BARIETAH KC-101 User manual

BARIETAH®
SMART COOKER
INSTRUCTION MANUAL
MODEL
Dear customer, congratulations on choosing Barietah®Smart Cooker. This versatile,
multifunctional cooking device will greatly simplify your daily cooking, enhance your cooking
KC-100/101
Test model：KC-101

experience, constantly and reliably produce professional quality meals within 10 minutes
with ingredients ready. Before use please use a screw driver to assemble the cooking pot
handler to the cooking pot with the two screws included.
Please read this manual carefully before you start using the cooker.
Exhaust Vents Connecting Arm Lid Lid Handle Display Panel LCD Panel
Cooking Pot Handle

Top IR Heater Connecting Arm Cooking Pot Stirrer Bar
Cooking Pot Handle

LCD Display Panel
Cooking Indicator Preheating Indicator Logo Cooking Time Indicator Adding Ingredients Indicator Broil Indicator
Bluetooth Logo Stir Fry Indicator Shallow Fry/Sauté Indicator
Custom Cooking Indicator Stirring Indicator Heating Indicator Stew Indicator Steam Indicator
Touch Button Controls
Power ON/OFF Function Selection Cooking Time Decrease Cooking Time Increase
Cooking Cycle Start/Stirring Toggle
ON/OFF: turns on or off the cooker after connecting power cord.
FUNCTION: toggles among built-in cooking cycles.
TIME (+ OR -): increases or decreases the cooking time after a cooking cycle has started.
START/STIR: starts a cooking after the cycle is selected. In ‘Custom’ cooking cycle, turns on and off the
stirring bar.

Cooking Cycle Controls:
Mode
Cycle
Preheating
Add Ingredients
Time
Cooking
Preset
Time(*)
Bottom Heating
Top Heating
Stirring
Stir Fry
Yes
3 min or
until
cooking
temp is
reached
30 sec, after
preheating 6.5 min
Always on or
unless
terminated by
overheating
protection
Turned on 20
sec after
cooking starts,
then on for 15
sec, off for 5
sec until done
Turned on
30 sec after
cooking
starts, then
on for 15
sec, off for
15 sec until
done
Custom
Yes
3 min or
until
cooking
temp is
reached
30 sec, after
preheating
5 min
Always on or
unless
terminated by
overheating
protection
Turned on 30
sec after
cooking starts,
then on for 15
sec, off for 5
sec until done
Controlled
by
"Start/Stir"
touch
button on
the panel
Braise
Yes
3 min or
until
cooking
temp is
reached
30 sec, after
preheating
10 min
Always on or
unless
terminated by
overheating
protection
Turned on 30
sec after
cooking starts,
then on for 15
sec, off for 5
sec until done
Turned on
60 sec after
cooking
starts, then
on for 15
sec, off for
15 sec until
done
Stew
No
Add Ingredients
without
preheating
40 min
Always on in the
first 10 min, then
continues on
with 1/4 power
until done No No
Steam
No
Add Ingredients
without
preheating
20 min
Always on or
unless
terminated by
overheating
protection
No
No
Shallow Fry
Sauté
Yes
3 min or
until
cooking
temp is
reached
30 sec, after
preheating 6 min
Always on or
unless
terminated by
overheating
protection
Turned on 30
sec after
cooking starts,
then on for 15
sec, off for 5
sec until done No

Broil
Yes
3 min or
until
cooking
temp is
reached
30 sec, after
preheating 10 min
Always on or
unless
terminated by
overheating
protection
Turned on 60
sec after
cooking starts,
then on for 40
sec, off for 20
sec until done No
*: if cooking is controlled by bluetooth, preset cooking time is controlled by bluetooth cooking signals (See
below ‘Use Bluetooth Features’ section for details
Safety Tips:
1) Keep out of reach from children.
2) Make sure you don’t use any other kitchen appliances consuming big amount of powers on the
same circuit that the cooker is using. The cooker consumes up to 1380w of power. If you are not
sure, consult your electrician first.
3) Before use, make sure that the cooker is dry inside out.
4) During cooking, never put hands directly on the lid, or go close to the exhaust vent. Doing so may
cause serious injuries.
5) After cooking, open the lid VERY SLOWLY from the backside of the lid handle, otherwise serious
injuries may occur.
6) Disconnect from power after use.
7) Wipe the cooking pot completely clean and dry before cooking. If cooking pot is not clean, excess
smokes might be generated; if cooking pot is not dry, there might be potential electric shock hazard.
8) If you don’t use the cooker for a long time, wrap and store the cooker in a dry and cool place.
9) If you plan to bring the cooker to travel, same safety rules should be followed on the road trips.
10) Do not expose the cooker in a direct sun light. Doing so may shorten the life of the cooker.
Cleaning Tips:
1) Cooking pot is dish washer safe.
2) After cooking, disconnect from power, let both top and bottom heating elements cool down
completely, use only soft cloth, paper towels to clean the lid and wipe out any condensed water on
the lid and inner chamber.
3) Keep the outside of the cooker clean with soft cloth, paper towels or sponge.

Operation Instruction:
1) Before the first use, carefully inspect all contents in the package. Use a screw driver and securely
assemble the cooking pot handle to the cooking pot.
2) Place the cooker on a counter top. Make sure you read and follow the safety tips.
3) Make sure stirring bar on the outer side of the bottom of the cooking pot has interlocked with the
stirring bar on the bottom of the cooker
Bottom Heater Bottom of Cooking Pot
4) After connection power cord:
On LCD panel, the Barietah® logo is steadily on and the Bluetooth logo is flashing
5) After turning on cooker by tapping on the ON/OFF touch button:
On LCD panel, the time indicator is on.
6) After selecting a cooking cycle by tapping/toggling on Function touch button:
One of the cooking cycle indicators is on
7) After starting a cooking cycle and preheating is on:
Preheat indicator is flashing.
8) After preheating ends and adding ingredient is on:
Add Ingredient indicator is flashing. Add ingredients at this time, following instructions on your
ingredient bag, or in case there is no instruction, then depending on your cooking cycle, a good rule
of thumb is adding in the following order: cooking oil, meat or seafood or other protein, vegetables,
flavor/sauce, etc, then cover the lid and let cooking cycle run thru. If your cooking instruction
requires adding something during cooking, then open the lid carefully, following the safety tips, add
the ingredients of your choice, and cover the lid let the cycle run thru.
9) After the cooking cycle starts and bottom heating is on:
Cooking time is shown with minutes and seconds. The green heating light is on
10) After cooking cycle starts and both bottom and top heating are on:
Cooking time shown and red heating light is on.
11) After cooking cycle is finished:
A ‘HOT’ message displays in the area where cooking time displayed previously. If you do not
continue to cook, unplug the power cord, clean and dry the cooking, let the cooker completely cool
down, put cooker in a dry place at room temperature. If you do, then clean and dry the cooking pot
thoroughly before cooking another item, make sure you always follow the safety tips.
12) Follow the safety tips, transfer food from cooking pot to a plate/container.
13) Clean the cooker following the safety and cleaning tips.

Use Bluetooth Features:
1) When you are using the built-in Bluetooth features which is indicated by the flashing Bluetooth logo
on the top left side on the panel, make sure the cooker is powered on, the ingredient bags contain
vendor-provided QR code, and you have installed Barietah mobile app (currently Barietah mobile
app supports iOS and Android platforms, mobile app details can be found on the mobile app itself)
2) Make sure no other Bluetooth enabled devices in your home is connected to the cooker. Some
devices, such as some versions of iPhone, do not show certain types of nearby Bluetooth devices it
can connect to, Barietah mobile app provide a ‘Test Connection’ button to let you test if your mobile
device can connect to the cooker. If the connection failed, most likely another device in your home
have already connected to the cooker and locked out any other Bluetooth-enabled devices to
connect to the cooker, find out the device, disconnect it from the cooker, then try again
3) Use Barietah mobile app to scan, validate the QR code on your ingredient bags, and then send
cooking instructions to the cooker via the Bluetooth connection. The cooker then starts the cooking
cycle. After this point follow the instructions above.
4) Barietah mobile app disconnects the Bluetooth connection after successfully transmitting the
cooking instructions to the cooker.
Trouble Shooting Tips:
1) After connecting power cord, the Barietah® logo or the Bluetooth logo are not on.
Possible reasons: power cord may be broken, or the power outlet may not be functioning
2) The food ingredients are either overcooked or undercooked.
Possible reasons: your portion size may be either too little or too much. The cooker produces ideal
results with two to three servings, within 6.5 to 10 minutes, depending on the nature of ingredients.
3) Touch buttons are malfunctioning.
Possible reasons: The cooker may need to reset, simply unplug and re-plug the power cord; or the
cooker might have caught some moisture, simply let the cooker dry thoroughly before trying again.
Product Specifications:
Total Power: 1380W (Bottom Heater: 1100W, Top Heater: 280W)
Electrical: AC 120 V, 60 Hz
Cooking Pot Capacity: 1.53 Gal (5.8 Liter)
Electrical Motor: 6W
Product Weight: 11 lb (5 Kg)
Package Contents:
1) A Cooking Pot with a detached handle and two screws
2) A Cooker (with a cooking pot and cooker itself)
3) A Power Cord
4) An Instruction Manual
5) Any other accessories you may have ordered
