1. DESCRIPTION
BAMOPHAR 436 is designed for turbidity measurements for control and monitoring of water.
Connected to a transmitter TURBICUBE or TRUBOMAT GAB for in-line measurement or to a TURBISENS for measurement in immersion,
BAMOPHAR will display and transmit 2 analogue signals, as 4-20 mA, for temperature and turbidity.
BAMOPHAR displays on a color touch-sensitive screen a multilingual friendly using menu.
The reading is easy for measurement, temperature and relay status.
It displays a menu with all parameters for configuration of analogue outputs and thresholds.
For a safe start-up a test menu allow a simulation of operation actuating all outputs and thresholds.
2. TECHNICAL FEATURES
End-user interface Color touch screen 4.3'', resolution 480x272 pixels
Display of measurements, menus, temperature, relay status
Configuration - Keyword protected
Measuring scales To set up according the turbidity transmitter in use (from 0.001 to 9999 FNU, FAU, mg/l, g/l)
Input signal For turbidity transmitter with 4-20 mA output signal.
Temperature display When a Pt 100 Ω (3-wire) is connected: range 0 ... 100 °C
Or manual set up
Relay outputs 4 contacts, potential free
S1, threshold for measurement or temperature (N.O.)
S2, threshold for measurement or temperature (N.O.)
S3, threshold for measurement or temperature (N.O.) or assigned to an external contact
S4, contact as alarm function (fault on Pt 100 loop) or over-riding measurement
Initial contact resistance 100 mΩ max. (voltage drop 6 V DC 1 A)
Switching power 831 VA AC / 3 A / 277 V AC
90 W / 3 A / 30 V DC
Switching capacity (min.) 100 mA, 5 V DC (depends of frequency, ambient conditions)
Mechanical lifetime (min.) 5 x 10⁶ operations (180 op./min)
Electrical lifetime (min.) 2 x 10⁵ (at 20 op./min) for 3 A 125 V AC, 3 A 30 V DC - 10⁵ (estimated load) for 3 A 125 V AC
Output measurement signal 0/4 - 20 mA (max. 600 Ω), directly proportional to measurement
Power supply 230 V, 50/60 Hz (other on request); Consumption 10 VA
Models Panel mounting, 96x144 mm, Front IP65, screw terminal IP40
Wall mounting, IP65, cable glands, screw terminals
OPTION (RS 422 + Logger)
Interface RS422 output, J-BUS link - Binary slave mode - 2400 to 9600 bauds
Data Logger: Automatic record of cycle average measurement
150 000 records max. on memory card
3. DIMENSIONS
TUR
07-06-2021 M-436.02-EN-AE 436-02/3
Turbidity monitor
BAMOPHAR 436
22, Rue de la Voie des Bans · Z.I. de la gare · 95100 ARGENTEUIL
Tel
Fax
[phone]
[phone]
Web
E-mail
www.bamo.eu
[email protected]
INTERNATIONAL

4. ELECTRICAL CONNECTIONS
PANEL MOUNT VERSION
WALL MOUNT VERSION
Measurement signal input 4-20 mA
OPTION : LOGGER & RS 422
(wall mount version: accessible
after removing the top cover)
Measurement signal input 4-20 mA
TUR
07-06-2021 M-436.02-EN-AE 436-02/4
Turbidity monitor
BAMOPHAR 436
22, Rue de la Voie des Bans · Z.I. de la gare · 95100 ARGENTEUIL
Tel
Fax
[phone]
[phone]
Web
E-mail
www.bamo.eu
[email protected]
INTERNATIONAL

4.1 TERMINAL STRIP ASSIGNMENTS
Description Terminal number Connections
(A) Measurement signal output, mA 1+ mA
2- mA
(B) Measurement signal output, mA 3- mA
4+ mA
Blocking regulation External sensor: 5+ 24 V
Inductive sensor (194 831) 6- 24 V
Power supply to sensor: 20 mA 7- 24 V
8+ 24 V
Temperature probe: Pt 100 Ω; 2-wire or 3-wire
9+
10 +
11 -
12 Shielding
Connection to an extension unit (blind version)
13 Y
14 Z
15 B
16 A
Relay S4: Fault on Pt 100 loop and over-riding measurement 17 S4
18
Relay S2: N.O. contact; for measurement signal 19 S2
20
Relay 1: N.O. contact for measurement 21 S1
22
Relay 3: N.O. contact for measurement 23 S3
24
Not used 25
Main power supply
26 PE = Earth (equipotential)
27 N = Neutral
28 L = Live
Sensor (2wire or 3 wire)
29 NC
30 - mA
31 + mA
CONNECTIONS TO EXTENSION UNIT
MAIN UNIT EXTENSION UNIT
Distance max. 500 m
Required cable Network cable or shielded 4-wire cable ( ≥ 0.25 mm² )
TUR
07-06-2021 M-436.02-EN-AE 436-02/5
Turbidity monitor
BAMOPHAR 436
22, Rue de la Voie des Bans · Z.I. de la gare · 95100 ARGENTEUIL
Tel
Fax
[phone]
[phone]
Web
E-mail
www.bamo.eu
[email protected]
INTERNATIONAL

4.2 CONNECTION OF TURBIDITY TRANSMITTERS
TUR
07-06-2021 M-436.02-EN-AE 436-02/6
Turbidity monitor
BAMOPHAR 436
22, Rue de la Voie des Bans · Z.I. de la gare · 95100 ARGENTEUIL
Tel
Fax
[phone]
[phone]
Web
E-mail
www.bamo.eu
[email protected]
INTERNATIONAL

5. DISPLAY MENU
5.1 WITHOUT EXTENSION UNIT
Switching status of relays S1, S2, S3, S4
(Contact symbol appears if relay is set up)
Measured values display
NTU; FAU; mg/l; g/l; FNU; °C
Designation
Parameter settings
Display settings Measurement details
Date and time
(Only for the versions with data-logger)
E1 Status
Closed =
Actuated; Open =
non active
5.2 WITH EXTENSION UNIT
Parameter settings of each monitor Date and time
(Only for data-logger versions)
Display settings Measurement details
(Contact symbol appears if relay is set up)
Switching status of relays S1, S2, S3, S4
Designation of each measuring systems
Measurements: Main Unit in FAU; Extension unit in mS (exemple for conductivity)
Measured values display
Monitor A is shown in yellow (main unit)
Monitor B is shown in green (extension unit)
TUR
07-06-2021 M-436.02-EN-AE 436-02/7
Turbidity monitor
BAMOPHAR 436
22, Rue de la Voie des Bans · Z.I. de la gare · 95100 ARGENTEUIL
Tel
Fax
[phone]
[phone]
Web
E-mail
www.bamo.eu
[email protected]
INTERNATIONAL

6. ICONS FUNCTIONS
Use the touch screen to navigate through the menus and set the display according to your application.
For each yellow button dedicated to the main unit, there is a green variant dedicated to the extension unit.
MAIN MENU
Return to main menu
Example with green icon for the extension unit
SETTINGS
Access to the display settings (language and monitor designation)
LANGUAGES
Language selection
MENU
Access to monitoring parameters
INFO
Access to serial number and version of BAMOPHAR
PADLOCK
Open = MODIFICATION MODE
Closed = CONSULTATION MODE (Query mode)
RETURN KEY
Return to previous screen
ARROWS
Display cursor for navigating within the menus
SELECTION
Scroll through the selection list
CONFIRM
Access to the next line of menu
SAVE
Save settings
TUR
07-06-2021 M-436.02-EN-AE 436-02/8
Turbidity monitor
BAMOPHAR 436
22, Rue de la Voie des Bans · Z.I. de la gare · 95100 ARGENTEUIL
Tel
Fax
[phone]
[phone]
Web
E-mail
www.bamo.eu
[email protected]
INTERNATIONAL

7. DISPLAY SETTINGS
To access to the display settings, BAMOPHAR must be in MODIFICATION mode (See § CONSULTATION / MODIFICATION).
7.1 SCREEN INFORMATION
Screen identification number and its version are available in this menu.
7.2 SCREENSAVER
Screensaver brightness is adjusted by moving the cursor: decreasing by the left, increasing by the right.
7.3 LANGUAGE SELECTION
Select the flag according to your choice.
The display automatically returns to previous view.
Press icon "HOME" to go back to MENU
7.4 DESIGNATION
It is recommended to name each channel (main unit A and Extension unit B):
1) Press on icon A or B according to the instrument you wish to rename.
2) A keyboard appears, enter the new name.
3) Save to record the new designation.
8. CONSULTATION / MODIFICATION
CONSULTATION mode allows the operator to check out all working parameters.
This mode is represented by the closed padlock icon.
To change the settings of the BAMOPHAR, you need to enter in the MODIFICATION mode.
This mode is protected by a password identical to the last 4 digits of the serial number.
On the main display, press MENU icon.
Press the padlock icon and type the 4 last digits of Serial Number.
To confirm, press "OK"; BAMOPHAR is now in MODIFICATION mode
If the entered keyword is wrong, an error message appears (****), pending correct keyword.
After 30 minutes the mode MODIFICATION switches back to CONSULTATION mode.
Where can we find the serial number?
The serial number (SN) is written on the identification label of the BAMOPHAR
It appears as well in "MENU", icon " i " (INFORMATION).
TUR
07-06-2021 M-436.02-EN-AE 436-02/9
Turbidity monitor
BAMOPHAR 436
22, Rue de la Voie des Bans · Z.I. de la gare · 95100 ARGENTEUIL
Tel
Fax
[phone]
[phone]
Web
E-mail
www.bamo.eu
[email protected]
INTERNATIONAL

9. SETTINGS
9.1 SETTING THE MEASUREMENT
Go to the menu MEASURE DATA
NTU This sequence is used to select a type of unit in relation to the working range of the sensor connected to
the device.
Select the unit NTU, FAU,mg/l, g/l, FNU, then save ) then confirm in order to proceed to the next
parameter.
x-xxxx Setting this parameter informs the instrument on the scale in use on the turbidity transmitter.
Example: For a working scale of 0.1 to 100 FNU, the comma (decimal point) should be set such that
display is x - xxx,x
For a working scale of 100 to 1000 FAU the comma (decimal point) should be deleted such as follows: x
- xxxx
Set this parameter, then confirm.
SCALE This parameter specifies the values min. & max. of the working scale.
Confirm to follow up to next sequence.
MINI : 0000 Type the value min. of working scale (keyboard appears), then confirm.
MAXI : 0000 Type the value max. of working scale, then confirm.
SENSOR This parameter is used to enter the current values 0/4 ... 20 mA signal from the turbidity transmitter.
Confirm to follow up to next sequence.
MINI : 00,00 mA Type the value 0 or 4 (keyboard appears), then confirm.
MAXI : 00,00 mA Type the value 20 (for 20 mA max.), then confirm.
SAVE ? To record the settings, press the icon SAVE.
9.2 THRESHOLDS SETTING FOR S1, S2, S3
As an example, below is a detailed description of the steps to set the threshold S1:
Go to the menu ADJUST ALARM 1.
ALARM 1 ON / OFF For programming the relay S1, select the ON mode, then confirm
To unable the use of relay S1, select OFF mode, then confirm and save (Icon SAVE)
ALARM 1 MEASURE / TEMP In the ON mode, threshold 1 can be set for signal MEASUREMENT or TEMPERATURE:
MEASUREMENT = Threshold dedicated to the monitoring of turbidity signal
TEMPERATURE = Threshold dedicated to the monitoring of temperature signal
Select your mode, then confirm.
ALARM 1 HIGH / LOW By selecting HIGH, triggering takes place as soon as the measured value is greater than the selected
limit valuefor S1.
By selecting LOW, triggering takes place as soon as the measured value is less than the selected limit
value for S1.
Select the right triggering mode, then confirm
ON 000.0 Enter the value at which relay S1 will be actuated, then confirm.
OFF 000,0 Enter the value at which relay S1 will be deactivated, then confirm.
DELAY UP ON / OFF With (ON) or without (OFF) pick-up delay for relay S1, then confirm.
TIME 0000 Sec Enter a delay duration for relay S1, then confirm.
DELAY DOWN ON / OFF With or without dropout delay for relay S1
TIME 0000 Sec Enter a delay duration for relay S1, then confirm
SAVE ? To record the settings, press the icon SAVE
The parameters for S2 and S3 are available in the respective “ALARM 2” and “ALARM 3” menus.
9.3 ASSIGNING S3 TO AN EXTERNAL SIGNAL
Go to the menu ADJUST ALARM 3
ALARM 3 ON / OFF For programming the relay S3, select the ON mode, then confirm
EXTERN. NO / YES NO = next parameters to set up are identical as for as previous relays S1 and S2
YES = assignment of external sensor signal to actuate relay S3
Relay S3 becomes N.C. (normally closed contact) and it opens when the external sensor is activated.
Then confirm
SAVE ? To record the settings, press the icon SAVE
TUR
07-06-2021 M-436.02-EN-AE 436-02/10
Turbidity monitor
BAMOPHAR 436
22, Rue de la Voie des Bans · Z.I. de la gare · 95100 ARGENTEUIL
Tel
Fax
[phone]
[phone]
Web
E-mail
www.bamo.eu
[email protected]
INTERNATIONAL

Measured value Measured value
Measured value Measured value
Time
Time
Time
Time
RISING SIGNAL
DECREASING SIGNAL
Trigger point, relay ON
Trigger point, relay OFF
Trigger point, relay OFF
Trigger point, relay ON
Actuated relay
Actuated relay
Actuated relay Actuated relay
Delay before relay switches ON
Delay before relay switches OFF
9.4 SETTING THE TEMPERATURE
Go to the menu TEMPERATURE
MEASURE : AUTO / MANUAL AUTO : Temperature is displayed if a Pt 100 sensor is connected, confirm, then save.
MANUAL : Without Pt 100 sensor connected, enter the temperature manually.
Confirm
FLUID T. +000.0 °C In the MANUAL mode, enter the temperature of the liquid, then confirm.
SAVE ? To record the settings, press the icon SAVE
9.5 mA OUTPUT SETTINGS FOR THE MEASUREMENT
Go to the menu OUTPUT mA TURB
HIGHER 2000 Enter the measured value for which the output is 20 mA, then confirm.
LOWER 0000 Enter the measured value for which the output is 0 or 4 mA, then confirm
OUTPUT 4/20 mA or 0/20 mA Select the output signal type, then confirm
SAVE ? To record the settings, press the icon SAVE
9.6 mA OUTPUT SETTINGS FOR THE TEMPERATURE
Go to the menu OUTPUT mA TEMP.
HIGHER +160.0 °C Enter the temperature value for which the output is 20 mA, then confirm.
LOWER +000.0 °C Enter the temperature value for which the output is 0 or 4 mA, then confirm.
OUTPUT 4/20 mA or 0/20 mA Select the output signal type, then confirm
SAVE ? To record the settings, press the icon SAVE
9.7 SIMULATION OF RELAYS
With the menu FORCED RELAY, it is possible to manually test (force) relays S1, S2, S3 and S4.
Last one, S4, is N.O. by default. The test begins by relay S1.
The respective relay can be switched from OFF (open) to ON (closed).
Confirm to go to the next relay, then to go back to previous menu.
9.8 SIMULATION OF MEASUREMENT
Go to the menu FORCED MEASURE
0.000 Simulation at this measured value.
First displayed value is the current measurement.
Confirm, then enter the value you wish to test.
Note: The value is immediately considered by the monitor and actuates thresholds, 4-20mA outputs, etc.
TUR
07-06-2021 M-436.02-EN-AE 436-02/11
Turbidity monitor
BAMOPHAR 436
22, Rue de la Voie des Bans · Z.I. de la gare · 95100 ARGENTEUIL
Tel
Fax
[phone]
[phone]
Web
E-mail
www.bamo.eu
[email protected]
INTERNATIONAL
