Bad Elf BE-GPS-3300 User manual
GNSS
Surveyor
BE-GPS-3300
Bluetooth GNSS Receiver
Made for iPod touch, iPhone, and iPad
LCD Display • Splash ResistantLCD Display • Splash Resistant
Real Time 1m AccuracyReal Time 1m Accuracy
Sub-meter Capable via Post ProcessingSub-meter Capable via Post Processing
Data Logger • All Day BatteryData Logger • All Day Battery
© 2022 Bad Elf, LLC
Bad Elf, LLC
Page 1
Bad Elf GNSS Surveyor
Contents of This Package
This package contains the following items:
• Bad Elf GNSS Surveyor receiver with Bluetooth® wireless technology and
Barometric Altimeter
• USB charging cable
• Vehicle Charging Adapter (suitable for 12V cigarette sockets)
• User Guide
Note: Apple device refers to the supported iPod touch, iPhone, or iPad equipped
with Bluetooth® wireless technology that you will be using for navigation.
Meet the Bad Elf GNSS Surveyor
Power Button
Bluetooth Button
GPS Button
LCD Display
Lanyard Loop
Figure 1 - Front View of the GNSS Surveyor
Page 2
Bad Elf GNSS Surveyor
Dimensions
The Bad Elf GNSS Surveyor is small and lightweight, but with a rugged, solid feel. Its
dimensions and weight are:
Dimensions: 3.0 x 2.4 x 0.7 inches (76.5 x 61.5 x 17.5 mm)
Weight: 3.2 ounces (90 grams)
Enclosure
The Bad Elf GNSS Surveyor enclosure oers IPX4 water resistance, making it splash
proof when used in many common outdoor application environments. Note the
pinholes on the lower rear surface to allow the barometer and thermometer to
sample the atmosphere
Figure 2 - Back View of the GNSS Surveyor
Page 3
Bad Elf GNSS Surveyor
Backlit LCD Display Interface
The Bad Elf GNSS Surveyor oers an Apple approved GPS with an informative user
interface. Prior GPS devices used simple LEDs to indicate status, leaving the user
guessing about status details. The Bad Elf GNSS Surveyor makes it easy for the user
to check location details (latitude, longitude, altitude, track, speed, and universal
time) directly on the GPS without requiring connectivity to the iPod touch, iPhone,
or iPad. Further information concerning the quality of data and satellite usage is also
available directly on the device. Additionally, users may check Bluetooth connection
status, battery levels, barometer, thermometer, and data log storage usage at a
glance. The display also has a backlight for readability at night.
Figure 3 - Side View of the GNSS Surveyor
Page 4
Bad Elf GNSS Surveyor
Buttons
The Bad Elf GNSS Surveyor uses three simple buttons for device control. More
extensive capabilities are available through the free, downloadable Bad Elf utility app
available through iTunes.
1. Power Button
a. Press and hold this button for 3 seconds to toggle the Bad Elf GPS device
ON or OFF.
b. Press this button momentarily to toggle the LCD backlight ON or OFF.
2. Bluetooth Button
a. Press and hold this button for 3 seconds to toggle the Bluetooth radio ON
or OFF.
b. Press this button momentarily to move through the Bluetooth related
screens.
3. GPS Button
a. Press and hold this button for 3 seconds to toggle the GPS Data Logging
ON or OFF.
b.Press this button momentarily to move through the GPS related screens.
Each button can be used as a simple click or as a press and hold action. See the
scenarios below for details of operation using the buttons in each context.
Additional configuration and features are controlled wirelessly via the Bad Elf GPS
utility app.
Page 5
Bad Elf GNSS Surveyor
USB Port / ElfPort™
The standard USB mini-B port on the back of the Bad Elf GNSS Surveyor operates
primarily as a standard charging port for recharging the GPS Pro’s internal battery.
This port also supports Bad Elf’s ElfPort™technology, which enables communication
with other devices.
Data Storage
The Bad Elf GNSS Surveyor contains 16MB of flash memory for storage of trip data.
At a standard sampling rate of one position recorded per second (1Hz), the device
can store up to 65 hours of trip data. The data can be divided into separate trips or
collected as one single data log. The Bad Elf Utility app readily ooads trip data logs
for storage on the Pod touch, iPhone, or iPad. The data can then be emailed and
shared.
Thumb Drive Mounting: Connect the Bad Elf GNSS Surveyor with a USB cable
to your computer and access data logs directly through your file system Explorer
(Windows) or Finder (Mac).
Power System
The Bad Elf GNSS Surveyor includes a long life, embedded lithium ion battery. When
both the Bluetooth® radio and the GPS are active, the battery oers more than 24
hours of continuous operation on a single charge. When operating in standalone
data logging mode, that is, with the Bluetooth radio OFF, the Bad Elf GNSS Surveyor
can operate for over 32 hours.
Page 6
Bad Elf GNSS Surveyor
Charge the Bad Elf GNSS Surveyor
The Bad Elf GNSS Surveyor is charged via the mini-USB connector on the back of
the device.
Before using the Bad Elf GPS Pro, fully charge the device. To charge, simply use the
provided cable and plug the Bad Elf GNSS Surveyor into any standard USB power
source, such as a computer, wall charger, or the included car charger. It takes up to 4
hours to fully charge the Bad Elf GNSS Surveyor.
Power On the Bad Elf GNSS Surveyor
To turn it on, press and hold the Power Button for 3 seconds until the display shows
the splash screen.
Once powered on, the device is ready to accept incoming Bluetooth® connections
from your Apple device. Follow the pairing instructions below.
Download the Bad Elf GPS utility app and any other location-based apps you want
to use with your Bad Elf GNSS Surveyor.
In the meantime, the unit will start searching for GPS satellites. Once a GPS lock
is acquired, location data will be displayed on the LCD. The accessory will also
begin sharing received location data with any devices (and apps) that have been
connected via the Bluetooth connection.
Pair an Apple Device with the Bad Elf GNSS
Surveyor
The Bad Elf GNSS Surveyor only needs to be paired once with your iPod touch,
iPhone, or iPad. After your Apple device and Bad Elf GNSS Surveyor are paired, they
will connect automatically when both units have their Bluetooth radios ON and are
within range of each other.
Page 7
Bad Elf GNSS Surveyor
To pair the Bad Elf GNSS Surveyor with an iPad, iPhone, or iPod touch, follow these
simple steps:
1. On the Apple device, start the Settings app, then select General > Bluetooth.
Make sure Bluetooth is turned ON.
2. This page will then show accessories that are within range and available for
pairing.
3. Turn on your Bad Elf GNSS Surveyor (if it is not ON already).
4. Within 10 seconds, you should see the Bad Elf GNSS Surveyor appear in the
list of devices, with a status of “Not Paired”. Tap this item in the list to start the
pairing process.
5. Within 10 seconds, you should see a dialog on your Apple device oering a
PIN number. This PIN will also be displayed on the LCD display. This allows
both sides of the connection to authorize the pairing with the remote device.
Matching the PIN numbers ensures that you can confirm that you are pairing
the correct devices. Data entry is not required.
6. On the Bad Elf GPS Pro, press the GPS Button to authorize the pairing. On
your Apple device, press the “Pair” button.
7. In the Settings app, under General > Bluetooth, you should now see the Bad
Elf GNSS Surveyor listed with a “Connected” status.
You can turn Bluetooth o by pressing and holding the Bluetooth button for 3
seconds. While Bluetooth is turned o, the GPS and data logging will still function,
but communications with your Apple device will not be possible. You can turn
Bluetooth on again by pressing and holding the Bluetooth button again for 3
seconds.
Page 8
Bad Elf GNSS Surveyor
Download the App from the App Store
The Bad Elf GPS Utility app is a free app available in iTunes. The app allows you
to verify the accessory is paired and correctly connected to your Apple device. It
shows the raw GPS data being received by the GPS receiver and allows you to
configure the GPS logging features. Once you have logged some trips, the app
allows you to transfer these logs to your Apple device for visualization and sharing.
Finally, if any firmware updates become available, the app will download them to
your Apple device for installation into the accessory hardware.
After you have paired your Bad Elf GNSS Surveyor to your Apple device for the first
time, you will be prompted to download the Bad Elf GPS Utility app from the iTunes
App Store. If you do not have Internet connectivity, or do not wish to download the
app at that time, you can ignore this prompt. Your Bad Elf GNSS Surveyor does not
require the Bad Elf Utility app to operate with apps and will work out of the box with
any location-based apps you have installed.
Please visit the Bad Elf website (http://bad-elf.com) for recommendations on
compatible apps for various activities such as aviation, marine, fitness, hiking,
running, cycling, geocaching and more. The Bad Elf GNSS Surveyor fits all lifestyles,
but was specifically designed to support advanced applications in land surveying
and other GIS domains.
Acquiring Satellites with the Bad Elf GPS Pro
Go outdoors to an open area, away from tall buildings and trees. Acquiring satellite
signals may take a minutes or more the first time the device is turned on or after it
has been out of use for an extended period of time.
While the Bad Elf GNSS Surveyor is acquiring satellites, the LCD display shows the
number of satellites that are acquired out of the possible satellites in view. Once a
lock is acquired, the LCD display shows speed, heading, altitude, and accuracy. Press
the GPS button to cycle through other screens that shows a variety of other values
and data logging status.
Page 9
Bad Elf GNSS Surveyor
Data Logging with the Bad Elf GNSS Surveyor
Press and hold the GPS button for 3 seconds to turn on data logging. Once data
logging is turned on, the LCD display shows a blinking icon along the bottom of the
display. The Bad Elf GNSS Surveyor records your position every second while data
logging is on.
When data logging is on, pressing and holding the GPS button for 3 seconds causes
a prompt to appear. You can then choose either to record a point of interest (POI)
and continue data logging or to turn data logging o.
Once data logging is complete, you can use the Bad Elf Utility app to save, map,
share, or delete the recorded trip or connect the GNSS Surveyor to your computer
with a USB cable and access the log files directly through your file explorer.
Support
Please visit our website for troubleshooting steps and to contact our support team.
Support is available be emailing support@bad-elf.com.
Page 10
Bad Elf GNSS Surveyor
Technical Specifications
• GPS
– 56 channel u-blox NEO-7P GPS/GLONASS/QNSS module
– configurable to 1-10Hz refresh rate
– Satellite acquisition times: (<30s cold, <15s warm, <5s hot)
• Bluetooth
– 2.1 + EDR – Range: 33ft (10m)
• Internal Battery
– Charging time: 4 hours
– Charging voltage: 5VDC @ 500mA – Capacity: 1600 mAH
– Operating time: 24+hrs with Bluetooth/GPS, 32+hrs GPS logging only
FCC RF Radiation Exposure
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. Follow the specific operating instructions for satisfying
RF exposure compliance. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
IC Compliance
This Class [B] digital apparatus complies with Canadian ICES-003.
Industry Canada Compliance
Category I radio communication devices comply with Industry Canada Standard
RSS-210. Category II radio communication devices comply with Industry Canada
Standard RSS-310.
Page 11
Bad Elf GNSS Surveyor
Battery Warnings
If these guidelines are not followed, the embedded lithium-ion battery may
experience a shortened life span or may present a risk of damage to the GPS, fire,
chemical burn, electrolyte leak, and/or injury.
Do not leave the GPS exposed to a heat source or in a high temperature location,
such as in the sun in an unattended vehicle (e.g., car, airplane, helicopter, or boat). To
prevent damage, remove the GPS from the vehicle or store it out of direct sunlight.
• Observe the following temperature ranges:
Battery Powered: 14°F to 140°F (-10°C to 60°C)
Externally Powered: -22°F to 140°F (-30°C to 60°C)
Charging Temperature: 41°F to 113°F (5°C to 45°C)
Storage Temperature: -22°F to 140°F (-30°C to 60°C)
• Do not use a sharp object to open the GPS enclosure or attempt to remove
the battery.
• Do not incinerate the GPS or the battery enclosed therein.
• Do not disassemble, puncture, or damage the GPS or the battery.
• Keep the battery away from children.
• If using an external battery charger, only use the accessory approved for your
product.
• Contact your local waste disposal department to properly recycle the battery.
• Do not attempt to replace the battery with a replacement battery.
Page 12
Bad Elf GNSS Surveyor
FCC Compliance
This product has been tested and found to comply with Part 15 of the FCC
interference limits for Class B digital devices FOR HOME OR OFFICE USE. These limits
are designed to provide more reasonable protection against harmful interference in
a residential installation, and are more stringent than “outdoor” requirements.
Operation of this device is subject to the following conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment generates, uses, and can radiate radio frequency energy and may
cause harmful interference to radio communications if not installed and used in
accordance with the instructions. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference
by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet that is on a dierent circuit from the
GPS unit.
• Consult the dealer or an experienced radio/TV technician for help.
This product does not contain any user-serviceable parts. Repairs should only be
made by an authorized Bad Elf service center. Unauthorized repairs or modifications
could result in permanent damage to the equipment, and void your warranty and
your authority to operate this device under Part 15 regulations.
Page 13
Bad Elf GNSS Surveyor
Limited Warranty
This Bad Elf product is warranted to be free from defects in materials or
workmanship for one year from the date of purchase. Within this period, Bad Elf will,
at its sole option, repair or replace any components that fail in normal use. Such
repairs or replacement will be made at no charge to the customer for parts or labor,
provided that the customer shall be responsible for any transportation cost. This
warranty does not cover failures due to abuse, misuse, accident, or unauthorized
alteration or repairs.
THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE EXCLUSIVE AND IN
LIEU OF ALL OTHER WARRANTIES EXPRESS, IMPLIED, OR STATUTORY, INCLUDING
ANY LIABILITY ARISING UNDER ANY WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, STATUTORY OR OTHERWISE. THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, WHICH MAY VARY FROM STATE
TO STATE.
IN NO EVENT SHALL BAD ELF BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT,
OR CONSEQUENTIAL DAMAGES, WHETHER RESULTING FROM THE USE, MISUSE,
OR INABILITY TO USE THIS PRODUCT OR FROM DEFECTS IN THE PRODUCT. Some
states do not allow the exclusion of incidental or consequential damages, so the
above limitations may not apply to you.
Bad Elf retains the exclusive right to repair or replace the unit or software or oer
a full refund of the purchase price at its sole discretion. SUCH REMEDY SHALL BE
YOUR SOLE AND EXCLUSIVE REMEDY FOR ANY BREACH OF WARRANTY.
To obtain warranty service, contact your local Bad Elf authorized dealer or call
Bad Elf Product Support for shipping instructions and a Return Merchandise
Authorization (RMA) tracking number. Securely pack the unit and a copy of the
original sales receipt, which is required as the proof of purchase for warranty repairs.
Write the RMA tracking number clearly on the outside of the package. Send the unit,
freight charges prepaid, to any Bad Elf warranty service station.
Online Auction Purchases: Products sold through online auctions are not eligible
for rebates or other special oers from Bad Elf. Online auction confirmations are not
accepted for warranty verification. To obtain warranty service, an original or copy of
Page 14
Bad Elf GNSS Surveyor
the sales receipt from the original retailer is required. Bad Elf will not replace missing
components from any package purchased through an online auction.
International Purchases: International distributors provide a separate warranty for
units purchased outside the United States. The local in-country distributor provides
this warranty and this distributor provides local service for your unit. Distributor
warranties are only valid in the area of intended distribution. Units purchased in the
United States must be returned to the Bad Elf service center in the United States for
service.
Legal
All rights reserved. Except as expressly provided herein, no part of this manual may
be reproduced, copied, transmitted, disseminated, downloaded, or stored in any
storage medium, for any purpose without the express prior written consent of Bad
Elf. Bad Elf hereby grants permission to download a single copy of this manual onto
a hard drive or other electronic storage medium to be viewed and to print one copy
of this manual or of any revision hereto, provided that such electronic or printed
copy of this manual must contain the complete text of this copyright notice and
provided further that any unauthorized commercial distribution of this manual or
any revision hereto is strictly prohibited.
Information in this document is subject to change without notice. Bad Elf reserves
the right to change or improve its products and to make changes in the content
without obligation to notify any person or organization of such changes or
improvements. Visit the Bad Elf website (http://bad-elf.com) for current updates and
supplemental information concerning the use and operation of this and other Bad
Elf products.
Bad Elf®, the Bad Elf logos, ElfPort, Engineering Magic, Engineered Magic, Engineer
Magic are trademarks of Bad Elf, LLC registered in the USA and other countries.
These trademarks may not be used without the express written permission of Bad
Elf.
“Made for iPod,” “Made for iPhone,” “Made for iPad” mean that an electronic
accessory has been designed to connect specifically to iPod, iPhone, or iPad,
Page 15
Bad Elf GNSS Surveyor
respectively, and has been certified by the developer to meet Apple performance
standards. Apple is not responsible for the operation of this device or its compliance
with safety and regulatory standards. Please note that the use of this accessory with
iPod, iPhone, or iPad may aect wireless performance.
iPad, iPhone, iPod, and iPod touch are registered trademarks of Apple, Inc., registered
in the US and other countries. iTunes is a registered trademarks of Apple, Inc.,
registered in the US and other countries.
The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by Bad Elf is under license.
Contact Bad Elf Product Support if you have any questions while using your GPS. In
the USA, go to http://bad-elf.com/support.
Bluetooth Security
This Bad Elf product implements the Bluetooth 2.1 BR+EDR specification for wireless
communication with mobile phones, tablets, and other computing devices. By
default, the Secure Simple Pairing (SSP) method is used for all pairings, requiring
confirmation of a random 6-digit PIN to be made by the user on both the Bad
Elf accessory and the phone/tablet. 128-bit encryption is used for all wireless
communications.
Based on the information above, this Bad Elf product meets the requirements of
Security Mode 4, Level 4 as specified in the NIST Guide to Bluetooth Security (Special
Publication 800-121 Rev 2) found at: https://doi.org/10.6028/NIST.SP.800-121r2-upd1
NOTE: If needed for compatibility with legacy computing systems, the user can
optionally disable Bluetooth pairing PIN confirmation. Doing so lowers the security
level compliance to Security Mode 4, Level 2 due to the lack of MITM protection.
Thank You!
All of us at Bad Elf would like to thank you for buying our products.
Page 16
Bad Elf GNSS Surveyor
Notes
Page 17
Bad Elf GNSS Surveyor
Notes
© 2022 Bad Elf, LLC
http://bad-elf.com
Engineering Magic®
Table of contents
Other Bad Elf GPS manuals
