Baumatic B40DSS User manual

即日起更改说明书页码3、5页、35页、36页、37页内容，删除原先
的37页(Baumatic consumables)，内页有标记颜色的都需要仔细注意 2014.4.12 周凤霞
李宇

s
B40DSS
570 Litre 4 door
frost free fridge-freezer

2
USER MANUAL FOR YOUR BAUMATIC
B40DSS
570 Litre 4 door
frost free fridge-freezer
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference, for
you or any person not familiar with the operation of the appliance.
JW 11/06/13

3
Contents
Environmental note 4
Important safety information 5-6
Specifications of your fridge freezer 7-12
Description of the appliance 8
Product features (fridge section) 9-12
Product features (freezer section 12
Using your Baumatic fridge freezer 13-18
Before switching on 13
During first use 13
Control panel 14-18
Switching on the appliance 15
Manually setting the temperature (fridge) 15
Manually setting the temperature (freezer) 15
Switching on Super Cool mode 16
Switching on Super Freeze mode 16
Switching on energy saving mode 16
Turning off the fridge section 17
Switching on the control panel lock 17
Returning the appliance to normal operation 17
Door open alarm 18
Temperature rise alarm 18
Arranging and storing food in the fridge section 18-19
The **** freezer section 20-24
Freezing fresh food 20
Tips on freezing 21
Storing commercially frozen food 21
Defrosting frozen food 22
In the event of power failure 22
Using the twist ice maker 23
Normal operating noises 23-24
Important user information 24
Saving energy when using your fridge-freezer 24-25
Cleaning and maintenance 26-28
General cleaning 26-28
Replacing the light bulb 28
Adjusting the fridge doors 28
Installation 29-33
Electrical connection 29
Positioning 30
Installation preparation 31
Installing the fridge door/freezer drawer handles 31-32
Installing the decorative plinth 33
Troubleshooting 33-35
36
Techni cal data
Contact details 38

4
Environmental note
Note: Before discarding an old appliance, switch off and
disconnect it from the power supply. Cut off and render any plug
useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person. Disable
the door lock to make sure that children cannot get stuck inside
the appliance.
oThe packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
oPlease discard all packaging material with due regard for the
environment.

5
Important safety information
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the Baumatic Advice Line.
IMPORTANT: Any installation work must be carried
out by a qualified electrician or competent person.
Use of the appliance
oYour appliance is only designed to be used in the
home. It is suitable for storing food that needs to
be chilled and refrigerated. If it is used for any
other purpose or it is not used correctly, then
. will accept no liability for any
damage that is caused.
oAltering the specification of the appliance must not be attempted
for reasons of safety.
Before using your appliance
oCheck the appliance for any signs of transport damage. If you
notice any damage, then you should not connect your appliance
to your mains supply and should contact your retailer.
Refrigerant
oYour appliance contains R600a refrigerant, which is a natural gas
that does not contain CFCs that can damage the environment.
However it is a flammable substance, therefore care should be
taken:
During the transportation and installation of the
appliance, make sure that the refrigeration pipe-
work does not get damaged.
If it does become damaged then sources of ignition
and open flames should be avoided. Also the room
that the appliance is situated in should be thoroughly
ventilated.
oDo not place any objects on top of the appliance,
as this may damage the table top.
Baumatic

6
Child safety
oPackaging material should be kept away from
children.
oChildren should not be allowed to touch the
controls or play with the appliance.
General safety
oDo not pull on the power supply cable to remove the plug from
your mains supply socket.
oDo not pull out or insert the plug with wet hands.
oDo not attempt to use your appliance outdoors or
any place where it is likely to come into contact
with the elements.
oBefore cleaning the appliance or performing maintenance work,
ensure that the appliance has been disconnected from your
mains supply.
oNever allow the back coils of the appliance to come into contact
with the wall surface.
oAlways ensure that the location where you are installing your
appliance is free of stored items such as papers and other
flammable materials.
oNever block the ventilation openings of the appliance, either on
the inside or its exterior.
oIt is vital to keep your appliance well ventilated, so
that there is proper air flow between the bottom of
the unit and the plinth/kick plate which it is sitting
on.
oDo not place electrical devices inside of the appliance, such as
mixers or ice cream makers.
oDo not store aerosol cans with a flammable propellant in this
appliance.
Service
You should not attempt to repair the appliance yourself,
as this could cause injury or a more serious malfunction.
If you require a service call then please contact the
Baumatic Customer Care Department.

7
Specifications of your fridge freezer
Dimensions of your appliance
oHeight: 1775 mm
oWidth: 911 mm
oDepth: 728.5 mm (excluding handles)
Energy efficiency class
oEnergy class: A+
Cubic capacities
oTotal gross/net capacity: 570/542 litres
oGross capacity (fridge/freezer): 425/145 litres
oNet capacity (fridge/freezer): 422/120 litres
Specifications of the appliance
oFrost free fridge and freezer
oStar rating ****
oMulti airflow cooling system
oElectronic temperature control
oDigital control panel
oAdjustable thermostat
oFast cooling switch
oFast Freeze switch
oFast freeze indicator light
oDoor open warning indicator
oTemperature rise warning indicator
oAdjustable feet
oMark resistant coating
o4 Adjustable fridge safety glass shelves
o1 Salad crisper shelf (Safety glass)
o2 Salad crispers
o1 Full width pantry drawer
o2 Bottle racks
o4 General door racks
o2 Butter and cheese compartments
o2 Egg racks
o1 Wine rack
o2 Non-transparent freezer drawers
oTwist ice maker

8
IMPORTANT: When you install your appliance it is important to bear
in mind its climatic rating.
In order to find out the climatic rating of your appliance, you should
check the rating plate. The rating plate is located inside of the fridge
section, on the left side. You will need to open the door of the fridge
section and you may need to remove one of the middle safety glass
shelves. The rating plate will indicate the ambient temperature range
that your appliance will function correctly within.
Description of the appliance
1) Pantry drawer
2) Storage compartment
3) Salad crisper (x2)
4) Wine rack
5) Adjustable safety glass shelf
6) Vertical girder
7) Adjustable safety glass shelf
8) Left refrigerator door
9) Top interior light
10) Light switch/door close sensor
11) Right refrigerator door
12) Dairy compartment
13) Rear wall airflow cover plate
14) Adjustable safety glass shelf
15) Interior side light
16) Bottle rack
17) General door rack
18) Freezer interior light
19) Upper freezer drawer
20) Lower freezer drawer
21) Bottom beam/ kick plate
22) Adjustable feet
23) Freezer door handles

9
Description of product features (fridge)
Adjustable safety glass shelves
oThe shelves may be placed in any of the guide slots within the
interior of the appliance. They are protected from sliding out.
oTo remove a shelf: Take off all of the items that are stored on
the shelf that you want to remove. Then whilst lifting the front of
the shelf, pull it forwards to unhook it from the slots at the rear
of the cabinet.
oTo refit a shelf: When placing a shelf back inside the fridge
compartments, place the hooks into the slots at the rear of the
cabinet. Lower the front of the shelf back down again.
IMPORTANT: You must ensure that both of the hooks are in slots
that are at the same height; otherwise the shelf will not be level.
Salad crispers
oThese drawers are suitable for storing fruits, salad and
vegetables. They are designed to keep the contents fresh for as
long as possible.
oCare should be taken when storing tropical fruit (bananas and
pineapples etc) and tomatoes. As these types of items can easily
deteriorate at a lower temperature.
