B-Tech ATLAS BT606 Instruction Manual

BT606
ATLAS™LOUDSPEAKER FLOOR STANDS
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 2 Speaker Stands
B-TECH AUDIO VIDEO MOUNTS
www.btechavmounts.com
FEATURES
CONTENTS
TOOLS REQUIRED
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions..........................................................................................................................11
B-Tech Contact Details.....................................................................................................................12
PLEASE KEEP THIS FOR FUTURE REFERENCE
●Designed for loudspeakers up to 35kg (77lbs)
●Sound isolating loudspeaker floor stands
●Fillable columns for superior dampening
●Top and bottom isolating spikes provided
●Stand height: 60cm (23.6”)
Dry sand and
funnel (optional)
4mm Hex Key
(supplied)
Level
(optional)
Adjustable spanner
(optional)

4
BT606
PARTS LIST
Suitable for loads up
to 35kg (77lbs)
This pack contains 2
loudspeaker floor
stands
1
2
2
3
4
4
4
49
5
10
6
78
9

PLEASE KEEP THIS FOR FUTURE REFERENCE 5
PARTS LIST
No. PART NAME QTY
1 SPEAKER PLATFORM 2
2 SUPPORT COLUMN 4
3 BASE PLATE 2
HARDWARE
4 M6 X 25mm HEX SCREW 8
5 M6 X 30mm BOTTOM SPIKE 8
6 M6 NUT (5mm THICK) 8
7 M6 X 15mm TOP SPIKE 8
8 M6 NUT (3mm THICK) 8
9 FOAM PAD 8
10 FLOOR PROTECTION DISC 8
11 4mm HEX KEY
(FOR PART 4)
1
12 B-TECH LOGO STICKER 2
6
5
10
7
8
49
11
12

6
INSTALLATION INSTRUCTIONS
1i. Attach poles to bottom plate.
2
2
3
4
11
Bottom
Top

7
ii. OPTIONAL - For enhanced performance the poles can be filled with sand.
2
2
3

8
2
4
4
1
2
2
3
11
Attach speaker platform to the poles.

9
3
i. Spikes
8
7
22
9
2
2
ii. Foam pads
Attach the spikes or alternative foam pads to the speaker platform.
1
1

10
4Attach spikes or foam pads to base plate.
3
9
ii. Foam Pads
i. Spikes
3
5
6
10
Optional - Floor
Protection Discs
5

11
BT606
PRODUCT DIMENSIONS
These instructions are intended as a guide only and B-Tech accepts no
liability for the accuracy of the information contained in this document.
240mm
9.4"
240mm
9.4"
175mm
6.9"
175mm
6.9"
BASE PLATE
SPEAKER PLATFORM
160mm
6.3"
160mm
6.3"
80mm
3.1"
130mm
5.1"
130mm
5.1"
633mm
24.9"
592mm
23.3"
