BATTLEBULL RED TWELVE User manual

Product images are for illustration purpose
only and may differ from the actual product.
1. Backrest
6. Castor Wheels
11. Gas Lift 12. Gas Lift Cover 13. Hex Wrench 14. Spare Screws
7.
2. Seat Cushion 3. Head Cushion
8.
4. Lumbar Rest
9.
5. 5-Point Base
10. Gloves
Screws and
Side Covers of backrest Head Cushion Lock Butterfly & Seat Tilt
Mechanism
All contents has been carefully checked, please
contact us if there is any printing mistake or
misunderstanding.
Note: All technical parameter are subject to change
without prior notice. Updated information will be
added to the next version of manual.
Product Reference: V1
Product
Information
Backrest Support
Rocking Chair Feature
User-friendly Operation System
Auxiliary Support
Seat Cushion Support
180° Reclining Feature
360° Rotation Feature
Ergonomic Concave Design - which supports your spine in a more comfortable way.
Suitable for different body shapes - like it is specially designed for the curves around
your neck, back as well as waist!
Further distribute pressure to minimize stress on legs and bottom. Feel comfortable all
day long! Deformation resistant, and durable.
Full rotation with no dead angle - which avoids from getting up frequently. Feel even
more relaxed during work!
Adjust the chair angle at around 120°~135°, then turn on the rocking chair function.
Gently touch the floor with your toes, and you will feel more relaxed!
Apart from the chair height, you can also adjust the angle of backrest and the armrest
according to your needs. Protect your back effectively and prevent RSI (Repetitive
Strain Injuries). More options, more freedom!
Interchangable head cushion and lumbar rest. Get one that fits your body shape and
relieves stress more effectively!
Provide multi-angle recline adjustment that fulfils user’s needs.
BATTLEBULL Chair Features
GAMING CHAIRS
RED
TWELVE

Please wear the gloves before installing the chair. Please wear the gloves before installing the chair.
Attach all five wheels to each hole
of the 5-point base.
Insert the gas lift into the center
hole o
Put on the gas lift cover.
Remove the pre-installed
screws and washers from
the side of the backrest.
Attach the chair back to the seat by
aligning the screw hole, inserting
and tightening all 4 screws and
washers (2 on each side).
Butterfly Mechanism: Attach the butterfly
mechanism and tighten the screws.
(Adjustable handles for chair height and
backrest should be on the same side.)
Seat Tilt Mechanism: Attach the seat tilt
mechanism and tighten the screws.
(The joint of gas lift in circle area is at
the back.)
Installation Steps
Installation of Head Cushion and Lumbar Rest
Installation Steps
Adjustment
Features
Put the chair upside down, then remove
four pre-installed screws and washers.
Attach the side covers of backrest and
then tighten the screws. (See inner side
of cover: “L”=Left “R”=Right)
Connect the main body to the chair base.
(We recommend two persons working
together for this step, as the chair is quite
heavy.)
Pull the belt out from
the back of chair. Height adjustment
of handrest
Chair Height
Rocking feature
Tightness.
Angle adjustment
of backrest
Rocking feature
Height adjustment Forward & Backward
Horizontal Angle
adjustment
Left & Right
adjustment
ON OFF
Pull the belt out directly and
then put it on from the top of
chair to the desired height.
Take the belt from the side of
lumbar rest, then go through
the backrest and seat cushion.
Take the belt from the other side,
then fasten it after going through
the back of chair from the buckle.
Pull the belt out from
the other side.
Wrap around the other
side of head cushion
lock.
Wrap the belt around the
side of head cushion lock.
Product images are for illustration purpose
only and may differ from the actual product.
Chair
Adjustment
Armrest
Adjustment
Note: There are three types of armrest: 1D, 3D, 4D.
For particular features please refer to the actual product.
1D only includes Feature . 3D includes Feature , , .
4D includes Feature , , , .
