Baumatic BTM17.2SS Operator's manual

User Instruction Manual for your
BTM17.2SS MICROWAVE
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING
YOUR MICROWAVE OVEN. IF YOU FOLLOW THE INSTRUCTIONS, YOUR
OVEN WILL GIVE YOU MANY YEARS OF GOOD, SAFE SERVICE. PLEASE
KEEP THIS MANUAL SAFELY FOR FUTURE REFERENCE.
* NOTE: This manual is designed to be used either as a whole
or to be used for quick set-up so you can get using your
appliance as soon as possible.
For the
Q
QU UI IC CK KF FI IR RE E V VE ER RS SI IO ON N O OF F T TH HI IS S M MA AN NU UA AL L, ,
y
yo ou u c ca an n G GO O D DI IR RE EC CT TL LY Y T TO O P PA AG GE E 1 17 7. Please also
quickly see the IMPORTANT PAGES. They are marked in
bold on the next page.
13/05/05
!>>
>
Q
Q
UICKFIRE! >>>>>>

2
Specifications………..…………….……………………………….……3
Safety Information ……..…………….…….…..…4-5
Environmental Note ……………………………………….………..5
Avoiding Exposure to Microwave Energy……….6
Never Use Your Microwave Oven to: ……..…..…7
Your Baumatic Microwave Oven ...…….…………8
Placing your Microwave Oven ………….……….…9
Installing your Microwave Oven ………………..10
Before you Start Cooking with
your Microwave….…………………………..……11-12
Materials that you CAN use in your Microwave………13
Materials that you CAN’T use
in your Microwave .…………….…………….….14
Setting your Microwave’s Clock …………..………..………15
Notes on Microwaving Food ……………………………...….16
Using your Microwave Oven ……………...…17-24
Child Lock Function…………………………..………25
Cleaning ……………………………………………………….…………26
Troubleshooting ……………………………….…27-30
Conditions of Guarantee ……………………………………….31
Contact Details……………….………………………………………32
C Co on nt te en nt ts s

3
Your Baumatic BTM17.2SS Microwave has:
8 Functions
5 Power Levels
Touch Control Operation
LED full programmer
Child Safety Lock
Stainless Steel Exterior
Optional Extra:
BTM17.1KIT - Stainless Steel building-in kit.
Cooking Features:
General (see page 17)
Speedy Cooking (see page 18)
Defrost by Weight (see page 18)
Speedy Defrost (see page 19)
Auto Menu Cooking (see pages 19-20)
Grilling (see page 21)
Combination Cooking (see page 21)
Delay Start (see page 22)
Checking Function (see page 23)
S
p
ecifications

4
PLEASE READ BEFORE USING!
(To reduce the risk of fire, electric shock, injury or exposure
to Mircowave energy)
ELECTRICAL SAFETY
• NOTE - This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce the risk of electric
shock by providing a path of least resistance of electrical current. You
will be able to tell if it is because a non-grounded appliance will give
off an electrical discharge. Your Microwave’s plug must have a
grounding pin and if you use an extension cord, this must have a 3-pin
inlet/outlet as well as carry the same rating or greater than your
microwave. Only connect to a properly grounded outlet.
• Manufacturer declines all responsibility for any damage due to non-
grounding of appliance.
• DURING THE GUARANTEE PERIOD ONLY BAUMATIC SERVICE ENGINEERS OR
AN AUTHORISED AGENT OF BAUMATIC SHOULD CARRY OUT REPAIRS ON
THIS UNIT. THEREAFTER, IT SHOULD BE SERVICED ONLY BY QUALIFIED
TECHNICIANS.
• DO NOT USE IF THE SUPPLY CORD IS DAMAGED OR IF IT HAS BEEN
IMMERSED IN WATER.
• DO NOT USE IF THE OVEN HAS BEEN DAMAGED OR DROPPED.
• KEEP CORD AWAY FROM HEAT SOURCES.
• DON’T LET THE CORD HANG OVER THE EDGE OF TABLE.
• DO NOT USE YOUR MICROWAVE OUTDOORS OR NEAR A KITCHEN SINK,
SWIMMING POOL, IN A WET BASEMENT OR ANYWHERE CLOSE TO A SOURCE
OF WATER.
• NEVER TRY TO DISASSEMBLE OR REPAIR YOUR MICROWAVE – IT RETAINS A
HIGH POWER VOLTAGE CHARGE EVEN WHEN UNPLUGGED!
Safet
y
Information

5
GENERAL SAFETY
•READ AND FOLLOW THE
“PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY” (Page 6).
•AS WITH MOST COOKING
APPLIANCES, CLOSE
SUPERVISION IS NEEDED TO
REDUCE THE RISK OF FIRE IN
YOUR MICROWAVE OVEN.
•SHOULD A FIRE START:
1) KEEP THE OVEN DOOR CLOSED.
2) TURN THE OVEN OFF & UNPLUG
THE APPLIANCE.
3) DISCONNECT THE POWER AT
THE FUSE OR CIRCUIT
BREAKER PANEL.
•ONLY EVER USE YOUR
MICROWAVE FOR ITS
INTENDED USE (HEATING
FOODS) AND NEVER FOR
INDUSTRIAL OR LABORATORY
PURPOSES.
•COOKING UTENSILS & DISHES
WILL BE HOT WHEN YOU TAKE
THEM OUT AFTER COOKING –
HANDLE WITH CARE!
•NEVER USE CORROSIVE
CHEMICALS OR VAPOURS IN
YOUR MICROWAVE. WHEN
YOU CLEAN THE DOOR AND
OVEN SURFACES, USE ONLY
MILD, NONABRAISIVE SOAPS
OR DETERGENTS APPLIED
WITH A SPONGE OR SOFT
CLOTH.
•DO NOT COVER OR BLOCK ANY
VENTS ON THE OVEN.
•ONLY PLACE YOUR OVEN ON A
FLAT, LEVEL SURFACE.
•DON’T LET CHILDREN PLAY
WITH YOUR MICROWAVE.
•MAKE SURE YOU READ THE
SECTION ON INSTALLING YOUR
MICROWAVE PROPERLY (Pages
9-10).
•MAKE SURE YOU READ THE
SECTION ON COOKING FOODS
IN YOUR OVEN. THERE ARE
SOME ITEMS WHICH SHOULD
NOT BE HEATED IN YOUR
MICROWAVE. (Page 14) AND
THINGS YOU MUST NEVER USE
YOUR MICROWAVE FOR (Page
7).
________________________________
CONFORMITY TO W.E.E.E. DIRECTIVE
Safet
y
Information / Environmental Note

6
AVOIDING POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
IMPORTANT NOTES ABOUT MICROWAVE ENERGY – READING THESE PRECAUTIONS
WILL HELP YOU TO AVOID POSSIBLE EXPOSURE TO MICROWAVE ENERGY
oNEVER
ATTEMPT TO
USE YOUR
OVEN WITH
THE DOOR
OPEN. THE
DOOR MUST BE
FULLY CLOSED
EVERY TIME
YOU OPERATE
YOUR OVEN
OTHERWISE
YOU RISK
EXPOSING
YOURSELF AND
OTHERS TO
HARMFUL
MICROWAVE
ENERGY.
oYOUR
MICROWAVE IS
FITTED WITH
SAFETY
INTERLOCKS.
IT IS VERY
IMPORTANT
THAT THESE
ARE NEVER
TAMPERED
WITH!
oDO NOT PLACE
ANY OBJECT
BETWEEN THE
OVEN’S DOOR
AND THE
DOORWAY
(FRONT FACE).
NEVER ALLOW
DIRT, FOOD OR
CLEANER
RESIDUE TO
ACCUMULATE
ON THE
SEALING
SURFACES
BETWEEN THE
INSIDE OF THE
DOOR AND THE
PART OF THE
DOORWAY
WHERE IT
MEETS.
oYOUR
MICROWAVE
HAS SEVERAL
BUILT-IN
SAFETY
SWITCHES TO
ENSURE THE
POWER
REMAINS OFF
WHEN THE
DOOR IS OPEN.
NEVER TAMPER
WITH THESE
SWITCHES.
oNEVER TRY TO
OPERATE A
DAMAGED
MICROWAVE
OVEN. APART
FROM MAKING
SURE THAT
THE OVEN
DOOR CAN
CLOSE
PROPERLY,
YOU NEED TO
ALSO CHECK
THAT THERE IS
NO DAMAGE TO
THE:
1) DOOR (EG.
DENTED)
2) HINGES &
LATCHES
(BROKEN OR
LOOSENED)
3) DOOR SEALS &
SEALING
SURFACES
oREMEMBER THAT
YOUR
MICROWAVE
OVEN SHOULD
NOT BE
ADJUSTED OR
REPAIRED BY
ANYONE BUT A
QUALIFIED
SERVICE
TECHNICIAN.
oNEVER USE THE
INTERIOR OF
YOUR
MICROWAVE
OVEN FOR
STORAGE
PURPOSES.
NEVER STORE
COMBUSTIBLE
ITEMS SUCH AS
BREAD, COOKIES,
PAPER
PRODUCTS, ETC.
INSIDE THE OVEN
TO FACILITATE
COOKING.
ACCIDENTAL
OPERATION CAN
CAUSE THESE
ITEMS TO GO ON
FIRE AND DO
DAMAGE TO YOUR
MICROWAVE,
THEREBY
PUTTING YOU AT
RISK IF YOU USE
IT WHILE IT IS
DAMAGED.
Avoidin
g
Ex
p
osure to Microwave Ener
gy

7
A note on the type of energy used
by your Microwave Oven
Microwaves are electromagnetic waves that transmit energy. When cooking,
the microwave energy penetrates food to a depth of 4cm (1½ inches),
causing its molecules to vibrate. The heat produced by this friction
enables food to be heated, cooked or defrosted.
How quickly a microwave oven cooks will depend on the size, quality and
shape of the food being cooked. Microwave cooking is healthy in that,
without the need for large amounts of cooking liquid, it means that food
retains vitamins, nutrients, aromas and flavour.
Microwave Ovens are also more energy efficient than conventional cooking
because they use up to 70% less energy.
______________________
Never use your
Microwave Oven to:
Dry clothes or fabrics
Dry or warm up pets or live animals
Warm or heat any item other than food and the
appropriate utensil
Cook sealed containers
Cook items where you have placed a liquid or
mercury thermometer (eg. Inside roasts or turkeys)
Heat large quantities of cooking oil (fondue or deep
frying) or drinks with high alcohol contents
Never use
y
our Microwave to…

8
Your Baumatic Microwave Oven

9
oONCE YOU ARE SURE THAT YOUR OVEN IS NOT DAMAGED (EG. DENTS
OR A BROKEN DOOR) AND THAT THERE ARE NO PACKING MATERIALS
AND ACCESSORIES INSIDE IT, YOU CAN THEN INSTALL IT ON A FLAT
SURFACE SUCH AS A COUNTERTOP. BE SURE THAT THE SURFACE CAN
HOLD AT LEAST YOUR MICROWAVE’S WEIGHT (12.4 kg).
oBEFORE PLACING ON YOUR COUNTERTOP: REMOVE ANY PROTECTIVE
FILM ON THE CABINET SURFACE.
oBUT DO NOT REMOVE THE LIGHT BROWN MICA COVER THAT IS SCREWED TO
THE OVEN CAVITY TO PROTECT THE MAGNETRON.
oFIND A LEVEL SURFACE THAT PROVIDES ENOUGH OPEN SPACE FOR
THE INTAKE AND OUTLET VENTS.
oYOU NEED TO LEAVE A MINIMUM OF 3.0 INCHES (7.5 CM) BETWEEN
THE OVEN AND ANY ADJACENT WALL. ONE SIDE MUST BE OPEN TO
ALLOW THE DOOR TO OPEN AND CLOSE.
oLEAVE A MINIMUM CLEARANCE OF 12 INCHES (30CM) ABOVE
THE OVEN.
oDO NOT REMOVE THE LEGS FROM THE BOTTOM OF THE OVEN.
oDON’T LET ANYTHING BLOCK EITHER THE INTAKE OR THE
OUTLET OPENINGS AS THIS CAN DAMAGE THE OVEN.
oPLACE YOUR MICROWAVE OVEN AS FAR AWAY AS POSSIBLE FROM
RADIOS AND TELEVISIONS - YOUR OVEN MAY CAUSE SIGNAL
INTERFERENCE.
o UNLESS YOU ARE INSTALLING YOUR MICROWAVE IN ACCORDANCE
WITH THE INSTALLATION INSTRUCTIONS ON PAGE 10 , DO NOT
PUT YOUR OVEN ON TOP OF ANY OTHER HEAT-PRODUCING
APPLIANCE OR A RANGE COOKTOP.
DOING SO COULD DAMAGE
YOUR OVEN AND MAKE THE WARRANTY VOID.
Placin
g
Your Microwave Oven
NOTE:
For in-unit
installation,
please see
next page.

10
Installin
g
y
our Microwave
SURROUND FRAME
NOTE: INSTALLATION KIT NOT
INCLUDED BUT MAY BE
PURCHASED AS AN ADDITIONAL
ITEM.
BTM17.1KIT
