The A-Line Series from Baby Lock
No one knows your style better than your friends… and no one can help you bring your
ideas to life like your friends in the A-Line Series from Baby Lock. Spend some time with
Sofia, Audrey, Grace, Maria, Natalie or Lauren and you’ll quickly see how fun they are to have
around! These machines will be your best friends, whether you enjoy sewing cool crafting
projects or classic, timeless fashions like the A-Line skirt.
When it comes to sewing, embroidering, and serging, you can count on these durable and
easy-to-use machines to help you with whatever you like to create. Each machine in the A-Line
Series includes the features you need, plus convenient extras like a built-in needle threader, a
guide to get you started, and extra stitches and accessories to explore your creativity.
Another friend you’ll find with the A-Line Series is your Authorized Baby Lock Retailer. When
you come to them for a machine, you’ll get a free machine demo, a sewing lesson and more!
They’re always there to help you out with questions, new techniques or a quick machine
tune-up. Visit your local Baby Lock Retailer today – they’ll love to show you what the A-Line
Series is all about!
LBCB-ALine_Bro4.indd 2 4/10/09 9:37:22 AM

LBCB-ALine_Bro4.indd 3 4/10/09 9:37:51 AM

Built-in Design Library
Sofia includes 70 built-in
fashionable embroidery
designs, 120 frame patterns
and 5 font styles, so you can
start embroidering right away!
Meet
Trend-setting Sofia is full of ideas – the
perfect friend for all of your sewing
and embroidery projects. No matter
what you’d like to create, Sofia has
something to show-off, like 70 built-in designs and 5
font styles. With a USB port, LCD Touch Screen and
embroidery card slot, you can share all of your ideas with
Sofia. If you’re ready to add a personalized, creative flair with
embroidery, Sofia is ready to inspire you.
Technology Features
• USB direct connect (Type B)
• LCD Touch Screen (120 x 64 dot matrix) with touch pen
• Embroidery card slot
• Advanced needle threader
• Automatic thread cutter
• Quick-Set, top loading bobbin
• Quick-Set bobbin winder
• Upper and lower thread sensors to alert when threads
are broken
• LED light illuminates sewing surface
Embroidery Capabilities
• Built-in Embroidery Design Library
• 70 Embroidery designs
• 120 Frame Patterns
• 5 Font styles in upper and lower case
• Embroiders up to 4” x 4” (100mm x 100mm)
embroidery field
• Reads embroidery designs with a stitch capacity
of up to 32,000 stitches per design
• Up to 12 Memory Pockets for embroidery
equaling 512KB
• Enlargement (up to 20%)
• Reduction (up to 10%)
• Mirror imaging
Embroidery Capabilities (Continued)
• 1°, 10°, and 90° pattern rotation
• LCD Touch Screen shows:
• Estimated embroidery time display
• Needle advancement (1, 10, or 100 stitch increments)
• Measurements displayed in inches or millimeters (mm)
• Thread color indicator
• On-screen hoop size indicator
• Trial function
• Embroidery speed up to 400 spm (stitches per minute)
Embroidery Hoop
Embroider every design in
Sofia’s library with the included
4 x 4 embroidery hoop.
6-7/10” x 4” Hoop Available
An optional Multi-Positioning
Hoop is perfect for embroidery
larger than 4”x 4”.
LBCB-ALine_Bro4.indd 4 4/10/09 9:38:27 AM

LBCB-ALine_Bro4.indd 5 4/10/09 9:38:35 AM

Meet
Included Accessories
• Touch pen (stylus)
• USB cable
• 8 Snap-On Feet
• Buttonhole
• Embroidery
• Overcasting
• Monogramming
• Zipper
• Zig zag
• Blind stitch
• Button tting
• Soft cover for machine
• Embroidery bobbin thread
(White)
• Bobbins
• Seam ripper
• Twin needle
• 4” x 4” Embroidery hoop
and grid
• Plus more
Warranty
• 25-year limited
manufacturer’s warranty
• 10-year parts
• 5-year electrical
• 5-year computer
• 1-year labor
Multiple Accessories
No matter what type of project
you’re creating, Sofia makes it
easier with 8 snap-on feet and a
variety of additional accessories.
Advanced Sewing Features
• 67 Built-in stitches including:
• 46 Utility (with 10 styles of one-step buttonholes)
• 19 Decorative
• 1 Satin
• 1 Cross
• Stitch length 0.0mm - 5.0mm on sewing stitches
• Maximum Utility stitch width: 7mm
• Utility stitch editing capabilities
• Store personal stitch settings for each
utility stitch on machine
• Lock key for Utility and Decorative stitches
• Variable needle positions
• Twin needle settings key
Convenient Sewing Features
• Convenient one-touch buttons for
• Start/Stop • Reverse sewing
• Needle up/down • Thread cutter
• Sewing speed control
• Programmable needle up/down
• Needle plate with scale in inches and centimeters
• Electronic foot control with separate power cord
• Free arm with drop feed lever
• Accessory storage compartment
• Lightweight and compact size for easy travel
• Weighs under 14 lbs
• Weighs under 17 lbs with the
embroidery unit attached
Advanced Needle Threader
Sofia includes easy-to-follow,
numbered guides so you can
thread your needle with a few
simple motions.
Quick-Set Bobbin
Easily set your bobbin.
Merely drop in the top-
loading bobbin and pull the
thread through the slot. Let
Quick-Set do the rest.
Sofia is a multi-talented machine with
sewing features that are just as impressive
as her embroidery abilities. She’s ready
to share 67 stitches, one-touch buttons
and more. With 8 included feet and other accessories, Soa
has something to bring to virtually every project.
LBCB-ALine_Bro4.indd 6 4/10/09 9:39:05 AM

LBCB-ALine_Bro4.indd 7 4/10/09 9:39:35 AM

If you’re an ambitious sewer, Grace can
help you get to the head of the class
when it comes to your sewing projects.
This versatile machine is equipped to
keep up with your creativity with project-enhancing features
such as 40 built-in stitches, 1-step buttonholes and 7 accessory
feet. Grace has thought of everything you need to make
challenging projects a breeze, like a drop-in bobbin and
a built-in needle threader. From timeless, classic fashions to
modern crafts and décor, Grace will always be there to lend
a hand.
• 40 Built-in stitches, including 5 one-step buttonholes
• Drop-in bobbin
• Built-in needle threader
• Quick-set bobbin
• Free-arm sewing
• Drop feed for free motion techniques
• Adjustable stitch length: 0-5mm
• Adjustable stitch width: 0-7mm
• Variable needle positions
• Convenient thread cutter
Built-in Buttonhole
With the buttonhole foot, your
one-step buttonhole will be
automatically sized to match
your button every time.
Quick-Set Bobbin
Easily set your bobbin. Merely
drop in the top-loading
bobbin and pull the thread
through the slot. Let Quick-Set
do the rest.
Multiple Accessories
No matter what type of project
you’re creating, Grace makes it
easier with 7 snap-on feet and a
variety of additional accessories.
Built-in Needle Threader
Grace includes easy-to-follow,
numbered guides so you can
thread your needle with a few
simple motions.
Free-Arm Sewing
Convenient for sewing in those
small hard-to-reach areas like
sleeves and pant hems.
Large Stitch Selection
Add variety to your projects
with a suite of 40 stitches.
Selection is made simple with a
pictured menu and LCD screen.
Meet
• 7 Snap-on accessory feet
• Blind stitch foot
• Button  tting foot
• Buttonhole foot
Features
Accessories
Warranty
• 25-year limited manufacturer’s warranty
• 10-year parts
• 2-year electrical
• 1-year labor
• Soft case cover
• Bobbins (4)
• Needle package
• Twin needle
• Spool caps (large, medium, and small)
• Overcasting foot
• Satin stitch foot
• Zig zag / standard foot
• Zipper foot
LBCB-ALine_Bro4.indd 8 4/10/09 9:40:36 AM

LBCB-ALine_Bro4.indd 9 4/10/09 9:40:39 AM

Whether you’re interested in decorating,
fashion or sewing with an artistic flair,
Maria is the perfect machine to bring
those ideas to life. This multi-purpose machine includes
23 built-in stitches, a 1-step buttonhole and adjustable
stitch widths. With 5 included accessory feet and a needle
threader, Maria is outgoing enough to handle a variety of
creative projects.
Meet
Built-in Buttonhole
The buttonhole foot will help
you make perfect buttonholes
every time.
Built-in Needle Threader
Maria includes easy-to-follow,
numbered guides so you can
thread your needle with a few
simple motions.
Multiple Accessories
Maria comes with the essential
accessories, including 5
functional feet to make your
sewing easier.
Free-Arm Sewing
For sewing in those hard to
reach areas.
Large Stitch Selection
With 23 stitches you won’t have
to sacrifice variety for portability.
Button Sewing
You’ll love how easy it is to
attach buttons using the
button sewing foot.
• 23 Built-in stitches, including one-step buttonhole
• Built-in needle threader
• Free-arm sewing
• Drop feed for free motion techniques
• Adjustable stitch length: 0-4mm
• Adjustable stitch width: 0-5mm
• Convenient thread cutter
• Twin needle sewing option
• Electronic foot control
• Built-in accessory storage
• 5 Snap-on accessory feet
• Blind hem foot
• Buttonhole foot
• Button sewing foot
• Zig zag foot
• Zipper foot
• Bobbins (3)
• Needle package
• Seam ripper
• Spool caps (large and small)
Features
Accessories
Warranty
• 25-year limited manufacturer’s warranty
• 10-year parts
• 2-year electrical
• 1-year labor
LBCB-ALine_Bro4.indd 10 4/10/09 9:41:12 AM

LBCB-ALine_Bro4.indd 11 4/10/09 9:41:21 AM

When it comes to sewing projects,
Natalie is a friend you can trust. With
several convenient features such
as 15 built-in stitches, a needle threader and a 4-step
buttonhole, this machine is perfect for beginning sewers.
Straightforward and reliable, Natalie is always there to
help with mending, hemming and even crafting.
Meet
Built-in Buttonhole
The buttonhole foot will
help you make perfect
buttonholes every time.
Multiple Accessories
Natalie comes with the
essential accessories,
including 5 accessory feet.
Free-Arm Sewing
For sewing in those hard to
reach areas.
Button Sewing
You’ll love how easy it is to
attach buttons using the
button sewing foot.
• 15 Built-in stitches, including four-step buttonhole
• Built-in needle threader
• Free-arm sewing
• Adjustable stitch length: 0-4mm
• Convenient thread cutter
• Twin needle sewing option
• Electronic foot control
• Built-in accessory storage
• 5 Snap-on accessory feet
• Blind hem foot
• Buttonhole foot
• Button sewing foot
• Zig zag foot
• Zipper foot
• Bobbins (3)
• Needle package
• Seam ripper
• Spool caps (large and small)
Features
Accessories
Built-in Needle Threader
Natalie includes easy-to-follow,
numbered guides so you can
thread your needle with a few
simple motions.
Large Stitch Selection
With 15 stitches you won’t have
to sacrifice variety for portability.
Warranty
• 25-year limited manufacturer’s warranty
• 10-year parts
• 2-year electrical
• 1-year labor
LBCB-ALine_Bro4.indd 12 4/10/09 9:41:46 AM

LBCB-ALine_Bro4.indd 13 4/10/09 9:42:04 AM

No matter where you love to sew, Audrey
is the free-spirited friend you’ll want by
your side. At just 12.8 lbs., this lightweight machine can easily
travel or attend classes with you. Don’t worry, Audrey has packed
plenty of features for the road, like 66 built-in stitches, push
button features, a drop-in bobbin and plenty of accessories.
Audrey even has a convenient travel bag – perfect for any sewer
on the go.
Meet
Drop-in Bobbin
Load and replace your
bobbins quickly and easily.
Built-In Needle Threader
Audrey includes easy-to-follow,
numbered guides so you can
thread your needle with a few
simple motions.
Multiple Accessories
There are many accessories to
help you get the most out of
Audrey.
Free-Arm Sewing
Convenient for sewing in those
small hard-to-reach areas like
sleeves and pant hems.
Lightweight
At 12.8 pounds, Audrey is the
perfect weight and size for
light and easy travel. Take it
to classes, sewing retreats,
vacations, and more!
Push Button Features
Easily program the needle
up or down, reinforce any
stitch with the reverse sewing
button, and sew at low speed
or without a foot control using
the start/stop button.
Large Stitch Selection
Selection is made simple with
7 direct select stitch buttons, a
menu and LCD screen.
• 66 Stitches
• Lockstitch
• One-step, automatic
buttonholes in 8 styles
• Drop-in bobbin
• Automatic needle threader
• Programmable needle up/down
• Tote bag for machine
• Extension table with ruler
• 9 Snap-on accessory feet
• 1/4” foot
• Free motion/darning foot
• Zipper foot
• Straight stitch foot
• Buttonhole foot
• Zig zag/standard foot
• Blindhem foot
• Open toe foot
• Overcasting foot
• Bobbins (3)
• Needle package
• Seam ripper
• Spool caps (large and small)
Features
Accessories
• Free-arm sewing
• Drop feed
• Adjustable stitch length:
0.0-4.5mm
• Adjustable stitch width:
0-7.0mm
• Variable needle positions
• Start/stop button
• Variable speed control
Warranty
• 25-year limited
manufacturer’s warranty
• 10-year parts
• 2-year electrical
• 1-year labor
LBCB-ALine_Bro4.indd 14 4/10/09 9:43:33 AM

LBCB-ALine_Bro4.indd 15 4/10/09 9:44:01 AM

Practical and steady, Lauren makes
sure every stitch stays in place with
professional quality and incredible
speed. This easy-to-thread serger can handle 4/3/2 thread
serging, blind hems, a narrow rolled edge and more. Lauren
loves to give projects a finished look with reinforced stitches
and decorative edging, so she’s great to have around for
virtually every project.
Meet
Differential Feed
The differential feed
mechanism has a single unit
feed dog mechanism to ensure
stronger feeding as well as
more consistent gathering on
all fabrics.
4/3/2-Thread Serging
Trims, seams and overcasts 3
times faster than traditional
methods of sewing. Serge with
4, 3, or 2-thread for all your
serging needs.
Easy Color-Coded Threading
Provides simpli ed threading
and precise tension control.
Free-arm Serging
Provides easy access to those
hard-to-reach areas of all your
sewing projects, especially
cuffs and sleeves.
4/3/2 thread serging •
• 4-thread seaming•
• 3-thread narrow or wide•
• Narrow rolled hem•
• Flatlock•
• Blind hem•
Color coded, lay-in tensions•
Differential feed•
Free-arm serging•
Blind hem foot included•
Instructional DVD included•
Features
By following the color-coded
thread system, you’ll have your
serger threaded in seconds.
Warranty
• 10-year limited manufacturer’s warranty
LBCB-ALine_Bro4.indd 16 4/10/09 9:46:28 AM

LBCB-ALine_Bro4.indd 17 4/10/09 9:46:40 AM

Sewing Machines Grace Maria Natalie Audrey Sofia
Total built-in stitches 40 23 15 66 67
Buttonholes; type 5; 1-step 1; 1-step 1; 4-step 8; 1-step 10; 1-step
Needle positions Variable Variable 2 positions Variable Variable
Needle threader Built-in Built-in Built-in Built-in Advanced
Bobbin loading Quick-set, drop-in Front loading Front loading Drop-in Quick-set, drop-in
Bobbin winding Standard Standard Standard Standard Quick-set
Extension table Yes - Optional N/A N/A Yes - Included N/A
Thread cutter Manual Manual Manual Manual Automatic
Maximum stitch length in mm 54 4 4.5 5
Maximum stitch width in mm 7 5 5 7.0 7
Tension Manual Manual Manual Manual Manual
Retractable feed dogs Yes Yes No Yes Yes
Free-arm Yes Yes Yes Yes Yes
Number of feet included 7 5 5 9 8
Accessory storage Built-in Built-in Built-in Built-in Built-in
Warranty • 25-year limited manufacturer’s warranty • 10-year parts • 1-year labor
• 2-year electrical (Grace, Maria, Natalie, Audrey) • 5-year electrical (Sophia only)
Embroidery Machine Sofia
Built-in designs 70 Data Input USB (Type B)
Built-in embroidery
alphabet styles
5Embroidery pattern memory Yes
Frame patterns 120 Embroidery speed 400
Embroidery  eld 4”x4” Number of Hoops included 1
Combine designs No Built-in needle threader Yes
Rotation 1, 10, and 90 degree Mirror image Yes
Sizing 20% up, 10% down Low bobbin indicator Yes
Ask your Baby Lock Retailer about machine maintenance programs.
LBCB-ALine_Bro4.indd 18 4/10/09 9:46:53 AM

Retailer Commitment
Whether you are new to sewing or an experienced sewer, Baby Lock and
its independent retailer network are committed to providing you with the highest
quality products and services. This amount of dedication and support can only be
found at Authorized Baby Lock Retailers.
Well-trained on the Baby Lock line, our retailers can guide you through the features and
innovations that make sewing so much fun and help you choose the machine that is best
suited for your needs. And unlike Big Box stores, Baby Lock Retailers will continue to be there
after your purchase for ongoing service and support, new techniques and ideas, the latest in
notions and more.
When you purchase a Baby Lock machine, you’ll gain access to the full resources that Baby
Lock and its retailer network has to offer. No other brand can offer you a full spectrum of
service, assistance, accessories, classes and inspiration like Baby Lock. So, be sure to visit a
Baby Lock Retailer to learn about all the wonderful Baby Lock products that will bring your
love of sewing to life.
Visit TotallyStitchin.net!
Whether you’re new to sewing or a stitchin’ pro, you’ll find plenty of juicy info
at Totally Stitchin’. This frequently updated site is like a virtual sewing circle,
full of inspiration, ideas, friends and tons of fun!
• Daily blog with what’s new and awesome in sewing — you can even join in
• Cool projects with you in mind
• A helpful sewing glossary
• Tips and tricks
• Inspiring Stitchin’ Women stories
• Fun contests
• Follow us on Facebook and Twitter
• And much more!
www.babylock.com
LBCB-ALine_Bro4.indd 19 4/10/09 9:46:56 AM

LBCB-ALINE 4/09
www.babylock.com
LBCB-ALine_Bro4.indd 20 4/10/09 9:46:59 AM
