B&B Electronics DSP-100 User manual

DSP-100
Dual Channel RS-232 PCMCIA
Asynchronous Adapter
for PCMCIA Card Standard compatible machines
User's Manual
QUATECH, INC. TEL: [phone]
5675 Hudson Industrial Parkway FAX: [phone]
Hudson, Ohio 44236 www.quatech.com
INTERFACE CARDS FOR IBM PC/AT AND PS/2

Warranty Information
Quatech Inc. warrants the DSP-100 to be free of defects for one (5) year from the date of purchase.
Quatech Inc. will repair or replace any adapter that fails to perform under normal operating conditions
and in accordance with the procedures outlined in this document during the warranty period. Any
damage that results from improper installation, operation, or general misuse voids all warranty rights.
The authors have taken due care in the preparation of this document and any associated software
program(s). In no event will Quatech Inc. be liable for damages of any kind, incidental or consequential,
in regard to or arising out of the performance or form of the materials presented herein and in the
program(s) accompanying this document. No representation is made regarding the suitability of this
product for any particular purpose.
Quatech Inc. reserves the right to edit or append to this document or the product(s) to which it refers at
any time and without notice.
Please complete the following information and retain for your records. Have this information available
when requesting warranty service.
Date of purchase:
Model Number: DSP-100
Product Description: Dual Channel Asynchronous RS-232
Communications PCMCIA Adapter
Serial Number:
iQuatech, Inc.
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

Declaration of Conformity
Manufacturer's Name: Quatech, Inc.
Manufacturer's Address: 5675 Hudson Industrial Pkwy.
Hudson, OH 44236 (USA)
Application of Council Directive: 89/336/EEC
Standards to which
Conformity is Declared: * EN50081-1
(EN55022)
* EN50082-1
(IEC 801-2, IEC 801-3, & IEC 801-4)
Type of Equipment: Information Technology Equipment
Equipment Class: Commercial, Residential, & Light
Industrial
Product Name: PCMCIA Card
Model Number : DSP-100
DSP-100 (Rev. G and later) User's Manual ii
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

Table of Contents
7-2
Specifications ........................................................6-1
External Connections .................................................5-2Installing DSP-100 ....................................................5-2
Windows NT .........................................................4-7Changing Resource Settings with Device Manager ......................4-6Viewing Resource Settings with Device Manager .......................4-4DSP-100 Resource Settings in Windows 2000/XP ..........................4-1Installing a DSP-100 Under Windows 2000/XP ............................4-1
Windows 2000/XP ....................................................3-3Frequently Asked Questions ...........................................3-2Changing Resource Settings with Device Manager ......................3-2Viewing Resource Settings with Device Manager .......................3-1DSP-100 Resource Settings in Windows 95/98/ME ........................3-1Installing a DSP-100 Under Windows 95/98/ME ..........................3-1
Windows 95/98/Millennium (ME) .....................................2-10Common Problems ...............................................2-8Command Line Options ............................................2-7DSP-100 Enabler for DOS ..............................................2-6Common Problems ................................................2-4Command Line Options ............................................2-3Client Driver Installation ...........................................2-3DSP-100 Client Driver for DOS .........................................2-2
DOS/Windows 3.x ....................................................1-1
Introduction ..........................................................
iii Quatech, Inc.
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

1. Introduction
The DSP-100 is a dual channel RS-232 asynchronous serial adapter for systems
equipped with PCMCIA Type II and/or Type III expansion sockets. The DSP-100 is a
PCMCIA Type II (5 mm) card and is PCMCIA PC Card Standard Specification 2.1
compliant.
The DSP-100's serial port is implemented using two 16C750 Universal Asynchronous
Receiver/Transmitters(UARTs), which are the recommended communications
interface for multitasking environments and with applications involving high data
transfer rates.
PCMCIA Card Cable Assembly
Standard D-9 Male (2)
Figure 1. DSP-100 Card and Cable Assembly
Introduction 1-1
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

This page intentionally left blank.
2-1 DSP-100 (Rev. G and later) User’sManual
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

2. DOS/Windows 3.x
Note: Quatech PCMCIA DOS support is dependent upon type of machine
and card and socket services software support. DOS support is not
guaranteed.
Two configuration software programs are provided with the DSP-100: a Client Driver,
and a card Enabler. Both of these programs are executed from DOS (before entering
Windows) and allow operation of the DSP-100 in both the DOS and Windows 3.x
environments. For optimal operation, however, the Client Driver is the preferred
method of installation and configuration. The table below highlights the differences
between these programs.
Does not require PCMCIA
Card and Socket Services
software
Requires PCMCIA Card and
Socket Services software
Does not support automatic
configuration of adapters upon
insertion (Hot Swapping)
Allows automatic configuration
of DSP-100 adapters upon
insertion (Hot Swapping)
Interfaces directly to Intel
82365SL and other PCIC
compatible PCMCIA host
adapters
Interfaces to PCMCIA Card
and Socket Services software
(PCMCIA host adapter
independent)
File type: DOS executableFile type: DOS device driver
EnablerClient Driver (recommended)
Figure 2. Client Driver versus Enabler for DOS/Windows 3.x.
Card and Socket Services software is commercially available from several vendors for
most desktop and laptop PCs. If you are unsure whether Card and Socket Services
software is currently installed on your system, install the DSP-100 Client Driver as
discussed in following section. When loaded, the Client Driver will display an error
message if Card and Socket Services software is not detected.
DOS/Windows 3.x 2-2
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

2.1DSP-100 Client Driver for DOS
In order to use the DSP-100 Client Driver, the system must be configured with Card
and Socket Services software. Card and Socket Services software is not provided with
the DSP-100 but is available from Quatech.
IMPORTANT:
Some versions of Card and Socket Services dated before
1993 do not support general purpose I/O cards. If after
careful installation of the Client Driver the adapter does
not configure or operate properly, an updated version of
Card and Socket Services may be required.
2.1.1Client Driver Installation
The following procedure is used to install the DSP-100 Client Driver:
1.Copy the Client Driver from the DSP-100 distribution diskette onto the
system's hard drive.
2.Using an ASCII text editor, open the system's CONFIG.SYS file located in the
root directory of the boot drive.
3.Locate the line(s) in the CONFIG.SYS file where the Card and Socket Services
software is installed.
4.AFTER the line(s) installing the Card and Socket Services software, add the
following line to the CONFIG.SYS file: DEVICE = drive:\path\
DSP130CL.SYS options where options are the DSP-100 Client Driver
command line options discussed on the following pages.
5.Save the CONFIG.SYS file and exit the text editor.
6.Insert the DSP-100 into one of the system's PCMCIA slots.
NOTE: Since the DSP-100 Client Driver supports "Hot Swapping", it is not
necessary to have the DSP-100 installed when booting the system. By inserting
the card before booting, however, the Client Driver will report the adapter
configuration during the boot process thereby verifying the changes made to the
CONFIG.SYS.
7.Reboot the system and note the message displayed when the DSP-100 Client
Driver is loaded. If the Client Driver reports an "invalid command line
option", correct the entry in the CONFIG.SYS file and reboot the system
again. If the Client Driver reports "Card and Socket Services not found", a
version of Card and Socket Services must be installed on the system or the
2-3 DSP-100 (Rev. G and later) User’sManual
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

DSP-100 Enabler program must be used to configure the adapter. If the
Client Driver reports the desired adapter configuration, the installation
process is complete and the DSP-100 may be removed and/ or inserted from
the system as desired. On each insertion into the PCMCIA socket, the
DSP-100 will be automatically reconfigured according to the command line
options.
2.1.2Command Line Options
The DSP-100 Client Driver accepts up to eight command line arguments from the user
to determine the configuration of theDSP-100. If any arguments are provided, the
Client Driver will attempt to configure any DSP-100s with the options specified in the
order they are entered on the command line. Each argument must be enclosed in
parenthesis and must be separated from other arguments by a space on the command
line. Within each argument, any or all of the following parameters may be specified
using a comma (no spaces) to separate each parameter:
Baddress specifies a the base I/O address of the DSP-100 in hexadecimal. This
address must reside on an even 8-byte boundary. If this option is omitted, a
base address will be assigned by Card and Socket Services.
Iirq specifies the interrupt level (IRQ) of the DSP-100 in decimal. irq must be one
of the following values: 3, 4, 5, 7, 9, 10, 11, 12, 14, 15, or 0 if no IRQ is
desired. If this option is omitted, an interrupt level will be assigned by Card
and Socket Services.
Ssocket specifies which PCMCIA socket the DSP-100 must be inserted into for this
configuration argument to be used. socket must be in the range 0 - 15. If this
option is omitted, the configuration argument will apply to DSP-100s
inserted into any socket.
Cclock specifies the multiple of the standard frequency for the UART clock. Valid
values for clock are 1 or 8. A value of 1 yields a clock frequency of 1.8432
MHz; a value of 8 yields 14.7456 MHz. If this option is omitted, the
standard clock frequency will be used.
2.1.2.1Example 1
DEVICE = C:\DSP-100\ DSP130CL.SYS
In example 1, no command line arguments are specified. The Client Driver will
configure a DSP-100 inserted into any socket with a base address and IRQ assigned by
Card and Socket Services.
DOS/Windows 3.x 2-4
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

2.1.2.2Example 2
DEVICE = C:\DSP-100\DSP130CL.SYS (b290,i11)
In example 2, a single command line argument is provided. The Client Driver will
attempt to configure a DSP-100 inserted into any socket with a base address of 290H
and IRQ 11. If address 290H or IRQ 11 is unavailable, the DSP-100 will not be
configured.
2.1.2.3Example 3
DEVICE = C:\DSP-100\DSP130CL.SYS(s0,b300,i5,o2)
In example 3, a single command line argument is provided. The Client Driver will
attempt to configure a DSP-100 inserted into socket 0 with a base address of 300H and
IRQ 5. If address 300H or IRQ 5 is unavailable, the DSP-100 will not be configured. In
addition, if aDSP-100 is inserted into any other socket, it will not be configured.
2.1.2.4Example 4
DEVICE = C:\DSP-100\DSP130CL.SYS(i5,h,b300)
In example 4, a single command line argument is provided. Because the parameter
order is not significant, the Client Driver will attempt to configure a DSP-100 inserted
into any socket with a base address of 300H and IRQ 5. If address 300H or IRQ 5 is
unavailable, the DSP-100 will not be configured.
2.1.2.5Example 5
DEVICE = C:\DSP-100\DSP130CL.SYS (b300,i5) (i10) ( )
In example 5, three command line arguments are provided. The Client Driver will first
attempt to configure a DSP-100 inserted into any socket with a base address of 300H
and IRQ 5. If address 300H or IRQ 5 is unavailable, the Client Driver will proceed to
the second command line argument and attempt to configure the card with a base
address assigned by Card and Socket Services and IRQ 10. If IRQ 10 is also
unavailable, the Client Driver will proceed to the third command line argument and
attempt to configure the DSP-100 with a base address and an IRQ assigned by Card and
Socket Services.
2-5 DSP-100 (Rev. G and later) User’sManual
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

2.1.2.6Example 6
DEVICE = C:\DSP-100\DSP130CL.SYS (b300,i5) ( ) (i10)
In example 6, the three command line arguments of example 5 have been rearranged.
The Client Driver will first attempt to configure a DSP-100 inserted into any socket with
a base address of 300H and IRQ 5. If address 300H or IRQ 5 is unavailable, the Client
Driver will proceed to the second command line argument and attempt to configure the
card with a base address and IRQ assigned by Card and Socket Services. Since the
second command line argument includes all available address and IRQ resources, the
third command line argument will never be reached by the Client Driver. It is the
user's responsibility to place the command line arguments in a logical order.
2.1.2.7Example 7
DEVICE = C:\DSP-100\DSP130CL.SYS (s0,b300,i5) (s1,b340,i10)
The type of configuration shown in example 7 may be desirable in systems where more
than one DSP-100 is to be installed. In this example, the Client Driver will attempt to
configure a DSP-100 inserted into socket 0 with a base address of 300H and IRQ 5. If
the DSP-100 is inserted into socket 1, the Client Driver will attempt to configure it with
base address 340H and IRQ 10. This allows the user to force the DSP-100's address and
IRQ settings to be socket specific which may simplify cable connections and software
development. As in the previous examples, however, if the requested address or
interrupt resources are not available, the DSP-100 will not be configured.
2.1.3Common Problems
Generic Client Drivers:
Many Card and Socket Services packages include a generic client driver (or
SuperClient) which configures standard I/O devices. If one of these generic client
drivers is installed, it may configure the DSP-100 causing the DSP-100 client driver to
fail installation. In these cases, the user should do one of the following:
1.Modify the operation of the generic client driver to disable the configuration
of modem/serial port cards. Consult the Card and Socket Services
documentation for availability and details of this feature.
2.Place the DSP-100 client driver before the generic client driver in the
CONFIG.SYS.
DOS/Windows 3.x 2-6
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

Available Resources:
One function of the Card and Socket Services software is to track which system
resources (memory addresses, I/O addresses, IRQs, etc.) are available for assignment to
inserted PCMCIA cards. Sometimes, however, the Card Services software assumes or
incorrectly determines that a particular resource is used when it is actually available.
Most Card and Socket Services generate a resource table in a file (typically in the form
of an .INI file) which the user can modify to adjust the available system resources.
Consult the Card and Socket Services documentation for availability and details of this
feature.
Multiple Configuration Attempts:
Some Card and Socket Services have a setting which aborts the configuration process
after a single configuration failure (such as a request for an unavailable resource). The
user should change this setting to allow for multiple configuration attempts. Consult
the Card and Socket Services documentation for availability and details of this feature.
Older Versions of Card and Socket Services:
Some versions of Card and Socket Services dated before 1993 do not support general
purpose I/O cards. If after careful installation of the Client Driver the DSP-100 does
not configure or operate properly, an updated version of Card and Socket Services may
be required. Card and Socket Services software is available from Quatech.
2.2DSP-100 Enabler for DOS
For systems that are not operating PCMCIA Card and Socket Services software, the
DSP-100 DOS Enabler may be used to enable and configure the adapter. This Enabler,
SSP200EN.EXE, will operate on any DOS system using an Intel 82365SL or PCIC
compatible PCMCIA host adapter including the Cirrus Logic CL-PD6710 /6720, the
VLSI VL82C146, and the Vadem VG-365 among others.
IMPORTANT:
In order to use the DSP-100 Enabler for DOS, the system
MUST NOT be configured with Card and Socket Services
software. If a Card and Socket Services software is installed,
the DSP-100 Enabler may interfere with its operation and
with the device(s) it controls.
2-7 DSP-100 (Rev. G and later) User’sManual
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

The DSP-100 Enabler does not support automatic configuration of adapters upon
insertion, more commonly referred to as "Hot Swapping". This means the adapter must
be installed in one of the system's PCMCIA sockets before executing DSP130EN.EXE. If
more than one adapter is installed in a system, the Enabler must be executed separately
for each adapter. Furthermore, DSP130EN.EXE should be executed to release the
resources used by the adapter before it is removed from the PCMCIA socket. Since
PCMCIA adapters do not retain their configuration after removal, any adapter that is
removed from the system must be reconfigured with the Enabler after re-inserting it
into a PCMCIA socket.
IMPORTANT:
The Enabler requires a region of high DOS memory when
configuring a DSP-100. This region is 1000H bytes (4KB) long
and by default begins at address D0000H (the default address
may be changed using the "W" option). If a memory manager
such as EMM386, QEMM, or 386Max is installed on the system,
this region of DOS memory must be excluded from the memory
manager's control. Consult the documentation provided with
the memory manager software for instructions on how to
exclude this memory region.
2.2.1Command Line Options
To configure a DSP-100 in the system, the Enabler requires one command line
argument from the user to determine the configuration of the card. This argument
must be enclosed in parenthesis and within the argument, any or all of the following
parameters may be specified using a comma (no spaces) to separate each parameter:
Ssocket specifies which PCMCIA socket the DSP-100 must be inserted into for this
configuration argument to be used. socket must be in the range 0 - 15. This
option is required if the 'R' option is not used.
Baddress specifies the base I/O address of the DSP-100 in hexadecimal. This address
must reside on an even 8-byte boundary. This option is required if the 'R'
option is not used.
Iirq specifies the interrupt level (IRQ) of the DSP-100 in decimal. irq must be one
of the following values: 3, 4, 5, 7, 9, 10, 11, 12, 14, 15, or 0 if no IRQ is
desired. This option is required if the 'R' option is not used.
DOS/Windows 3.x 2-8
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

Waddress specifies the base address of the memory window required to configure the
DSP-100. Set address = D0 for a memory window at segment D000, address =
D8 for a memory window at segment D800, etc. Valid settings for address
are C8, CC, D0, D4, D8, and DC. If this option is omitted, a memory
window at segment D000 will be used.
Cclock specifies the multiple of the standard frequency for the UART clock. Valid
values for clock are 1 or 8. A value of 1 yields a clock frequency of 1.8432
MHz; a value of 8 yields 14.7456 MHz. If this option is omitted, the
standard clock frequency will be used.
Before removing a DSP-100 from its PCMCIA socket, the Enabler should be executed to
free the system resources allocated when the card was installed. For this operation the
Enabler provides on additional command line option:
Rinstructs the enabler to release the resources previously allocated to the
DSP-100. When the 'R' option is used, any settings specified by the 'B' and 'I'
options are ignored.
2.2.1.1Example 1
DSP130EN.EXE
In example 1, no command line argument is specified. The Enabler will report an error
and display the proper usage of the command.
2.2.1.2Example 2
DSP130EN.EXE (s0,b300,i5)
In example 2, the Enabler will configure the DSP-100 in socket 0 with a base address of
300H and IRQ 5 using a configuration memory window at segment D000.
2.2.1.3Example 3
DSP130EN.EXE (i10,h,b340,s1)
In example 3, the Enabler will configure the DSP-100 in socket 1 with a base address of
340H and IRQ 10 using a configuration memory window at segment D000.
2.2.1.4Example 4
DSP130EN.EXE (s0,b300,i3,wd8)
In example 4, the Enabler will configure the DSP-100 in socket 0 with a base address of
300H and IRQ 3 using a configuration memory window at segment D800.
2-9 DSP-100 (Rev. G and later) User’sManual
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

2.2.1.5Example 5
DSP130EN.EXE (o1,i5,b340,s1)
In example 2, the Enabler will configure the DSP-100 in socket 1 with a base address of
340H and IRQ 5 using a configuration memory window at segment D000.
2.2.1.6Example 6
DSP130EN.EXE (s0,b300,i5,r)
In example 6, the Enabler will release the configuration used by the DSP-100 in socket 0
using a configuration memory window at segment D000. The base address and IRQ
parameters are ignored and may be omitted.
2.2.1.7Example 7
DSP130EN.EXE (s1,r,wcc)
In example 7, the Enabler will release the configuration used by the DSP-100 in socket 1
using a configuration memory window at segment CC00.
2.2.2Common Problems
Memory Range Exclusion:
The Enabler requires a region of high DOS memory when configuring a DSP-100. This
region is 1000H bytes (4KB) long and by default begins at address D0000H (the default
address may be changed using the "W" option). If a memory manager such as
EMM386, QEMM, or 386Max is installed on the system, this region of DOS memory
must be excluded from the memory manager's control. Consult the documentation
provided with the memory manager software for instructions on how to exclude this
memory region.
Furthermore, some systems use the high memory area for BIOS shadowing to improve
overall system performance. In order for the Enabler to operate, any BIOS shadowing
must be disabled in the address range specified for the configuration window. BIOS
shadowing can usually be disabled through the system's CMOS setup utility.
Socket Numbers:
The Enabler requires the DSP-100's socket number to be specified on the command line
and the DSP-100 must be inserted into the socket before the Enabler is invoked. Some
vendors number their sockets from 1 to N while other vendors number their sockets
from 0 to N-1. For theDSP-100 Enabler, the lowest socket number in the system is
designated socket 0.
DOS/Windows 3.x 2-10
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

Card and Socket Services Software:
In order to use the DSP-100 Enabler for DOS, the system MUST NOT be configured
with Card and Socket Services software. If a Card and Socket Services software is
installed, the Enabler may interfere with its operation and with the device(s) it controls.
For systems configured with Card and Socket Services, the DSP-100 Client Driver is the
recommended method of configuration.
2-11 DSP-100 (Rev. G and later) User’sManual
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

3. Windows 95/98/Millennium (ME)
To allow easy configuration of the DSP-100, a Windows 95/98/ME "INF"
configuration file has been written for the hardware.
3.1Installing a DSP-100 Under Windows 95/98/ME
1.Insert the DSP-100 into any available PC Card socket.
2.The first time a new PC Card type is installed the New Hardware Found
window opens. After this first installation Windows 95/98/ME will
automatically detect and configure the card. If the New Hardware Found
window does not open, then skip to the next section, “DSP-100 Resource
Settings".
3.The New Hardware Found window provides several options to configure
the DSP-100 card. Click the "Search for the best driver for your device"
option button. Click "NEXT" to continue.
4.An "Install from Disk" dialog box should appear. Insert the Quatech COM
CD file, select the correct drive letter and path, and click "OK". Windows
95/98/ME will browse the path for the aforementioned files.
5.During the installation process, it may be required to supply the computer
with the Windows 95/98/ME CD or installation CDs. Insert the CD and
click "OK".
The DSP-100 PC Card should now be configured. With the default configuration,
the DSP-100's interrupt status register will be enable and the 16C750 UART’s
scratchpad register will be disabled. In the future, Windows 95/98/ME will
automatically recognize and configure the DSP-100 in this default configuration.
3.2DSP-100 Resource Settings in Windows 95/98/ME
Windows 95/98/ME maintains a registry of all known hardware installed within the
computer. Inside this hardware registry Windows 95/98/ME keeps track of all the
computer's resources, such as base I/O addresses, IRQ levels, and DMA channels. In
the case of a PC Card (PCMCIA) type board, Windows 95/98/ME configures the new
hardware using free resources it finds within the hardware registry, and updates the
registry automatically.
Windows 95/98/Millennium (ME)3-1
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

To view and/or edit hardware devices in Windows 95/98/ME use the system Device
Manager. To access Device Manager double click the System icon in the Windows
95/98/ME control panel, or click the My Computer icon on the Windows 95/98/ME
desktop with the right mouse button and select Properties from the pull down menu.
Consult Windows 95/98/ME on-line help for details on the use of the Device Manager.
3.2.1Viewing Resource Settings with Device Manager
1.Start the Windows 95/98/ME Device Manager.
2.Double click on the hardware class Quatech Comm Adapters to list
hardware devices in the class.
3.The DSP-100 “parent device” belongs to this hardware class. The device
name for the DSP-100 is Quatech DSP-100: Dual RS-232 Serial Port PC
Card.
4.Open the Properties dialog for the DSP-100 device, then click the Resources
tab to view the Input/Output Range and Interrupt Request resource
allocations.
5.Double click the hardware class Ports (Com and LPT).Each Quatech
Communications Port listed in this class is a “child device” of the DSP-100
“parent device.”
6.Open the Properties dialog for a COM port, then click the Resources tab to
view the Input/Output Range and Interrupt Request resource allocations.
These will match those of the “parent device.”
7.Record the COM Port device names(COM1,COM2,etc.) for the DSP-100.
These namesare required by Windows 95/98/ME applicationswhen
accessing particular ports.
3.2.2Changing Resource Settings with Device Manager
1.Start the Windows 95/98/ME Device Manager.
2.Double click on the hardware class Quatech Comm Adapters to list
hardware devices in the class.
3.The DSP-100 “parent device” belongs to this hardware class. The device
name for the DSP-100 is Quatech DSP-100: Dual RS-232 Serial Port PC
Card.
4.Open the Properties dialog for the DSP-100 device, then click the Resources
tab to view the Input/Output Range and Interrupt Request resource
allocations.
3-2 DSP-100 (Rev. G and later) User’sManual
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

5.Several predefined Basic Configurations have been included for the DSP-100
(see Figure 5. DSP-100 Basic Configuration Table). The Basic Configurations
provide many combinations of the operating modes and options listed below.
See the Hardware Information section of this manual for complete
descriptions.
When the Use Automatic Settings check box is enabled Windows 95/98/ME
will attempt to configure the DSP-100 in the order listed in the Basic
Configurations table.
Scratch Pad8xAny0003 Scratch PadNormalAny0002 ISR8xAny0001 ISRNormalAny0000
Scratch
Pad/ ISR
Clock
Speed
I/O Range***Basic
Configuration
*** Any indicates variable value; this value may or may not be user selectable depending on
platform.
6.Select a Basic Configurations that displays "No conflicts" in the bottom
display region titled Conflicting Device List from the drop down list.
7.To modify the Interrupt Request setting click the resource name and click
the Change Setting button. An Edit Resource window will open up. Inside
this window click on the up/down arrows to the right of the Interrupt
Request value. This scrolls you through all of the allowable resources for
your hardware. Pay attention to the conflict information at the bottom of the
window. Do not select a value that causes a conflict with any other installed
hardware.
8.If any changes have been made to the DSP-100’sconfiguration the card will
automatically be reconfigured to the new resources specified. Any time a
PCMCIA card of this type is inserted Windows 95/98/ME will attempt to
configure the card at these resource settings. Click the Use Automatic
Settings box to reset this card type for automatic configuration.
3.3Frequently Asked Questions
Basic Configuration List Not Available:
A problem noted on some systems is after a basic configuration has been manually
selected the basic configurations list for the DSP-100 is no longer available. The
solution to this problem is to check the “Use Automatic Settings”box and allow
Windows 95/98/ME to reconfigure the DSP-100 card. The basic configurations list
should once again be visible.
Windows 95/98/Millennium (ME)3-3
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]

Base I/O Address Resource Modification Not Allowed:
The DSP-100 is configured to allow only a fixed number of base I/O addresses. To
change the I/O address resources for the DSP-100 select another “Basic Configuration”.
Refer to the Basic Configurations table for a list of the availabe I/O address resources
for the DSP-100.
3-4 DSP-100 (Rev. G and later) User’sManual
www.bb-elec.com [e-mail] [e-mail]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax [phone]
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland [phone] Fax [phone]
