Argos 343761 User manual

343761
380/8089
Thornbury Slatted Back Dining Chair
Assembly Instructions - Please keep for future reference
Issue 1 - 08/04/15
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Homebase = 0345 077 8888
Width - 46 cm
Depth - 50 cm
Height - 90 cm
Dimensions

1
• Check you have all the
components and tools listed on
the following pages.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• During assembly do not stand
or put weight on the product, this
could cause damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Maximum safe weight of user:
110kgs.
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Care and maintenance
Handy Hints
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
• Do not stand on the chair.
• Do not use this chair as step
ladder.
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the
bolts.
• Regularly check and ensure
that all bolts and fittings are
tightend properly.

2
Note: The quantities below are the correct amount to complete the assembly of one chair.
Components - Parts
Please check you have all the parts listed below
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly of one chair. In some cases
more fittings may be supplied than are required.
AB
M6 x 50mm Bolt x 6 M4 x 30mm Screw x 6
D
Spring Washer x 6
E
Flat Washer x 6
F
Allen key x 1
Components - Fittings
Phillips screwdriver
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
The screwslength is measured from the head to the point (30mm screw shown).
C
Wooden Dowel x 6
Tools required
If you have damaged or missing components, call the
Customer Helpline: Homebase = 0345 077 8888
Siderail x 2
(31 x 6 x 2 cm)
1Seat
(46.5 x 37.5 x 4.5 cm)
4Backrest
(90.1 x 40.3 x 10.3 cm)
2Front Leg
(43 x 41.5 x 4 cm)
3

3
Attaching backrest
Place the backrest on
a flat protected surface.
Insert wood dowels in
the centre holes of the
siderails and attach it
to the backrest .
Then fix the siderails to
the backrest with bolts ,
spring washers and
flat washers .
Tighten bolts using allen
key .
Note: Do not
fully tighten until
chair is placed
on a flat surface.
Put the chair upright on
the flat surface and fully
tighten all bolts.
Attaching siderails
Place the front leg on
a flat protected surface.
Insert wood dowels in
the holes on the siderails
. Position the siderails
as shown and insert the
wood dowels in the holes
on the front leg.
Then fix using bolts ,
spring washers and
flat washers .
Tighten bolts using allen
key .
Note: Do not
fully tighten until
chair is placed
on a flat surface.
Assembly Instructions
Step 1
Step 2
3
1
C
A
D
E
F
3
3
1
1
1
C
C
C
C
C
C
A
F
D
E
A
D
E
A
D
E
C
C
C
C
A
F
F
F
D
E
A
D
E
A
D
E
A
D
E
A
A
D
E
D
E
2
2
2
2
1
1
1
1

4
Attaching seat
Place the seat face
down on a raised
protected surface.
Position the chair on
center of the seat and fix
using screws .
Tighten screws using a
crosshead screwdriver.
Note: Fully
tighten all screws
assembled in
previous steps.
Carefully turn over the
chair.
Assembly is complete.
Assembly Instructions
Step 3
If you need help or have damaged or missing parts, call the Customer Helpline:
Homebase = 0345 077 8888
B
B
B
B
B
B
B
1
1
4
4
3
