Barco UDM W22 User manual

Download Product Manual
Product manuals and documentation are available online at www.barco.com/td/R9009049
Registration may be required; follow the instructions given on the website.
IMPORTANT!
Read Installation Instructions before connecting equipment to the mains power supply.
UDM
Quick reference guide
Button backlight status
BUTTON COLOR STATUS DESCRIPTION
Projector starts up (Booting)Blinking WHITE
Projector is in StandbySolid WHITE
Blinking RED Error condition
Blinking BLUE Projectorgoes to ON mode
Projector is ON
Power button
Solid BLUE
O Projector not in power ON state
Solid WHITE Shutter is open
Shutter is closedSolid RED
Shutter button
1Menu Navigation
2Menu Selection
3Open Menu
4Menu Back
5Power On/O
6OSD On/O
7Input Selection
8Shutter Open/Close
9Test Patterns
10 Lens Menu
11 LCD Panel
10 9 8 7
1 2 3 4 5 6
Local keypad
11

- 2 -
1Button pressed indicator
2Shutter Open
3Shutter Close
4LCD panel On/O
5OSD On/O
6Lens Zoom
7Lens Shift
8MenuOpen/Close
9Menu Selection, OK button
10 Menu Navigation
11 Input Selection
12 Address button
13 Numeric buttons
14 Backspace (when entering values)
15 XLR connector
16 Decimal mark (when entering values)
17 Macro button
18 MenuBack
19 Defaultbutton
20 Lens Focus
21 Color menu
22 Test Patterns
23 Power On
24 Power O
25 3.5 mm jack
26 RCU On/O
25 26
1
2
3
4
5
6
7
8
9
10
11
12
13
15
24
23
22
21
20
19
18
17
14 16
RCU buttons
RCU batteries
- Two AA size batteries. Use alkaline batteries for optimum range and life time.
- Replacing batteries will reset the broadcast address of the RCU to its default value ’0’.
- Replacing batteries switches on the RCU automatically.

1. Place the primary lens lock in “unlock” position. Handle (ref. 1) towards electrical socket (ref 3).
2. If present, remove the plastic protection cover from the lens holder opening.
3. Check if the secondary lens lock stands in the “ulock” position (ref 2).
4. Gently insert the lens. Ensure the lens connector matches the electrical socket on
the lens holder.
5. Insert the lens until the connector seats into the socket.
- The secondary lens lock (ref. 2) makes an audible clicking sound when latching.
- Do not release the lens holder by sliding the primary lens lock handle into the
“locked” position.
6. Check if the lens touches the front plate of the Lens Holder.
7. Check if the lens is really secured by trying to pull the lens out of the lens holder.
Start up
1. Power on. Turn the mains switch to on ( I ).
- Startup sequence starts. Backlight of the Power on / o button flashes WHITE.
- When startup sequence is finalized the Power on / o button will be lit WHITE.
2. Press the Power on / o button.
- The backlight of the Power on / o button changes from WHITE to BLUE.
- local LCD displays a startup screen.
Connect power
Ensure that the power is properly connected to the power input.
(120-180V / 200-240V, 60 - 50Hz).
Install Lens !! ONLY USE TLD+ Zoom Lenses !!
2
1
1
2 3 2
1

2. Orientation of the unit is set as standard in table front projection mode.
Change the projector set up in the INSTALLATION > ORIENTATION menu.
3. For Advanced adustments like Warping, Light management, etc. see projector User Guide.
1. Adjust the lens settings by pressing the lens menu button on the keypad or via the zoom,
shift and focus buttons on the RCU.
1. Press the Power on/o button for three seconds.
2. Wait until the after-cooling cycle is finished (approximately 5 minutes).
3. Turn the mains switch to o (’0’).
4. Unplug the power cord from the projector.
Adjust
Switch o
Precautions
- Remove the lens before transporting the projector.
- Switch the projector to standby mode and wait until the after-cooling
cycle is finished before switching o the main power.
- Ensure the projector is operating with clean filters.
- Do not block the ventilation in and outlets of the projector and chiller
(if used).
- External laser light can cause severe damage to the DMD. This damage
is not covered by warranty.
1 2 3
4
3 sec 5 min
Please allow the projector to cool down properly as this will positively impact the lifetime
of its components.
Note

Connect and select source
1. Connect available sources to the appropriate input ports.
2. Select connected source:
- Select LED (1) = GREEN -> Port configured as input. Image appears on the screen
- Select LED (1) = Blinking GREEN -> Bidirectional port configured as output/loopthrough
- Sync LED (2) = YELLOW -> sync/signal is present
Sync
Select
2
1
SEL SEL SEL SEL SEL SEL SEL
SDI IN SDI IN/OUT
SEL
SYNC SYNC
AB CD
SYNC SYNC SYNC SYNC
DP HDBT 2
SYNC
HDMI HDBT 1
SYNC
3G/12G 3G 3G 3G
1Quad SDI channel A: 3G/12G input
2Quad SDI channel B: 3G input
3Quad SDI channel C: 3G input or 3G/12G output
4Quad SDI channel D: 3G input/output
5DisplayPort 1.2 Input
6HDMI 2.0 Input
7HDBaseT Input 1
8HDBaseT Input 2
1 2 3 4 5 6 7 8
Quad combo input card
SEL SEL SEL SEL
DP ADP BDP CDP D
SYNC SYNC SYNC SYNC
3 4
1Quad DisplayPort 1.2 channel A Input
2Quad DisplayPort 1.2 channel B Input
3Quad DisplayPort 1.2 channel C Input
4Quad DisplayPort 1.2 channel D Input
1 2
Quad DP1.2 input card
Support
Website www.barco.com/esupport
- USA [phone]
- EMEA [phone]
- APAC [phone]
Tel.:

Communication panel
O No power
Projector is in Standby
RED
Projector is Ready
ORANGE
GREEN Projector is on
Light source is o
O
Light source not detected
RED
GREEN Light source is on in normal mode
Light source is on in CLO mode
GREEN-ORANGE
O No error
RED toggles on/o Error
ORANGE toggles on/o Warning / Software update
IR signal received
RED
GREEN IR signal acknowledged
LED COLOR STATUS DESCRIPTION
PWR (power LED)
LIGHT (Illumination LED)
ERR (error LED)
IR
Doc No: R5911411 /00 ENABLING BRIGHT OUTCOMES
1WiFi antenna for wireless IP (optional)
212V 1A output
3Firmware update/Download log files
410/100 base-T for external control over IP / Art-Net
5DMX interface input
6DMX interface output
7XLR input for wired projector control
8RS232 for serial communication
9Sync Out 3D
10 Sync In 3D
11 Status lights
12 IR receive sensor
13 GSM antenna input (optional)
1 2 3 4 5 6 7 8 9 10 11 12 13
LED status
