Barco Baron 908 R9040060 User manual

BARON
908
R9040060
R9040069
OWNER'S MANUAL

BARCO PROJECTION SYSTEMS
Art. No. :
R5976419
Date :
15032003
OWNER'S MANUAL
Rev. :
01
BARON
908
R9040060
R9040069

Due to constant research, the information in this manual is subject to change without notice.
Produced by BARCO NV, March 2003.
All rights reserved.
Trademarks are the rights of their respective owners.
BARCO n.v. / Projection Systems
Noordlaan 5
B-8520 Kuurne
Belgium
Tel : [phone]
Fax : [phone]
E-mail : [email protected]
Visite Barco at the web : http://www.barco.com
Printed in Belgium

Table of contents
0 - 1
5976419 BARON 908 04122001
0TABLE OF CONTENTS
SAFETY INSTRUCTIONS ................................................................................................. 1-1
Safety instructions ...................................................................................................................................... 1-1
Notice on safety ............................................................................................................................................................................... 1-1
installation instructions ..................................................................................................................................................................... 1-1
Owner's record ................................................................................................................................................................................ 1-1
Safety indication on the product ...................................................................................................................................................... 1-1
Safety warning................................................................................................................................................................................. 1-2
Federal communication commission (FCC Statement) ..................................................................................................................... 1-2
On safety .......................................................................................................................................................................................... 1-2
Caution on fire hazard ...................................................................................................................................................................... 1-3
On installation ................................................................................................................................................................................... 1-3
On servicing ..................................................................................................................................................................................... 1-3
On cleaning ....................................................................................................................................................................................... 1-3
On repacking .................................................................................................................................................................................... 1-4
On illumination ................................................................................................................................................................................... 1-4
CONNECTIONS ................................................................................................................ 2-1
AC Power .................................................................................................................................................... 2-1
AC Power cord connection ............................................................................................................................................................. 2-1
Power voltage ................................................................................................................................................................................. 2-1
Switching on/off ............................................................................................................................................................................... 2-1
Source connections .................................................................................................................................... 2-2
Input locations ............................................................................................................................................. 2-2
Input facilities .................................................................................................................................................................................... 2-2
Which source to which input ? ........................................................................................................................................................ 2-2
Video input selection ........................................................................................................................................................................ 2-3
RGB Analog source to port 3 ....................................................................................................................... 2-3
Which signal to port 3 ? .................................................................................................................................................................... 2-3
Pin configuration D9 connector of the analog input. ....................................................................................................................... 2-3
Input selection port 3 ........................................................................................................................................................................ 2-3
RGB Analog source with composite sync to port 4/5 ................................................................................... 2-3
Which signal to port 4/5 ? ................................................................................................................................................................. 2-3
RGBS or RGsB input selection ......................................................................................................................................................... 2-3
Component video source to port 4/5 ............................................................................................................ 2-4
Which signal to port 4/5 ? ................................................................................................................................................................. 2-4
Component video input selection ..................................................................................................................................................... 2-4
RGB Analog source with tri level sync to port 4/5 (option) ........................................................................... 2-4
Which signal to port4/5 ? ................................................................................................................................................................. 2-4
RGB3S or RG3sB input selection ..................................................................................................................................................... 2-4
Component video source with tri level sync to port 4/5 (option) .................................................................... 2-4
Which signal to port 4/5 ? ................................................................................................................................................................. 2-4
(R-Y)Y(B-Y)3S or (R-Y)Y3s(B-Y) input selection ......................................................................................................................... 2-4
RS232 Connection ...................................................................................................................................... 2-5
RS232 input and RS232 output of the projector .............................................................................................................................. 2-5
Communication port for communication with peripherals ............................................................................. 2-5
Connecting a RCVDS 05 switcher to the projector ......................................................................................................................... 2-5
GETTING STARTED ......................................................................................................... 3-1
Remote control unit and local keypad ......................................................................................................... 3-1
Battery installation in the RCU .......................................................................................................................................................... 3-1
How to replace the batteries in the RCU ? ...................................................................................................................................... 3-1
Overview of functions ..................................................................................................................................................................... 3-2
Operating the projector ................................................................................................................................ 3-3
Switching on ..................................................................................................................................................................................... 3-3
Start up in operational mode ............................................................................................................................................................. 3-3
Start up in stand-by mode ................................................................................................................................................................ 3-3

Table of contents
0 - 2 5976419 BARON 908 04122001
Stationary image warning ............................................................................................................................ 3-3
RCU Commands to the projector ................................................................................................................. 3-4
Pointing the RCU to the reflective screen ........................................................................................................................................ 3-4
Pointing the RCU towards the IR sensor in the projector ................................................................................................................ 3-4
RCU used in a hardwired configuration .......................................................................................................................................... 3-4
Projector address ........................................................................................................................................ 3-5
Why a projector address ? .............................................................................................................................................................. 3-5
Set up an individual projector address ............................................................................................................................................ 3-5
How to control the projector or projectors ? ................................................................................................................................... 3-5
Common address .............................................................................................................................................................................. 3-5
Before using the RCU ....................................................................................................................................................................... 3-5
Display the projector address on the screen .................................................................................................................................. 3-5
How to program an address into the RCU ? .................................................................................................................................... 3-5
Controlling the projector .............................................................................................................................. 3-6
Input selection modes ....................................................................................................................................................................... 3-6
When the source is selected ........................................................................................................................................................... 3-6
Picture controls ................................................................................................................................................................................. 3-6
Sound controls ................................................................................................................................................................................. 3-7
The pause key .................................................................................................................................................................................. 3-7
The freeze key (only with line multiplier) ......................................................................................................................................... 3-7
ENTERING THE ADJUSTMENT MENUS ........................................................................ 4-1
Adjustment menus ...................................................................................................................................... 4-1
What is available in the adjustment menus ? ................................................................................................................................... 4-1
How to enter the adjustment menus ? ............................................................................................................................................. 4-1
Password protection ........................................................................................................................................................................ 4-1
Entering the password ..................................................................................................................................................................... 4-1
RANDOM ACCESS ADJUSTMENT MODE ...................................................................... 5-1
Random access adjustment mode .............................................................................................................. 5-1
Starting up ......................................................................................................................................................................................... 5-1
Overview flowchart ......................................................................................................................................................................... 5-1
Set up of the selected setup pattern ? ............................................................................................................................................ 5-3
Note: .................................................................................................................................................................................................. 5-3
Internal cross hatch pattern ......................................................................................................................... 5-3
When using the internal pattern ? .................................................................................................................................................... 5-3
Factory preset frequencies ............................................................................................................................................................. 5-4
Picture tuning .............................................................................................................................................. 5-5
Start up the picture tuning ................................................................................................................................................................ 5-5
Color balance .............................................................................................................................................. 5-5
What can be done ? ......................................................................................................................................................................... 5-5
How to select the color balance ? ................................................................................................................................................... 5-5
Fixed color balance .......................................................................................................................................................................... 5-6
Custom color balance ....................................................................................................................................................................... 5-6
Color select ....................................................................................................................................................................................... 5-6
Contrast modulation .................................................................................................................................... 5-7
Why contrast modulation ? ............................................................................................................................................................... 5-7
Important note ................................................................................................................................................................................... 5-8
How to select the contrast modulation ............................................................................................................................................ 5-8
Why contrast equalisation ? ............................................................................................................................................................ 5-8
How to adjust the contrast equalisation ? ....................................................................................................................................... 5-8
Why contrast edge correction ? ...................................................................................................................................................... 5-8
How to adjust the contrast edge correction (Hot spot) .................................................................................................................. 5-9
Note ................................................................................................................................................................................................... 5-9
Sync fast/slow adjustment .......................................................................................................................... 5-9
What can be done ? ......................................................................................................................................................................... 5-9
How to setup the sync function ? ................................................................................................................................................... 5-9
Note ................................................................................................................................................................................................... 5-9
Peaking ..................................................................................................................................................... 5-10
What can be done with peaking ? ................................................................................................................................................. 5-10
How to set up ? .............................................................................................................................................................................. 5-10
Clamp mode: normal/restoration ................................................................................................................. 5-10
What can be done ? ....................................................................................................................................................................... 5-10
How to set up ? .............................................................................................................................................................................. 5-10
Port 2 : video/S-video (optional) .................................................................................................................. 5-11
What can be done ? ........................................................................................................................................................................ 5-11
How to configure port 2 ? ............................................................................................................................................................... 5-11
Line multiplier (optional) ............................................................................................................................. 5-11

Table of contents
0 - 3
5976419 BARON 908 04122001
What can be done ? ........................................................................................................................................................................ 5-11
How to activate ? ............................................................................................................................................................................ 5-11
Motion processing: on/off ........................................................................................................................... 5-12
Why motion processing ? ............................................................................................................................................................... 5-12
How to activate ? ........................................................................................................................................................................... 5-12
Output mode .............................................................................................................................................. 5-12
What can be done ? ....................................................................................................................................................................... 5-12
How to select a new scan rate ? .................................................................................................................................................. 5-12
Video equalizing ......................................................................................................................................... 5-13
What can be done ? ....................................................................................................................................................................... 5-13
How to select video equalizing ? ................................................................................................................................................... 5-13
How to adjust the video equalizing ? ............................................................................................................................................. 5-13
Noise reduction .......................................................................................................................................... 5-13
What can be done ? ....................................................................................................................................................................... 5-13
How to select and adjust the noise reduction ? ............................................................................................................................ 5-13
Contrast enhancement ............................................................................................................................... 5-14
What can be done ? ....................................................................................................................................................................... 5-14
How to select and adjust the contrast enhancement ? ................................................................................................................ 5-14
Split screen: on/off ..................................................................................................................................... 5-14
What can be done ? ....................................................................................................................................................................... 5-14
How to activate the split screen function ? ................................................................................................................................... 5-14
Advanced settings ......................................................................................................................................5-14
How to select the advanced settings ? ......................................................................................................................................... 5-14
Time base correction ...................................................................................................................................................................... 5-15
Luminace delay ............................................................................................................................................................................... 5-15
Vertical sync reference: direkt/indirekt .......................................................................................................................................... 5-15
Clamp gating: on/off ....................................................................................................................................................................... 5-16
Limo pro options ............................................................................................................................................................................. 5-16
Coring .............................................................................................................................................................................................. 5-17
LTI .................................................................................................................................................................................................... 5-17
CTI ................................................................................................................................................................................................... 5-18
Factory preset ................................................................................................................................................................................ 5-18
Geometry adjustments ............................................................................................................................... 5-19
What can be done ? ....................................................................................................................................................................... 5-19
Start up ............................................................................................................................................................................................ 5-19
Important ......................................................................................................................................................................................... 5-19
Green convergence: on/off .......................................................................................................................... 5-19
Why switching your green convergence on or off ? ................................................................................................................... 5-19
How to switch off the green convergence ? ................................................................................................................................ 5-19
Horizontal phase adjustment ...................................................................................................................... 5-20
Start up ............................................................................................................................................................................................ 5-20
Note ................................................................................................................................................................................................. 5-20
How to adjust ? .............................................................................................................................................................................. 5-20
Raster shift adjustment .............................................................................................................................. 5-20
What has to be done ? ................................................................................................................................................................... 5-20
Caution ............................................................................................................................................................................................ 5-20
Start up ............................................................................................................................................................................................ 5-20
Note ................................................................................................................................................................................................. 5-20
Warning ........................................................................................................................................................................................... 5-20
Left-right (east-west) adjustments ..............................................................................................................5-21
What can be adjusted ? ................................................................................................................................................................. 5-21
Start up ............................................................................................................................................................................................ 5-21
Note ................................................................................................................................................................................................. 5-21
Which adjustment can be executed ? ........................................................................................................................................... 5-22
How to enter an alignment ? .......................................................................................................................................................... 5-22
Warning ........................................................................................................................................................................................... 5-22
Fine side correction.................................................................................................................................... 5-24
What can be done ? ....................................................................................................................................................................... 5-24
Top-bottom (north-south) adjustments ........................................................................................................ 5-24
What can be adjusted ? ................................................................................................................................................................. 5-24
Start up ............................................................................................................................................................................................ 5-24
Note ................................................................................................................................................................................................. 5-24
Which adjustment can be executed ? ........................................................................................................................................... 5-24
How to enter an alignment ? .......................................................................................................................................................... 5-25
Size adjustment .........................................................................................................................................5-26
What can be done ? ....................................................................................................................................................................... 5-26
Start up ............................................................................................................................................................................................ 5-26
Hint .................................................................................................................................................................................................. 5-26
Fine horizontal size adjustment .................................................................................................................. 5-27
What can be done ? ....................................................................................................................................................................... 5-27
Start up ............................................................................................................................................................................................ 5-27

Table of contents
0 - 4 5976419 BARON 908 04122001
Linearity adjustment ................................................................................................................................... 5-27
What can be done ? ....................................................................................................................................................................... 5-27
Start up ............................................................................................................................................................................................ 5-27
Coarse linearity ..........................................................................................................................................5-28
Start up ............................................................................................................................................................................................ 5-28
Fine vertical linearity ..................................................................................................................................5-28
Start up ............................................................................................................................................................................................ 5-28
Fine horizontal linearity ..............................................................................................................................5-28
Start up ............................................................................................................................................................................................ 5-28
Blanking adjustments .................................................................................................................................5-29
What can be done with blanking ? ................................................................................................................................................. 5-29
Start up ............................................................................................................................................................................................ 5-29
How to adjust the blanking ? .......................................................................................................................................................... 5-29
Convergence adjustment ............................................................................................................................5-31
What has to be done ? ................................................................................................................................................................... 5-31
Adjustment order ............................................................................................................................................................................ 5-31
Start up ............................................................................................................................................................................................ 5-31
Coarse convergence adjustment ................................................................................................................. 5-31
What has to be done ? ................................................................................................................................................................... 5-31
Start up ............................................................................................................................................................................................ 5-31
Fine convergence adjustment ..................................................................................................................... 5-32
What can be done ? ....................................................................................................................................................................... 5-32
Start up ............................................................................................................................................................................................ 5-32
Focusing ....................................................................................................................................................5-33
What can be done ? ....................................................................................................................................................................... 5-33
Start up ............................................................................................................................................................................................ 5-33
Midpoint focusing ............................................................................................................................................................................ 5-33
Top image focusing ........................................................................................................................................................................ 5-33
Bottom image focusing ................................................................................................................................................................... 5-34
Digital adjustment ............................................................................................................................................................................ 5-34
Blue on source ............................................................................................................................................................................... 5-34
Color select ................................................................................................................................................ 5-35
What can be done ? ....................................................................................................................................................................... 5-35
Start up ............................................................................................................................................................................................ 5-35
Driver voltage (optional) .............................................................................................................................. 5-36
When available ? ............................................................................................................................................................................ 5-36
What can be done ? ....................................................................................................................................................................... 5-36
Start up ............................................................................................................................................................................................ 5-36
SERVICE MODE ............................................................................................................... 6-1
Service mode .............................................................................................................................................. 6-1
Start up .............................................................................................................................................................................................. 6-1
Overview flowchart ......................................................................................................................................................................... 6-1
Projector set-up .......................................................................................................................................... 6-2
What can be done ? ......................................................................................................................................................................... 6-2
Start up the projector set-up ............................................................................................................................................................ 6-2
Identification ................................................................................................................................................ 6-2
What can be seen ? ......................................................................................................................................................................... 6-2
How to start up ? .............................................................................................................................................................................. 6-3
Total run time .............................................................................................................................................. 6-3
What can be displayed ? .................................................................................................................................................................. 6-3
Run time note .................................................................................................................................................................................... 6-3
How to start up ? .............................................................................................................................................................................. 6-3
How to reset the CRT run times ? .................................................................................................................................................... 6-3
Change password ....................................................................................................................................... 6-4
What can be done ? ......................................................................................................................................................................... 6-4
Note ................................................................................................................................................................................................... 6-4
How to select ? ................................................................................................................................................................................ 6-4
How to enter a new password ? .................................................................................................................................................... 6-4
Change projector address ........................................................................................................................... 6-4
What can be done ? ......................................................................................................................................................................... 6-4
How to change that address ? ........................................................................................................................................................ 6-4
Change baudrate ......................................................................................................................................... 6-5
What can be set up ? ....................................................................................................................................................................... 6-5
How to set up ? ................................................................................................................................................................................ 6-5
Projector warm up ....................................................................................................................................... 6-5
What can be done ? ......................................................................................................................................................................... 6-5
How to select ? ................................................................................................................................................................................ 6-5

Table of contents
0 - 5
5976419 BARON 908 04122001
Warm up on/off............................................................................................................................................ 6-6
What can be done ? ......................................................................................................................................................................... 6-6
How to install ? ................................................................................................................................................................................. 6-6
Warm up frequency ..................................................................................................................................... 6-6
What can be done ? ......................................................................................................................................................................... 6-6
How to install a warm up frequency ? ............................................................................................................................................ 6-6
Projector warm up time ............................................................................................................................... 6-6
What can be done ? ......................................................................................................................................................................... 6-6
How to program the warm up time ? ............................................................................................................................................... 6-6
Power up mode: operating/stand by ............................................................................................................ 6-7
What can be done ? ......................................................................................................................................................................... 6-7
How to change the mode ? .............................................................................................................................................................. 6-7
Common address ........................................................................................................................................ 6-7
What can be done ? ......................................................................................................................................................................... 6-7
Why 2 different common address ? ................................................................................................................................................ 6-7
How to change the common address ? .......................................................................................................................................... 6-7
Memory management ................................................................................................................................. 6-8
What can be done ? ......................................................................................................................................................................... 6-8
How to select ? ................................................................................................................................................................................ 6-8
Copy a block ............................................................................................................................................... 6-8
What can be done ? ......................................................................................................................................................................... 6-8
How to copy ? .................................................................................................................................................................................. 6-8
Copy soft edge block .................................................................................................................................. 6-9
What can be done ? ......................................................................................................................................................................... 6-9
How to copy the softedge settings ? .............................................................................................................................................. 6-9
Deletion of blocks ....................................................................................................................................... 6-9
What can be done ? ......................................................................................................................................................................... 6-9
Deleting a block .......................................................................................................................................... 6-9
What can be done ? ......................................................................................................................................................................... 6-9
How to delete a block ? .................................................................................................................................................................... 6-9
Deleting all blocks ......................................................................................................................................6-10
What can be done ? ....................................................................................................................................................................... 6-10
How to delete all blocks ? .............................................................................................................................................................. 6-10
Set to midposition ...................................................................................................................................... 6-10
What can be done ? ....................................................................................................................................................................... 6-10
How to start up ? ............................................................................................................................................................................ 6-10
R&B convergence midposition .................................................................................................................... 6-10
What can be done ? ....................................................................................................................................................................... 6-10
How to set convergence to midposition ? ...................................................................................................................................... 6-11
Undo R&B convergence midposition ........................................................................................................... 6-11
What can be done ? ........................................................................................................................................................................ 6-11
How to undo ? ................................................................................................................................................................................. 6-11
Green convergence midposition .................................................................................................................. 6-11
What can be done ? ........................................................................................................................................................................ 6-11
How to set green settings to midposition ? .................................................................................................................................... 6-11
Undo green convergence midposition ......................................................................................................... 6-12
What can be done ? ....................................................................................................................................................................... 6-12
How to undo ? ................................................................................................................................................................................ 6-12
Undo focus to midposition .......................................................................................................................... 6-12
What can be done ? ....................................................................................................................................................................... 6-12
How to undo the focus to midposition ? ........................................................................................................................................ 6-12
Focus to midposition .................................................................................................................................. 6-12
What can be done ? ....................................................................................................................................................................... 6-12
How to set the focus settings to midposition ? ............................................................................................................................. 6-12
East-west to midposition ........................................................................................................................... 6-13
What can be done ? ....................................................................................................................................................................... 6-13
How to set the east-west settings to midposition ? ...................................................................................................................... 6-13
Undo east-west to midposition ................................................................................................................... 6-13
What can be done ? ....................................................................................................................................................................... 6-13
How to undo the east-west to midposition ? ................................................................................................................................. 6-13
North-south to midposition ......................................................................................................................... 6-13
What can be done ? ....................................................................................................................................................................... 6-13
How to set the north-south settings to midposition ? .................................................................................................................... 6-14
Undo north-south to midposition ................................................................................................................. 6-14
What can be done ? ....................................................................................................................................................................... 6-14
How to Undo the north-south to midposition ? .............................................................................................................................. 6-14
Digital vertical linearity to midposition ......................................................................................................... 6-14
What can be done ? ....................................................................................................................................................................... 6-14
How to set the digital vertical linearity to midposition ? ................................................................................................................. 6-14

Table of contents
0 - 6 5976419 BARON 908 04122001
Undo digital vertical linearity to midposition ................................................................................................6-15
What can be done ? ....................................................................................................................................................................... 6-15
How to undo the digital vertical linearity to midposition ? .............................................................................................................. 6-15
Digital horizontal linearity to midposition ....................................................................................................6-15
What can be done ? ....................................................................................................................................................................... 6-15
How to set the digital horizontal linearity to midposition ? ............................................................................................................. 6-15
Undo digital horizontal linearity to midposition ............................................................................................ 6-15
What can be done ? ....................................................................................................................................................................... 6-15
How to undo the digital vertical linearity to midposition ? .............................................................................................................. 6-16
Astigmatism midposition ............................................................................................................................ 6-16
What can be done ? ....................................................................................................................................................................... 6-16
How to set the astigmatism to midposition ? .................................................................................................................................. 6-16
Undo astigmatism to midposition .............................................................................................................. 6-16
What can be done ? ....................................................................................................................................................................... 6-16
How to undo the astigmatism settings to midposition ? ................................................................................................................. 6-16
All settings to midposition .......................................................................................................................... 6-17
What can be done ? ....................................................................................................................................................................... 6-17
How to set to midposition ? ............................................................................................................................................................ 6-17
Undo all settings to midposition .................................................................................................................6-17
What can be done ? ....................................................................................................................................................................... 6-17
How to cancel 'set to midposition' ? ............................................................................................................................................... 6-17
Common settings .......................................................................................................................................6-18
What can be done ? ....................................................................................................................................................................... 6-18
How to select ? .............................................................................................................................................................................. 6-18
Dynaminc astigmatism ..............................................................................................................................6-18
What can be done ? ....................................................................................................................................................................... 6-18
Start up ............................................................................................................................................................................................ 6-19
How to adjust ? .............................................................................................................................................................................. 6-19
Focusing on current source .......................................................................................................................................................... 6-19
Gamma corrections ....................................................................................................................................6-20
Gamma corrections warning ? ...................................................................................................................................................... 6-20
Start up ............................................................................................................................................................................................ 6-20
CRT run in cycle ........................................................................................................................................6-20
What can be done ? ....................................................................................................................................................................... 6-20
How to select CRT run in cycle ? .................................................................................................................................................. 6-20
CRT drive mode ..........................................................................................................................................6-21
What can be done ? ....................................................................................................................................................................... 6-21
Available drive modes .................................................................................................................................................................... 6-21
How to change the drive mode ? ................................................................................................................................................... 6-21
CRT drive mode warning ................................................................................................................................................................ 6-21
Memory banks ...........................................................................................................................................6-21
What can be done ? ....................................................................................................................................................................... 6-21
How to select memory banks ? ..................................................................................................................................................... 6-21
How to create a new memory bank ? ........................................................................................................................................... 6-22
How to recall a specific memorybank for the actual source ? ..................................................................................................... 6-22
Flyback turnover point ................................................................................................................................6-22
What can be done ? ....................................................................................................................................................................... 6-22
Set Up of the flyback turnover point .............................................................................................................................................. 6-22
Menu position ............................................................................................................................................ 6-23
What can be done ? ....................................................................................................................................................................... 6-23
How to change the position ........................................................................................................................................................... 6-23
Option 1 .....................................................................................................................................................6-23
What can be done ? ....................................................................................................................................................................... 6-23
How to change option 1 ................................................................................................................................................................. 6-23
Real time clock .......................................................................................................................................... 6-23
What can be done ? ....................................................................................................................................................................... 6-23
How to change real time clock ....................................................................................................................................................... 6-23
Voltage diagnostics .................................................................................................................................... 6-24
What can be seen ? ....................................................................................................................................................................... 6-24
How to start up ? ............................................................................................................................................................................ 6-24
How to change the position ? ........................................................................................................................................................ 6-24
I2C Diagnostics ..........................................................................................................................................6-24
What can be seen ? ....................................................................................................................................................................... 6-24
How to select ? .............................................................................................................................................................................. 6-24
Projector diagnostics .................................................................................................................................6-25
What can be seen ? ....................................................................................................................................................................... 6-25
How to display the projector diagnostics ? ................................................................................................................................... 6-25

Table of contents
0 - 7
5976419 BARON 908 04122001
MESSAGES, WARNINGS AND FAILURES ...................................................................... 7-1
SOUND MODULE ............................................................................................................. 3-1
Sound connections ..................................................................................................................................... 3-1
Audio input ........................................................................................................................................................................................ 3-1
Connecting speaker wires ............................................................................................................................................................... 3-1
Speaker selection switch ................................................................................................................................................................. 3-1
Sound control with the RCU or the local keyboard ....................................................................................... 3-1
INDEX .................................................................................................................................. I-1

Table of contents
0 - 8 5976419 BARON 908 04122001

Safety instructions
1 - 1
5976419 BARON 908 04122001
1SAFETY INSTRUCTIONS
Safety instructions
Notice on safety
This equipment is built in accordance with the requirements of the international safety standards EN60950, UL 1950 and CSA C22.2
No.950, which are the safety standards of information technology equipment including electrical business equipment.
These safety standards impose important requirements on the use of safety critical components, materials and isolation, in order
to protect the user or operator against risk of electric shock and energy hazard, and having access to live parts.
Safety standards also impose limits to the internal and external temperature rises, radiation levels, mechanical stability and strength,
enclosure construction and protection against the risk of fire.
Simulated single fault condition testing ensures the safety of the equipment to the user even when the equipment's normal operation
fails.
Installation instructions
Before operating this equipment please read this manual thoroughly, and retain it for future reference.
Installation and preliminary adjustments should be performed by qualified BARCO personnel or by authorized BARCO service dealers.
Owner's record
The part number and serial number are located at the back side of the projector. Record these numbers in the spaces provided below.
Refer to them whenever you call upon your BARCO dealer regarding this product.
PART NUMBER :
SER. NUMBER :
DEALER :
Safety indication on the product
image 1.1
Safety indication
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION/ TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
The lightning flash with an arrowhead within a triangle
is intended to tell the user that parts inside this product
may cause risk of electrical shock to persons.
The exclamation point within a triangle is intended to tell
the user that important operating and/or servicing instructions
are included in the technical documentation for this equipment.
CAUTION
!
!

Safety instructions
1 - 2 5976419 BARON 908 04122001
Safety warning
TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE !
Federal communication commission (FCC Statement)
This equipment has been tested and found to comply with the limits of a class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own
expense.
Note :
The use of shielded cables is required to comply within the limits of Part 15 of FCC rules and EN55022.
* All the safety and operating instructions should be read before using this unit.
* The safety and operating instructions manual should be retained for future reference.
* All warnings on the equipment and in the documentation manuals should be adhered to.
* All instructions for operating and use of this equipment must be followed precisely.
On safety
1. This product should be operated from an AC power source.
Power input is autoranging from 90 V to 230V.
2. All equipment in the system is equipped with a 3-wire grounding plug, a plug having a third (grounding) pin. This plug will only
fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not defeat the purpose of the grounding-type plug.
WARNING FOR THE CUSTOMERS: THIS APPARATUS MUST BE GROUNDED (EARTHED) via the supplied 3 conductor AC power
cable.
If the supplied power cable is not the correct one, consult your dealer.
The wires of the mains lead are colored in accordance with the following code.
3. Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on the cord.
To disconnect the cord, pull it out by the plug. Never pull the cord itself.
4. If an extension cord is used with this product, make sure that the total of the ampere ratings on the products plugged into the
extension cord does not exceed the extension cord ampere rating.
5. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out
parts that could result in a risk of fire or electrical shock.
Never spill liquid of any kind on the product. Should any liquid or solid object fall into the cabinet, unplug the set and have it checked
by qualified service personnel before resuming operations.
6. Lightning - For added protection for this video product during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet. This will prevent damage to the projector due to lightning and AC power-line surges.
image 1.2
Power cord plugs
CEE 7 Plug
Green and yellow : Ground
Blue : Neutral
Brown : Line
ANSI 73.11 Plug
Green and yellow : Ground
White : Neutral
Black : Line

Safety instructions
1 - 3
5976419 BARON 908 04122001
Caution on fire hazard
DO NOT PLACE FLAMMABLE OR COMBUSTIBLE MATERIALS NEAR PROJECTOR !
BARCO large screen projection products are designed and manufactured to meet the most stringent safety regulations. This projector
radiates heat on its external surfaces and from ventilation ducts during normal operation, which is both normal and safe.
Explosing flammable or combustible materials into close proximity of this projector could result in the spontaneous ignition of that
material, resulting in a fire. For this reason, it is absolutely necessary to leave an "exclusion zone" around all external surfaces of
the projector whereby no flammable or combustible materials are present. The exclusion zone must be not less that 10 cm (4") for
Barco Retro Projectors. Do not cover the projector with any material while the projector is in operation.
Keep flammable and combustible materials away from the projector at all times. Mount the projector is a well ventilated area away
from sources of ignition and out of direct sun light. Never expose the projector to rain or excessive moisture. In the event of fire,
use sand, CO2, or dry powder fire extinguishers; never use water on anelectrical fire.
Always have service performed on this projector by authorized BARCO service personnel. Always insist on genuine BARCO
replacement parts. Never use non-BARCO replacement parts as they may degrade the safety of this projector.
On installation
1. Do not place this equipment on an unstable cart, stand, or table. The product may fall, causing serious damage to it.
2. Do not use this equipment near water.
3. Slots and openings in the cabinet and the back or bottom are provided for ventilation; to ensure reliable operation of the product
and to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator
or heat register.
The projector should not be placed in a built-in installation or enclosure unless proper ventilation is provided.
4. Do not block the projector cooling fans or free air movement under and around the projector. Loose papers or other objects
may not be nearer to the projector than 4" on any side.
On servicing
Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage potentials
and risk of electric shock!
Refer all servicing to qualified service personnel.
Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the equipment.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally when the operating instructions are followed.
Note : Adjust only those controls that are covered by the operating instructions since improper adjustment of the other controls
may result in damage and will often require extensive work by a qualified technician to restore the product to normal operation.
e. If the product has been dropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance, indicating a need for service.
Replacement parts - When replacement parts are required, be sure the service technician has used original BARCO replacement
parts or authorized replacement parts which have the same characteristics as the BARCO original part. Unauthorized substitutions
may result in degraded performance and reliability, fire, electric shock or other hazards. Unauthorized substitutions may void
warranty.
Safety check - Upon completion of any service or repairs to this projector, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
On cleaning
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
-To keep the cabinet looking brand-new, periodically clean it with a soft cloth. Stubborn stains may be removed with a cloth lightly
dampened with mild detergent solution. Never use strong solvents, such as thinner or benzine, or abrasive cleaners, since these
will damage the cabinet.
- To ensure the highest optical performance and resolution, the projection lenses are specially treated with an anti-reflective coating,
therefore, avoid touching the lens. To remove dust on the lens, use a soft dry cloth. Do not use a damp cloth, detergent solution,
or thinner.

Safety instructions
1 - 4 5976419 BARON 908 04122001
On repacking
Save the original shipping carton and packing material; they will come in handy if you ever have to ship your equipment. For maximum
protection, repack your set as it was originally packed at the factory.
On illumination
In order to obtain the best quality for the projected image, it is essential that the ambient light which is allowed to fall on the screen
be kept to an absolute minimum.
When installing the projector and screen, care must be taken to avoid exposure to ambient light directly on the screen. Avoid adverse
illumination on the screen from direct sunlight or fluorescent lighting fixtures.
The use of controlled ambient lighting, such as incandescent spot light or a dimmer, is recommended for proper room illumination.
Where possible, care should also be taken to ensure that the floors and walls of the room in which the projector is to be installed are
non-reflecting, dark surfaces. Brighter surfaces will tend to reflect and diffuse the ambient light and hence reduce the contrast of
the projected image on the screen.

Connections
2 - 1
5976419 BARON 908 15032003
2CONNECTIONS
AC Power
AC Power cord connection
Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector
at the front side of the electronic block.
Power voltage
The power voltage is autoranging between 100V (-10%) and 240V (+6%).
Switching on/off
The projector is switched ON and OFF using the power (mains)switch.
Pressed : ON
Not pressed : OFF
Stand by indication lamp :
No light up : projector switched off
Green color : projector in Operational mode
Red color : projector is in Standby mode.
When switching on with the power switch, the projector can start now in :
1 Operational mode (picture displayed)
2 Stand by mode
The way of start up depends on the 'Power up' setting in the service mode.
COMM. PORT
REMOTE
REMOTE
IR
IR
RS 232 OUT
RS 232 OUT
RS 232 IN
RGB
Comp / H-Sync V-Sync
RGB
Comp / H-Sync
DEFOCUS
75 Ohm
OFF - ON
75 Ohm
ON - OFF
75 Ohm
OFF - ON
75 Ohm
ON - OFF
red: standby
green: operation
red: standby
green: operation
DEFOCUS
X-POS Y-POS
X-POSY-POS
V-Sync
RS 232 IN
PORT 3
COMM. PORTPORT 3
PORT 4 / 5
PORT 4 / 5
PORT 2
PORT 2
PORT 1 PROJECTOR MODE
PROJECTOR MODE
PORT 1
ONOFF
ONOFF
POWER MAINS
800 periphals
800 periphals
This device complies with part 15 of the FCC rules.
Operation is subject to following two conditions (1).
This device may not cause harmful interference,
and (2) this device must accept any interference that
may cause undesired operation.
See installation instructions before connecting to the supply.
Voir la notice d' installation avont de raccorder au réseau.
See installation instructions before connecting to the supply.
Voir la notice d' installation avont de raccorder au réseau.
This device complies with part 15 of the FCC rules.
Operation is subject to following two conditions (1).
This device may not cause harmful interference,
and (2) this device must accept any interference that
may cause undesired operation.
image 2.1
AC Power cord connection
POWER MAINS
POWER MAINS COMM. PORT
REMOTE
REMOTE
IR
IR
RS 232 OUT
RS 232 OUT
RS 232 IN
RGB
Comp / H-Sync V-Sync
RGB
Comp / H-Sync
75 Ohm
OFF - ON
75 Ohm
ON - OFF
75 Ohm
OFF - ON
75 Ohm
ON - OFF
red: standby
green: operation
red: standby
green: operation
V-Sync
RS 232 IN
PORT 3
COMM. PORTPORT 3
PORT 4 / 5
PORT 4 / 5
PORT 2
PORT 2
PORT 1 PROJECTOR MODE
PROJECTOR MODE
PORT 1
ONOFF
ON
POWER MAINS
800 periphals
800 periphals
This device complies with part 15 of the FCC rules.
Operation is subject to following two conditions (1).
This device may not cause harmful interference,
and (2) this device must accept any interference that
may cause undesired operation.
See installation instructions before connecting to the supply.
Voir la notice d' installation avont de raccorder au réseau.
See installation instructions before connecting to the supply.
Voir la notice d' installation avont de raccorder au réseau.
This device complies with part 15 of the FCC rules.
Operation is subject to following two conditions (1).
This device may not cause harmful interference,
and (2) this device must accept any interference that
may cause undesired operation.
image 2.2
Power switch
OFF
DEFOCUS
DEFOCUS
X-POS Y-POS
X-POSY-POS

Connections
2 - 2 5976419 BARON 908 15032003
Source connections
Input locations
Input facilities
The following source types can be connected to the inputs:
- Composite video (Optional) (1)
- S-Video (Optional) (1)
- RGBS or RGsB
- RGB3S or RG3sB
- (R-Y)Y(B-Y)S or (R-Y)Ys(B-Y) [component input]
- (R-Y)Y(B-Y)3S or (R-Y)Y3s(B-Y) [component input]
(1) Optional module: decoder + Limo Pro to select Composite Video or S-Video.
Which source to which input ?
This table (image 2.4) gives an overview of the relation between source type, input terminals and selection key on the RCU.
POWER MAINS COMM. PORT
REMOTE
REMOTE
IR
IR
RS 232 OUT
RS 232 OUT
RS 232 IN
RGB
Comp / H-Sync V-Sync
RGB
Comp / H-Sync
75 Ohm
OFF - ON
75 Ohm
ON - OFF
75 Ohm
OFF - ON
75 Ohm
ON - OFF
red: standby
green: operation
red: standby
green: operation
V-Sync
RS 232 IN
COMM. PORTPORT 3
PORT 4 / 5
PORT 4 / 5
PORT 2
PORT 2
PROJECTOR MODE
PROJECTOR MODE
PORT 1
ONOFF
ONOFF
POWER MAINS
800 periphals
800 periphals
This device complies with part 15 of the FCC rules.
Operation is subject to following two conditions (1).
This device may not cause harmful interference,
and (2) this device must accept any interference that
may cause undesired operation.
See installation instructions before connecting to the supply.
Voir la notice d' installation avont de raccorder au réseau.
See installation instructions before connecting to the supply.
Voir la notice d' installation avont de raccorder au réseau.
This device complies with part 15 of the FCC rules.
Operation is subject to following two conditions (1).
This device may not cause harmful interference,
and (2) this device must accept any interference that
may cause undesired operation.
image 2.3
Inputfacilities
PORT 3 PORT 1
DEFOCUS
DEFOCUS
X-POS Y-POS
X-POSY-POS
Port #
1
2
3
4/5
4/5
4/5
4/5
Projector input
For future expansion
For future expansion
RGB
2
RGB
2
Component video
3
RGB with tri level sync
4
(Optional)
Component video with tri level sync
5
(Optional)
Press RCU digit buttons
-
-
3
4 or 5
6
7
8
image 6.2
Input port, source type, RCU key table
2 Input signal : R, G and B with automatic sync detection between seperate sync (separate composite sync
or with separate hor and vert. sync) or sync on green (composite sync).
3 Input signal : R-Y,Y and B-Y with separate composite sync or with separate hor and vert. sync or with
composite sync onY.
4 Input signal : R, G and B with separate tri level sync or with tri level sync on green.
5 Input signal : R-Y,Y and B-Y with separate tri level sync or with composite tri level sync.
* Video or S-Video : switchable in the picture tuning menu.

Connections
2 - 3
5976419 BARON 908 15032003
RGB Analog source to port 3
Which signal to port 3 ?
Connect your RGB source with sync on green, composite or separate sync via an interface to Port 3.
Always use an interface (e.g. Barco Magik Interface R9828120) when a computer and local monitor have to be connected to the
projector as the signal cable coming from the computer is limited to 60 cm due to interferences.
The RGB analog input accepts only sources with a horizontal frequency of 32 kHz and higher.
The Baron is installed with a decoder + Limo Pro to connect a source with a horizontal frequency lower than 32 kHz.
Pin configuration D9 connector of the analog input.
1 Not connected 4GREEN 7 Ground RGBS
2 Ground RGBS 5 BLUE 8 Hor/comp. sync
3RED 6 Ground RGBS 9 Vert. sync
Input selection port 3
With the RCU, press digit button 3
RGB Analog source with composite sync to port 4/5
Which signal to port 4/5 ?
RGB analog input terminals with separate H and V sync inputs, composite sync input or with sync on green (BNC terminals). The
projector detects automatically where the sync signal is located.
Always use an interface (e.g. Barco Magik Interface R9828120) when a computer and local monitor have to be connected to the
projector as the signal cable coming from the computer is limited to 60 cm due to interferences.
The RGB analog input accepts only sources with a horizontal frequency of 32 kHz and higher.
The Baron is installed with a decoder + Limo Pro to connect a source with a horizontal frequency lower than 32 kHz.
RGBS or RGsB input selection
With the RCU, press digit button 4 or 5.
4 when sync on green.
5 when separate sync
Computer
Port on projector
Magik Interface
(R9828120)
to computer
to monitor
PORT 3
image 2.8
Port 3
Computer
Port on projector
Magik Interface
(R9828120)
to computer
to monitor
RGB
Comp / H-Sync V-Sync
PORT 4 / 5
image 2.9
Port 4/5

Connections
2 - 4 5976419 BARON 908 15032003
Component video source to port 4/5
Which signal to port 4/5 ?
(R-Y)Y(B-Y) analog input terminals with sync input or with sync on the luminance (Y) input (BNC terminals). The projector detects
automatically where the sync signal is located.
Always use an interface (e.g. Barco Magik Interface R9828120) when a computer and local monitor have to be connected to the
projector as the signal cable coming from the computer is limited to 60 cm due to interferences.
Component video input selection
With the RCU, press digit button 6
RGB Analog source with tri level sync to port 4/5 (option)
Which signal to port4/5 ?
RGB analog input terminals with tri level sync input or with tri level sync on green (BNC terminals). The projector detects automatically
where the sync signal is located.
This feature requires a optional tri level sync Module (Order number: R9828040).
RGB3S or RG3sB input selection
With the RCU, press digit button 7
Component video source with tri level sync to port 4/5 (option)
Which signal to port 4/5 ?
Component Video with Tri level sync input can be connected to the projector via Port 4/5. The projector detects automatically where
the sync signal is located.
This feature requires a optional tri level sync module (Order number: R9828040).
(R-Y)Y(B-Y)3S or (R-Y)Y3s(B-Y) input selection
With the RCU, press digit button 8.
