Baumatic BMC255SS User manual

1 uping e
BMC255SS 25 Litre
built in microwave
oven with grill

User Manual for your Baumatic
BMC255SS
25 Litre built in microwave oven
with grill
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
DD 24/03/10
2

3
Contents
Environmentalnote 4
Important safety information 5 – 9
Specifications 9 - 12
Product dimensions 9
Aperturedimensions 9
Product specifications 9 - 10
Description of the appliance 10 - 11
Controlpanel 11
Theturntable 12
Usingyourmicrowave 12 - 25
Settingtheclock 12
Beforefirstuse 13
Cooking food (microwave mode) 13 - 14
Duringoperation 14
Cooking food (grill/grill combi mode) 15 - 16
Automatic defrost programmes 16
Automatic cooking programmes 17 - 18
Setting multiple cooking phases 18
Settingadelaystart 19
Safetylock 20
Microwave cooking guidelines 21
Materials you can use in a microwave oven 22
Materials not to be placed in a microwave oven 23
Utensilstable 23
Defrosting guidelines 24
Defrostingtable 25
Cleaning and maintenance 26 - 27
The appliance exterior 26
The appliance interior 26
Rotating plate and rotating base 26
General cleaning advice 26-27
Installation 27 – 31
Electricalconnection 28
Aperture and ventilation requirements 29
Installing the microwave into the housing unit 30 - 31
Troubleshooting 31 - 33
Contactdetails 34

Environmental note
4
oThe packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
all packaging material with due regard for the
environment.
oPlease discard

5
IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
ooklet, please contact the Baumatic Advice Line.
eneral Information
or housing unit (see the section
liance when the turntable and
nly use ovenware that is suitable for being used in a
microwave should be wiped dry
le materials. If left unattended, they could pose a
your microwave oven, if you
Installation
d by
the microwave, to
ambient temperature
of the room it is located in, whilst in use.
b
G
oThis appliance is designed for domestic household use. It can
NOT be used as a freestanding microwave and must be built in
to a standard kitchen cabinet
entitled “Installation” below).
oYou should only operate the app
turntable support are in position.
oYou should o
microwave.
oTo prevent corrosion occurring due to moisture/condensation,
the cavity and the door of the
after each use of the appliance.
oThe appliance must not be left unattended if you are heating or
cooking food in containers that are made of paper, plastic or
other flammab
fire hazard.
oIf you notice smoke coming from the appliance, you should keep
the door of the microwave closed and then disconnect it from
your mains supply. DO NOT use
think it is not operating correctly.
IoMPORTANT: Only the built in installation sanctione
Baumatic and outlined in this manual should be followed.
A separate building in kit will be supplied witho
allow you to complete a built in installation.
oIMPORTANT: The adjacent furniture or housing and all
materials used in the installation must be able to withstand a
minimum temperature of 85°C above the

6
oCertain types of vinyl or laminate kitchen furniture are
particularly prone to heat damage or discolouration at
temperatures below the guidelines given above.
oAny damage caused by the appliance being installed in
contravention of this temperature limit, or by placing adjacent
cabinet materials closer than 4mm to the appliance, will be the
liability of the owner.
oFor use in leisure accommodation vehicles, please refer to
the appropriate information given in the installation instructions
for this appliance.
oThe use of this appliance for any other purpose or in any other
environment without the express agreement of Baumatic Ltd.
will invalidate any warranty or liability claim.
oYour new appliance is guaranteed against electrical or
mechanical defects, subject to certain exclusions that are noted
in Baumatic’s Conditions Of Guarantee. The foregoing does not
affect your statutory rights.
Service
oYour microwave complies with all relevant safety standards. In
order for it to continue to operate safely, only an engineer that
is approved by the Baumatic Customer Care Department
should work on the appliance.
oIMPORTANT: It is dangerous for a non qualified person to work
on the appliance, in particular if they remove the cover that
provides protection against exposure to microwave energy.
oIf you notice that the door seal, door surfaces, power cord and
plug are damaged. You should stop using the appliance,
disconnect it from the mains supply and contact the Baumatic
Customer Care Department.
oOnly genuine Baumatic spare parts should be fitted to your
appliance. These can be obtained from the Baumatic Spares
Department.
Warning and safety instructions
oThis appliance complies with all current European safety
legislation. Baumatic do wish to emphasise that this compliance
does not remove the fact that the appliance surfaces will
become hot during use and retain heat after operation.

7
oDO NOT place anything between the door and the door frame.
oDO NOT store anything that is flammable inside of the
microwave. When it is switched on, the items could catch fire.
oDO NOT switch the appliance on if there is no food or liquid
inside of the microwave. If you run the microwave whilst it is
empty, there is a chance that it will overload.
oThe door seals and the door surfaces should ALWAYS be kept
clean and free from debris.
Child Safety
oBaumatic strongly recommend that babies and young children
are prevented from being near to the appliance and not allowed
to touch the appliance at any time.
oIf it is necessary for younger family members to be in the
kitchen, please ensure that they are kept under close supervision
at all times.
oIMPORTANT: This appliance should only be operated by adults.
You SHOULD NOT allow young children to use the microwave
without supervision. Older children should only operate the
appliance if they have been thoroughly instructed on how to use
the microwave and the consequences of improper usage.
General Safety
oDo not allow electrical fittings or cables to come into contact
with areas on the appliance that get hot.
oDo not use the appliance to heat the room it is located in.
oDo not use the appliance to dry paper, textiles or animals.
oDo not install the appliance next to curtains or soft furnishings.
oDo not use the appliance to heat unopened bottles or cans etc.
oDo not heat cooking oil or liquid containing alcohol, as there is
the chance of spontaneous combustion.
oDo not boil eggs or similar foods in their shells, otherwise they
may burst. It is possible to poach eggs in your microwave,
providing you prick the yolks first.

oDo not attempt to lift or move cooking appliances by using the
oven door, as this may cause damage to the appliance or result
in injury to the person lifting the appliance.
Cleaning
oCleaning of the oven should be carried out on a regular basis.
oGreat care should be taken whilst using this appliance and when
following the cleaning procedure.
oIMPORTANT: The appliance must be disconnected from the
mains before following the cleaning procedure.
Installation
This appliance must be correctly installed by a
suitably qualified person, strictly in accordance
with the manufacturer’s instructions.
oBaumatic Ltd. declines any responsibility for injury or
damage, to person or property, as a result of improper
use or installation of this appliance.
oHeat, steam and moisture will be created during use of the
appliance, take care to avoid injury and ensure that the room is
adequately ventilated. If the appliance is going to be used for
prolonged periods of time, then additional ventilation may be
required.
oPlease consult with your qualified installer if you are in any doubt
about the amount of ventilation that you will require.
8

Declaration of conformity
oCE: Appliance conforming to the European directives
89/336/EEC, 93/68/EEC, 73/23/EEC and subsequent revisions
and “RoHS” directive 2002/95/CE.*
oThe manufacturer declares that the oven is built using certified
materials and requires the appliance to be installed in
accordance with the standards currently in force. This appliance
must be used by a trained person for domestic purposes only.
*The RoHS directive stands for “the restriction of the use of
certain hazardous substances in electrical and electronic
equipment”. This directive bans the placing on the EU market of
new electrical and electronic equipment containing more than
the agreed levels of lead, cadmium, mercury, hexavalent
chromium, polybrominated biphenyl (PBB) and polybrominated
diphenyl ether (PBDE) flame retardants.
Specifications
Product dimensions
Height: 385 mm
Width: 594 mm
Depth: 383 mm
Aperture dimensions
Height: 360 mm
Width: 560 mm
Depth: 550 mm
Product specifications
o5 power levels oDefrosting by weight
modeoPush button control
operation oGrill mode
oSafety lock oStainless steel exterior
and interioroInterior light
oLED display oStainless steel frame
oLED full programmer oViewing window
9

oCapacity: 25litres
oMicrowave output: 800 W
For future reference please record the following information which can
be found on the rating plate and the date of purchase which can be
found on your sales invoice. The rating plate for your oven can be
located by opening the microwave oven door and looking on the right
hand side of the chassis and/or on the rear of the appliance.
Model Number ……………………………….
Serial Number ……………………………….
Date of Purchase ……………………………….
Description of the appliance
1) Microwave door
2) Door catches
3) Cavity
4) Slot for rotating base
5) Rotating plate
6) Rotating base
7) Door open button
8) Control buttons
9) LED display
10) Microwave housing
11) Wave guide cover
10

Control panel
A) Micro power button
(power level button)
B) Grill combi button
C) Preset clock button
(delayed start button)
D) LED display
E) Stop clear button
F) Instant start button
(start button)
G) Auto defrost button
H) Auto cooking
button
I) Time weight button
NOTE: To access the programming buttons, you need to open the
microwave door by pressing the door open button (7).
11

The turntable
oNever place the rotating
plate upside down.
oThe rotating plate and
rotating base MUST always
be used during cooking.
oAll food and food
containers must ALWAYS
be placed on the rotating
plate during cooking.
oIf the rotating plate or rotating base cracks or breaks, it must be
replaced immediately. Genuine Baumatic parts can be obtained
from the Baumatic Spares Department.
Using your microwave
Setting the clock
oWhen your microwave is connected to the power supply, you can
set the clock to the correct time of day.
oThe entire LED display will flash and then the “:” symbol on its
own. You should press the preset clock button (C) to set the
time of day. The appliance has a 24 hour clock.
oPress the time weight button (I) and the hour digits will start to
flash. Continue to press the time weight button until the correct
hour digit is displayed.
oPress the preset clock button again to confirm the hour time. The
minute digits will start to flash. Continue to press the time
weight button until the correct minute digit is displayed.
oPress the preset clock button for a third time to confirm the
minute time. The digits on the LED display will stop flashing and
the time of day is set.
oIf you do not set the time of day, every time you connect your
microwave to the power supply, you will need to press the stop
clear button (E) once before you can use the microwave.
12

13
Before first use
oTo remove any residue from the oven that may have been left
from the manufacturing process, you should place a cup that is
half filled with water in the microwave.
oSet the microwave on its highest power level for 2 minutes.
oThe oven cavity and outside of the appliance should be cleaned
with warm soapy water, using either a sponge or soft cloth. No
abrasive cleaners should be used. The appliance should be
thoroughly dried afterwards.
oWe would recommend that an appropriate stainless steel cleaner
and polish is regularly used on the stainless steel surfaces of this
appliance.
Cooking food (microwave mode)
oOnce the clock has been set, your microwave is then ready to
use.
oUse the door open button (7) to open the door of the
microwave.
oCheck that the rotating plate and rotating base are correctly
assembled in the cavity.
oPlace whatever you are cooking in the centre of the microwave
cavity and then press the micro power button (A) to set the
required power level, 100P, 80P, 60P, 40P, 20P will appear on
the LED display.
LED
Display
Microwave
power
level
Power level
suitable for…
100P Full power (100%) Meat and vegetables
80P Medium/high power
(80%)
Eggs, fish, congee, rice,
soup
60P Medium power (60%) Steaming food
40P Medium/low power (40%) Defrosting food
20P Low power (20%) Keeping food warm
oOnce the correct power level is displayed, press the time weight
button (I) to set the cooking time. The maximum cooking time
that can be set is 60 minutes.
oClose the microwave door. IMPORTANT: You should make sure
that the door of the microwave is shut securely.

14
oPress the instant start button (F) and the microwave will start to
heat.
oAt the end of the cooking time, your microwave will give an
audible signal and the LED display will show the word “END”.
oThe audible signal will be repeated every 3 minutes, until the
stop clear button is pressed or the door is opened by pressing
the door open button.
oIMPORTANT: The inside of the microwave and the food that
you have been cooking may be extremely hot. So care should be
taken when removing items from the microwave. We would
recommend that you use an oven glove.
oAfter the food has been removed from the microwave, you
should make sure that the door is closed.
During operation
oTo interrupt the cooking process to turn or stir the food, press
the stop clear button (E) once.
oPress the door open button (7) to open the door of the
microwave.
oWhilst the door is open, it is possible to stir the food stuffs that
you are cooking or adjust its position on the rotating plate.
oTo restart the cooking process, close the door and then press the
instant start button once.
oIf you wish to remove the food before the cooking time has
completed, then press the stop clear button twice to cancel the
cooking operation.

Cooking food (grill/grill combi mode)
IMPORTANT: When using the grill and/or grill combi
mode, the inside of the oven, grill rack and cooking
containers may become extremely hot. YOU MUST use
an oven glove when removing items from the cavity.
oUse the door open button (7) to open the door of the
microwave.
oCheck that the rotating plate and rotating base are correctly
assembled in the cavity.
oPlace whatever you are grilling in the centre of the microwave
cavity on the grill rack.
oThere is no need to preheat the cavity when using any of the
grill modes.
oPress the grill combi button (B) and the LED display will show G,
C1, C2.
LED
display
Description Suitable for…
G Grill cooking
only
Grilling and browning thin meats, pork,
sausage and chicken wings.
C1 Grill and
microwave
cooking
The microwaves will penetrate thicker
food, alternating with the grill element,
which will brown and crisp off the food.
C2 Grill and
microwave
cooking
As C1, but the grill element remains on
for longer periods of time.
oOnce the correct grilling programme is displayed, press the time
weight button (I) to set the cooking time. The maximum
cooking time that can be set is 60 minutes.
oClose the microwave door. IMPORTANT: You should make sure
that the door of the microwave is shut securely.
oPress the instant start button (F) and the microwave will start to
heat.
oAt the end of the cooking time, your microwave will give an
audible signal and the LED display will show the word “END”.
15

16
oThe audible signal will be repeated every 3 minutes, until the
stop clear button is pressed or the door is opened by pressing
the door open button.
Automatic defrost programmes
oUse the door open button (7) to open the door of the
microwave.
oCheck that the rotating plate and rotating base are correctly
assembled in the cavity.
oPlace whatever you are defrosting in the centre of the microwave
cavity.
oPress the auto defrost button (G) and the LED display will show
d.1, d.2, d.3.
LED display Defrost level
suitable for…
Weight range
(kg)
d.1 Defrosting meat 0.1 – 2.0
d.2 Defrosting poultry 0.2 – 3.0
d.3 Defrosting seafood 0.1 – 0.9
oOnce the correct defrost programme is displayed, press the time
weight button (I) to set the weight of the food that you are
defrosting.
oClose the microwave door. IMPORTANT: You should make sure
that the door of the microwave is shut securely.
oPress the instant start button (F) and the microwave will start to
defrost.
oAt certain points in the defrosting process, the microwave will
give an audible signal. When this occurs, you should open the
door of the microwave and turn the food over.
oTo restart the cooking process, close the door and then press the
instant start button once.
oAt the end of the defrosting time, your microwave will give an
audible signal and the LED display will show the word “END”.
oThe audible signal will be repeated every 3 minutes, until the
stop clear button is pressed or the door is opened by pressing
the door open button.

17
Automatic cooking programmes
oUse the door open button (7) to open the door of the
microwave.
oCheck that the rotating plate and rotating base are correctly
assembled in the cavity.
oPlace whatever you are cooking in the centre of the microwave
cavity.
oPress the auto cooking button (H) and the LED display will show
A.1 – A.8.
LED
display
Food
group
Cooking guidance Maximum
weight
A.1 Popcorn Suitable for popping a bag of corn,
which are available at supermarkets.
If during cooking the popping speed
slows to once every 1 – 2 seconds,
press the stop clear button to end the
process.
85 g
A.2 Popcorn As A.1 100 g
A.3 Pizza Suitable for warming a piece of
chilled pizza.
150 g
A.4 Beverage Use a cup with a large opening and
DO NOT cover it.
250 ml
A.5 Beverage As A.4 500 ml
A.6 Potato Cut the potatoes into 5 cm³ pieces.
Place them into a large dish and put
a suitable microwave cover over the
dish.
450 g
A.7 Potato As A.6 650 g
A.8 Fish Wash the fish, remove the scales and
make slits into the skin. Place the fish
in a shallow dish and then season as
required. Put a suitable microwave
cover over the dish. After cooking,
stand for 2 minutes.
450 g
oClose the microwave door. IMPORTANT: You should make sure
that the door of the microwave is shut securely.
oThe automatic cooking times are suitable for food that is stored
at room temperature.
oThe temperature, weight and shape of the food will all influence
the final cooking results. It is possible to adjust the cooking
times to suit personal preference.

18
oPress the instant start button (F) and the microwave will start
the automatic cooking programme that you have selected.
Setting multiple cooking phases
It is possible to set the microwave to cook at different power levels
within a single cooking time. A maximum number of 4 cooking phases
can be set at once.
oPress the micro power button (A) to set the required power level
for the first cooking phase. 100P, 80P, 60P, 40P, 20P will appear
on the LED display.
oPress the time weight button (I) to set the cooking time for the
first cooking phase.
oIt is possible to program a further 3 cooking phases by following
the above two steps.
oWhen you have set the final cooking phase, press the instant
start button (F) and the microwave will start the first cooking
phase.
oWhen the first cooking phase has completed, it will automatically
move onto the next cooking phase.
oAt the end of all of the cooking phases, your microwave will give
an audible signal and the LED display will show the word “END”.
oThe audible signal will be repeated every 3 minutes, until the
stop clear button is pressed or the door is opened by pressing
the door open button.
oAfter the food has been removed from the microwave, you
should make sure that the door is closed.

Setting a delay start
This function will allow you to set a time in the future that the
microwave will switch on at.
oIMPORTANT: You must make sure that the clock is set to the
correct time before using this feature.
oIMPORTANT: It is not possible to set a delay start when using
automatic cooking, automatic defrost or quick start.
oSet the power level and cooking time (as described previously in
this instruction manual).
oDO NOT press the instant start button (F) at this point,
otherwise the microwave will start cooking immediately.
oPress and hold down the preset clock button (C) until you hear a
brief audible signal.
oPress the time weight button (I) and the hour digits will start to
flash. Continue to press the time weight button until the hour
digit that you want the cooking to start at is displayed.
oPress the preset clock button again to confirm the hour time. The
minute digits will start to flash. Continue to press the time
weight button until the minute digit that you want the cooking to
start at is displayed.
oPress the preset clock button for a third time to confirm the time
of day that the microwave will start cooking at.
oWhen the time of day that you have programmed is reached, the
microwave will bleep twice and then the microwave will start
cooking automatically.
oIMPORTANT: If the microwave door is not shut when the time
of day that you have programmed is reached, then cooking will
not commence.
IMPORTANT: Although your microwave has a
delay start feature, we do not recommend that the
microwave is EVER programmed to switch on
when it is unattended.
19

20
Safety lock
oWhen the microwave is not heating, it is possible to switch on
the safety lock.
oPress and hold down the stop clear button (E) until the word
“OFF” appears on the LED display.
oUntil the safety lock is switched off, all control buttons on the
microwave will be disabled.
oTo switch off the safety lock, press and hold down the stop clear
button until a “:” appears on the LED display.
