination lugs.
Example;
1000W Inverter - at least Gauge 2 (35mm²)
2000W Inverter - at least Guage 00 (70mm²)
The spring washers must be used on the battery terminal bolts - they apply pressure to the lugs for a
secure connection. There is no need to over-tighten the bolts, simply ensure there is no movement of the
cables. Make sure the main Battery Cable lug is mounted directly onto the Battery terminal with no
washers between them.
Step 2. Your charger/s need to be programmed for Lithium, with a charging voltage of 14.0 -14.6 Volts
and Float 13.5 - 13.6 Volts.
Do not use a lead-acid charger if you want the best out of your battery. These chargers can damage the
battery if left connected and will void your warranty.
Step 3. Fully charge the battery and it is ready for use.
*Note: The above is a“Quick Start” guide, detailed information follows.
Page 4 Enerdrive B-TEC G2 Manual (Rev. 2.1)

Section 2 - Charging
Lithium batteries need to be charged slightly differently to other batteries.
To ensure they live a long life and provide maximum capacity, you must use a charger with a lithium
setting - this includes:
AC Chargers
DC to DC Chargers
Solar Controllers
If your charger allows, set the charge voltage from 14.0 -14.6 Volts and Float 13.5 - 13.6 Volts. and proceed
with charging. We recommend charging at the lower end of the voltage scale for maximum longevity of
the battery.
It is recommended that the charging current for the 100Ah & 125Ah batteries should be 40 Amps or less,
and for the 200Ah battery, 60 Amps or less. You can charge at higher currents, but the recomended 60
Amps or less is recommended. See Section 9 - Battery Specifications.
*Note:
You can charge a lithium battery with a non-lithium charger, but these chargers can deliver too much or
too little voltage and may not cut off when the battery is full. Enerdrive recommends the use of a Lithium
profiled charger that meets the batteries voltage specifications.
DO NOT use a charger with a“Pulse Stage”or“Equalisation Mode”. This will damage the battery and void
warranty.
DO NOT connect this battery to a start battery with a VSR (Dual Battery System or “Voltage Sensitive
Relay”). The voltage of the Lithium battery may keep the VSR switched on resulting in it discharging into
the start battery and possible damage to the Lithium BMS system. The battery is not covered by warranty
if installed in this manner.
www.enerdrive.com.au Page 5

Section 3 - Discharging (using the battery)
The Enerdrive B-TEC Lithium Battery can deliver a maximum of 100 Amps for the 100 & 125Ah battery and
200 Amps for the 200Ah battery for 30 minutes due to the high power, high quality Battery Management
System (BMS) and prismatic Lithium cells inside the battery. For this to happen, you MUST USE cable of the
correct guage.
These are recommended wire guages and approximate current specifications for cable lengths shorter
than 1-2 meters:
Guage 2 35mm² 100 Amps
Guage 0 50mm² 150 Amps
Guage 00 70mm² 200 Amps
A 2000W inverter will draw approximately 170-180 Amps through the cables connected between it and the
battery - this will NOT be achieved with undersized wire.
Consider current like plumbing...
The thicker the pipe (cable) the more current can flow through it.
Page 6 Enerdrive B-TEC G2 Manual (Rev. 2.1)

Section 4 - Protecting Your Battery
Lithium batteries cannot be protected effectively by monitoring voltage due to their ability to maintain
a higher voltage for much longer than AGM or flooded/sealed batteries.
“State of Charge” (SOC%) percentage is the most accurate and effective method of disconnecting loads
from the battery - this requires a battery monitor which uses a“shunt”to measure the current going into
(Charging) and coming out of (Discharging) the battery.
Example;
200 Amp Battery Fully Charged State of Charge = 100%
50 Amps used State of Charge = 75%
100 Amps used State of Charge = 50%
It is recommended that Lithium batteries not be discharged below 20% State of Charge or the battery
life may be shortened.
As an added layer of protection, the Enerdrive B-TEC Lithium Battery also has a built-in low voltage
disconnect circuit. If this occurs, please refer to Section 5 - Restarting Your Battery.
www.enerdrive.com.au Page 7

Section 5 - Restarting Your Battery
We strongly recommend keeping the battery charged to avoid activating the internal low battery
voltage disconnect.
If your DC system shuts down, the battery may require re-starting. Please use the following procedure:
1. Turn off ALL DC and AC loads
2. Connect charging source/s and switch ON
3. Hold the“Reset”button on top of the battery for 5-10 seconds
4. Release and wait 7 seconds
5. Power should now be restored and charging will commence
6. When the SOC (State of Charge) is above 20%, loads can be switched on if required
By continuously tripping the low voltage disconnect of the battery you may cause damage to sensitive
electronic equipment that is attached to the battery. I.E. battery chargers, solar controllers, inverters,
stereo equipment etc - all of which are not covered under the battery warranty.
Page 8 Enerdrive B-TEC G2 Manual (Rev. 2.1)
EPL-100BT-12V-G2, EPL-125-12V-G2
EPL-200BT-12V-G2 FLAT BATTERY
RESET BUTTON
FLAT BATTERY
RESET BUTTON

Section 6 - Using the Smart Phone Battery Monitor
The Enerdrive B-TEC Lithium Battery incorporates a Smart Phone Monitoring system. By downloading
the Android™ or Apple® app to your smart phone or tablet, you can monitor the following information:
Battery Capacity Individual Cell Voltage
Battery Voltage Battery Temperature
Battery Current (Amps) Battery Cycles
Battery State of Charge (SOC) Battery Alarms
Battery State of Health (SOH) Battery Event Information
Battery Status
* Red light is only an indicator, not a fault condition.
* The default password is 1234 (this allows you to change the Bluetooth name of the battery).
* A notification will only appear in the notifications page if under alarm condition.
www.enerdrive.com.au Page 9

Please read and follow the cautions listed on the battery before installation. Improper use may cause
heat, fire, rupture, damage or capacity deterioration of the battery. Enerdrive Pty Ltd is not responsible
for any accidents cause by the usage without following our specification.
The battery has a low voltage disconnect incorporated for self protection. If the battery is drawn down
to the internal low voltage disconnect set point (≤2.8v per cell) the battery will disconnect.
Section 7 - Warnings
Page 10 Enerdrive B-TEC G2 Manual (Rev. 2.1)

Section 8 - FAQ
Q: Can I parallel B-TEC batteries?
A. The short answer is yes.
The long answer is - if you are drawing large currents, the maximum current delivered will be limited to
the maximum instantaneous discharge capacity of one battery. for the 100 & 125Ah batteries this is 100
Amps and for the 200Ah battery, 200 Amps. With low to medium current draw installations (the vast
majority of applications) you may never see an issue and your storage capacity will be greatly increased
- I.E. 2 x 200 Amp = 400 Amp capacity.
When installing, ensure they are fully charged, separately - then let sit for 30 minutes before connecting
together. When connecting in parallel - take the positive from Battery 1, and the negative from
Battery 2 to your system as per the diagram below.
Battery Monitor Shunt
(if installed)
Battery Positive & Negative Link Cable
must be equal lengths
Main Fuse
Main Negative Cable
Main Positive Cable
The Smart Phone App will only show the information from one battery at a time - not both. This is another
advantage of a separate Battery Monitor - it will show the total system environment.
Ultimately for larger AH systems, the best solution is to use the Enerdrive“Pro Series”battery system -
see our website or contact us for details.
www.enerdrive.com.au Page 11

Q: Can I series connect B-TEC batteries to achieve higher voltage?
A: No. Enerdrive offers higher voltage Lithium solutions - contact us for details.
Q: Can I use an Inverter with my B-TEC battery?
A: Of course! We recommend an inverter size of 1000 watts maximum for the 100 &125Ah batteries
and 2000 watts maximum for the 200Ah battery.
Q: Can I install the B-TEC battery in a wet area?
A: It is not recommended - the best environment is a dry, cool, well ventilated area.
Q: Can I install the B-TEC battery on its side or end?
A: No.
Page 12 Enerdrive B-TEC G2 Manual (Rev. 2.1)

EPL-100BT-12V-G2
3.90V ± 0.03V
5s Auto Release
Disconnect Load
Protection to 65°C ± 5°C
Release at 50°C ± 5°C
Release at 55°C ± 5°C
Release at 45°C ± 5°C
Auto release after 5s
Length 318mm Length 318mm Length 505mm
Width 165mm Width 165mm Width 172.5mm
Height 215mm Height 215mm Height 265mm
Approx 12.6 kg Approx 15.0 kg Approx 25.0 kg
≤30 days -20°C to 35°C,
45 to 75% RH
≤ 30 days -20°C to 35°C,
45 to 75% RH
≤ 30 days -20°C to 35°C,
45 to 75% RH
≥ 30 days -10°C to 30°C,
45 to 75% RH
≥ 30 days -10°C to 30°C,
45 to 75% RH
≤30 days -20°C to 35°C,
45 to 75% RH
≤3% Per Month ≤3% Per Month ≤3% Per Month
Battery Discharge Over Temperature
Battery Charge Over Temperature
Short Circuit Protection
Mechanical Characteristics
Dimensions
Weight
Storage Information
Temperature & Humidity Range
Self-Discharge Rate
Over Temperature Protection
12.8V
≤11.20V≤11.20V≤11.20V
≤60A
100Ah
11.20 - 14.60V
Discharge below release voltage
Over-Charge Release Per Cell
Over-Charge Release Method
Circuit Protection
Section 9 - Battery Specifications
www.enerdrive.com.au Page 13
Enerdrive B-TEC Lithium Battery Technical Data
Normal Specification EPL-100BT-12V-G2 EPL-125BT-12V-G2 EPL-200BT-12V-G2
Standard Charge Specification (Lithium profile charger required)
Standard Discharge Specification
Nominal Voltage 12.8V12.8V
≤2000 Cycles
≤33A ≤40A
0 - 45°C
60A @ 25°C for 30 mins
-20 - 60°C
11.20 - 14.60V 11.20 - 14.60V
450A for 1.0s
100A @ 25°C ± 5°C for 30 mins 100A @ 25°C ± 5°C for 30 mins 200A @ 25°C ± 5°C for 30 mins
3.60V ± 0.05V
80A @ 25°C for 30 mins 150A @ 25°C for 30 mins
14.20 - 14.60V14.20 - 14.60V14.20 - 14.60V
13.50 - 13.80V 13.50 - 13.80V 13.50 - 13.80V
125Ah 200Ah
Nominal Capacity
Battery Charge Temperature
Normal ChargeVoltage CV/CC*
Standby (Float) Voltage
Maximum Charge Current
Battery Discharge Temperature
Battery Output Voltage Range
Maximum Discharge Current
Pulse Discharge Current
Discharge Cut-off Voltage
Over-Charge Protection
Over-Charge Protection Per Cell
2.80V ± 0.05V
Yes Yes Yes
3.20V ± 0.05V
110A for 30s - 450A for 1s 110A for 30s - 450A for 1s 220A for 30s – 450A for 1s
Apply Charge/Voltage ≥12.8V Apply Charge/Voltage ≥12.8V Apply Charge/Voltage ≥12.8V
Over-Discharge Protection Per Cell
Over-Discharge Release Per Cell
Over-Discharge Release Method
Battery Manual Reset Button
Discharge Over Current
Protection Reset Time
Over Current Release Method
Over Current Protection
Over-Discharge Protection
The battery is supplied with a LiFeP04 Battery Management System (BMS) that can monitor and optimise each single prismatic cell during charge and discharge, to
protect the battery pack from overcharge, over discharge and short circuit. Overall, the BMS helps to ensure safe and accurate operation of the battery.
Recommended Charge Current for Maximum Life
Cycle Life (DOD-80% under controlled conditions)

Page 16 Enerdrive B-TEC G2 Manual (Rev. 2.1)
Section 10 - Warranty & Support Information
3 years for; pleasure marine and automotive applications in cycling and non-cycling applications.
1-3 Year Limited Warranty
2 years for; commerical & industrial applications in cycling and non-cycling applications
Return and/or Repair Policy
If you are experiencing any problems with your unit, please contact our customer service department
at [e-mail] or Phone [phone] before returning product to retail store. After
speaking to a customer service representative, if products are deemed non-working or malfunctioning,
the product may be returned to the purchasing store within 30 days of original purchase. Any defective
unit that is returned to Enerdrive within 30 days of the date of purchase will be replaced free of charge.
If such a unit is returned more than 30 days but less than the states warranty period, Enerdrive will
repair the unit or, at its option, replace it, free of charge. If the unit is repaired, new or reconditioned
replacement parts may be used, at manufacturer’s option. A unit may be replaced with a new or
reconditioned unit of the same or comparable design. The repaired or replaced unit will then be
warranted under these terms for the remainder of the warranty period. The customer is responsible
for the shipping charges on all returned items back to Enerdrive.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be
of acceptable quality and the failure does not amount to a major failure.
The limited warranty is the only one that applies to this unit, and it sets forth all the responsibilites of
Enerdrive. There is no other warranty, other than described herein. Any implied warranty of merchantability of
fitness for a particular purpose on this unit is limited in duration to the duration of this warranty.
Enerdrive Pty Ltd warrants it B-TEC Lithium Battery (hereafter referred to as “Battery”) to be free of defects
in material and workmanship for the following Applicable Warranty Period:
An additional 24 months Pro-Rata support service is included in the battery for pleasure, marine and
automotive applications. The pro-rated price is calculated as a percentage of the current suggested
retail price. Pro-Rata Support Service applicable to original end user only.
The battery is warranted, to the original purchaser only, to be free of defects in materials and workmanship
for the stated warranty period above from the date of purchase without additional charge. The warranty
does not extend to subsequent purchasers or users other than OEM applications.
Enerdrive does not warrant the battery for use in any residential system sold with the intent or purpose of a
“Tariff Adjustment Program” of any type.

www.enerdrive.com.au Page 17
Limitations
This warranty does not cover damage or defects resulting from normal wear and tear (including chips,
scratches, abrasions, discolouration or fading due to usage or exposure to sunlight), accidents, damage
during shipping to our service facility, alterations, unauthorized use or repair, neglect, misuse, abuse,
failure to follow instructions for care and maintenance, acts of god, re and ood.
If your problem is not covered by this warranty, contact our Support Team at
[e-mail].
au or phone [phone] for general information if applicable.

Page 14 Enerdrive B-TEC G2 Manual (Rev. 2.1)
                               

www.enerdrive.com.au Page 15
   
     
110.00
41.00 41.00131.00 131.00131.00
30.00
170.00
475.00
30.00
4mm4mm
Fastening Holes
(fasteners
not included)
(fasteners
not included)
Fastening Holes
            
          
            
           
  
  
  
Flat Battery
Reset Button
                  

ENERDRIVE PTY LTD
P.O. Box 9159, Wynnum Plaza, Queensland, Australia 4178
Ph: 1300 851 535 / Fax: [phone]
Email: [email protected]
Web: www.enerdrive.com.au
