Bauknecht MHC 8822 User manual

1
Gebrauchsanweisung
Instructions for use
Mode d’emploi
Gebruiksaanwijzing
Istruzioni per l’uso
Brugsanvisning
Bruksanvisning
Käyttöohje
Manual de utilização
Instrucciones para el uso
Instrukcje użytkowania
Használati utasítás
Οδηγίες Χρήσης
Инструкция за употреба
Návod k použití
Návod na použitie
Instrucţiuni de utilizare
Инструкции по эксплуатации
MHC 8822

2
INSTALLATION
BEFORE MOUNTING THE APPLIANCE
ENSURE the oven cavity is empty before mounting.
ENSURE that the appliance is not damaged before mounting
it in the cabinet.
CHECKTHAT ALL MATERIAL for mounting the appliance is sup-
plied in the package.
IFTHECOOKER HOOD IS USED TOGETHER WITHOTHER AP-
PLIANCES which consume the air in the room
(e.g. gas, diesel oil or coal appliances, water-
heaters, boilers) remember that the hood as-
pires air from the room which may therefore
not be sufficient for burning.
THIS APPLIANCEIS DESIGNED to be mounted
over electrical or gas cooker ranges only!
The distance between the cooker range
and bottom part of this appliance must
be at least 460 mm for electrical cooker
ranges and at least 650 mm for gas cook-
er ranges.
THEMANUFACTURER MUST BE CONTACTED for the mini-
mum mounting distance where:
Electrical range:
The cooker range has more than 4 hob ele-
ments.
The two rear elements exceed a rating of 2
kW per element.
The two front hob elements exceed a
rating of 1.5 kW per element.
Gas range:
The gas burner develop more than 3.2 kw
per burner
The cooker range develop more than 10
kw in total.
EXTERNAL EVACUATION:
THEFLANGE has a Ø 120 mm opening so that,
evacuation pipes with Ø 120 mm can be
mounted.
EVACUATION SHOULD NOT be through a flue
used for the evacuation of other vapours
or burnt gas, that is through a pipe used
as a flue for open flame sources.
COOKER HOODS AND OTHER APPLIANCES REQUIRING A
FLUE, can only be used together safely if there
is a maximum depression of 0.04 mbar in room
which prevents the reabsorbing of the burnt
gases.
This is possible only if the combustion air is
evacuated through non-closing apertures such
as doors, windows, wall boxes for the supply
and evacuation of air or similar technical devic-
es such as reciprocal blocking devices or sim-
ilar. If you are not certain call a qualified tech-
nician.
NOTE: For best function keep the kitchen win-
dows closed when using the fan. If not you
have no negative pressure in the kitchen. But
one window in an adjacent room ought to be
open.
FOR EVACUATION use flexible aluminium pipes or
sheet plate pipes which are resistant to corro-
sion.
IFYOU ARE INSTALLING THEAPPLIANCETO AN UNUSED
FLUE for the evacuation of vapour’s or burnt
gas, we recommend that you request the ad-
vice and approval of a competent technician
before making the installation.
DONOT USE INFLAMMABLE PLASTICPIPES. Always
ensure that the evacuation channels and
pipes are as short as possible.
DONOT MOUNT THEPIPES AT RIGHTANGLES. They
must always be curved and should be fitted
into the flue at an upward angle. The diameter
of the pipe must not narrow towards the top.
THEPERFORMANCEOF THEFAN will be reduced with
small diameter pipes.

3
DONOT USE EXTENSION CORD:
IFTHEPOWER SUPPLY CORD IS TOO SHORT, have a
qualied electrician or serviceman install
an outlet near the appliance.
PRIOR TO CONNECTING
ENSURE THAT THEAPPLIANCEIS NOT DAMAGED. Check
that the oven door closes firmly against the
door support. Empty the oven and clean the
interior with a soft, damp cloth.
AFTER CONNECTING
THEEARTHING OF THIS APPLIANCEis compulsory. The
manufacturer will accept no responsibility for
injury to persons, animals or damage to ob-
jects arising from the non-observance of this
requirement.
The manufacturers are not liable for any pro-
blems caused by the user’s failure to observe
these instructions.
DONOT OPERATE THIS APPLIANCEif it has a damaged
mains cord or plug, if it is not working proper-
ly, or if it has been damaged or dropped. Do
not immerse the mains cord or plug in water.
Keep the cord away from hot surfaces. Electri-
cal shock, fire or other hazards may result.
DONOT REMOVE THEMICROWAVE INLET PROTECTION
PLATES located on the side of the oven cavity
wall. They prevent grease & food particles from
entering the microwave inlet channels.
CHECKTHAT THEVOLTAGE on the rating plate corre-
sponds to the voltage in your home.
THEOVEN CAN BE OPERATED ONLY
if the oven door is firmly
closed.
Poor television reception
and radio interference may result if the
oven is located close to a TV, radio or aerial.
FOLLOW THESUPPLIED separate mounting in-
structions when installing the appliance.
INTERNAL RECIRCULATION
THECOOKER HOOD is used with the internal recir-
culation system when there is no pipe or open-
ing on the external wall. In the case of internal
recirculation, the optional carbon filter must
be installed for the absorption of the cooking
vapours.
THEINTERNAL RECIRCULATION COOKER HOOD – with
carbon filter is in no way dangerous.
INSTALLATION

4
IMPORTANT SAFETY INSTRUCTIONS
DONOT HEAT, OR USE FLAMMABLE MATERIALS in or
near the oven. Fumes can create a fire hazard
or explosion.
DONOT USE YOUR APPLIANCEFOR DRYING TEXTILES, PA-
PER, SPICES, HERBS, WOOD, FLOWERS, FRUIT OR OTHER
COMBUSTIBLE MATERIALS. FIRE COULD RESULT.
DONOT OVER-COOK FOOD. Fire could result.
DONOT LEAVE THEOVEN UNATTENDED, especially
when using paper, plastic or other combusti-
ble materials in the cooking process. Paper can
char or burn and some plastics can melt if used
when heating foods.
IFMATERIAL INSIDE / OUTSIDE THEOVEN SHOULD IGNITE
OR SMOKE IS OBSERVED, keep oven door closed and
turn the oven off. Disconnect the power cord
or shut off power at the fuse or circuit break-
er panel.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
ONLY ALLOW CHILDREN to use the appliance under
adult supervision and after adequate instructions
have been given, so that the child is able to use
the appliance in a safe way and understands the
hazards of improper use.
THIS APPLIANCE IS NOT INTENDED FOR use by persons
(including children) with reduced physical,
sensory or mental capabilities, unless used under
the supervision of a person responsible for their
safety.
WARNING!
ACCESSIBLE PARTS MAY BECOME HOT during use, young
children should be kept away.
DONOT USE YOUR APPLIANCEFOR HEAT-
ING ANYTHING IN AIRTIGHTSEALED CON-
TAINERS. THEPRESSURE INCREASES
AND MAY CAUSE DAMAGE WHEN OPEN-
ING OR MAY EXPLODE.
EGGS
DONOT USE THEMICROWAVE FUNCTION for cook-
ing or reheating whole eggs with or
without shell since they may
explode even after microwave
heating has ended.
THEDOOR SEALS AND THEDOOR SEAL AREAS must be
regularly inspected for damage. If these areas
are damaged the appliance should not be op-
erated until it has been repaired by a trained
service technician.
DONOT USE corrosive chemicals or vapors in this
appliance. This type of oven is specifically de-
signed to heat or cook food. It is not designed
for industrial or laboratory use.
IFTHEFILTER IS DAMAGED it must be replaced. Do
not use the extractor hood without the filter. It
is not designed for such operation.
NEVER PREPARE ”FLAMBÉ” DISHES under the cook-
er hood!
NEVER USE AN OPEN FLAMEunder the hood. The
use of an unprotected flame is dangerous for
the filters and could cause fires.
NEVER LEAVE THEPAN ALONE when frying foods.
The cooking oil can easily flare up. This is a po-
tential fire hazard!
The manufacturers refuse to accept any responsi-
bility for damage to the hood or its catching on re
because of failure to observe the above instructions.

5
GENERAL
THIS APPLIANCE IS DESIGNED FOR DOMESTIC USE ONLY!
THE APPLIANCE SHOULD NOT BE OPERATED without food
in the oven when using microwaves. Operation in
this manner is likely to damage the appliance.
IFYOU PRACTICEOPERATING the oven, put a glass
of water inside. The water will absorb the mi-
crowave energy and the oven will not be dam-
aged.
REMOVE WIRE TWIST-TIES from paper or
plastic bags before placing bag in
the oven.
DEEPFRYING
DONOT USE YOUR APPLIANCEFOR DEEP-FRYING, BECAUSE
THEOIL TEMPERATURE CANNOT BE CONTROLLED.
LIQUIDS
E.G. BEVERAGES OR WATER. Overheating the liquid
beyond boiling point can occur
without evidence of bubbling.
This could result in a sudden
boil over of the hot liquid.
To prevent this possibility the
following steps should be taken:
1. AVOID using straight-sided containers with
narrow necks.
2. STIR the liquid before placing the container
in the oven and let the teaspoon remain in
the container.
3. AFTER HEATING, allow standing for a short
time, stirring again before carefully remov-
ing the container from the oven.
CAREFUL
ALWAYS REFER to a microwave cookbook for de-
tails. Especially, if cooking or reheating food
that contains alcohol.
AFTER HEATING BABY FOOD or liquids in a
baby bottle or in a baby food
jar, always stir and check the
temperature before serving.
This will ensure that the heat is evenly distributed
and the risk of scalding or burns can be avoided.
Ensure the Lid and the Teat is removed before
heating!
PRECAUTIONS
USE HOT PADS OR OVEN MITTS to prevent burns,
when touching containers, oven parts, and
pan after cooking.
DONOT USE THECAVITY for any storage purposes.

6
IFACCESSORIES CONTAINING METAL comes in contact
with the oven interior, while the oven is in op-
eration, sparking can occur and the oven could
be damaged.
ALWAYS ENSURE that the turntable is able to turn
freely before starting the oven. If the turntable
isn’t able to turn freely you should use a small-
er vessel.
ACCESSORIES
GENERAL
ENSURE THAT THEUTENSILS YOU USE are oven proof
and allow microwaves to
pass through them before
cooking.
THERE ARE a number of accessories available on
the market. Before you buy, ensure they are
suitable for microwave use.
CARBON FILTER
THECARBON FILTER effectively absorbs the va-
pours from the kitchen range.
ITIS NOT WASHABLE AND MUST BE REPLACED AT REGU-
LAR INTERVALS and can be obtained via your lo-
cal dealer.
SUPPLIED
OPTIONAL
TURNTABLE SUPPORT
USE THETURNTABLE SUPPORT un-
der the Glass turntable. Nev-
er put any other utensils on
the turntable support.
Fit the turntable support
in the oven.
GLASS TURNTABLE
USE THEGLASS TURNTABLE with all cooking meth-
ods. It collects the dripping
juices and food particles
that otherwise would stain
and soil the interior of the oven.
Place the Glass turntable on
the turntable support.
WHEN YOU PUT FOOD AND ACCESSORIES in the micro-
wave oven, ensure that they do not come in
contact with the interior of the oven.
This is especially important with accessories
made of metal or metal parts.
CRISP HANDLE
USE THESUPPLIED SPECIAL CRISP HAN-
DLE to remove the hot Crisp plate
from the oven.
CRISPPLATE
PLACETHEFOOD DIRECTLY ON THECRISP-PLATE.
Always use the Glass turn-
table as support when us-
ing the Crisp-plate.
DONOT PLACEANY UTENSILS on the
Crisp-plate since it will quickly be-
come very hot and is likely to cause
damage to the utensil.
THECRISP-PLATE may be preheated before use
(max. 3 min..). Always use the Crisp function
when preheating the crisp-plate.

7
START PROTECTION / CHILD LOCK
THIS AUTOMATICSAFETY FUNCTION IS ACTIVATED ONE
MINUTE AFTER the oven has returned to
“stand by mode“. (The oven is in
“stand by” when the 24-hour clock is
displayed or if the clock has not been
set, when the display is blank).
THEDOOR MUST BE OPENED AND CLOSED e.g. putting
food into it, before the safety lock is released.
Else the display will show “DOOR“.
DOOR
PAUSE OR STOP COOKING
TOPAUSE COOKING:
THECOOKING CAN BE PAUSED to
check, turn or stir the food
by opening the door. The
setting will be maintained
for 10 minutes.
IFYOU DON’TWANT TO CONTINUE COOKING:
REMOVE THEFOOD, close the door
and press the STOP button
TOCONTINUE COOKING:
CLOSE THEDOOR and press the Start
button ONCE. The cooking is re-
sumed from where it was paused.
PRESSING THESTART BUTTON TWICE will in-
crease the time by 30 seconds.
A BEEP WILL SIGNAL once a minute for 10 min-
utes when the cooking is fin-
ished. Press the STOP but-
ton or open the door to can-
cel the signal.
NOTE: The oven will only hold the settings for
30 seconds if the door is opened and then
closed after the cooking is finished.
WHEN AFUNCTION IS FINISHED, the oven carries out
a cooling procedure. This is normal.
After this procedure the oven switches off au-
tomatically.
THECOOLING PROCEDURE can be interrupted with-
out any harm to the oven by opening the door.
COOLING DOWN

8
FAN
THEHOOD HAS AFAN FUNCTION. It is turned on / off
or regulates the fan speed by pressing the Fan
button repeatedly. The Fan always starts with
the speed set to minimum. Repeated pressing
increases the fan speed. When max fan speed
is reached the next press turns the fan off.
KITCHEN TIMER
USE THIS FUNCTION when you need a kitchen tim-
er to measure exact time for various purpos-
es such as cooking eggs, pasta or letting the
dough rise before baking etc.
PRESS THE+/- BUTTONS to set the time to
measure.
PRESS THEPOWER BUTTON repeatedly to set
the power to 0 W.
PRESS THESTART BUTTON.
ANACOUSTICSIGNAL will be heard when the timer
has finished to count down.
TOTURN THEKITCHEN TIMER OFF before the count-
down have finished, press the Stop button.
THEHOOD HAS ALIGHTFUNCTION. It is turned on /
off by pressing the light button.
LIGHT
MIN SPEED MED SPEED MAX SPEED



9
CLOCK
KEEP THEDOOR OPEN while setting the Clock. This
gives you 5 minutes to complete the setting
of the Clock. Otherwise, each step must be ac-
complished within 30 seconds.
PRESS THESTOP BUTTON (3 seconds) until the
left-hand digit (hour’s) flicker.
PRESS THE+/- BUTTONS to set the hours.
PRESS THESTART BUTTON. (The two right
hand digits (minutes) flicker).
PRESS THE+/- BUTTONS to set the minutes.
PRESS THESTART BUTTON AGAIN.
THECLOCKIS SET and in operation.
NOTE: When the appliance is first plugged in
or after a power failure, the display is blank.
If the clock is not set, the display will remain
blank until the cooking time is set.



10
COOK & REHEAT WITH MICROWAVES
CHOOSING POWER LEVEL
USE THIS FUNCTION for normal cooking and re-
heating, such as vegetables, fish, potatoes and
meat.
PRESS THE+/- BUTTONS TO SET THETIME.
PRESS THEPOWER BUTTON REPEATEDLY TO SET THE
POWER.
PRESS THESTART BUTTON.
ONCETHECOOKING PROCESS HAS BEEN STARTED:
THETIMECAN EASILY BE INCREASED in 30-second
steps by pressing the Start button. Each press
increases the time with 30 seconds. You may
also alter the time by pressing the +/- buttons
to increase or decrease the time.
PRESSING THEPOWER BUTTON may also change the
power level. The first press will show you the
current power level. Press the power button
repeatedly to change power level.


MICROWAVES ONLY
POWER SUGGESTED USE:
RAPID
750 W
REHEATING OF BEVERAGES, water, clear soups, coffee, tea or other food with a high
water content. If the food contains egg or cream choose a lower power.
500 W MORE CAREFUL COOKING e.g. high protein sauces, cheese and egg dishes and to finish
cooking casseroles.
350 W SIMMERING STEWS, melting butter.
160 W DEFROSTING. Softening butter, cheeses.

11
THIS FUNCTION IS USED for quick reheating of food
with a high water content such as clear soups,
coffee or tea.
RAPID START
PRESS THESTART BUTTON.
PRESS TO AUTOMATICALLY START with full microwave
power level and the cooking time set to 30 sec-
onds. Each additional press increases the time
with 30 seconds. You may also alter the time
by pressing the +/- buttons to increase or de-
crease the time after the function has started.
MANUAL DEFROST
FOLLOW THEPROCEDURE for “Cook & Reheat with
Microwaves” and choose power level 160 W
when defrosting manually.
CHECKAND INSPECTTHEFOOD REGULARLY. Experi-
ence will give you the times needed for vari-
ous amounts.
TURN LARGE JOINTS halfway through the defrost-
ing process.
FROZEN FOOD IN PLASTICBAGS, plastic films or card-
board packages can be placed directly in the
oven as long as the package has no met-
al parts (e.g. metal twist ties).
THESHAPE OF THEPACKAGE alters the de-
frosting time. Shallow packets defrost
more quickly than a deep block.
SEPARATE PIECES as they begin to defrost.
Individual slices defrost more easily.
SHIELD AREAS OF FOOD with small
pieces of aluminum foil if they
start to become warm (e.g.
chicken legs and wing tips).
BOILED FOOD, STEWS AND MEAT SAUCES defrost
better if stirred during defrosting time.
WHEN DEFROSTING it is better to under-
thaw the food slightly and allow the
process to finish during standing time.
STANDING TIMEAFTER DEFROSTING ALWAYS IMPROVES
the result since the temperature
will then be evenly distributed
throughout the food.


12
RAPID DEFROST
USE THIS FUNCTION FOR DEFROSTING MEAT, FISH&
POULTRY ONLY. For other foods such as Bread
& Fruit you should follow the procedure for
”How to cook and reheat with microwaves”
and choose 160 W when defrosting.
RAPID DEFROST SHOULD ONLY BE USED if the net
weight is between 100 - 2000g.
PRESS THERAPID DEFROST BUTTON.
PRESS THE+ / - BUTTONS TO SET THEWEIGHTOF
THEFOOD.
PRESS THESTART BUTTON.
MIDWAY THROUGHTHEDEFROSTING PROCESS the oven
stops and prompts you to TURN FOOD.
Open the door.
Turn the food.
Close the door and restart by pressing the
Start button.
NOTE: The oven continues automatically after
2 min. if the food hasn’t been turned. The de-
frosting time will be longer in this case.
THIS FUNCTION NEEDS TO KNOW the net weight of the food.
IFTHEWEIGHTIS LESSER OR GREATER THAN RECOMMEND-
ED WEIGHT: Follow the procedure for
“Cook & Reheat with Microwaves”and
choose 160 W when defrosting.
IFTHEFOOD IS WARMER than deep-freeze temper-
ature (-18°C), choose lower weight of
the food.
IFTHEFOOD IS COLDER than deep-freeze
temperature (-18°C), choose higher
weight of the food.



FOOD AMOUNT HINTS
MEAT 100G- 2KGMINCED MEAT, CUTLETS, STEAKS OR ROASTS.
POULTRY 100G- 2KGCHICKEN WHOLE, PIECES OR FILLETS.
FISH 100G- 2KGWHOLE, STEAKS OR FILLETS.
FOR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves” and choose 160 W
when defrosting.

13
GRILL
USE THIS FUNCTION TO quickly give a pleasant
brown surface to the food.
PRESS THEGRILL BUTTON.
PRESS THE+/- BUTTONS to set the time.
PRESS THESTART BUTTON.
PRESSING THEGRILL BUTTON DURING COOKING switch-
es the Grill element on and off. The timer will
continue to count down when the Grill ele-
ment is turned off.
DONOT LEAVE THEOVEN DOOR OPEN for long periods
when the Grill is in operation, as this will cause
a drop in temperature.
ENSURE THAT THE UTENSILS used are heat
resistant and ovenproof before grilling with
them.
DONOT USE PLASTIC utensils when grilling.
They will melt. Items of wood or paper are
not suitable either.



TH
IS
F
F
UN
UN
C
CT
IO
NG
s
s
i
wi
wi
tc
tc
h
h-

14
GRILL COMBI
USE THIS FUNCTION TO cook such food as Gratin’s,
Lasagne, Poultry and Baked potatoes.
PRESS THEGRILL BUTTON.
PRESS THEPOWER BUTTON to set the power.
PRESS THE+/- BUTTONS to set the time.
PRESS THESTART BUTTON.
DURING OPERATION you can switch the Grill ele-
ment on/off by pressing the Grill button. The
Max. possible microwave power level when us-
ing the Grill is limited to a factory-preset level.
CHOOSING POWER LEVEL
ITIS POSSIBLE to switch the microwaves off by
reducing the microwave power level to 0 W.
When 0 W is reached, the oven switches to Grill
only mode.



ETHIS FUNC
ON TO
coo
k
wi
wi
i
tc
tc
tc
h
h
h
h
th
th
th
e
r
il
l
l
el
l
el
el
e
e-
e-
GRILL COMBI
POWER SUGGESTED USE:
350  500 W COOKING Poultry, Lasagne &
Vegetables
160  350 W COOKING Fish & frozen gratins
160 W COOKING Meat
90 W GRATINATING fruit
0 W BROWNING only during cooking

15
CRISP
USE THIS FUNCTION TO reheat and cook pizzas and
other dough based food. It is also good for fry-
ing bacon and eggs, sausages, hamburgers
etc.
ENSURE that the Crisp-plate is correctly
placed in the middle of the Glass turntable.
USE OVEN MITTENS
or the special Crisp handle supplied when
removing the hot Crisp-plate.
BECAREFUL, NOT TO TOUCH the ceiling beneath
the Grill element.
DONOT PLACE THE HOT CRISP-PLATE on any
surface susceptible to heat.
THE OVEN AND THE CRISP-PLATE become very
hot when using this function.
PRESS THECRISP BUTTON.
PRESS THE+/- BUTTONS to set the time.
PRESS THESTART BUTTON.
ITIS NOT POSSIBLE TO CHANGE OR SWITCH, the Power
level or Grill, on/off, when using the Crisp func-
tion.
ONLY USE the supplied Crisp plate with this func-
tion. Other available Crisp plates on the market
will not give the correct result when using this
function.
THEOVEN AUTOMATICALLY use Microwaves and Grill
in order to heat the Crisp-plate. This way the
Crisp-plate will rapidly reach its working tem-
perature and begin to brown and crisp the
food.



16
MAINTENANCE & CLEANING
CLEANING IS THEONLY MAINTENANCEnormally re-
quired.
DISHWASHER SAFE:
TURNTABLE SUPPORT.
GLASS TURNTABLE.
FAILURE TO MAINTAIN THEOVEN in a clean condition
could lead to deterioration of the surface that
could adversely affect the life of the appliance
and possibly result in a hazardous situation
and risk of fire.
DONOT USE METAL SCOURING PADS,
ABRASIVE CLEANSERS, steel-
wool pads, gritty wash-
cloths, etc. which can
damage the control
panel, and the interior and exterior oven
surfaces. Use a sponge with a mild de-
tergent or a paper towel with spray glass
cleaner. Apply spray glass cleaner to a
paper towel.
DONOT SPRAY directly on the oven.
ATREGULAR INTERVALS, especially if spill
overs have occurred, remove the
turntable, the turntable support
and wipe the base of the oven
clean.
THIS OVEN IS DESIGNED to operate with the turnta-
ble in place.
USE AMILD DETERGENT, water and a soft cloth to
clean the interior surfaces, front and rear of the
door and the door opening.
DONOT ALLOW GREASE or food particles to
build up around the door.
DONOT USE STEAMCLEANING APPLIANCES when
cleaning your appliance.
ADDING SOMELEMON JUICEto a cup of water, plac-
ing this on Glass drip tray and boiling for a few
minutes can eliminate odors inside the oven.
FOR STUBBORN STAINS, boil a cup of water in the
oven for 2 or 3 minutes. Steam will soften the
marks.
GREASE FILTER
CAREFUL CLEANING:
THECRISP-PLATE should be cleaned
in mild, detergent water.
Heavily soiled areas can
be cleaned with a scouring
sponge and a mild cleanser.
ALWAYS let the crisp-plate cool off before clean-
ing. DONOT immerse or rinse with water while
the crisp-plate is hot. Quick cooling may
damage it.
DONOT USE STEEL-WOOL PADS. This will
scratch the surface.
CRISP HANDLE.

17
GREASE FILTER
THEGREASE FILTER captures the greases from the
cooking fumes and needs to be cleaned at a
regular basis. The more often the better they
work. The grease filter is made of several layers
of streched aluminium. Wash it in hot soapy
water or in a dishwasher (60°C) once a month.
Remove the grease filter by pulling the han-
dle down to release the filter from it’s mount-
ed position.
PUSHthe release handle to
the side and lower the
grease filter.
REPLACING THE LIGHTS
DISCONNECTthe appliance from the mains.
UNSCREW the fix-
ing sqrews on
the glass shelf. (It
also serves as lamp
cover).
MAINTENANCE & CLEANING
REMOVE the glass shelf
by pulling it out.
REPLACEthe damaged lamp
with one of the
same power.
INREVERSE ORDER re-
fit the glass shelf
and tighten the
sqrews.
BEFORE CALLING for repair ser-
vice beacuse the lights fail to light up. Please
check that the lamps are fitted tightly.
REMOUNT the grease
filter in the re-
verse order af-
ter it has been
cleaned.

18
TROUBLE SHOOTING GUIDE
IFTHEOVEN DOES NOT WORK, do not make a service
call until you have made the following checks:
The Turntable and turntable support is in
place.
The Plug is properly inserted in the wall
socket.
The Door is properly closed.
Check your Fuses and ensure that there is
power available.
Check that the oven has ample ventilation.
Wait for 10 minutes, then try to operate the
oven once more.
Open and then close the door before you
try again.
THIS IS TO AVOID unnecessary calls for which you
will be charged.
When calling for Service, please give the serial
number and type number of the oven (see Ser-
vice label). Consult your warranty booklet for
further advice.
IFTHEMAINS CORD NEEDS REPLACING it should
be replaced by the original mains cord,
which is available via our ser-
vice organization. The mains
cord may only be replaced
by a trained service techni-
cian.
SERVICE ONLY TO BE CARRIED OUT BY
ATRAINED SERVICE TECHNICIAN. It
is hazardous for anyone other
than a trained person to carry
out any service or repair ope-
ration, which involves the
removal of any cover, which gives pro-
tection against exposure to microwave
energy.
DONOT REMOVE ANY COVER.
ENVIRONMENTAL HINTS
THESYMBOL on the product, or on the docu-
ments accompanying the
product, indicates that this
appliance may not be treated
as household waste. Instead
it shall be handed over to the
applicable collection point for
the recycling of electrical and
electronic equipment.
DISPOSAL must be carried
out in accordance with lo-
cal environmental regula-
tions for waste disposal.
FOR MORE DETAILED INFORMATION about treatment,
recovery and recycling of this product, please
contact your local city office, your household
waste disposal service or the shop where you
purchased the product.
BEFORE SCRAPPING, cut off the mains cord so that
the appliance cannot be connected to the
mains.
THEPACKING BOX may be fully recy-
cled as confirmed by the recy-
cling symbol. Follow local
disposal regulations. Keep
potentially hazardous pack-
aging (plastic bags, polysty-
rene etc.) out of the reach of children.
THIS APPLIANCEis marked according to the Euro-
pean directive 2002/96/EC on Waste Electrical
and Electronic Equipment (WEEE). By ensuring
this product is disposed of correctly, you will
help prevent potential negative consequences
for the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product.

19

20
GB
4619-694-74581
Whirlpool is a registered trademark of Whirlpool, USA.
© Whirlpool Sweden AB 2009. All rights reserved. Made in Sweden.
INACCORDANCEWITHIEC60705.
THEINTERNATIONAL ELECTROTECHNICAL COMMISSION has developed a standard for comparative testing of
heating performance of different appliances. We recommend the following for this oven:
TECHNICAL SPECIFICATION
DATA FOR PERFORMANCE TESTS
SUPPLY VOLTAGE 230 V/50 HZ
RATED POWER INPUT 2200 W
FUSE 10 A (UK 13 A)
MW OUTPUT POWER 750 W
LIGHTING 2 X25 W
FLANGE OPENING Ø120 MM
OUTER DIMENSIONS (HXWXD) 583 X598 X320 MM
INNER DIMENSIONS (HXWXD) 187 X370 X290 MM
Test Amount Approx. time Power level Container
12.3.1 750 G10 MIN 750 W PYREX 3.220
12.3.2 475 G5 ½ MIN 750 W PYREX 3.827
12.3.3 900 G15 MIN 750 W PYREX 3.838
12.3.4 1100 G23-25 MIN GRILL + 500 W PYREX 3.827
13.3 500 G12 - 13 MIN 160 W
