BALUN EAP245 User manual

Report No.: BL-SZ1680250-601
2 / 129
Revision History
Version
Issue Date
Revisions Content
Rev. 01
Nov. 15, 2016
Initial Issue
Rev. 02
Dec. 06, 2016
Updating radiated spurious emission and
restricted-band edge data.
TABLE OF CONTENTS
1ADMINISTRATIVE DATA (GENERAL INFORMATION) ........................................................................ 5
1.1 Identification of the Testing Laboratory ..................................................................................... 5
1.2 Identification of the Responsible Testing Location .................................................................... 5
1.3 Laboratory Condition ................................................................................................................ 5
1.4 Announce ................................................................................................................................. 5
2PRODUCT INFORMATION ................................................................................................................... 6
2.1 Applicant Information ................................................................................................................ 6
2.2 Manufacturer Information .......................................................................................................... 6
2.3 Factory Information ................................................................................................................... 6
2.4 General Description for Equipment under Test (EUT) ............................................................... 6
2.5 Ancillary Equipment .................................................................................................................. 6
2.6 Technical Information ............................................................................................................... 7
2.7 Additional Instructions .............................................................................................................. 9
3SUMMARY OF TEST RESULTS ......................................................................................................... 11
3.1 Test Standards ....................................................................................................................... 11
3.2 Verdict .................................................................................................................................... 11
4GENERAL TEST CONFIGURATIONS ................................................................................................ 12
4.1 Test Environments .................................................................................................................. 12
4.2 Test Equipment List ................................................................................................................ 12
4.3 Measurement Uncertainty ....................................................................................................... 13
4.4 Description of Test Setup ....................................................................................................... 13
4.4.1 For Antenna Port Test ............................................................................................................ 13
4.4.2 For AC Power Supply Port Test .............................................................................................. 14
4.4.3 For Radiated Test (Below 30 MHz) ......................................................................................... 14
4.4.4 For Radiated Test (30 MHz-1 GHz) ........................................................................................ 15

Report No.: BL-SZ1680250-601
3 / 129
4.4.5 For Radiated Test (Above 1 GHz) .......................................................................................... 15
4.5 Measurement Results Explanation Example ........................................................................... 16
4.5.1 For conducted test items: ....................................................................................................... 16
4.5.2 For radiated band edges and spurious emission test: ............................................................. 16
5TEST ITEMS ....................................................................................................................................... 17
5.1 Antenna Requirements ........................................................................................................... 17
5.1.1 Standard Applicable ............................................................................................................... 17
5.1.2 Antenna Anti-Replacement Construction ................................................................................ 17
5.1.3 Antenna Gain ......................................................................................................................... 17
5.2 Output Power ......................................................................................................................... 18
5.2.1 Test Limit ................................................................................................................................ 18
5.2.2 Test Setup .............................................................................................................................. 18
5.2.3 Test Procedure ....................................................................................................................... 18
5.2.4 Test Result ............................................................................................................................. 19
5.3 6dB Bandwidth ....................................................................................................................... 20
5.3.1 Limit........................................................................................................................................ 20
5.3.2 Test Setup .............................................................................................................................. 20
5.3.3 Test Procedure ....................................................................................................................... 20
5.3.4 Test Result ............................................................................................................................. 20
5.4 Conducted Spurious Emission ................................................................................................ 21
5.4.1 Limit........................................................................................................................................ 21
5.4.2 Test Setup .............................................................................................................................. 21
5.4.3 Test Procedure ....................................................................................................................... 21
5.4.4 Test Result ............................................................................................................................. 22
5.5 Band Edge (Authorized-band band-edge)............................................................................... 23
5.5.1 Limit........................................................................................................................................ 23
5.5.2 Test Setup .............................................................................................................................. 23
5.5.3 Test Procedure ....................................................................................................................... 23
5.5.4 Test Result ............................................................................................................................. 24
5.6 Conducted Emission ............................................................................................................... 25
5.6.1 Limit........................................................................................................................................ 25
5.6.2 Test Setup .............................................................................................................................. 25

Report No.: BL-SZ1680250-601
4 / 129
5.6.3 Test Procedure ....................................................................................................................... 25
5.6.4 Test Result ............................................................................................................................. 25
5.7 Radiated Spurious Emission ................................................................................................... 26
5.7.1 Limit........................................................................................................................................ 26
5.7.2 Test Setup .............................................................................................................................. 26
5.7.3 Test Procedure ....................................................................................................................... 26
5.7.4 Test Result ............................................................................................................................. 27
5.8 Band Edge (Restricted-band band-edge) ............................................................................... 28
5.8.1 Limit........................................................................................................................................ 28
5.8.2 Test Setup .............................................................................................................................. 28
5.8.3 Test Procedure ....................................................................................................................... 28
5.8.4 Test Result ............................................................................................................................. 28
5.9 Power Spectral density (PSD) ................................................................................................ 29
5.9.1 Limit........................................................................................................................................ 29
5.9.2 Test Setup .............................................................................................................................. 29
5.9.3 Test Procedure ....................................................................................................................... 29
5.9.4 Test Result ............................................................................................................................. 29
ANNEX A TEST RESULT ....................................................................................................................... 30
A.1 Output Power ......................................................................................................................... 30
A.2 Bandwidth............................................................................................................................... 32
A.3 Conducted Spurious Emissions .............................................................................................. 46
A.4 Band Edge (Authorized-band band-edge)............................................................................... 72
A.5 Conducted Emissions ............................................................................................................. 83
A.6 Radiated Emission .................................................................................................................. 85
A.7 Band Edge (Restricted-band band-edge) ............................................................................. 111
A.8 Power Spectral Density (PSD) .............................................................................................. 121
ANNEX B TEST SETUP PHOTOS ....................................................................................................... 129
ANNEX C EUT EXTERNAL PHOTOS .................................................................................................. 129
ANNEX D EUT INTERNAL PHOTOS .................................................................................................... 129

Report No.: BL-SZ1680250-601
5 / 129
1 ADMINISTRATIVE DATA (GENERAL INFORMATION)
1.1Identification of the Testing Laboratory
Company Name
Shenzhen BALUN Technology Co., Ltd.
Address
Block B, 1st FL, Baisha Science and Technology Park, Shahe Xi Road,
Nanshan District, Shenzhen, Guangdong Province, P. R. China
Phone Number
[phone]
Fax Number
[phone]
1.2Identification of the Responsible Testing Location
Test Location
Shenzhen BALUN Technology Co., Ltd.
Address
Block B, 1st FL, Baisha Science and Technology Park, Shahe Xi Road,
Nanshan District, Shenzhen, Guangdong Province, P. R. China
Accreditation
Certificate
The laboratory has been listed by Industry Canada to perform
electromagnetic emission measurements. The recognition numbers of
test site are 11524A-1.
The laboratory has been listed by US Federal Communications
Commission to perform electromagnetic emission measurements. The
recognition numbers of test site are 832625.
The laboratory is a testing organization accredited by China National
Accreditation Service for Conformity Assessment (CNAS) according to
ISO/IEC 17025. The accreditation certificate number is L6791.
Description
All measurement facilities used to collect the measurement data are
located at Block B, FL 1, Baisha Science and Technology Park, Shahe Xi
Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China
518055
1.3 Laboratory Condition
Ambient Temperature
20 to 25℃
Ambient Relative
Humidity
45% - 55%
Ambient Pressure
100 kPa - 102 kPa
1.4Announce
(1) The test report reference to the report template version v5.3.
(2) The test report is invalid if not marked with the signatures of the persons responsible for preparing and
approving the test report.
(3) The test report is invalid if there is any evidence and/or falsification.
(4) The results documented in this report apply only to the tested sample, under the conditions and modes of
operation as described herein.
(5) This document may not be altered or revised in any way unless done so by BALUN and all revisions are duly
noted in the revisions section.
(6) Content of the test report, in part or in full, cannot be used for publicity and/or promotional purposes without
prior written approval from the laboratory.

Report No.: BL-SZ1680250-601
6 / 129
2 PRODUCT INFORMATION
2.1Applicant Information
Applicant
TP- LINK TECHNOLOGIES CO., LTD.
Address
Building 24 ( floors 1, 3, 4, 5 ) and 28 ( floors1- 4) Central Science
and Technology Park, Shennan Rd, Nanshan, Shenzhen, China
2.2Manufacturer Information
Manufacturer
TP- LINK TECHNOLOGIES CO., LTD.
Address
Building 24 ( floors 1, 3, 4, 5 ) and 28 ( floors1- 4) Central Science and
Technology Park, Shennan Rd, Nanshan, Shenzhen, China
2.3Factory Information
Factory
N/A
Address
N/A
2.4General Description for Equipment under Test (EUT)
EUT Type
AC1750 Wireless Daul Band Gigabit Ceiling Mount Access Point
Model Name Under
Test
EAP245
Series Model Name
N/A
Description of Model
name differentiation
N/A
Hardware Version
N/A
Software Version
N/A
Dimensions (Approx.)
N/A
Weight (Approx.)
N/A
Network and Wireless
connectivity
WIFI 802.11a, 802.11b, 802.11g and 802.11n(HT20/40) and 802.11ac
2.5Ancillary Equipment
Ancillary Equipment 1
Charger
Brand Name
TP-LINK
Model No.
T120150-2B1
Serial No.
N/A
Rated Input
100-240 V , 0.6 A, 50/60 Hz
Rated Output
12 V , 1.5 A

Report No.: BL-SZ1680250-601
7 / 129
2.6Technical Information
The requirement for the following technical information of the EUT was tested in this report:
Frequency Range
802.11b/g/n(20 MHz): 2.412 GHz - 2.462 GHz
fc = 2412 MHz + (N-1)*5 MHz, where
- fc = “Operating Frequency” in MHz,
- N = “Channel Number” with the range from 1 to 11.
802.11n(40 MHz): 2.422 GHz - 2.452 GHz
fc = 2412 MHz + (N-1)*5 MHz, where
- fc = “Operating Frequency” in MHz,
- N = “Channel Number” with the range from 3 to 9.
Modulation Type
DSSS, OFDM
Product Type
Indoor for IC standard
Indoor Access Point for FCC standard
Antenna System (eg., MIMO,
Smart Antenna)
Cyclic Delay Diversity (CDD)
Categorization as Correlated or
Completely Uncorrelated
Correlated
Antenna
Type
Antenna 0 (ANT 0)
PIFA Antenna
Antenna 1 (ANT 1)
Antenna 2 (ANT 2)
Antenna
Gain
Antenna 0 (ANT 0)
4.62 dBi
Antenna 1 (ANT 1)
4.65 dBi
Antenna 2 (ANT 2)
4.86 dBi
Total
directional
gain
For power spectral
density(PSD)
measurements
9.63 dBi
Formulas: Directional gain = GANT + Array Gain, Array
Gain = 10 log(NANT/NSS) dB.NSS =1, GANT set equal to the
gain of the antenna having the highest gain.
For power
measurements
4.86 dBi
Formulas: Directional gain = GANT + Array Gain, Array
Gain = 0, GANT set equal to the gain of the antenna having
the highest gain.
Adaptive or non-adaptive
Adaptive
About the Product
Only the WIFI 802.11b, 802.11g and 802.11n (HT20/40) was
tested in this report.
Mode
Antenna
Antenna 0
Antenna 1
Antenna 2
802.11b
√
√
√
802.11g
√
√
√
802.11n20
√
√
√
802.11n40
√
√
√

Report No.: BL-SZ1680250-601
8 / 129
Modulation technology
Modulation Type
Transfer Rate (Mbps)
DSSS (802.11b)
DBPSK
1
DQPSK
2
CCK
5.5/ 11
OFDM (802.11g)
BPSK
6 / 9
QPSK
12 / 18
16QAM
24 / 36
64QAM
48 / 54
OFDM
(802.11n-20MHz)
BPSK
6.5
QPSK
13/19.5
16QAM
26/39
64QAM
52/58.5/65
OFDM
(802.11n-40MHz)
BPSK
13.5
QPSK
27/40.5
16QAM
54/81/108
64QAM
121.5/135
Note: Preliminary tests were performed in different data rate in above table to find the worst radiated emission. The
data rate shown in the table below is the worst-case rate with respect to the specific test item. Investigation has
been done on all the possible configurations for searching the worst cases. The following table is a list of the test
modes shown in this test report.
Test Items
Mode
Data Rate
Channel
Output Power
11b/11g/11n20/11n40
1/6/6.5/13.5 Mbps
1/6/11
3/6/9
6dB Bandwidth
11b/11g/11n20/11n40
1/6/6.5/13.5 Mbps
1/6/11
3/6/9
Conducted Spurious Emission
11b/11g/11n20/11n40
1/6/6.5/13.5 Mbps
1/6/11
3/6/9
Conducted Emission
11b/11g/11n20/11n40
1/6/6.5/13.5 Mbps
1/6/11
3/6/9
Radiated Spurious Emission
11b/11g/11n20/11n40
1/6/6.5/13.5 Mbps
1/6/11
3/6/9
Band Edge
11b/11g/11n20/11n40
1/6/6.5/13.5 Mbps
1/6/11
3/6/9
Power spectral density (PSD)
11b/11g/11n20/11n40
1/6/6.5/13.5 Mbps
1/6/11
3/6/9
Note: The above EUT information in section 2.4 and 2.6 was declared by manufacturer and for more detailed
features description, please refer to the manufacturer's specifications or user's manual.

Report No.: BL-SZ1680250-601
9 / 129
2.7Additional Instructions
EUT Software Settings:
Mode
Special software is used.
The software provided by client to enable the EUT under
transmission condition continuously at specific channel
frequencies individually.
During testing. Channel and Power Controlling Software provided by the customer was used to control the
operating channel as well as the output power level. The RF output power selection is for the setting of RF output
power expected by the customer and is going to be fixed on the firmware of the final end product.
EUT Software Settings:
Power level setup in software
Test Software
Version
Cart
Mode
Frequency(MHz)
Channel
Soft Set
802.11 b
2412
1
22
2422
3
25
2437
6
25
2452
9
25
2462
11
21
802.11 g
2412
1
17
2422
3
21
2437
6
25
2452
9
21
2462
11
16
802.11 n20
2412
1
16
2422
3
22
2437
6
25
2452
9
20
2462
11
17
802.11 n40
2422
3
13
2432
5
20
2437
6
18
2442
7
18
2452
9
16

Report No.: BL-SZ1680250-601
10 / 129
Run software:

Report No.: BL-SZ1680250-601
11 / 129
3 SUMMARY OF TEST RESULTS
3.1Test Standards
No.
Identity
Document Title
1
47 CFR Part 15,
Subpart C
(10-1-15 Edition)
Miscellaneous Wireless Communications Services
2
KDB Publication
558074 D01v03r05
Guidance for Performing Compliance Measurements on
Digital Transmission Systems (DTS) Operating Under §15.247
3
KDB Publication
662911 D01v02r01
Emissions Testing of Transmitters with Multiple Outputs in the Same Band
(e.g., MIMO, Smart Antenna, etc)
4
RSS-Gen
(Issue 4, Nov. 2014)
General Requirements for Compliance of Radio Apparatus
5
RSS-247
(Issue 1, May 2015)
Digital Transmission Systems (DTSs), Frequency Hopping Systems(FHSs)
and Licence-Exemp Local Area Network (LE-LAN) Devices
6
ANSI C63.10-2013
American National Standard of Procedures for Compliance Testing of
Unlicensed Wireless Devices
3.2Verdict
No.
Description
FCC PART No.
ISED Part No.
Test Result
Verdict
1
Antenna Requirement
15.203; 15.247(b)
RSS-247, 5.4 (6)
N/A
PassNote 1
2
Output Power
15.247(b)
RSS-247, 5.4 (4)
ANNEX A.1
Pass
3
6dB Bandwidth
15.247(a)
RSS-GEN, 6.6;
RSS-247, 5.2 (1)
ANNEX A.2
Pass
4
Conducted Spurious
Emission
15.247(d)
RSS-247, 5.5
ANNEX A.3
Pass
5
Band Edge(Authorized-
band band-edge)
5.209; 15.247(d)
RSS-GEN, 8.9;
RSS-247, 5.5
ANNEX A.4
Pass
6
Conducted Emission
15.207
RSS-GEN, 8.8
ANNEX A.5
Pass
7
Radiated Spurious
Emission
15.209; 15.247(d)
RSS-247, 5.5
ANNEX A.6
Pass
8
Band Edge(Restricted-
band band-edge)
15.209; 15.247(d)
RSS-247, 5.5
ANNEX A.7
Pass
9
Power spectral density
(PSD)
15.247(e)
RSS-247, 5.2 (2)
ANNEX A.8
Pass
10
Receiver Spurious
Emissions
N/A
RSS-Gen, 7.1.2
N/A
N/ANote 2
Note 1: Please refer to section 5.1
Note 2: Only radio communication receivers operating in stand-alone mode within the band 30-960 MHz,
as well as scanner receivers, are subject to Industry Canada requirements, so this test is not applicable.

Report No.: BL-SZ1680250-601
12 / 129
4 GENERAL TEST CONFIGURATIONS
4.1Test Environments
During the measurement, the normal environmental conditions were within the listed ranges:
Relative Humidity
45% - 55%
Atmospheric Pressure
100 kPa - 102 kPa
Temperature
NT (Normal Temperature)
+22℃ to +25℃
Working Voltage of the EUT
NV (Normal Voltage)
12 V
4.2Test Equipment List
Description
Manufacturer
Model
Serial No.
Cal. Date
Cal. Due
Spectrum Analyzer
ROHDE&SCHWARZ
FSV-30
103118
2016.07.13
2017.07.12
Vector Signal
Generator
ROHDE&SCHWARZ
SMBV100A
177746
2016.07.13
2017.07.12
Signal Generator
ROHDE&SCHWARZ
SMB100A
260592
2016.07.13
2017.07.12
Switch Unit with OSP-
B157
ROHDE&SCHWARZ
OSP120
101270
2016.07.13
2017.07.12
Spectrum Analyzer
AGILENT
E4440A
MY45304434
2015.10.15
2016.10.14
EMI Receiver
ROHDE&SCHWARZ
ESRP
101036
2016.07.05
2017.07.04
LISN
SCHWARZBECK
NSLK 8127
8127-687
2016.07.05
2017.07.04
Bluetooth Tester
ROHDE&SCHWARZ
CBT
101005
2016.07.13
2017.07.12
Power Splitter
KMW
DCPD-LDC
1305003215
--
--
Power Sensor
ROHDE&SCHWARZ
NRP-Z21
103971
2016.07.13
2017.07.12
Attenuator (20 dB)
KMW
ZA-S1-201
110617091
--
--
Attenuator (6 dB)
KMW
ZA-S1-61
1305003189
--
--
DC Power Supply
ROHDE&SCHWARZ
HMP2020
018141664
2016.07.13
2017.07.12
Temperature Chamber
ANGELANTIONI
SCIENCE
NTH64-40A
1310
2016.07.13
2017.07.12
Test Antenna-
Loop(9 kHz-30 MHz)
SCHWARZBECK
FMZB 1519
1519-037
2015.07.22
2017.07.21
Test Antenna-
Bi-Log(30 MHz-3 GHz)
SCHWARZBECK
VULB 9163
9163-624
2015.07.22
2017.07.21
Test Antenna-
Horn(1-18 GHz)
SCHWARZBECK
BBHA
9120D
9120D-1148
2015.07.22
2017.07.21
Test Antenna-
Horn(15-26.5 GHz)
SCHWARZBECK
BBHA 9170
9170-305
2015.07.22
2017.07.21
Anechoic Chamber
RAINFORD
9m*6m*6m
N/A
2015.02.28
2017.02.27
Shielded Enclosure
ChangNing
CN-130701
130703
--
--

Report No.: BL-SZ1680250-601
13 / 129
4.3 Measurement Uncertainty
The following measurement uncertainty levels have been estimated for tests performed on the EUT
as specified in CISPR 16-4-2.
This uncertainty represents an expanded uncertainty expressed at approximately the 95%
confidence level using a coverage factor of k=2.
Measurement
Value
Occupied Channel Bandwidth
±4%
RF output power, conducted
±1 .4 dB
Power Spectral Density, conducted
±2.5 dB
Unwanted Emissions, conducted
±2.8 dB
All emissions, radiated
±5.4 dB
Temperature
±1°C
Humidity
±4%
4.4Description of Test Setup
4.4.1 For Antenna Port Test
(Diagram 1)

Report No.: BL-SZ1680250-601
14 / 129
4.4.2 For AC Power Supply Port Test
(Diagram 2)
4.4.3 For Radiated Test (Below 30 MHz)
(Diagram 3)

Report No.: BL-SZ1680250-601
15 / 129
4.4.4 For Radiated Test (30 MHz-1 GHz)
(Diagram 4)
4.4.5 For Radiated Test (Above 1 GHz)
(Diagram 5)

Report No.: BL-SZ1680250-601
16 / 129
4.5Measurement Results Explanation Example
4.5.1 For conducted test items:
The offset level is set in the spectrum analyzer to compensate the RF cable loss and attenuator between EUT
conducted output port and spectrum analyzer. With the offset compensation, the spectrum analyzer reading level
is exactly the EUT RF output level.
The spectrum analyzer offset is derived from RF cable loss and attenuator factor.
Offset = RF cable loss + attenuator factor.
4.5.2 For radiated band edges and spurious emission test:
E = EIRP – 20log D + 104.8
where:
E = electric field strength in dBμV/m,
EIRP = equivalent isotropic radiated power in dBm
D = specified measurement distance in meters.
EIRP= Measure Conducted output power Value (dBm) + Maximum transmit antenna gain (dBi) + the appropriate
maximum ground reflection factor (dB)

Report No.: BL-SZ1680250-601
17 / 129
5 TEST ITEMS
5.1Antenna Requirements
5.1.1 Standard Applicable
FCC §15.203 & 15.247(b); RSS-247, 5.4 (6)
An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible
party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a
unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this section.
The manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a
standard antenna jack or electrical connector is prohibited. This requirement does not apply to carrier current
devices or to devices operated under the provisions of § 15.211, § 15.213, § 15.217, § 15.219, or § 15.221. Further,
this requirement does not apply to intentional radiators that must be professionally installed, such as perimeter
protection systems and some field disturbance sensors, or to other intentional radiators which, in accordance with
§ 15.31(d), must be measured at the installation site. However, the installer shall be responsible for ensuring that
the proper antenna is employed so that the limits in this part are not exceeded.
If directional gain of transmitting antennas is greater than 6 dBi, the power shall be reduced by the same level in
dB comparing to gain minus 6 dBi. For the fixed point-to-point operation, the power shall be reduced by one dB for
every 3 dB that the directional gain of the antenna exceeds 6 dBi. The use of a permanently attached antenna or
of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with
the FCC rule.
5.1.2 Antenna Anti-Replacement Construction
The Antenna Anti-Replacement as following method:
Protected Method
Description
The antenna is An embedded-in
An embedded-in antenna design is used.
Reference Documents
Item
5.1.3 Antenna Gain
The antenna peak gain of EUT is less than 6 dBi. Therefore, it is not necessary to reduce maximum peak output
power limit.
2.4G Antenna 0
5.8G Antenna 2
2.4G Antenna 2
2.4G Antenna 1
5.8G Antenna 0
5.8G Antenna 1

Report No.: BL-SZ1680250-601
18 / 129
5.2Output Power
5.2.1 Test Limit
FCC § 15.247(b); RSS-247, 5.4 (4)
For systems using digital modulation in the 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz bands: 1 Watt.
As an alternative to a peak power measurement, compliance with the one Watt limit can be based on a
measurement of the maximum conducted output power. Maximum Conducted Output Power is defined as the total
transmit power delivered to all antennas and antenna elements averaged across all symbols in the signaling
alphabet when the transmitter is operating at its maximum power control level. Power must be summed across all
antennas and antenna elements.
5.2.2 Test Setup
See section 4.4.1 for test setup description for the antenna port. The photo of test setup please refer to ANNEX B.
5.2.3 Test Procedure
Maximum peak conducted output power
The maximum peak conducted output power may be measured using a broadband peak RF power meter. The
power meter shall have a video bandwidth that is greater than or equal to the DTS bandwidth and shall utilize a
fast-responding diode detector.
Maximum conducted (average) output power (Reporting Only)
a) As an alternative to spectrum analyzer or EMI receiver measurements, measurements may be performed
using a wideband RF power meter with a thermocouple detector or equivalent if all of the conditions listed below
are satisfied.
1) The EUT is configured to transmit continuously, or to transmit with a constant duty factor.
2) At all times when the EUT is transmitting, it shall be transmitting at its maximum power control level.
3) The integration period of the power meter exceeds the repetition period of the transmitted signal by at least a
factor of five.
b) If the transmitter does not transmit continuously, measure the duty cycle (x) of the transmitter output signal as
described in Section 6.0.
c) Measure the average power of the transmitter. This measurement is an average over both the on and off
periods of the transmitter.
d) Adjust the measurement in dBm by adding 10log (1/x), where x is the duty cycle to the measurement result.
Measurements of duty cycle
The zero-span mode on a spectrum analyzer or EMI receiver if the response time and spacing between bins on
the sweep are sufficient to permit accurate measurements of the on and off times of the transmitted signal.
Set the center frequency of the instrument to the center frequency of the transmission.

Report No.: BL-SZ1680250-601
19 / 129
Set RBW ≥ OBW if possible; otherwise, set RBW to the largest available value.
Set VBW ≥ RBW. Set detector = peak or average.
The zero-span measurement method shall not be used unless both RBW and VBW are > 50/T and the number of
sweep points across duration T exceeds 100. (For example, if VBW and/or RBW are limited to 3 MHz, then the
zero-span method of measuring duty cycle shall not be used if T ≤ 16.7 microseconds.)
5.2.4 Test Result
Please refer to ANNEX A.1.

Report No.: BL-SZ1680250-601
20 / 129
5.36dB Bandwidth
5.3.1 Limit
FCC §15.247(a); RSS-GEN, 6.6
Make the measurement with the spectrum analyzer's resolution bandwidth (RBW) = 100 kHz. In order to make an
accurate measurement, set the span greater than RBW. The 6 dB bandwidth must be greater than 500 kHz.
5.3.2 Test Setup
See section 4.4.1 for test setup description for the antenna port. The photo of test setup please refer to ANNEX B.
5.3.3 Test Procedure
Use the following spectrum analyzer settings:
Set RBW = 100 kHz.
Set the video bandwidth (VBW) ≥ 3 RBW.
Detector = Peak.
Trace mode = max hold.
Sweep = auto couple.
Allow the trace to stabilize.
Measure the maximum width of the emission that is constrained by the frequencies associated with the two
outermost amplitude points (upper and lower frequencies) that are attenuated by 6 dB relative to the maximum
level measured in the fundamental emission.
5.3.4 Test Result
Please refer to ANNEX A.2.
