Babyviewer RA-4500 User manual

user manual
user manual
Before installing, operating or adjusting this product, please read this instruction
booklet carefully and completely. This monitor should not be used as an alternative for
adult supervision of young children.
RA-4500
KS-4246
USER GUIDE / HANDLEIDING / MANUEL D’UTILISATEUR /
BEDIENUNGSANLEITUNG / MANUAL DE USUARIO / BRUKSANVISNING /
BRUGERVEJLEDNING / ANVÄNDARHANDBOK / KÄYTTÖOHJE /
MANUALE D’USOMANUAL DO UTILIZADOR / UŽIVATELSKÁ PŘÍRUČKA /
Ο∆ΗΓΙΕΣ ΧΡΗΣΗΣ/ HASZNÁLATI ÚTMUTATÓ / INSTRUKCJA OBSŁUGI /
UŽÍVATEL’SKÝ MANUÁL
V 1.0 - 07/13
®
UK The features described in this manual are published with reservation to
modifications.
NL De in deze handleiding beschreven mogelijkheden worden gepubliceerd onder
voorbehoud van wijzigingen.
FLes possibilités décrites dans ce manuel sont publiées sous réserve de
modifications.
DDie in dieser Bedienungsanleitung umschriebenen Möglichkeiten, werden
vorbehaltlich Änderungen publiziert.
ES Las características descritas en este manual pueden ser objeto de futuras
modificaciones.
SFunktionerna i denna bruksanvisning publiceras med reservation för ändringar.
DK Vi forbeholder os retten til ændringer af de specifikationer, der er beskrevet i denne
brugsanvisning.
NFunksjoner beskrevet i denne manualen kan endres uten nærmere informasjon.
SF Tässä ohjekirjassa julkaissut tiedot voivat muuttua ilman ennakkoilmoitusta.
IT Le caratteristiche descritte nel presente manuale vengono pubblicate con riserva di
modifica.
PT As características descritas neste manual são publicadas sob reserva de
modificação.
CZ Možnost úpravy funkcí popsaných v této příručce vyhrazena.
GR Οι λειτουργίεςπου περιγράφονται στοπαρόν εγχειρίδιο, δημοσιεύονταιμε
επιφύλαξη τυχόν τροποποιήσεων.
HU A jelen használati útmutatóban leírt adatokra a gyártó fenntartja a változtatás jogát.
PL Właściwości opisane w niniejszej instrukcji obsługi sąpublikowane z zatrzeżeniem
prawa wprowadzenia zmian.
SK Vlastnosti popísané v tejto príručke sú publikované s vyhradeným právom na
zmenu.
Babyviewer
RA-4500_usermanual Jan 2014.indd 1 21/01/2014 11:53 am

user manual
2
CONTENTS Pg
General 4
Information regarding this user guide
Copyright
Warnings
Proper use 5
Safety • Risk of electric shock
• Using batteries (regular or rechargeable) 6
• General rules for safe use
Operation • Baby unit components 7
• Parent unit components
• Display description 8
Initial use • Package content
• Installing batteries in the baby unit
• Connecting the baby unit to the AC mains 9
• Installing the rechargeable battery pack in
the parent unit
• Connecting the parent unit to the AC mains 10
Installing • Fine tuning
Operation and use • Switching the baby and parent unit on and off
• Baby phone mode. 11
• Checking the connection between the parent
unit and the baby unit
• Out of range indication
• Setting the reproduction volume of the parent unit
• Setting the parent unit display brightness
• Temperature indication 12
• Zoom function
• Talking with your baby
• Playing a lullaby 13
• Switching the night light on and off
• Voice activated transmission (VOX)
• Night vision 14
• Registering the parent unit with the baby unit or register a new camera.
• Selecting the camera
Cleaning and maintenance 15
• Safety Instructions
• Cleaning
• Maintenance
RA-4500_usermanual Jan 2014.indd 2 21/01/2014 11:53 am

user manual
3
Babyviewer RA-4500
A
19
B
17
11
5
14
16
17
18
2
4
16
O
P
E
N
1
8
12
13
10
20
21
22
24
25
23
15
3
9
28
29
26
27
PAIR
Troubleshooting • Safety Instructions 16
• Problem causes and solutions 17
Storage and disposal instructions 18
• Storage
• Waste disposal of package materials (environmental protection)
Technical data 18
RA-4500_usermanual Jan 2014.indd 3 21/01/2014 11:53 am

user manual
4
Dear customer,
We request that you read this information in order to quickly become familiar with this equipment and
learn how to use its functions.
INFORMATION REGARDING THIS USER GUIDE
This user guide contains information on the Babyviewer RA-4500 babyphone (referred to as ‘the
equipment’ in the following) and provides important instructions on the initial use, safety, proper use
and maintenance of this equipment. Always keep the user guide available near the equipment. Every
person responsible for operating, repairing or cleaning the equipment must read and/or consult the
user guide. Keep this user guide in a safe place and give it to the next owner of the equipment.
COPYRIGHT
This document is protected by copyright legislation. All rights are reserved, including rights of photo
mechanical reproduction, copying or distribution using specific means such as data processing, data
storage media or data networks, either in full or in part, as well as technical changes and changes to
the contents.
WARNINGS
DANGER
This warning points out an imminent hazardous situation.
Death or severe injuries may result if the hazardous situation cannot be avoided.
CAUTION!
This warning points out a potentially hazardous situation.
Injuries and/or material damage may result if the hazardous situation cannot be avoided.
This symbol points out information that makes it
easier to use the equipment
RA-4500_usermanual Jan 2014.indd 4 21/01/2014 11:53 am

user manual
5
Babyviewer RA-4500
PROPER USE
This equipment is exclusively intended for private (nonprofessional) use in closed rooms for
monitoring babies. All other forms of use are improper and can lead to hazards. Always follow the
instructions provided in this user guide. No liability is accepted for any loss or damage resulting from
improper use. The user of the equipment is exclusively responsible for all risks.
SAFETY
Risk of electric shock
DANGER
Contact with conductors or components under electrical tension can be lethal.
Observe the following safety instructions in order to avoid the risk of electric shock:
• To avoid the risk of damage to the equipment, use only the AC mains adapter supplied with the
equipment.
• Do not use the equipment if the AC mains adapter, the power cable or the plug is damaged.
• Never open the enclosure of the AC mains adapter. There is a risk of electric shock if you touch
any contacts or connections under electrical tension or if you modify the electrical or
mechanical construction.
• Protect the equipment against moisture and moisture penetration, and keep it free of dust.
Unplug the AC mains adapter immediately in case of contact with moisture.
• Unplug the AC mains adapter in case of malfunctions, during thunderstorms, and when cleaning
the equipment.
• Protect the cable against contact with hot surfaces or other sources of hazard, and do not allow it to
be pinched.
RA-4500_usermanual Jan 2014.indd 5 21/01/2014 11:53 am

user manual
6
Using Batteries (regular or rechargeable
CAUTION!
Failure to use batteries according to instructions can be hazardous.
• Always use batteries (regular or rechargeable) of the same type.
• Ensure that batteries are installed with correct polarity. Damage to the batteries and the equipment
can result from installation with incorrect polarity.
• Never toss batteries into a fire, due to the risk of explosion.
• Never allow battery terminals to come into contact with each other or with metal objects, either
intentionally or accidentally. This can cause overheating, fire or explosion.
• Keep batteries out of the reach of children. Consult a doctor immediately in case of swallowing.
• Fluid from leaking batteries can cause permanent damage to the equipment. Take particular care
when handling damaged or leaking batteries, due to the risk of corrosion. Wear safety gloves.
• Remove the batteries if the equipment will not be used for an extended period.
General rules for safe use
To ensure safe use of the equipment, always observe the following safety instructions:
• The equipment must always be assembled by an adult. During assembly, keep small parts out of
the reach of children.
• Do not allow children to play with the equipment or parts of the equipment.
• Ensure that the babyphone and power cable are always out of the reach of the baby.
• Never cover the babyphone with a towel, blanket etc.
• Defective components must always be replaced by original replacement parts, as other
components may not fulfil the safety standards.
• Switch off your babyphone whenever this is requested by a sign, poster, or other message. The
equipment used in hospitals and other health care facilities may be sensitive to high-frequency
signals from external sources.
RA-4500_usermanual Jan 2014.indd 6 21/01/2014 11:53 am

user manual
7
Babyviewer RA-4500
OPERATION
The babyphone consists of two units: one for the parents and one for the baby. They are connected
by a wireless link compliant with the 2,4 GHz FHSS standard. Thanks this digital technology, this
equipment is protected against eavesdropping and immune to interference from other equipment.
The baby unit starts transmitting as soon as the microphone picks up a sound. The sound is
reproduced by the parent unit. The microphone sensitivity can be adjusted by the user
(see “10.13 Voice activated transmission (VOX)”).
The babyphone can never replace proper supervision
by an adult; it only provides support.
Baby unit components
1 On/Off LED 8 Crib connector nut
2 Night light LED 9 Light Sensor
3 Infrared LED for night vision 10 Pair button
4 On/off switch 11 Speaker
5 Lens 12 Connector for AC mains adapter
6 Microphone 13 Room temperature sensor
7 Wall mounting cavity
Parent unit components
14 Volume LED 22 Power on/off LED
15 Microphone 23 Menu Button
16 Increase volume/ 24 Push to talk button
Next menu item 25 On/off button
17 Decrease volume/ 26 Belt clip
previous menu item 27 Speaker
18 Music button 28 Connector for AC mains adapter
19 Camera Button 29 Battery cover with screw
20 3,5” (8,8cm) colour display
21 Link LED
RA-4500_usermanual Jan 2014.indd 7 21/01/2014 11:53 am

user manual
8
Display description
Out of range or no connection LCD display brightness icon
Volume icon
C
Temperature unit icon
Melody icon Night light icon
INITIAL USE
Package content
The equipment is supplied as standard with the following items:
• 1 baby unit • 1 user guide
• 1 parent unit • 1 Li-ion rechargeable battery pack
• 2 AC mains adapters
Installing batteries in the baby unit
• You can operate the baby unit with 4 AAA cells (LR03; we recommend alkaline cells)
or the included AC mains adapter.
• The baby unit cannot recharge batteries.
• It is recommended to always leave the batteries in the unit, even if you use the AC
mains adapter. The unit will automatically switch to battery power in case of a
mains power interruption.
Turn the screw on the cover of the battery compartment at the back
of the baby unit 90° counter clockwise and remove the battery
compartment cover.
Do not turn the screw past the “OPEN” point
O
P
E
N
90° MAX
OPEN
RA-4500_usermanual Jan 2014.indd 8 21/01/2014 11:53 am

29

user manual
10
• Place the Li-ion battery pack in the battery compartment. Ensure that the battery contacts do make
contact with the charge contacts as illustrated.
• Carefully close the battery compartment and rotate the belt clip back downwards.
Connecting the parent unit to the AC mains
• Insert the small plug of the AC mains adapter in the mains power connector
28
and plug the AC
mains adapter into a mains connector (100~240 V - 50/60 Hz).
It takes around 10 hours to fully charge the batteries.
INSTALLING THE BABYVIEWER RA-4500
Fine tuning
• Place the camera in a convenient location, point the lens of the camera to the observation area.
• Adjust the angle by rotation the camera.
CAUTION!
Do not place the camera and wires within the baby’s reach!
Fix the camera at least 1 meter away from the baby.
OPERATION AND USE
Switching the baby unit and parent unit on and off
• Press the on/off button
25
to switch on the parent unit. The display
20
is activated.
• Slide the on/off switch
4
up to switch on the baby unit. The on/off LED
1
is activated.
The parent unit will try to establish a connection with the baby unit. If captured image
from the camera is displayed, a connection has been established.
• Press the on/off button
25
to switch off the parent unit
(press and hold until the display goes blank).
• Slide the on/off switch
4
down to switch off the baby unit.
RA-4500_usermanual Jan 2014.indd 10 21/01/2014 11:53 am

user manual
11
Babyviewer RA-4500
Baby phone mode.
The Babyviewer can also be used as a audio babyphone, this is an option to save energy. Follow the
procedure below.
• Make sure the VOX mode is off, see the VOX paragraph for instructions
(See “10.13 Voice activated transmission (VOX)”).
• Press the on/off button
25
to go to audio babyphone modus.
• Press the on/off button
25
again to turn on the display again.
Checking the connection between the parent unit and the baby unit
You should always check the wireless connection when you use the babyphone for the first time.
• Put the parent unit in the same room as the baby unit, separated by at least two meters.
Switch on both devices. The parent unit will try to establish a connection with the baby unit.
• The display of the parent unit will show the captured image from the baby unit after the connection
has been established (monitor mode).
• The sounds picked up by the microphone
6
are reproduced by the parent unit.
• The volume of the reproduced sound is indicated by the volume LED’s
14
at the top of the parent
unit. The higher the volume, the more LED’s are on.
• If no connection is established, “OUT OF RANGE” is displayed.
Out of range indication
The maximum range between the parent- and baby unit is 300 meter in open area. Different factors,
such as bricks and plaster walls, will reduce the range. Moreover, reinforced concrete floors will
influence the range tremendously.
In a residence, normal operating range is up to 50 meters and 2 floors.
• If the connection is interrupted, “OUT OF RANGE” is displayed.
• Reduce the distance between the parent and baby units until a new connection is established.
Setting the reproduction volume of the parent unit
There are 5 volume levels.
• Press button
16
to increase the volume.
• Press button
17
to decrease the volume.
Setting the parent unit display brightness
When the display in on.
• Press the menu button
23
once. The Brightness icon is displayed.
• Press the up
16
or down button
17
to select the desired brightness (5 steps).
• Press the menu button
23
to confirm.
• After 10 seconds the parent unit will switch back to monitor mode.
RA-4500_usermanual Jan 2014.indd 11 21/01/2014 11:53 am

After 10 seconds the parent unit will

user manual
13
Babyviewer RA-4500
Press the Talk button
24
on the parent unit and hold it pressed.
• Hold the parent unit vertical with the microphone approximately 10 cm from your mouth, and speak
into the microphone.
• Release button
24
when you have finished talking.
Playing a lullaby
There are 5 pre-programmed lullabies that you can play on the baby unit.
• To play the currently selected lullaby or stop playback, press the music button
18
on the
baby unit.
• To select a different lullaby, repeatedly press the up button
16
or down button
17
until the
desired lullaby is selected. The lullaby icon will display the selected lullaby (1 to 5).
• Press the on/off button
25
when the desired lullaby is selected.
Switching the night light on and off
• Press the menu button
23
5 times. The night light icon is displayed.
• Press the up
16
or down button
17
to switch the night light “ON” (night light is on) or “OFF”.
• Press the menu button
23
to confirm.
• After 10 seconds the parent unit will switch back to monitor mode.
Voice activated transmission (VOX)
During night and to save energy, the RA-4500 can be set in VOX mode.
In VOX mode, the display will be activated as soon as the microphone of the baby unit will capture
sound. You can set the sound detection sensitivity (VOX) of the babyphone. If the sensitivity is set to
high, the baby unit will pick up weaker sounds.
• Press button
23
6 times. “VOX” is displayed.
• Repeatedly press button
16
or
17
to set the VOX sensitivity.
The VOX sensitivity is indicated by a black bar on the display:
high sensitivity
low sensitivity
• To switch off VOX mode, select “OFF”.
• Press the menu button to confirm.
RA-4500_usermanual Jan 2014.indd 13 21/01/2014 11:53 am

Press and hold the pair button to registration.
10

user manual
15
Babyviewer RA-4500
CLEANING AND MAINTENANCE
This section contains important instructions for cleaning and maintaining the equipment.
Follow these instructions to ensure trouble-free use and prevent damage to the equipment due to
improper maintenance.
Safety Instructions
DANGER
Risk of fatal injury due to electric shock!
• Before cleaning the equipment, switch it off and unplug the power cable from the mains receptacle.
CAUTION!
Risk due to leaking battery fluid
Fluid from leaking batteries (regular or rechargeable) can cause injuries (skin irritation) or damage to
the equipment. Wear safety gloves.
CAUTION!
• Do not use cleaning products or solvents. They can damage the case or seep into the equipment
and cause permanent damage.
Cleaning
• Clean the equipment with a soft, slightly dampened cloth.
• Clean soiled connectors and contacts with a soft brush.
• Clean the battery contacts and battery compartment with a dry, lint-free cloth.
• If the equipment gets wet, switch it off and remove the batteries immediately. Wipe the battery
compartment dry with a soft cloth in order to minimize potential water damage. Leave the battery
compartment open until it is completely dry. Do not use the equipment before it is completely dry.
Maintenance
• Check the batteries (regular or rechargeable) in the equipment regularly and replace them when
necessary.
• Check the connectors and cables for defects.
CAUTION!
• If you suspect that the equipment is damaged, always have it checked by an expert before using
it again.
RA-4500_usermanual Jan 2014.indd 15 21/01/2014 11:53 am

user manual
16
TROUBLESHOOTING
This section provides important instructions for localizing and correcting problems.
Follow these instructions in order to avoid hazards and damage.
Safety Instructions
DANGER
Risk of fatal injury due to electric shock!
• Unplug the power cable before attempting to correct a problem.
CAUTION!
Risk of hazard due to incorrect repairs
Incorrect repairs can expose users to serious hazards and cause damage to the equipment.
• Never attempt to modify or repair the equipment.
• Always have repairs to equipment or cables performed by a specialist or the service centre.
• If you suspect that the equipment is damaged (for example, if it has fallen on the floor), have it
checked by a specialist before you use it again.
RA-4500_usermanual Jan 2014.indd 16 21/01/2014 11:53 am

user manual
17
Babyviewer RA-4500
Problem causes and solutions
The following table is intended to help you localise and solveminor problems.
PROBLEM POSSIBLE CAUSE SOLUTION
The rechargeable battery
pack of the parent unit
does not charge
Charging station plug not connected
Dirty Contacts
The rechargeable battery pack is defective
Connect plug
Clean the battery terminals and
charging station contacts with a soft
cloth
Replace the battery pack
Parent unit does not
switch on (display
remains black)
The rechargeable battery pack is not
charged
Equipment defective
Charge the battery pack
Contact customer service
The ‘orange’ icon
appears on the parent
unit display t of r
Baby unit not switched on Switch on the baby unit
The parent unit and baby unit are too far
apart
The parent unit is not registered with the
baby unit
The wrong camera is selected.
Reduce the distance between the
parent unit and the baby unit
Register the parent unit with the baby
unit (see “10.15 Registering the parent
unit with the baby unit or register a
new camera.”
See “10.16 Selecting the camera”
The parent unit does not
reproduce the sounds
picked up by the baby
unit
The volume setting of the parent unit may
be too low.
The microphone sensitivity of the baby unit
may be set too low.
Increase the volume setting of the
parent unit
Check the VOX sensitivity and the
volume setting of the parent unit and
increase if necessary.
Limited range and
interference during
transmission
The range of the equipment depends on
the surroundings. Steel structures and
concrete walls can impair transmission.
Avoid obstacles as much as possible.
The equipment emits a
high pitched whistle
The parent unit and baby unit are too close
together
Increase the distance to at least 2
metres
RA-4500_usermanual Jan 2014.indd 17 21/01/2014 11:53 am

A

A

user manual
20
RA-4500_usermanual Jan 2014.indd 20 21/01/2014 11:53 am
