Barco CINE7 R9010040 User manual

HOME CINEMA
BARCO CINE7
R9010040
R9010050
OWNERS MANUAL
26022003 R5976584/00

Barco nv Home Cinema
Noordlaan 5, B-8520 Kuurne
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Visit us at the web: www.homecinema.barco.com
Printed in Belgium

Changes
Barco provides this manual “as is” without warranty of any kind, either expressed or implied, including but not limited to the implied war-
ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the
program(s) described in this publication at any time without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the information in this
publication; these changes are incorporated in new editions of this publication.
Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be recorded, transmitted or
stored in a retrieval system without the prior written consent of BARCO.
Trademarks
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders.
All brand and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for
the products or their manufactures.

Table of contents
TABLE OF CONTENTS
1. SafetyInstructions.................................................................................................. 5
1.1 SafetyInstructions...................................................................................................................... 5
2. ACPower............................................................................................................. 9
2.1 AC Power Cord Connection ............................................................................................................ 9
2.2 ACPowerVoltage....................................................................................................................... 9
2.3 SwitchingON/OFF...................................................................................................................... 9
3. Source Connections...............................................................................................11
3.1 Input Locations.........................................................................................................................11
3.2 Connecting a Composite Video source................................................................................................12
3.3 Connecting a S-Video source..........................................................................................................13
3.4 Connecting a RGB Analog source with composite sync..............................................................................15
3.5 Connecting a RGB Analog source with Tri level composite sync ....................................................................16
3.6 Connecting a Component source with composite sync...............................................................................17
3.7 Connecting a Component source with Tri level composite sync .....................................................................18
3.8 RS232 Connection.....................................................................................................................19
3.9 Communication Port for Communication With Peripherals...........................................................................20
3.1012V Trigger output.....................................................................................................................20
4. GettingStarted......................................................................................................21
4.1 Batteries................................................................................................................................21
4.1.1 Batteryinstallation...............................................................................................................21
4.1.2 Batteryreplacement.............................................................................................................21
4.2 RCU&Localkeypad...................................................................................................................22
4.3 Terminologyoverview..................................................................................................................23
4.4 Switchingontheprojector.............................................................................................................25
4.5 UsingtheRCU.........................................................................................................................26
4.6 ProjectorAddress......................................................................................................................27
4.6.1 Controllingtheprojector.........................................................................................................27
4.6.2 Displaying and Programming addresses .......................................................................................28
4.7 Controlling the projector ...............................................................................................................28
4.7.1 Inputselection...................................................................................................................28
4.7.2 Picturecontrols..................................................................................................................28
5. Startupofthe adjustmentmode................................................................................31
5.1 How to start up the adjustment mode .................................................................................................31
5.2 How to adjust an analog control.......................................................................................................32
6. Main Menu...........................................................................................................33
6.1 MainMenuOverview ..................................................................................................................33
6.2 Image Control ..........................................................................................................................33
6.2.1 Startinguptheimagecontrols..................................................................................................34
6.2.2 LineMultiplier....................................................................................................................34
6.2.2.1 Changing the Multiplier setting ...........................................................................................34
6.2.2.2 Multipliermode............................................................................................................35
6.2.2.3 MotionProcessingOn/Off................................................................................................36
6.2.2.4 VideoEqualizing..........................................................................................................36
6.2.2.5 Noise Reduction ..........................................................................................................37
6.2.2.6 Contrast Enhancement ...................................................................................................38
6.2.3 ColorAdjust,Colortemperaturesetup.........................................................................................38
6.2.4 FormatSelect....................................................................................................................39
6.2.4.1 SelectingaFormat........................................................................................................39
6.2.4.2 AddinganametoaFormat ..............................................................................................39
6.2.4.3 StoringthesettingstoanewFormat.....................................................................................40
6.3 IRISControl............................................................................................................................40
6.3.1 StartinguptheIRISControls ...................................................................................................41
6.3.2 IRISTouchUp...................................................................................................................41
6.3.3 IRISAutoConverge.............................................................................................................41
6.3.4 IRISFullAlignment..............................................................................................................42
6.4 Sound Control..........................................................................................................................42
6.5 FunctionKeys..........................................................................................................................43
6.6 ServiceMenus.........................................................................................................................43
7. Enteringtheservicemenus......................................................................................45
7.1 The Adjustment menus ................................................................................................................45
7.2 PasswordProtection...................................................................................................................46
8. Random Access Adjustment Mode .............................................................................49
8.1 Introduction.............................................................................................................................49
8.2 Random Access Overview.............................................................................................................50
8.3 SelectingSetupPattern................................................................................................................51
8.4 Random Access mode selection menu ...............................................................................................52
R5976584 BARCO CINE7 26022003 1

Table of contents
8.5 PictureTuning..........................................................................................................................52
8.5.1 StartingupPictureTuning ......................................................................................................53
8.5.2 ColorBalance ...................................................................................................................53
8.5.2.1 SelectingtheColorBalance..............................................................................................53
8.5.2.2 SetaFixedColorBalance................................................................................................54
8.5.2.3 CustomColorBalance,WhiteBalanceadjustment .....................................................................54
8.5.2.4 CustomColorBalance,BlackBalanceadjustment......................................................................55
8.5.3 Sync mode: Fast/Slow ..........................................................................................................55
8.5.4 Decoding.........................................................................................................................55
8.5.5 Port 2 Video/S-Video (Optional) ................................................................................................56
8.5.6 Peaking..........................................................................................................................56
8.5.7 LineMultiplierSettings..........................................................................................................57
8.5.7.1 StartingupLineMultipliersettings.......................................................................................57
8.5.7.2 SwitchingthemultiplierON/OFF.........................................................................................58
8.5.7.3 MotionProcessingOn/Off................................................................................................58
8.5.7.4 OutputMode..............................................................................................................59
8.5.7.5 VideoEqualizing..........................................................................................................59
8.5.7.6 Noise Reduction ..........................................................................................................60
8.5.7.7 Contrast Enhancement ...................................................................................................60
8.5.7.8 SplitScreenOn/Off.......................................................................................................61
8.5.7.9 AdvancedSettings........................................................................................................61
8.5.7.9.1 StartingUpAdvancedSettings ....................................................................................62
8.5.7.9.2 TimeBaseCorrection ..............................................................................................62
8.5.7.9.3 Luminance Delay ...................................................................................................62
8.5.7.9.4 VerticalSyncReference............................................................................................63
8.5.7.9.5 ClampGating.......................................................................................................63
8.5.7.10LimoProOptions.........................................................................................................64
8.5.7.10.6StartingUpLimoProOptions......................................................................................64
8.5.7.10.7Coring...............................................................................................................64
8.5.7.10.8LTI ..................................................................................................................65
8.5.7.10.9CTI..................................................................................................................66
8.5.7.10.10FactoryPresets...................................................................................................67
8.6 Geometry Adjustments ................................................................................................................68
8.6.1 Starting Up Geometry ...........................................................................................................68
8.6.2 HorizontalPhaseAdjustment...................................................................................................68
8.6.3 RasterShiftAdjustment.........................................................................................................69
8.6.4 Left-Right(East-West)Adjustment .............................................................................................70
8.6.5 Top-Bottom(Nord-South)Adjustment..........................................................................................73
8.6.6 SizeAdjustment.................................................................................................................76
8.6.7 Vertical Linearity Adjustment....................................................................................................78
8.6.8 BlankingAdjustments...........................................................................................................79
8.7 Convergence Adjustment..............................................................................................................80
8.7.1 Starting Up Convergence .......................................................................................................80
8.7.2 Convergence Adjustment .......................................................................................................81
9. ServiceMode........................................................................................................83
9.1 Introduction.............................................................................................................................83
9.2 ServiceModeOverview ...............................................................................................................84
9.3 ProjectorSetup........................................................................................................................84
9.3.1 StartingUpProjectorSet-Up....................................................................................................85
9.3.2 Identification.....................................................................................................................85
9.3.3 TotalRunTime ..................................................................................................................85
9.3.4 Change Password...............................................................................................................86
9.3.5 Change Language...............................................................................................................86
9.3.6 Change Projector Address......................................................................................................87
9.3.7 Change Baudrate................................................................................................................87
9.3.8 Power Up Mode Operating/Stand-By...........................................................................................88
9.3.9 CommonAddress...............................................................................................................88
9.3.10Barco Logo ......................................................................................................................89
9.4 Memory Management..................................................................................................................90
9.4.1 Starting Up Memory Management..............................................................................................91
9.4.2 CopyaBlock ....................................................................................................................91
9.4.3 DeleteaBlock...................................................................................................................91
9.4.4 DeleteAllBlocks ................................................................................................................92
9.4.5 AllSettingstoMidposition.......................................................................................................92
9.4.6 R & B Convergence to Midposition .............................................................................................93
9.4.7 Green Convergence to Midposition.............................................................................................94
9.5 CommonSettings......................................................................................................................95
9.5.1 StartingUpCommonSettings..................................................................................................95
9.5.2 G2 Adjustment...................................................................................................................95
9.5.3 CRTRunInCycle...............................................................................................................95
9.5.4 ProjectorWarmUp..............................................................................................................96
9.5.5 MemoryBanks...................................................................................................................96
9.6 I2C Diagnostics ........................................................................................................................97
2R5976584 BARCO CINE7 26022003

Table of contents
10.Programmable Function Keys ...................................................................................99
10.1ProgrammingaFunctionKeys........................................................................................................99
10.2Differentfunctionwhichcanbeprogrammed........................................................................................100
11.Messages,Warnings andFailures ............................................................................ 101
11.1Messages.............................................................................................................................101
11.2Warnings..............................................................................................................................101
11.3Failures ...............................................................................................................................102
A.SourceNumbers81—86 and 91 —96....................................................................... 103
A.1 Projector without any 800 peripheral connected.....................................................................................103
A.2 Projector with a 800 peripheral connected...........................................................................................103
A.2.1 Source numbers 91 — 96......................................................................................................103
A.2.2 Source numbers 81 — 86......................................................................................................104
Glossary............................................................................................................... 105
Index.................................................................................................................... 107
R5976584 BARCO CINE7 26022003 3

Table of contents
4R5976584 BARCO CINE7 26022003

1. Safety Instructions
1. SAFETY INSTRUCTIONS
Overview
• Safety Instructions
1.1 Safety Instructions
Notice on Safety
This equipment is built in accordance with the requirements of the international safety standards EN60950, UL 1950 and CSA C22.2
No.950, which are the safety standards of information technology equipment including electrical business equipment. These safety
standards impose important requirements on the use of safety critical components, materials and isolation, in order to protect the
user or operator against risk of electric shock and energy hazard, and having access to live parts. Safety standards also impose
limits to the internal and external temperature rises, radiation levels, mechanical stability and strength, enclosure construction and
protection against the risk of fire. Simulated single fault condition testing ensures the safety of the equipment to the user even when
the equipment’s normal operation fails.
Installation Instructions
Before operating this equipment please read this manual thoroughly, and retain it for future reference. Installation and preliminary
adjustments should be performed by qualified BARCO personnel or by authorized BARCO service dealers.
Owner’s Record
The part number and serial number are located at the back side of the projector. Record these numbers in the spaces provided
below. Refer to them whenever you call upon your BARCO dealer regarding this product.
Part Number:
Ser. Number:
Dealer:
Safety Indication on the Product
Image 1-1
Safety Indication
Safety Warning
TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE !
Federal Communication Commission (FCC Statement)
This equipment has been tested and found to comply with the limits of a class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment
R5976584 BARCO CINE7 26022003 5

1. Safety Instructions
in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his
own expense.
The use of shielded cables is required to comply within the limits of Part 15 of FCC rules and EN55022.
• All the safety and operating instructions should be read before using this unit.
• The safety and operating instructions manual should be retained for future reference.
• All warnings on the equipment and in the documentation manuals should be adhered to.
• All instructions for operating and use of this equipment must be followed precisely.
On Safety
• This product should be operated from an AC power source. Power input is autoranging from 90 V to 230V.
• All equipment in the system is equipped with a 3-wire grounding plug, a plug having a third (grounding) pin. This plug will only
fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not defeat the purpose of the grounding-type plug.
• Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on the cord. To disconnect
the cord, pull it out by the plug. Never pull the cord itself.
• If an extension cord is used with this product, make sure that the total of the ampere ratings on the products plugged into the
extension cord does not exceed the extension cord ampere rating.
• Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out
parts that could result in a risk of fire or electrical shock.
• Never spill liquid of any kind on the product. Should any liquid or solid object fall into the cabinet, unplug the set and have it
checked by qualified service personnel before resuming operations.
• Lightning - For added protection for this video product during a lightning storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet. This will prevent damage to the projector due to lightning and AC power-line
surges.
• The wires of the main lead are colored in accordance with the following code.
Image 1-2
Power cord plugs
This apparatus must be grounded (earthed) via the supplied 3 conductor AC power cable. If the supplied
power cable is not the correct one, consult your dealer.
Caution on Fire Hazard
DO NOT PLACE FLAMMABLE OR COMBUSTIBLE MATERIALS NEAR THE PROJECTOR !
BARCO large screen projection products are designed and manufactured to meet the most stringent safety regulations. This pro-
jector radiates heat on its external surfaces and from ventilation ducts during normal operation, which is both normal and safe.
Exposing flammable or combustible materials to the close proximity of this projector could result in the spontaneous ignition of that
material, resulting in a fire. For this reason, it is absolutelynecessary to leave an "exclusion zone"around all external surfaces of the
projector whereby no flammable or combustible materials are present. The exclusion zone must be not less that 10 cm (4") for Barco
Retro Projectors. Do not cover the projector with any material while the projector is in operation. Keep flammable and combustible
materials away from the projector at all times. Mount the projector is a well ventilated area away from sources of ignition and out
of direct sun light. Never expose the projector to rain or excessive moisture. In the event of fire, use sand, CO2, or dry powder fire
extinguishers; never use water on an electrical fire. Always have service performed on this projector by authorized BARCO service
personnel. Always insist on genuine BARCO replacement parts. Never use non-BARCO replacement parts as they may degrade
the safety of this projector.
6R5976584 BARCO CINE7 26022003

1. Safety Instructions
On Installation
• Do not place this equipment on an unstable cart, stand, or table. The product may fall, causing serious damage to it.
• Do not use this equipment near water.
• Slots and openings in the cabinet and the back or bottom are provided for ventilation; to ensure reliable operation ofthe product
and to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator or
heat register. The projector should not be placed in a built-in installation or enclosure unless proper ventilation is provided.
• Do not block the projector cooling fans or free air movement under and around the projector. Loose papers or other objects
may not be nearer to the projector than 4" on any side.
On Servicing
Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage potentials and
risk of electric shock!
Refer all servicing to qualified service personnel.
Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:
• When the power cord or plug is damaged or frayed.
• If liquid has been spilled into the equipment.
• If the product has been exposed to rain or water.
• If the product does not operate normally when the operating instructions are followed. Adjust only those controls that are
covered by the operating instructions since improper adjustment of the other controls may result in damage and will often
require extensive work by a qualified technician to restore the product to normal operation.
• If the product has been dropped or the cabinet has been damaged.
• If the product exhibits a distinct change in performance, indicating a need for service.
• Replacement parts: When replacement parts are required, be sure the service technician has used original BARCO replace-
ment parts or authorized replacement parts which have the same characteristics as the BARCO original part. Unauthorized
substitutions may result in degraded performance and reliability, fire, electric shock or other hazards. Unauthorized substitu-
tions may void warranty.
• Safety check: Upon completion of any service or repairs to this projector, ask the service technician to perform safety checks
to determine that the product is in proper operating condition.
On Cleaning
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning. To keep the cabinet looking brand-new, periodically clean it with a soft cloth. Stubborn stains may be removed with a cloth
lightly dampened with mild detergent solution. Never use strong solvents, such as thinner or benzine, or abrasive cleaners, since
these will damage the cabinet. To ensure the highest optical performance and resolution, the projection lenses are specially treated
with an anti-reflective coating, therefore, avoid touching the lens. To remove dust on the lens, use a soft dry cloth. Do not use a
damp cloth, detergent solution, or thinner.
On Repacking
Save the original shipping carton and packing material; they will come in handy if you ever have to ship your equipment. For maxi-
mum protection, repack your set as it was originally packed at the factory.
On Illumination
In order to obtain the best quality forthe projected image, it is essential that the ambient lightwhich is allowed to fall on thescreen be
kept to an absolute minimum. When installing the projectorand screen, care must be taken to avoid exposure to ambient light directly
on the screen. Avoid adverse illumination on the screen from direct sunlight or fluorescent lighting fixtures. The use of controlled
ambient lighting, such as incandescent spot light or a dimmer, is recommended for proper room illumination. Where possible, care
should also be taken to ensure that the floors and walls of the room in which the projector is to be installed are non-reflecting, dark
surfaces. Brighter surfaces will tend to reflect and diffuse the ambient light and hence reduce the contrast of the projected image on
the screen.
R5976584 BARCO CINE7 26022003 7

1. Safety Instructions
8R5976584 BARCO CINE7 26022003

2. AC Power
2. AC POWER
Overview
• AC Power Cord Connection
• AC Power Voltage
• Switching ON/OFF
2.1 AC Power Cord Connection
How to connect the AC Power Cord?
Use the supplied power cord to connect your projector to the wall outlet.
1. Plug the female power connector into the male connector at the front side of the electronic block. (image 2-1)
Image 2-1
Power connection
2.2 AC Power Voltage
What is the AC Power Voltage?
The power input voltage is autoranging between 100V (-10%) and 240V (+6%).
2.3 Switching ON/OFF
Switching and led indication
The projector is switched ON and OFF using the power (mains) switch ON/OFF.
• Pressed : ON
• Not pressed : OFF
R5976584 BARCO CINE7 26022003 9

2. AC Power
The projector can start now in the ’operational mode’ (image displayed) or in the ’stand by mode’, depending on the software setup.
Stand by indication lamp :
• no light up : projector in operational mode
• red : projector is in stand by.
Leds on the front plate of the projector
Image 2-2
10 R5976584 BARCO CINE7 26022003

3. Source Connections
3. SOURCE CONNECTIONS
Overview
• Input Locations
• Connecting a Composite Video source.
• Connecting a S-Video source.
• Connecting a RGB Analog source with composite sync
• Connecting a RGB Analog source with Tri level composite sync
• Connecting a Component source with composite sync
• Connecting a Component source with Tri level composite sync
• RS232 Connection
• Communication Port for Communication With Peripherals
• 12V Trigger output
3.1 Input Locations
Input Facilities
• Composite Video
• S-Video
•RGBSorRG
SB
• RGB3S or RG3SB
• (R-Y)Y(B-Y)S or (R-Y)YS(B-Y) [Component Input]
• (R-Y)Y(B-Y)3S or (R-Y)Y3S(B-Y) [Component Input]
Which source to which input
Image 3-1
This table gives an overview of the relation between Input Port #, Source Type and Selection Keys on the RCU:
Input Port # Source Type Selection Keys on the RCU
1Composit Video 1
2S-Video12
3RGBs or RGsB23
3RGB with tri level sync34
3Component video45
3Component video with tri level sync56
Table 3-1
Input Port #, Source type and Selection Keys on the RCU
1. Input signal Y/C (luma/chroma)
2. Input signal : R, G and B with automatic sync detection between seperate sync (separate composite sync or with separate hor and vert. sync) or sync on green (composite sync).
3. Input signal : R, G and B with separate tri level sync or with tri level sync on green.
4. Input signal : R-Y, Y and B-Y with separate sync or with compositesync.
5. Input signal : R-Y, Y and B-Y with separate tri level sync or with composite tri level sync.
R5976584 BARCO CINE7 26022003 11

3. Source Connections
3.2 Connecting a Composite Video source.
Which signal to the video input?
Connect Composite video signals from a VCR, OFF air signal decoder, etc..
If a line multiplier is built in, the default position of this line multiplier soft option is ON (active). The video
input signal will be displayed as a non interlaced image (= improved image stability). To enable or to disable
this function, enter the adjustment mode and change the position of the ON/OFF toggle switch (see chapter
’Random access’ adjustment mode).
Image 3-2
Video connection
Video input selection via the RCU
1. Press digit button 1
Video input selection via the keypad
1. press ADJUST key.
The General access menu is displayed on the screen. (image 3-3)
2. Use the cursor keys to highlight 1.
3. Press ENTER to select the highlighted source.
Image 3-3
12 R5976584 BARCO CINE7 26022003

3. Source Connections
3.3 Connecting a S-Video source.
Chrominance
The color component of a video signal that includes information about tint and saturation.
Luminance
The component of a video signal that includes information about its brightness.
Which signal to the S-video input?
Separate Y-luma/C-chroma signals for higher quality playback of Super VHS signals.
If a line multiplier is built in, the default position of this line multiplier soft option is ON (active). The video
input signal will be displayed as a non interlaced image (= improved image stability). To enable or to disable
this function, enter the adjustment mode and change the position of the ON/OFF toggle switch (see chapter
’Random access’ adjustment mode).
Image 3-4
S-Video input selection via the RCU
1. Press digit button 2
Video input selection via the keypad
1. press ADJUST key.
The General access menu is displayed on the screen. (image 3-5)
2. Use the cursor keys to highlight 2.
3. Press ENTER to select the highlighted source.
R5976584 BARCO CINE7 26022003 13

3. Source Connections
Image 3-5
Input priority setting
Depending on the priority setting in the ’Picture Tuning menu’, Video or S-Video can be displayed. If the setting is not correct, handle
as follow :
1. Press ADJUST key to start up the adjustment mode.
The main menu will be displayed. (menu 3-1)
2. Select Service Menus.
3. Press ENTER to select.
A warning menu, risk of incorrect adjustment, will be displayed. (menu 3-2)
4. Press ENTER to continue if you are qualified, or EXIT if not.
When ENTER is pressed, the Adjustment main menu will be displayed. (menu 3-3)
5. Select Random Access.
6. Press ENTER to select.
The Choose a setup pattern menu will be displayed. (menu 3-4)
7. Select Selected source.
8. Press ENTER to display the Random Access menu. (menu 3-5)
9. Select Picture Tuning.
10.Press ENTER to display the picture tuning menu. (menu 3-6)
11.Select Port2 : Video.
12.Press ENTER to toggle between VIDEO or S-VIDEO.
13.Press ADJUST to return to operational mode.
14 R5976584 BARCO CINE7 26022003

3. Source Connections
MAIN MENU
Image control
Iris control
Sound control
Function keys
Service menus
Select with ↑or ↓
then <ENTER>
<EXIT> to return
Menu 3-1
Warning
Risk of incorrect adjustment
of the projector
The following
SERVICE menus
are reserved to,
and to be performed only
by qualified personnel !
If qualified, press
<ENTER> to continue, or
if not, <EXIT> to return.
Menu 3-2
ADJUSTMENT MODE
Select a path from below :
AUTO IMAGE
RANDOM ACCESS
INSTALLATION
SERVICE
Source 01
Select with ↑or ↓
then <ENTER>
<EXIT> to return
Menu 3-3
Choose a setup path
from below :
SELECTED SOURCE
GENLOCKED PATTERN
INTERNAL # PATTERN
Source 01
Select with ↑or ↓
then <ENTER>
<EXIT> to return
Menu 3-4
RANDOM ACCESS
ADJUSTMENT MODE
PICTURE TUNING
GEOMETRY
CONVERGENCE
COLOR SELECT
Select with ↑or ↓
then <ENTER>
<EXIT> to return
Menu 3-5
PICTURE TUNING
COLOR BALANCE
SYNC : FAST
DECODING : EBU
PORT2 : VIDEO
LINE MULTIPLIER : ON
Select with ↑or ↓
then <ENTER>
<EXIT> to return
Menu 3-6
3.4 Connecting a RGB Analog source with composite sync
Which signals can be connected to the input
Connect your RGB source with sync on green, composite or separate sync via an interface to RGBS input. Always use an interface
(e.g. Barco Magik Interface R9828120) when a computer and local monitorhave to be connected tothe projector as the signal cable
coming from the computer is limited to 60 cm due to interferences.
Image 3-6
RGBS or RGsB selection via the RCU
1. Press digit button 3.
RGBS or RGsB selection via the local keypad
1. Press ADJUST key to start up the adjustment mode.
The General access menu will be displayed. (image 3-7)
2. Use the cursor keys to highlight 3
3. Press ENTER to select the highlighted source.
R5976584 BARCO CINE7 26022003 15

3. Source Connections
Image 3-7
3.5 Connecting a RGB Analog source with Tri level composite sync
Which signal can be connected to the input?
RGB analog input terminals with tri level sync input or with tri level sync on green (BNC terminals). The projector detects automati-
cally where the sync signal is located.
Image 3-8
RGB3S or RG3sB connection
RGB3S or RG3sB selection via the RCU
1. Press digit button 4.
RGB3S or RG3sB selection via the local keypad
1. Press ADJUST key to start up the adjustment mode.
The General Access menu will be displayed. (image 3-9)
2. Use the cursor keys to highlight 4
3. Press ENTER to select the highlighted source.
16 R5976584 BARCO CINE7 26022003
